EGO LB4800E User manual
•WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
OPERATING MANUAL
56V-VOLT LITHIUM-ION
CORDLESS BLOWER
MODEL NUMBER LB4800E
56V LITHIUM-ION CORDLESS BLOWER — LB4800E2
TABLE OF CONTENTS
Read All Instructions ......................................3
Safety Symbols ..........................................4
Safety Instructions.....................................5-12
Introduction ............................................13
Specications ..........................................14
Assembly ...........................................15-16
Packing List ............................................17
Description .........................................17-18
Operation ...........................................18-21
Maintenance ...........................................22
Troubleshooting .........................................23
Warranty ...........................................24-25
Parts List ..............................................26
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 3
READ ALL INSTRUCTIONS!
This Blower has many features for making its use more pleasant and enjoyable. Safety,
performance, and dependability have been given top priority in the design of this
product making it easy to maintain and operate.
DANGER! People with electronic devices, such as pacemakers, should consult
their physician(s) before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure of the pacemaker.
WARNING: To ensure safety and reliability, all repairs and replacements should
be performed by a qualied service technician.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E4
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, re, and/or serious personal injury.
DAMAGE PREVENTION AND INFORMATION MESSAGES
These inform the user of important information and/or instructions that could lead
to equipment or other property damage if they are not followed. Each message is
preceded by the word “NOTICE”, as in the example below:
NOTICE: Equipment and/or property damage may result if these instructions are not
followed.
WARNING: The operation of any power tools can result in foreign objects being
thrown into your eyes, which can result in severe eye damage.
Before beginning power tool operation, always wear safety goggles
or safety glasses with side shields and a full face shield when
needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use
eye protection complying with Australian Standards AS1337.1 2010.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product.
Read, understand, and follow all instructions on the machine before attempting to
assemble and operate.
Safety Alert Precautions that involve your safety.
Wear eye protection
Always wear safety goggles or safety
glasses with side shields and a full face
shield when operating this product.
Wear ear protection Always wear ear protection when
operating this product.
Read Operator’s Manual
To reduce the risk of injury, user must
read and understand operator’s manual
before using this product.
Keep Bystanders Away Keep all bystanders at least 15m away.
Class II Construction Double-insulated Construction.
Do Not Expose To Moisture Do not use in the rain or leave outdoors
while it is raining.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E6
V Volt Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
WWatt Power
min Minutes Time
m3/h cubic meter per hour Air volume
km/h kilometers per hour Air velocity
Alternating Current Type of current
Direct Current Type or a characteristic of current
n0No Load Speed Rotational speed, at no load
... /min Per Minute Revolutions per minute
When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT!
DANGER: People with electronic devices, such as pacemakers, should consult
their physician(s) before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure of the pacemaker.
TRAINING
Read the instructions carefully. Be familiar with the controls and the proper use
of the appliance.
Never allow children to use the appliance.
Never allow people unfamiliar with these instructions to use the appliance.
Local regulations may restrict the age of the operator.
Never operate the appliance while people, especially children, or pets are nearby.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 7
The operator or user is responsible for accidents or hazards occurring to
other people or their property.
PREPARATION
While operating the appliance, always wear substantial footwear and long
trousers.
Do not wear loose clothing or jewellery that can be drawn into the air inlet.
Keep long hair away from the air inlets.
Wear protective goggles while operating
To prevent dust irritation the wearing of a face mask is recommended
Before using, check the batteries or battery packs for damage. Do not use
the appliance if the batteries or battery pack is damaged.
Never operate the appliance with defective guards or shields, or without
safety devices, for example debris collector in place.
OPERATION
Disconnect the batteries or battery packs
1. Whenever you leave the machine;
2. Before clearing a blockage;
3. Before checking, cleaning or working on the appliance;
4. If the appliance starts to vibrate abnormally.
Operate the appliance only in daylight or in good articial light.
Do not overreach and keep your balance at all times.
Always be sure of your footing on slopes.
Walk, never run.
Keep all cooling air inlets clear of debris.
Never blow debris in the direction of bystanders.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E8
Recommendation to operate the machine only at reasonable hours – not
early in the morning or late at night when people might be disturbed.
Recommendation to use rakes and brooms to loosen debris before blowing.
Recommendation to slightly dampen surfaces in dusty conditions or use
mister attachment.
MAINTENANCE AND STORAGE
Keep all nuts, bolts and screws tight to be sure the appliance is in safe
working condition.
Check the debris collector frequently for wear or deterioration.
Replace worn or damaged parts.
Use only genuine replacement parts and accessories
Store the appliance only in a dry place.
WARNING: To ensure safety and reliability, all repairs should be performed by a
qualied service technician.
WARNING: To reduce risk of re, electric shock, or injury:
IMPORTANT
READ CAREFULLY BEFORE USE.
KEEP FOR FUTURE REFERENCE.
Know your power blower. Read the instruction manual carefully. Learn
the blower’s applications and limitations, as well as the specic potential
hazards related to this blower. Following this rule will reduce the risk of electric
shock, re, or serious injury.
Don’t expose the blower to rain or wet conditions. Water entering a blower
will increase the risk of electric shock.
Do not allow the blower to be used as a toy. Close attention is necessary when
used by or near children.
Use only as described in this manual. Use only manufacturer’s
recommended attachments.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 9
If the blower is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center.
Do not handle the charger, including charger plug, or charger terminals
with wet hands.
Do not put any object into any openings. Do not use with any opening
blocked; keep openings free of dust, lint, hair, and anything that may
reduce air ow.
Keep hair, loose clothing, ngers, and all parts of body away from openings and
moving parts. Loose clothes, jewelry, or long hair can be drawn into air vents.
Secure long hair above shoulder level to prevent entanglement in moving
parts.
Use extra care when cleaning on stairs.
Do not charge the battery pack outdoors.
Use only the charger supplied by the manufacturer to recharge.
Do not leave blower unattended when the battery is inserted. Remove the
battery when the blower is not in use and before servicing.
Do not operate blowers in explosive atmospheres, such as in the presence
of ammable liquids, gases, or dust. Blowers create sparks which may ignite
the dust or fumes.
Use the battery operated blower only with specically designated battery
pack. Use of any other batteries may create a risk of re.
Use only with battery packs and chargers listed below.
BATTERY PACK CHARGER
BA2240E
BA1120E
CH5500E
CH2100E
WARNING:
- The battery pack must be removed from the appliance before it is scrapped.
- The battery shall be disposed of safely.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E10
Stay alert, watch what you are doing and use common sense when
operating a power blower. Do not use the blower while tired, upset, or
under the inuence of drugs, alcohol, or medication. A moment of inattention
while operating blowers may result in serious personal injury.
Avoid accidental starting. Be sure that the switch is in the locked or off
position before inserting the battery pack. Carrying blowers with your nger
on the switch or inserting the battery pack into a blower with the switch on invites
accidents.
Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
Do not use on a ladder, rooftop, tree, or other unstable support. Stable
footing on a solid surface enables better control of the blower in unexpected
situations.
Always take care of your feet, children, or pets around you when removing the
battery pack from blower. Serious injury could result if the battery pack falls.
NEVER remove the battery pack when in a high position.
Do not use the blower if switch does not turn it on or off. A blower that
cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the battery pack from the blower before making any
adjustments, changing accessories, or storing the blower. Such preventive
safety measures reduce the risk of starting the blower accidentally.
Turn off all controls before removing the battery.
DO NOT attempt to clear clogs from the unit without rst removing the battery.
Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the blower’s operation. If damaged,
have the blower serviced before using. Many accidents are caused by poorly
maintained blowers.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 11
Keep the blower and its handle dry, clean and free from oil and grease.
Always use a clean cloth when cleaning. Never use brake uids, gasoline,
petroleum-based products, or any strong solvents to clean your blower. Following
this rule will reduce the risk of loss of control and deterioration of the enclosure
plastic.
Always wear safety glasses with side shields. Everyday glasses have only
impact resistant lenses. They are NOT safety glasses. Following this rule will
reduce the risk of eye injury.
Always wear eye protection with side shields marked to comply with
AS1337.1 2010 along with hearing protection when operating
this equipment.
Protect your lungs. Wear a face or dust mask if the operation is dusty.
Following this rule will reduce the risk of serious personal injury.
Protect your hearing. Wear hearing protection during extended periods of
operation. Following this rule will reduce the risk of serious personal injury.
Battery powered blowers do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition. Be aware of
possible hazards when not using your battery powered blower or when
changing accessories. Following this rule will reduce the risk of electric shock,
re, or serious personal injury.
Wear heavy long pants, long sleeves, boots, and gloves. Avoid loose
garments or jewelry that could get caught in moving parts of the machine or its
motor.
Do not operate the equipment while barefoot or when wearing sandals or
similar lightweight footwear. Wear protective footwear that will protect your
feet and improve your footing on slippery surfaces.
Batteries can explode in the presence of a source of ignition, such as a
pilot light. To reduce the risk of serious personal injury, never use any cordless
product in the presence of open ame. An exploded battery can propel debris and
chemicals. If exposed, ush with water immediately.
Keep rm footing and balance. Do not overreach. Overreaching can result in
loss of balance.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E12
Check the work area before each use. Remove all objects such as rocks,
broken glass, nails, wire, or string which can be thrown by or become entangled
in the machine.
Do not point the blower tube in the direction of people or pets.
Never run the unit without the proper equipment attached. Always ensure
that the blower tube is installed.
When not in use, the blower should be stored indoors in a dry, secure place
out of the reach of children.
Keep all bystanders, children, and pets at least 15m away.
Blower service must be performed only by qualied repair personnel.
Service or maintenance performed by unqualied personnel may result in a risk of
injury.
When servicing a blower, use only identical replacement parts. Follow
instructions in the Maintenance section of this manual. Use of unauthorized parts
or failure to follow Maintenance Instructions may create a risk of shock or injury.
Never use the blower near res or hot ashes. Use near res or ashes can
spread res and result in serious injury and/or property damage.
Never use blower to spread chemicals, fertilizers, or any other toxic
substances. Spreading these substances could result in serious injury to the
operator or bystanders.
Never place the blower on any surface, except a hard, clean surface when
the engine is running. Gravel, sand, and other debris can be picked up by the air
inlet and thrown at the operator or bystanders, causing possible serious injuries.
Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you loan this tool to someone else, also loan these
instructions to them to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS!
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 13
INTRODUCTION
Congratulations on your selection of a new generation of 56V Lithium-ion cordless
blower. It has been designed, engineered and manufactured to give you the best
possible dependability and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1300 000 EGO (1300 000 346).
This manual contains important information on to the safe assembly, operation and
maintenance of your hedge trimmer. Read it carefully before using the hedge trimmer.
Keep this manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE
56V LITHIUM-ION CORDLESS BLOWER — LB4800E14
SPECIFICATIONS
Voltage 56V
No Load Speed
Boost: 21000/min
High: 18000/min
Low: 10000/min
Air Volume
Boost: 810m3/h
High: 650m3/h
Low: 420m3/h
Air Velocity
Boost: 148km/h
High: 120km/h
Low: 72km/h
Approx. Run Time
(with EGO BA1120E 56V Battery 2.0Ah)
10min. (Boost)
18min. (High speed)
60min. (Low speed)
Blower Weight (Without battery pack, with tube) 2.34kg
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 15
ASSEMBLY
WARNING: If any parts are damaged or missing, do not operate this product
until the parts are replaced. Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING: Do not attempt to modify this product or create accessories not
recommended for use with this blower. Any such alteration or modication is misuse
and could result in a hazardous condition leading to possible serious personal injury.
UNPACKING
Carefully remove the product and any accessories from the box. Make sure that
all items listed in the packing list are included.
WARNING: Do not use this product if any parts on the packing list are already
assembled to your product when you unpack it. Parts on this list are not assembled to
the product by the manufacturer and require customer installation. Use of a product
that may have been improperly assembled could result in serious personal injury.
Inspect the tool carefully to make sure no breakage or damage occurred during
shipping.
Do not discard the packing material until you have carefully inspected and
satisfactorily operated the tool.
If any parts are damaged or missing, please return the product to the place of
purchase.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E16
ASSEMBLING THE BLOWER TUBE
WARNING:
To prevent
accidental starting that could cause
serious personal injury, always
remove the battery pack from the tool
when assembling parts.
1. Align either of the grooves in
the tube with the knob on the
blower housing. Push the tube
onto the blower housing until
the knob engages the grooves
(Fig. 1&2).
2. Turn the tube in the direction
of the arrow until both of
the knobs slide into the lock
positions (Fig. 2&3).
Tube
Groove
Knob
1
2
3
Lock Position
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 17
PACKING LIST
PART NAME QUANTITY
Blower 1
Blower tube 1
Instruction manual 1
DESCRIPTION
KNOW YOUR BLOWER (Fig. 4)
Electric Contacts
Latch
Battery Release
Button
Hanging Hole
Hanging Hole
Lock-off Lever
Overmold
Handle
Boost Button
Air-Velocity
Adjustment Knob
Ejection
Mechanism
Trigger
Air Inlet
Air Inlet
Blower Tube
Air Outlet
4
WARNING: The safe use of this product requires an understanding of the
information on the tool and in this instruction manual as well as knowledge of the
project you are attempting. Before use of this product, familiarize yourself with all
operating features and safety rules.
56V LITHIUM-ION CORDLESS BLOWER — LB4800E18
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection with side shields marked to comply with
AS1337.1 2010, along with hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious injuries.
WARNING: Do not use any attachments or accessories not recommended by the
manufacturer of this product. The use of attachments or accessories not recommended
can result in serious personal injury.
Before each use, inspect the entire product for damaged, missing, or loose parts, such
as screws, nuts, bolts, caps,etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts are replaced.
APPLICATION
You may use this product for the purposes listed below:
Clearing hard surfaces such as driveways and walkways
Keeping decks and driveways free from leaves and pine needles
Trigger Starts/stops the blower
Lock-off Lever Helps prevent accidental or unauthorized activating of the
trigger. It must be depressed before the trigger can be
activated
Air-Velocity
Adjustment Knob
Increases or reduces the air velocity of the blower
Boost Button Amplies the air velocity to the maximum
Battery Release Button Releases the battery pack from the blower
Latch Locks the battery pack when installing it on the blower
Hanging Holes For use with a strap (not included)
Overmold Handle Ergonomic handle with overmold improves comfort and grip
56V LITHIUM-ION CORDLESS BLOWER — LB4800E 19
TO INSTALL/REMOVE BATTERY PACK (Fig. 5)
CHARGE BEFORE FIRST USE.
WARNING: Always remove battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when not in use. Removing battery
pack will prevent accidental starting that could cause serious personal injury.
TO INSTALL
Align the ribs of the battery pack with the mounting slots in the blower’s battery
port.
Press the battery pack down until it snaps into position.
TO REMOVE
WARNING: Always take care of your feet, children, or pets around you when
pressing the battery release button. Serious injury could result if the battery pack falls.
NEVER remove the battery pack when in a high location.
Press the battery-release button; the battery pack will disengage from the latch
and the ejection mechanism will assist with removal.
Remove the battery pack from the blower.
5Battery Release Button
Mounting Slot
56V LITHIUM-ION CORDLESS BLOWER — LB4800E20
STARTING/STOPPING THE BLOWER (Fig. 6)
To start the blower, press down on the lock-off lever and hold it, then depress the
trigger. The blower will begin to run.
To stop the blower, release the trigger.
ADJUSTING THE AIR VELOCITY (Fig. 6)
6Air Velocity Adjusting Knob Boost Button
Lock-off Lever
Trigger
The blower is equipped with stepless speed regulation to control air speed.
To increase the air velocity, turn the air velocity adjusting knob clockwise to the “rabbit”
position; To reduce the air velocity, turn the knob counterclockwise to the “tortoise”
position.
To enhance the air velocity, press the boost button to temporarily amplify the air speed
to the maximum.The blower will resume the previous speed when this button is
released.
Other manuals for LB4800E
2
Table of contents
Other EGO Blower manuals
