Eizo ColorEdge CG19 User manual

SAFETY SYMBOLS
PRECAUTIONS
1. INTRODUCTION
1-1.Features
1-2.Package Contents
1-3.Controls & Connectors
2. CABLE CONNECTION
2-1.Before Connecting
2-2.Connecting the Signal
Cable (D-Sub or DVI)
2-3.Connecting the Signal
Cable (ADC)
2-4.Connecting Two PCs to
the Monitor
2-5.How to remove the Tilt
Stand
3. ScreenManager
3-1.How to use the
ScreenManager
3-2.ScreenManager
Adjustments and Settings
3-3.FineContrast
3-4.Useful Functions
4. ADJUSTMENT
4-1.Screen Adjustment
4-2.Displaying a low
resolution
4-3.Color Adjustment
4-4.Power-save Setup
5. MAKING USE OF USB
(Universal Serial Bus)
6. TROUBLESHOOTING
7. CLEANING
This manual is checked under the browser settings shown
below. Text size can change for another one through
browser setting.
Microsoft Internet Exproler:
Text size: Medium
Encoding: Western European

8. SPECIFICATION
9. GLOSSARY
APPENDIX/ ANHANG/
ANNEXE
About TCO'03 (Applicable to
gray)
About TCO'99 (Applicable to
black)
FCC Declaration of
Conformity
Hinweis zur Ergonomie /
Recycle Auskunft / Hinweise
zur Auswahl des richtigen
Schwenkarms für Ihren
Monitor

This manual uses the safety symbols below. They denote critical information. Please read them
carefully.
WARNING
Failure to abide by the information in a WARNING may result in serious
injury and can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION may result in moderate
injury and/or property or product damage.
Indicates a prohibited action.
Indicates to ground for safety.
Copyright© 2004 EIZO NANAO CORPORATION All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, or otherwise, without the prior written
permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or
information confidential unless prior arrangements are made pursuant to EIZO NANAO
CORPORATION's receipt of said information Although every effort has been made to ensure
that this manual provides up-to-date information, please note that EIZO monitor specifications
are subject to change without notice.
ENERGY STAR is a U.S. registered mark.
Apple and Macintosh are registered trademarks of Apple Computer, Inc.
VGA is a registered trademark of International Business Machines Corporation.
DPMS is a trademark and VESA is a registered trademark of Video Electronics Standards
Association.
Windows is a registered trademark of Microsoft Corporation.
PowerManager is a trademark of EIZO NANAO CORPORATION.

ScreenManager, ColorEdge and EIZO are registered trademarks of EIZO NANAO
CORPORATION in Japan and other countries.
As an ENERGY STAR®Partner, EIZO NANAO CORPORATION has
determined that this product meets the ENERGY STAR guidelines for
energy efficiency.

IMPORTANT!
●This product has been adjusted specifically for use in the region to which it
was originally shipped. If operated outside the region to which it was originally
shipped, the product may not perform as stated in the specifications.
●To ensure personal safety and proper maintenance, please read this section and
the caution statements on the unit (refer to the figure below).
[Location of the Caution Statements]
If the unit begins to emit smoke, smells like something is burning, or
makes strange noises, disconnect all power connections immediately
and contact your dealer for advice.
Attempting to use a malfunctioning unit may result in fire, electric shock,
or equipment damage.
Do not open the cabinet or modify the unit.
Opening the cabinet or modifying the unit may result in fire, electric shock,
or burn.

Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening or removing
covers may result in fire, electric shock, or equipment damage.
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the
cabinet or spillage into the cabinet may result in fire, electric shock, or
equipment damage.
If an object or liquid falls/spills into the cabinet, unplug the unit
immediately. Have the unit checked by a qualified service engineer before
using it again.
Place the unit at the strong and stable place.
A unit placed on an inadequate surface may fall and result in injury or
equipment damage.
If the unit falls, disconnect the power immediately and ask your dealer for
advice. Do not continue using a damaged unit. Using a damaged unit may
result in fire or electric shock.
Set the unit in an appropriate location.
Not doing so may result in fire, electric shock, or equipment damage.
●Do not place outdoors.
●Do not place in the transportation system (ship, aircraft, trains,
automobiles, etc.)
●Do not place in a dusty or humid environment.
●Do not place in a location where the steam comes directly on the
screen.
●Do not place near heat generating devices or a humidifier.

To avoid danger of suffocation, keep the plastic packing bags away
from babies and children.
Use the enclosed power cord and connect to the standard power outlet
of your country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may result in fire or electric shock.
To disconnect the power cord, grasp the plug firmly and pull.
Tugging on the cord may damage and result in fire or electric shock.
The equipment must be connected to a grounded main outlet.
Not doing so may result in fire or electric shock.
Use the correct voltage.
* The unit is designed for use with a specific voltage only. Connection to
another voltage than specified in this User's Manual may cause fire, electric
shock, or equipment damage.
* Do not overload your power circuit, as this may result in fire or electric
shock.
Handle the power cord with care.
* Do not place the cord underneath the unit or other heavy objects.
* Do not pull on or tie the cord.
If the power cord becomes damaged, stop using it. Use of a damaged cord
may result in fire or electric shock.

Never touch the plug and power cord if it begins to thunder.
Touching them may result in electric shock.
When attaching an arm stand, please refer to the user's manual of the
arm stand and install the unit securely with the enclosed screws.
Not doing so may cause the unit to become unattached, which may result in
injury or equipment damage. When the unit is dropped, please ask your
dealer for advice. Do not continue using a damaged unit. Using a damaged
unit may result in fire or electric shock. When reattaching the tilt stand,
please use the same screws and tighten them securely.
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the
eyes or mouth.
If any part of the skin or body comes in direct contact with the panel,
please wash thoroughly. If some physical symptoms result, please consult
your doctor.
Follow local regulation or laws for safe disposal.
The backlight of the LCD panel contains mercury.
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the
unit with the cord attached is dangerous. It may result in injury.
When handling the unit, grip the bottom of the unit firmly with both
hands ensuring the panel faces outward before lifting.
Dropping the unit may result in injury or equipment damage.

Do not block the ventilation slots on the cabinet.
* Do not place any objects on the ventilation slots.
* Do not install the unit in a closed space.
* Do not use the unit laid down or upside down.
Blocking the ventilation slots prevents proper airflow and may result in
fire, electric shock, or equipment damage.
Do not touch the plug with wet hands.
Doing so may result in electrical shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a
problem.
Periodically clean the area around the plug.
Dust, water, or oil on the plug may result in fire.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in
electric shock.
If you plan to leave the unit unused for an extended period, disconnect
the power cord from the wall sochekt after turning off the power
switch for the safety and the power conservation.

In order to suppress the luminosity change by long-term use and to
maintain the stable luminosity, use of a monitor in lower brightness is
recommended.
The screen may have defective pixels. These pixels may appear as slightly
light or dark area on the screen. This is due to the characteristics of the
panel itself, and not the product.
The backlight of the LCD panel has a fixed life span. When the screen
becomes dark or begins to flicker, please contact your dealer.
Do not press on the panel or edge of the frame strongly, as this may result
in damage to the screen. There will be prints left on the screen if the
pressed image is dark or black. If pressure is repeatedly applied to the
screen, it may deteriorate or damage your LCD panel. Leave the screen
white to decrease the prints.
Do not scratch or press on the panel with any sharp objects, such as a
pencil or pen as this may result in damage to the panel. Do not attempt to
brush with tissues as this may scratch the LCD panel.

Thank you very much for choosing an EIZO Color Monitor.
●The exclusive use calibration software caliblates the monitor characteristics
and generate colorprofile.
●Dual inputs compliant
●DVI Digital input (TMDS) compliant.
●ADC (Apple Display Connector) inputs compliant.
●[Horizontal scanning frequency]
Analog: 30 - 82 kHz
Digital: 30 - 65 kHz
[Vertical scanning frequency]
Analog: 49 - 86 Hz Vertical (1280 x 1024: 49 - 75 Hz)
Digital: 59 - 61 Hz (VGA text: 69 - 71 Hz))
[Resolution] 1280 dots x 1024 lines
●Support to sRGB standard
●The height adjustable stand incorporated
●Ultra slim bezel incorporated
●The Portrait/Landscape display capability
●Attaching the "Adjustment Certificate" to describe the monitor color
characteristics individually.
Please contact your local dealer for assistance if any of the listed items are missing or
damaged.

* LCD Monitor * User's Manual (in the CD-ROM)
* Power Cord * Calibration software
"ColorNavigator" (in the CD-ROM)
* Signal Cable (FD-C35/FD-C39) * Setup Guide
* Signal Cable (FD-C16) * ColorNavigator Quick Reference
* EIZO USB Cable (MD-C93) * LIMITED WARRANTY
*EIZO LCD Utility Disk * Adjustment Certificate
* Please retain the packing materials for future transference.
Front

(1) ScreenManager®
(2) Main Power Switch
(3) Input Signal Selection Button
(4) Mode Button*1
(5) Auto Adjustment Button
(6) Enter Button
(7) Control Buttons (Up, Down, Left, Right)*2
(8) Power Button
(9) Power Indicator*3
Blue Operation
Yellow Power saving
Flashing yellow
(2 times for each) Power save mode Digital only
Flashing yellow slowly Power is off (Main power is on)
Off Power off
*1 Pressing the Mode button once allows you to display a FineContrast menu.
Pressing the Mode button more than once allows you to select a FineContrast
mode. (The main menu of ScreenManager and the FineContrast menu cannot be
displayed at the same time.)
*2 These buttons are changed to Up, Left, Right, Down in case of selecting
"Portrait" for <Orientation> of ScreenManager <Others>.
*3 Blue lighting, when the screen is displayed (Operation mode), is made to non-
light, see "Power Indicator "
Regarding the power indicator for the "Off Timer", see "3-4. Useful Functions".
Rear

(10) Height Adjustable Stand (Detachable)*4
(11) Security Lock Slot*5
(12) DVI-I Input Connector (SIGNAL 1, SIGNAL 2)
(13) USB Port (1 Upstream)
(14) USB Port (2 Downstream)
(15) Power Connector
*4 The LCD monitor has the capability of the Portrait/Landscape display. (The
panel pivots in the clockwise direction 90°.) The LCD monitor can be used with
an optional arm stand by removing the stand. (see "2-5. How to remove the Tilt
Stand").
*5 Allows for connection of a security cable. This lock supports Kensington's
MicroSaver security system.
For further information, please consult:
Kensington Technology Group
2855 Campus Drive, San Mateo, CA 94403 USA
Tel: [phone], x3348
Intl: 650-572-2700, x3348 / Fax: [phone]
http://www.kensington.com

Before connecting your monitor to the PC, change the display screen settings
(resolution and frequency) in accordance with the charts below.
* When your computer and display support VESA DDC, the suitable resolution
and the refresh rate are set by just plugging your display into the computer
without any manual settings.
Analog Input
Resolution Frequency Dot Clock Remarks
640 x 480 ~ 85 Hz
135 MHz
(Max.)
VGA, VESA
640 x 480 67 Hz Apple Macintosh
720 x 400 70 Hz VGA TEXT
720 x 480 60 Hz VESA
800 x 600 ~ 85 Hz VESA
832 x 624 75 Hz Apple Macintosh
1024 x 768 ~ 85 Hz VESA
1152 x 864 75 Hz VESA
1152 x 870 75 Hz Apple Macintosh
1152 x 900 ~ 76 Hz SUN WS
1280 x 960 60 Hz VESA
1280 x 960 75 Hz Apple Macintosh
1280 x1024 ~75 Hz VESA
1280 x1024 67 Hz SUN WS

Digital Input
The monitor supports the following resolutions only.
Resolution Frequency Dot Clock Remarks
640 x 480 60 Hz
108 MHz
(Max.)
VGA
720 x 400 70 Hz VGA TEXT
720 x 480 60 Hz VESA Safe Mode
800 x 600 60 Hz VESA
1024 x 768 60 Hz VESA
1280 x 1024 60 Hz VESA
* Be sure that the power switches of both the PC and the monitor are OFF.
1.Plug the signal cable into the connector at the rear of the monitor
and the other end of the cable into the video connector on the PC.
After connecting, secure the connection with the screw-in fasteners.
Analog Input

Signal Cable Connector PC
Signal Cable (FD-C16
enclosed) Video Output Connector D-Sub 15
pin
Input Connector
(monitor) / DVI
Standard graphics card
Macintosh G3 (Blue &
White) /Power Mac G4 (VGA)
Signal Cable (FD-C16
enclosed) + Macintosh
Adapter (Optional)
Video Output
Connector D-Sub 15
pin
Input Connector
(monitor) / DVI
Macintosh
Digital Input
Signal Cable Connector PC
Signal Cable (FD-C35/FD-
C39 enclosed) Video Output Connector / DVI
Input Connector
(monitor) / DVI
Digital graphics card
Power Mac G4 / G5 (DVI)
2.Plug the power cord into the power connector on the rear of the
monitor.
3.Lead the power cord and signal cable into the cable holder at rear
of the monitor.

* The cables are recommended to lead with slight sag for the smooth motion of the
stand and the Portrait/Landscape display.
4.Plug the other end of the power cord into a power outlet.
The monitor's power indicator will flash yellow slowly.
WARNING
Use the enclosed power cord and connect to the standard
power outlet of your country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may result in fire or electric shock.
The equipment must be connected to a grounded main outlet.
Not doing so may result in fire or electric shock.

5.Turn on the monitor's power button and then switch on the PC's
power.
The monitor's power indicator will light up (blue).
If an image does not appear, refer to the "6. TROUBLESHOOTING" for advice.
Whenever finished, turn off the PC and the monitor.
* When turning on the monitor, the kid of the input signal (Signal1 or 2/Analog or
Digital) is displayed for a few seconds on the right top corner of the screen.
* Adjust brightness of the screen depending on the brightness of your environment.
* Be sure to take adequate rests. A 10-minute rest period each hour is suggested.
When connecting a Power Mac G4 / G5 through ADC (Apple Display Connector),
change the input signal settings of monitor in advance to turn on the Power Mac.
* Be sure that the power switches of both the PC and the monitor are OFF.
1.Plug the signal cable into the connector at the rear of the monitor
and the other end of the cable into the video connector on the PC.
After connecting, secure the connection with the screw-in fasteners.
To input the Signal through ADC

Signal Cable Connector PC
Signal Cable (FD-C35/FD-
C39 enclosed) +ADC-DVI
display adapter
(commercially available)
Video Output
Connector / ADC
Input Connector
(monitor) / DVI
Power Mac G4 / G5 (ADC)
* ADC-DVI display adapter is required if the monitor connects to Power Mac G4 /
G5. The adapter is commercially available.
2.Plug the power cord into the power connector on the rear of the
monitor.
3.Lead the power cord and signal cable into the cable holder at rear
of the monitor.
* The cables are recommended to lead with slight sag for the smooth motion of the
stand and the Portrait/Landscape display.
