EINHELL RG-AW 1139 User manual

tOriginal operating instructions
Garden Pump

Art.-Nr.: 41.770.02 I.-Nr.: 11010 RG-AW 1139
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 1

2
Read and follow the operating instructions and safety information
before using for the first time.

Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 2

3
2 3
6
8
6
8
7
1
5
3
71
2
6
4
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 3

Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions and
the safety information.
1. Safety regulations
 Caution!
In stagnant water bodies, garden ponds, dams
and their surrounding areas the unit may only be
used with an earth-leakage circuit breaker with
an actuating rated current of up to 30 mA
(according to VDE 0100 Part 702 and 738).
The equipment is not designed for use in
swimming pools and paddling pools of any kind
or other bodies of water in which people or
animals may be present during operation. It is
prohibited to operate the equipment if a person
or animal is in the danger area. Ask your
electrician!
This equipment is not designed to be used by people
(including children) with limited physical, sensory or
mental capacities or those with no experience and/or
knowledge unless they are supervised by a person
who is responsible for their safety or they have
received instructions from such a person in how to
use the equipment safely. Children must always be
supervised in order to ensure that they do not play
with the equipment.
Important!
Always inspect the equipment visually before
using it. Do not use the equipment if safety
devices are damaged or worn. Never disable
safety devices.
Use the equipment only for the purposes
indicated in these operating instructions.
You are responsible for safety in the work area.
If the cable or plug is damaged by external
influences, the cable may not be repaired. The
cable must be replaced by a new one. This work
may only be carried out by a trained electrician.
The voltage of 230 V alternating voltage specified
on the rating plate must be the same as the mains
voltage.
Never use the power cable to lift, transport or
secure the equipment.
Ensure that the electrical plug connections are in
areas that are not at risk of flooding or protect
them from moisture.
Pull the mains plug before starting any work on
the equipment.
Do not expose the equipment to a direct jet of
water.
The operator is responsible for complying with
local safety and installation regulations. (Ask an
electrician if you are in any doubt.)
Consequential damage caused by flooded rooms
in the event of the equipment suffering faults must
be prevented by the user by means of suitable
measures (for example installing alarm systems
or a reserve pump, etc.).
In the event of a failure, repair work may only be
carried out by an electrician or by ISC after sales
service personnel.
The equipment must never run dry or be used
when the intake line is closed fully. The
manufacturer’s warranty does not cover damage
caused to the equipment as a result of running it
dry.
The pump must not be used to operate swimming
pools.
The equipment must not be installed in the
drinking water pipe line.
 CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout and items supplied (Fig. 1-2)
1. Pressure connector
2. Carry handle
3. Power switch
4. Water drain screw
5. Suction connector
6. Coarse filter screw
7. Ventilation screw
8. Coarse filter
Not illustrated: Operating instructions
Take all parts out of the packaging and check that the
equipment is complete.
4
GB
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 4

5
GB
3. Items supplied
Open the packaging and take out the equipment
with care.
Remove the packaging material and any
packaging and/or transportation braces (if
available).
Check to see if all items are supplied.
Inspect the equipment and accessories for
transport damage.
If possible, please keep the packaging until the
end of the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of
swallowing or suffocating!
Original operating instructions
Safety instructions
4. Proper use
Applications
Irrigation and watering of green areas, vegetable
beds and gardens.
Operation of lawn sprinklers.
For drawing water from ponds, streams, rainwater
butts, rainwater cisterns and springs
For supplying service water
Transport media:
For the pumping of clear water (fresh water),
rainwater or light suds/service water.
The maximum temperature of the fluid must not
exceed +35°C if the equipment is operated
permanently.
Do not use the equipment to pump inflammable,
gassing or explosive fluids.
The pumping of aggressive liquids (acids, alkalis,
silo seepage etc.) as well as liquids with abrasive
substances (sand) must likewise be avoided.
This equipment is not designed to convey
drinking water.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the manufacturer
will be liable for any damage or injuries of any kind
caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Technical data
Mains connection 240V ~ 50 Hz
Power rating 1100 W
Pumping rate 4100 l/h
Max. delivery head 48 m
Max. delivery pressure 0.48 MPa (4.8 bar)
Max. suction height 8 m
Pressure and suction connector R1 internal thread
Max. water temperature 35 °C
6. Before putting the equipment into
operation
6.1 Connecting the intake line
As a basic principle, we recommend the use of a
preliminary filter and a suction set with suction hose,
suction strainer and non-return valve, in order to
prevent long priming periods and unnecessary
damage to the pump as a result of stones and solid
foreign bodies.
The intake hose or pipe should have a minimum
diameter of 25 mm (1”); a diameter of 32 mm
(1 1/4”) is recommended for suction heights
exceeding 5 m.
Connect the intake valve (foot valve) with intake
cage to the intake line.
Position the intake line so that it rises from the
water withdrawal point to the equipment. Avoid
positioning the suction pipe higher than the
pump, as this would delay the escape of air
bubbles from the suction pipe and impede the
priming process.
Install the intake and discharge lines in such a
way that they do not exert any mechanical
pressure on the equipment.
The intake valve should be low enough in the
water to ensure that if the water level falls, the
equipment will not run dry.
A leaking intake line will draw in air and therefore
not draw in any water.
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 5

6.2 Connecting the discharge line
The discharge line (min. 19 (3/4”)) must be
connected to the R1 (1”) female thread discharge
line connector of the equipment either directly or
with the aid of a threaded nipple.
With the right couplings it is also possible, of
course, to use a 13 mm (1/2“) delivery hose. The
smaller delivery hose results in a lower delivery
rate.
During the priming operation, fully open any shut-
off mechanisms (spray nozzles, valves, etc.) in
the pressure line so that the air can escape
without obstruction.
6.3 Electrical connections
Connect the appliance to a 240 V ~ 50 Hz socket-
outlet with earthing contact. Minimum fuse 10
ampere.
A built-in thermostat protects the motor from
overloading and blocking. The pump is switched
off automatically by the thermostat if overheating
occurs and is switched on again automatically
after cooling.
7. Operation
Install the equipment on a solid and level surface.
Remove the ventilation screw (7).
Unscrew the coarse filter screw (6) and remove
the coarse filter (8) as shown in Figure 2. Now
you can fill the pump housing with water via the
coarse filter screw (6). Filling the intake line
accelerates the intake process.
Assemble in reverse order.
Open the discharge line.
Connect the mains cable.
Switch on the equipment with the power switch
(3) - water can be suctioned in for up to 5 minutes
(maximum suction height).
After finishing the work, switch off the equipment
with the power switch (3).
8. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
9. Cleaning, maintenance and
ordering of spare parts
The equipment is almost completely maintenance
free. In order to ensure a long service life, however,
we recommend that you regularly check and care for
the product.
Important!
The equipment must be disconnected from the power
supply (pull the power plug) prior to performing any
maintenance.
9.1 Servicing
If the equipment becomes clogged, connect the
discharge line to the water line and disconnect
the suction hose. Open the water line. Switch on
the equipment several times for approx.
two seconds. This should resolve the majority of
clog-related problems.
Replacing the mains cable: Important:
Disconnect the equipment from the power
supply! A defective mains cable may only be
replaced by a qualified electrician.
There are no parts inside the equipment which
require additional maintenance.
9.2 Cleaning the coarse filter insert
Clean the coarse filter insert at regular intervals,
and replace it if necessary.
Remove the coarse filter screw (6) and coarse
filter (8) (Figure 2).
Disassemble the coarse filter insert as shown in
Figure 3.
Do not use abrasive cleaning agents or petrol to
clean the coarse filter.
Clean the coarse filter by tapping it on a flat
surface. In cases of stubborn dirt first clean with
soapy water, then rinse with clear water and air-
dry.
Assemble in reverse order.
9.3 Storage
If the pump is not going to be used for a long time
or has to be removed for the winter months, rinse
it out with water, empty it completely and allow it
to dry.
The equipment must be completely drained
before it is subjected to frost.
After long stoppages, make sure the rotor turns
correctly by briefly switching the pump on and off.
6
GB
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 6

7
GB
9.4 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
10. Disposal and recycling
The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to the
raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic. Defective
components must be disposed of as special waste.
Ask your dealer or your local council.
11. Storage
Store the equipment and accessories out of children’s
reach in a dark and dry place at above freezing
temperature. The ideal storage temperature is
between 5 and 30 °C. Store the electric tool in its
original packaging.
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 7

8
GB
Faults Cause Remedy
Motor fails to start up - No mains voltage
- Pump rotor blocked -thermostat
switched off
- Check voltage
- Dismantle and clean pump
No intake - Non-return valve dirty
- Pump chamber without water
connection
- Air in intake line air-tight
- Max. suction height exceeded
- clean
- Fill water into intake
- Make sure intake line is close
- Check suction height
Inadequate delivery rate - Suction height too high
- Coarse filter dirty
- Water level falling rapidly
- Pump performance diminishedby
contaminants part
- Check suction height
- clean
- Place the suction hose at a
deeper level
- Clean pump and replace wearing
Thermostat switches pump off - Motor overloaded - friction
caused by foreign substances
too high
- Dismantle and clean pump.
Prevent intake of foreign
substances (filter)
12. Troubleshooting guide
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 8

9
tFor EU countries only
Never place any electric tools in your household refuse.
To comply with European Directive 2002/96/EC concerning old electric and electronic equipment and its
implementation in national laws, old electric tools have to be separated from other waste and disposed
of in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the demand to return electrical devices:
As an alternative to returning the electrical device, the owner is obliged to cooperate in ensuring that the
device is properly recycled if ownership is relinquished. This can also be done by handing over the used
device to a returns center, which will dispose of it in accordance with national commercial and industrial
waste management legislation. This does not apply to the accessories and auxiliary equipment without
any electrical components which are included with the used device.
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 9

10

The reprinting or reproduction by any other means, in whole or in part,
of documentation and papers accompanying products is permitted only
with the express consent of ISC GmbH.
 Technical changes subject to change
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 10

11
tGUARANTEE CERTIFICATE
Dear Customer,
All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely
event that your device develops a fault, please contact our service department at the address shown on this
guarantee card. Of course, if you would prefer to call us then we are also happy to offer our assistance under
the service number printed below. Please note the following terms under which guarantee claims can be made:
1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights.
We do not charge you for this guarantee.
2. Our guarantee only covers problems caused by material or manufacturing defects, and it is restricted to the
rectification of these defects or replacement of the device. Please note that our devices have not been
designed for use in commercial, trade or industrial applications. Consequently, the guarantee is invalidated
if the equipment is used in commercial, trade or industrial applications or for other equivalent activities. The
following are also excluded from our guarantee: compensation for transport damage, damage caused by
failure to comply with the installation/assembly instructions or damage caused by unprofessional
installation, failure to comply with the operating instructions (e.g. connection to the wrong mains voltage or
current type), misuse or inappropriate use (such as overloading of the device or use of non-approved tools
or accessories), failure to comply with the maintenance and safety regulations, ingress of foreign bodies
into the device (e.g. sand, stones or dust), effects of force or external influences (e.g. damage caused by
the device being dropped) and normal wear resulting from proper operation of the device.
The guarantee is rendered null and void if any attempt is made to tamper with the device.
3. The guarantee is valid for a period of 2 years starting from the purchase date of the device. Guarantee
claims should be submitted before the end of the guarantee period within two weeks of the defect being
noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee
period remains applicable to the device even if repairs are carried out or parts are replaced. In such cases,
the work performed or parts fitted will not result in an extension of the guarantee period, and no new
guarantee will become active for the work performed or parts fitted. This also applies when an on-site
service is used.
4. In order to assert your guarantee claim, please send your defective device postage-free to the address
shown below. Please enclose either the original or a copy of your sales receipt or another dated proof of
purchase. Please keep your sales receipt in a safe place, as it is your proof of purchase. It would help us if
you could describe the nature of the problem in as much detail as possible. If the defect is covered by our
guarantee then your device will either be repaired immediately and returned to you, or we will send you a
new device.
Of course, we are also happy offer a chargeable repair service for any defects which are not covered by the
scope of this guarantee or for units which are no longer covered. To take advantage of this service, please send
the device to our service address.
EINHELL AUSTRALIA PTY LTD
6/166 Wellington Street
Collingwood VIC 3066
Australia
Phone: [phone]
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 11

EH 05/2010 (01)
Anleitung_RG_AW_1139_SPK7:_ 07.05.2010 14:45 Uhr Seite 12
