EIP AM2000 User manual

UK Head Office
Ebac Industrial Products Ltd
St Helens Trading Estate
Bishop Auckland
County Durham
DL14 9AD
Tel: [phone]
Fax: [phone]
www.eipl.co.uk
[email protected]
American Sales Office
Ebac Industrial Products Inc
700 Thimble Shoals Blvd.
Suite 109, Newport News
Virginia, 23606-2575
USA
Tel: [phone]
Fax: [phone]
www.ebacusa.com
[email protected]
German Sales Office
Ebac Industrial Products Ltd.
Gartenfelder Str. 29
Tel: [phone]
Fax: +49
AM2000
AIR
USER MANUAL
German Sales Office
Ebac Industrial Products Ltd.
Gartenfelder Str. 29
-37
Gebäude 35
D-13599, Berlin
Germany
Tel: [phone]
Fax: +49
3043 557240
www.eip-ltd.de
[email protected]
READ AND SAVE THESE INSTRUCTIONS
AM2000
MOVER
USER MANUAL
Drawing No.
:
-
TPC
403
Issue :- 4
Date :- 06/06/14
READ AND SAVE THESE INSTRUCTIONS

IF YOUR
AIRMOVER
FAILS TO
OPERATE
1. Check that the plug
is fully pushed
into the socket and is switched on.
2.
Check with some other electrical
device that the wall socket is “live”. If
it is not, contact a qualified
electrician.
3. Check the
circuit breaker on the
control panel and reset as required.
Should none o
f the above remedies
work, then disconnect from the mains.
Contact your supplier
. DO NOT attempt
to repair the unit or unscrew the outer
casing.
UNPACKING
Remove the top insert and your E
IPL
Air M
over from its packing carton,
v
isually inspect for any signs of transit
damage. If
there are any signs of
damage, do not operate your unit. Call
your supplier immediately for advice. Do
not discard the packing for it will be
useful for transporting your unit in the
future.
TRANSPORTATION
A cord wrapping facility has been
moulded into the
plastic fan housing.
The power cord should be wrapped
around this facility during transit
. Do not
drop or abuse your Air Mover during
ELECTRICAL CONNECTION
If the appliance is fitted with a plug for
which your socket is unsuitable, then it
should be cut off
and an appropriate plug
fitted.
OPERATING PROCEDURES
Connect the power cord into a
grounded
electrical outlet and
turn the power
switch to the ON position.
If you have no
power or hear any
loud or abnormal
noises and consult your supplier.
Your EIPL
Air Mover is designed to
operate in 4 positions to allow drying of
floors, walls and ceilings.
Your EIPL
Air Mover comes with internal
circuit protection for your safety. When
working around a wet environment, we
also recommend always plugging the
unit in
to a ground fault interrupter to
assure the best protection.
For the drying of water damaged
facilities, we recommend using an EIPL
dehumidifier along with your air mover to
provide you with more efficient drying.
Your air mover is designed to induce
evapo
ration or water contained within
flooded surfaces or materials. Yet,
without a mechanism for
removing the
moisture from the air, drying will not
occur. It is recommended that the
dehumidifier outlet is close to the air
mover intake. This allows for dry air
to
be distributed by the air mover.
•
Electric shock hazard, rotating fan, hot surface hazard. Unplug
unit before
opening covers for cleaning or servicing
•
This machine should be serviced by qualified Ebac personnel or other
persons having technical competence servicing refrigeration equipment
following the instructions in the Ebac service manual.
•Ebac
service manuals and spares lists are available upon request by
contacting your local Ebac distributor.
•Never operate the unit in a bathroom or swimming pool area
•Do not use the machine if the power cord or case is damaged.
•Do not poke objects into and of the grilles on the machine.
•Do not cover or obstruct the air inlet or outlet.
•This machine has been manufactured in the United Kingdom.
•
This appliance can be used by children from 8 years and above and persons
with reduced physical, sensory or mental capabi
lities or lack of experience
and knowledge if they have been given supervision or instruction concerning
use of the application in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
•Not Suitable for use with solid state speed controls
•Ne convient pas à des régulateurs de vitesse à semi-conducteurs
TECHNICAL SPECIFICATIONS
AM2000
115V/60Hz/1 PH Horsepower
½
Height
21” Max running current
5A
Width
20” Fan Speeds
3
Depth
19”
Weight
34lbs
The wire which is coloured Green and
Yellow must be connected to the terminal
in the plug which is marked with the letter
E or by the Earth.
The wire which is
coloured White
must be connected to the
terminal in the
plug which is marked with
the letter N. The wire which is coloured
Black
must be connected to the terminal
which is marked with the letter L
You must dispose of the non rewireable
plug once it has been removed from the
flexible cord. It is dangerous to at
tempt to
insert the plug into any electrical socket
elsewhere in the house. If the flexible cord
becomes damaged it must be replaced by
an identical cord.
IMPORTANT:- The wires in this mains
lead are coloured in accordance with the
following code:-
Green Earth
White Neutral
Black Live
WARNING
–
THIS APPLIANCE MUST BE EARTHED
As the colours of the wires in the mains
lead of this appliance may not
correspond with the coloured markings
identifying the terminals in your own
plug, proceed as follows
WARNING
INTRODUCTION
EIPL
Air Movers are high performance,
high efficiency fan systems designed to
optimize air movement and minimize
operating costs for drying applications.
Each model incorporates a double inlet,
centrifugal type fan design to provide the
high static pressure an
d airflow required
to dry water damaged facilities and
equipment. The EIPL
Air Mover series
was designed to provide you the best
performance and serviceability.
•
25 ft. Power Cord with cord grip
This appliance complies with the
EMC
Directive 2004/108/EC.
•
Internal thermal Circuit Breaker
•
Aerodynamic, Rotationally Moulded
Polythene Housing.
•
High Efficient 1/2 HP Motor
•
Three Speed Fan Design
•
4 operating Positions (0º, 12º, 45º, &
90º)
•
Stack ability in the Vertical Plane
during both Storage and Operation.
•
Moulded Cord wrap Facility
transit for risk of damage to both the
motor and housing.
