EGO POWER+ SP1000 User manual

WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
SOLAR PANEL
OPERATOR’S MANUAL
100W SOLAR PANEL
MODEL NUMBER SP1000/SP1000-FC
Español p. 35
Français p. 17

100W SOLAR PANEL — SP1000/SP1000-FC2
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
TABLE OF CONTENTS
Safety Symbols ..........................................3
Symbols ...............................................4
Safety Instructions for Solar Panel ...........................5
FCC Statement ........................................5-6
Introduction ............................................7
Specications ...........................................8
Packing List ............................................8
Description .............................................9
Operation ..........................................10-12
Maintenance ...........................................13
EGO Limited Warranty .................................14-15

100W SOLAR PANEL — SP1000/SP1000-FC 3
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER”, “WARNING”,
and “CAUTION” before using this tool. Failure to follow all instructions listed below may
result in electric shock, fire, and/or serious personal injury.
The definitions below describe the level of severity for each signal word. Please read
the manual and pay attention to these symbols.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
DANGER: DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION:
CAUTION, used with the safety alert symbol, indicates a
hazardous situation which, if not avoided, will result in minor
or moderate injury.
DAMAGE PREVENTION AND INFORMATION MESSAGES
These inform the user of important information and/or instructions that could lead
to equipment or other property damage if they are not followed. Each message is
preceded by the word “NOTICE”, as in the example below:
NOTICE: Equipment and/or property damage may result if these instructions are not
followed.

100W SOLAR PANEL — SP1000/SP1000-FC4
SYMBOLS
This page depicts and describes symbols that may appear on this product. Read,
understand, and follow all instructions on the product before attempting to assemble
and operate.
Safety Alert Indicates a potential personal injury hazard.
Read & Understand
Operator’s Manual
To reduce the risk of injury, user must read
and understand the operator’s manual
before using this product.
WWatt Power
V Volt Voltage
A Amperes Current
kg Kilogram Weight
lb Pound Weight
°C Degrees Celsius Temperature
°F Degrees Fahrenheit Temperature

100W SOLAR PANEL — SP1000/SP1000-FC 5
SAFETY INSTRUCTIONS FOR SOLAR PANEL
 Do not bend the solar panel.
 Do not immerse the solar panel into water or any other liquid.
 Do not use or store this solar panel near sources of heat such as open fires or
heaters.
 Do not scratch the solar panel with sharp objects.
 Do not attempt to disassemble the solar panel in any way.
 Do not put corrosive substance on this solar panel.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures: Reorient or relocate the receiving antenna. Increase
the separation between the equipment and receiver. Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.

100W SOLAR PANEL — SP1000/SP1000-FC6
Save these instructions. Refer to them frequently and use them to instruct others
who may use this product. If you lend this product to someone else, also lend these
instructions to them to prevent misuse of the product and possibly injury.

100W SOLAR PANEL — SP1000/SP1000-FC 7
INTRODUCTION
Congratulations on your selection of the EGO 100W SOLAR PANEL. It has been
designed, engineered and manufactured to give you the best possible dependability
and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on to the safe assembly, operation and
maintenance of your product. Read it carefully before using the product. Keep this
manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE

100W SOLAR PANEL — SP1000/SP1000-FC8
SPECIFICATIONS
Peak Power 100 W
Solar Cell Sunpower
Solar Cell Lamination ETFE
Cell Efficiency ≥23%
Voltage at Maximum Power 19.2 V
Current at Maximum Power 5.2 A
Open Circuit Voltage 23 V
Short Circuit Current 6.24 A
USB-A Maximum Power 5V, 3.5A / 9V, 2A / 12V, 1.5A Max.
USB-C Maximum Power 5V, 3.5A / 9V, 2A / 12V, 1.5A Max.
Recommended Operating
Temperature* 14 °F – 113 °F (-10 °C – 45 °C )
Recommended Storage
Temperature 14 °F – 149 °F (-10 °C – 65 °C )
Weight 7.5 lb (3.4 kg)
*NOTE: The best operating temperature is 77 °F (25 °C).
PACKING LIST
PART NAME QUANTITY
Solar Panel 1
MC4 to XT60 charging cable 1
Operator’s Manual 1

100W SOLAR PANEL — SP1000/SP1000-FC 9
DESCRIPTION
KNOW YOUR SOLAR PANEL (Fig. 1)
The safe use of this product requires an understanding of the information on the
product and in this instruction manual, as well as knowledge of the project you are
attempting. Before use of this product, familiarize yourself with all operating features
and safety rules.
1
Support Legs USB-C
Output Port
USB-A
Output Port
LED Indicator
MC4 Output Port Charging Cable
(MC4 to XT60)
Handle
Handle
Allows the user to carry the solar panel when it is folded.
LED Indicator
Indicates the working status of the solar panel.
USB Output Ports
To connect USB devices.
MC4 Output / Charging Cable (MC4 to XT60)
Connects the solar panel to the MC4/XT60 input port on compatible EGO power
stations.

100W SOLAR PANEL — SP1000/SP1000-FC10
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufficient to inflict serious injury.
APPLICATION
You may use this product for the purposes listed below:
 Supplying power for operating compatible USB electronics when the output power
of the solar panel reaches 18W.
 Supplying power to EGO Nexus power station or other compatible EGO power
stations for energy storage when the output power of the solar panel meets the
required input power of the connected power station.
SETTING UP THE SOLAR PANEL
(Fig. 2)
1. Disengage the buckles to unfold the
solar panel (Fig. 2a).
2. Prop up the solar panel with support
legs (Fig. 2b).
3. Adjust the support legs to position so
that the solar panel is perpendicular to
the sunlight (Fig. 2c).
NOTE: To use the solar panel in midday sun, you may simply place it flat on the
ground.
PRESS
2a
Buckles
2b
Support Legs
2c
90°

100W SOLAR PANEL — SP1000/SP1000-FC 11
+
+
3
MC4 Output Port
Charging Cable
(MC4 to XT60)
CONNECTING TO USB DEVICES
The solar panel converts sunlight to electricity allowing the user to charge/power a
variety of USB-A or USB-C devices (5V, 3.5A / 9V, 2A / 12V, 1.5A Max).
CONNECTING TO EGO POWER
STATION (Fig. 3)
WARNING: Never use multiple
solar panels in series or parallel, failure
to follow this can result in electric shock,
serious personal injury or damage to the
product.
The solar panel can be connected to
the EGO Nexus Power Station PST3040/
PST3040-FC (sold separately) or other
compatible EGO power stations (coming
soon).
NOTICE: The solar charging adapter CH1800/CH1800-FC (sold separately) is required
when connecting the solar panel to the EGO Nexus Power Station PST3040/PST3040-
FC. Refer to the manuals of the power station and solar charging adapter for more
information.
NOTICE: When connecting cables, always make sure positive pole meets negative
pole. Failure to follow this may cause damage to the solar panel.
1. Connect the positive pole (+) of the solar panel with the negative pole (–) of the
charging cable (MC4 to XT60).
2. Connect the negative pole (–) of the solar panel with the positive pole (+) of the
charging cable (MC4 to XT60).
3. Connect the XT60 output port of the charging cable to compatible EGO power
stations.

100W SOLAR PANEL — SP1000/SP1000-FC12
LED INDICATOR
The solar panel features a LED indicator beside the USB-A output port to indicate the
status of the solar panel.
LED Indicator Status Action
Red The solar panel is unfolded and ready to
supply power.
No action needed.
Green The solar panel is supplying power for USB
devices or power station.
No action needed.
No light The solar panel is folded. Unfold the solar panel and
expose it to sunlight.
Other errors. Contact EGO service center for
repair.

100W SOLAR PANEL — SP1000/SP1000-FC 13
MAINTENANCE
WARNING: When cleaning the solar panel, DO NOT immerse it in water or
other liquids.
CLEANING
Remove the dust and debris from the surface of the solar panel with a soft brush. Then
wipe the surface with a clean damp cloth.
TRANSPORTING AND STORING
1. Make sure no devices are connected to the solar panel and no stacking of heavy
objects on the solar panel before storing or transporting.
2. Clean the solar panel thoroughly before storing. Store the solar panel indoors, in a
dry place that is locked and/or inaccessible to children.
3. Keep away from corrosive agents such as garden chemicals and de-icing salts.

100W SOLAR PANEL — SP1000/SP1000-FC14
EGO LIMITED WARRANTY
WARRANTY POLICY TERMS AND DURATION
Chervon North America, Inc. (“Chervon North America”) provides the following Limited
Warranty for EGO products to the original purchaser of EGO products.
The detailed warranty period for each EGO product can be found online at
http://egopowerplus.com/warranty-policy.
Please contact EGO Customer Service Toll-Free at 1-855-EGO-5656 any time you
have questions or warranty claims or would like a hard copy of the warranty.
LIMITED SERVICE WARRANTY
EGO products are warranted against defects in material or workmanship from the date
of original retail purchase for the applicable warranty period. For any properly and
timely submitted warranty claim, if Chervon North America determines a product to be
defective during the warranty period, the product will receive free repair or replacement
as determined by Chervon North America.
HOW TO OBTAIN SERVICE
For warranty service, within the applicable warranty period, please contact EGO
customer service toll-free at 1-855-EGO-5656. When requesting warranty service,
you must present the original dated sales receipt. An authorized service center will
be selected to evaluate and repair the product if defective according to the stated
warranty terms. When bringing your product to the authorized service center, there may
be a small deposit that will be required when dropping off your tool. This deposit is
refundable when the repair service is deemed to be covered under warranty.
ADDITIONAL LIMITATIONS & EXCLUSIONS
This limited warranty applies only to the original purchaser from an authorized EGO
retailer and is not transferable. EGO products shall not be considered defective, and this
warranty will not apply, where the claimed defect is attributable to any cause other than
the above-defined defects. This warranty shall be void if the product has been used for
rental purposes. This warranty shall not apply to damage caused by accident, abuse,
misuse, alteration, modification, unauthorized repair, liquid contact, fire, earthquake or
other external cause; operating the product outside EGO’s instructions, specifications
or guidelines; or failure to properly service of maintain the product. This warranty also
does not apply to cosmetic damage, including but not limited to scratches or dents;
defects caused by normal wear and tear or otherwise due to the normal aging of the
product.

100W SOLAR PANEL — SP1000/SP1000-FC 15
THIS EXPRESS WARRANTY IS GIVEN IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR PARTICULAR PURPOSE OR USE, WHICH ARE DISCLAIMED. Any implied
warranties, including warranties of merchantability or fitness for a particular purpose,
that cannot be disclaimed under state law are limited to the applicable warranty period
defined at the beginning of this article. The sole and exclusive remedy in connection
with the purchase, installation, use, and/or performance of the EGO products is repair
or replacement of the product as determined by Chervon North America. Chervon North
America’s maximum liability shall not in any case exceed the purchase price paid for
the product. CHERVON NORTH AMERICA SHALL NOT BE LIABLE TO THE USER OR TO
ANYONE ELSE FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL, EXEMPLARY, INDIRECT,
OR PUNITIVE DAMAGES ARISING FROM USE OF THE PRODUCTS, INCLUDING BUT NOT
LIMITED TO PERSONAL INJURY, DEATH, PROPERTY DAMAGE, LOST PROFITS, OR OTHER
ECONOMIC INJURY. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. Some states do not allow limitations on how
long an implied warranty lasts, the exclusion or limitation of incidental or consequential
damages, or the limitations on time to bring certain actions, so such limitations
contained herein do not apply to individual consumers in those states.
This warranty is subject to and shall be interpreted according to Michigan law without
regard to principles of conflicts of laws. No legal action shall be brought against
Chervon North America unless filed within one (1) year after the basis for such legal
action becomes known, or with the exercise of reasonable diligence should have
become known. Any action not timely filed shall be deemed waived.
For customer service contact us toll-free at: 1-855-EGO-5656 or
EGOPOWERPLUS.COM.
EGO Customer Service
769 Seward Ave. NW, Suite 102
Grand Rapids, Michigan 49504.

SOLAR PANEL
MANUAL DEL OPERADOR
PANNEAU SOLAIRE DE 100 W
NÚMERO DE MODELO SP1000/SP1000-FC
ADVERTENCIA: Para reducir el riesgo de lesiones, el usuario debe leer y comprender el
Manual del usuario antes de usar el producto. Guarde estas instrucciones para consultarlas
en el futuro.

PANNEAU SOLAIRE DE 100 W — SP1000/SP1000-FC18
LISEZ TOUTES LES INSTRUCTIONS !
ASSUREZ-VOUS DE LIRE ET DE
COMPRENDRE LE GUIDE D’UTILISATION
TABLE DES MATIÈRES
Lisez toutes les instructions ............................19-20
Symboles..............................................21
Symboles relatifs à la sécurité .............................22
Déclaration de conformité FCC ..........................22-23
Introduction ............................................24
Spécications ..........................................25
Liste des pièces.........................................25
Description .........................................26-27
Fonctionnement......................................27-29
Maintenance ...........................................30
Garantie limitée d’EGO.................................31-33

PANNEAU SOLAIRE DE 100 W — SP1000/SP1000-FC 19
SYMBOLES RELATIFS À LA SÉCURITÉ
La raison d’être des symboles relatifs à la sécurité est d’attirer votre attention sur des
dangers possibles. Il est important de vous familiariser avec les symboles relatifs à
la sécurité et les explications qui les accompagnent afin de bien les comprendre. Les
avertissements et les symboles associés ne suffisent pas à éliminer tous les dangers.
Les instructions et les avertissements qu’ils donnent ne sauraient remplacer des
mesures de prévention des accidents appropriées.
AVERTISSEMENT : Lisez toutes les consignes de sécurité qui sont contenue
dans ce Mode d’emploi, y compris tous les symboles d’alerte relatifs à la sécurité tels
que « DANGER », « AVERTISSEMENT » et « MISE EN GARDE », et assurez-vous que
vous les comprenez bien avant de commencer à utiliser cet outil. La non-observation
de toutes les instructions figurant ci-après pourrait causer un choc électrique, un
incendie et/ou des blessures personnelles graves.
Les définitions ci-dessous décrivent le degré de gravité pour chaque mot-indicateur.
Veuillez lire ce manuel et prêter attention à ces symboles.
Voici le pictogramme d’alerte de sécurité. Il sert à
vous indiquer les risques potentiels de blessures.
Respectez toutes les consignes de sécurité
associées à ce pictogramme pour éviter les risques
de blessures ou de mort.
DANGER :
La mention DANGER indique un danger imminent
qui, s’il n’est pas évité, causera des blessures
graves ou la mort.
AVERTISSEMENT :
La mention AVERTISSEMENT indique un risque
pouvant entraîner des blessures graves ou la mort
s’il n’est pas prévenu.
MISE EN GARDE :
La mention MISE EN GARDE, utilisée avec le
symbole d’alerte de sécurité, indique un risque
potentiel qui, s’il n’est pas éliminé, provoquera des
blessures mineures ou moyennement graves.

PANNEAU SOLAIRE DE 100 W — SP1000/SP1000-FC20
MESSAGES D’INFORMATION ET DE PRÉVENTION DES DOMMAGES
Ils informent l’utilisateur d’informations et/ou d’instructions importantes qui pourraient
entraîner des dommages matériels ou aux équipements s’ils ne sont pas suivis. Chaque
message est précédé par le terme « AVIS », comme dans l’exemple ci-dessous :
AVIS : Un dommage matériel et/ou aux équipements peut survenir si ces instructions
ne sont pas suivies.
