LC displays for medical applications
High-End 19" Color and
Gray Scale Flat Panel Display
SCD 19102 / SMD 19102
Instruction Manual
10/2011
A5E01588521A-004
Introduction
1
Safety notes
2
Description
3
Application planning
4
Assembly
5
Connecting
6
Commissioning
7
Operation
8
Service and maintenance
9
Troubleshooting
10
Technical specifications
11
Dimensional drawings
12
Accessories
13
Appendix
A
List of
abbreviations/acronyms
B

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the relevant information is not taken into account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of EIZO products
Note the following:
WARNING
EIZO products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of their respective owners. Please refer to the trademarks
listed in the appendix. The remaining trademarks in this publication may be trademarks whose use by third parties
for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
EIZO GmbH
Display Technologies
Siemensallee 84
76187 KARLSRUHE
GERMANY
A5E01588521A-004
Ⓟ 10/2011 Technical data subject to change
Copyright © EIZO GmbH 2011.
All rights reserved

SCD 19102 / SMD 19102
Instruction Manual, 10/2011, A5E01588521A-004 3
