Eisco ESRDS1337 User manual

POWER SUPPLY
Instruction Manual
CAT NO. ESRDS1337

The power supply ESRDS1337 Discharge Tube Power Supply is a very useful & unique
Power Supply which provides the High Voltage (10 to 500V & 0 to 80V) & Low Voltage (0
to 20V DC, 5 Amps.) along with the DIGITAL DISPLAY for Voltage & Current. It also
provides theAC Voltage selectable from 1 to 6VAC, 2Amps.All the outputs provided are
independent of each other and can be used simultaneously.
The DC voltage 10 to 500V (adjustable) & 0 to 80V (adjustable) are displayed on the
DIGITALDISPLAY by selecting with the help of Voltage Monitor Selector Switch.
The Low Voltage 0 to 20V, 5 Amps. DC output voltage is displayed on the DIGITAL
DISPLAY. The Voltage or Current Display is selected with the help ofA/V selector switch.
The 6V AC, 2Amp. is also provided on four different Sockets, The A/C Voltage can be
selected from 1 to 6V in the step of 1V, out of these four sockets.
The 2 Amps. AC Overload Cut-Off Resettable Switch is provided in series with the AC
O/P for the overload protection. Once the AC Current exceeds the 2 Amps. The switch
will be cut off & O/P will be reduced to Zero. This switch has to be reset to reactivate the
AC Output voltage.
Operation :
1. Select the mains input with the help of slide switch provided on the rear panel 120V
(50/60Hz) or 240V (50/60Hz) .
2. Connect the power chord to the mains outlet after selecting the desired input.
3. Flip the ON/OFF ( I & O) switch to the (I) ON position. The ON position of the Power
Supply is indicated by the Neon light.
WARM - UP PERIOD :
For accurate, outputs & Digital Displays of voltage & current the warm up period about
the 15 minutes is required.
POWER SUPPLY ESRDS1337
VOLTS VOLTS/AMPS.
A
V
VOLTAGE MONITOR SELECTOR
DISCHARGE
TUBE
POWER SUPPLY
FILAMENT SUPPLY
AC VOLTS, 2 AMPS. MAX.
500V 80V
RED
OVER LOAD
6
13
4
---- ----
DC
0 - 500V, 10mA
DC DC
0 - 80V, 10mA
+
- --
+ +
---- ----
!!!!!
0 - 20V, 5A
!
5
2
-
----
I
AC - OVERLOAD
CUT-OFF
PRESS TO RESET
-1-
© EISCO SCIENTIFIC ●www.eiscolabs.com
!

4. Over all the supply has four outputs, out of which three are the DC outputs & one is
the Low Voltage AC 6.0V, 2Amps.
Technical Data :
Fuse Rating: F 3.15A/ 250V
Mains Input: Selectable120 (50/60Hz) or 240 (50/60Hz)
Max. Output Wattage: 140 Watt Max.
DC :
Voltage: 0-20V (Regulated), 5 Amps. Max. adjustable from 0 to +20V the
output voltage is displayed on the DPM, keeping A/V selector
switch in the V (Voltage Position). To know the current, set the
selector switch toA(Amps.) position.
10 - 500V, 0.01Amp. Max. adjustable from 10 to +500V. The output
voltage is displayed on the DPM keeping the selector switch
towards 500V markings.
0-80V, 0.01 Amp. Max. adjustable from 0 to +80V. The output
voltages is displayed on the DPM keeping the selector switch
towards the 80V markings.
Important Note :
While using H-Voltages 10-500V & 0-80V, please note down the following instruction
very Carefully.
1. Always turn the voltage controls knobs (Grey for 10-500V & Yellow for 0-80V)
fully anti Clockwise to make the O/P voltages 000V.
2. Connect the required Load / Under Test apparatus at the appropriate O/P
sockets.
3. Then slowly turn the voltage control knobs in the clockwise direction to set the
desired O/P voltage which is also displayed on the Digital Voltmeter.
4. Before removing the load / apparatus from the O/P sockets first of all alwasys
make the O/P Voltage 000, only then remove the connections from O/P sockets,
for the safe guard of DPM / equipment to avoid any electric shock due to HV DC
available at the O/P Sockets.
AC :
Voltages 6V (Max.) selectable from 1 to 6V as per the markings.
Current 2Amps. Max.
Caution :
1. Replace the fuse as per the specified rating & type.
2. Do not over-load more than 5Amps.
-2-
© EISCO SCIENTIFIC ●www.eiscolabs.com
!

3. In case of DC (0 to + 20V) O/P voltage, GREEN LED indicates that the supply
is in the normal condition & when the GREEN LED changes to the RED, it means
that supply is overloaded. In that case reduce the load Connected at the DC
Output Sockets, so that the LED changes from RED to GREEN.
Cleaning Instruction :
For cleaning the unit / Power Supply outwardly only use the damped moist cloth soaked
with clear water.
Intended Use of Equipment :
Mostly this equipment will be used in Educational Institutions, Schools for carrying out
the experiments.
Environmental Conditions :
1. Pollution Degree: 2
2. Installation Category: 2
3. Altitude: 2000 meters Max.
4. Maximum recommended humidity: 75% RH.
5. Electrical Supply: 120V/240V, ± 10%, 50/60Hz
6. Equipment is meant for Indoor use only.
7. Ambient Temperature: 30°C Max.
Equipment Installation :
Equipment to be installed by qualified trained personnel only.
Explanation of Symbols :
Caution, Refer Instruction Manual.
Danger High Voltage Present.
Protective Earth.
Important :
Protection impairment if used in a manner not specified as per this manual.
MUST "DISCONNECT THE SUPPLY BEFORE SERVICING".
-3-
!
!
!
!
!
!
!
!
!
!
EISCO SCIENTIFIC instructions, content and design is intellectual property of EISCO
U.S. Distributor :
Eisco Scientific
850 St Paul St, Suite 15, Rochester, NY 14605
Website : www.eiscolabs.com
Manufactured by :
www.eiscolabs.com
No operator serviceable parts inside. Refer to qualified personnel for servicing repairs only.
