Eizo FlexScan S1701 User manual

S1701 (P.1-P.5)
S1721 (P.6-P.10)
S1921 (P.26-P.30)
S1901 (P.16-P.20)
S
S
pecifications Sheet
Click a model name to see the specifications, outside view,
and other information of the model.
S1731 (P.11-P.15)
S1911 (P.21-P.25)
S1931 (P.31-P.35)

P.1
Specifications Sheet
Specifications (S1701)
LCD Panel 17-inch (43 cm) TFT color LCD with anti-glare hard coating
Viewing angle: Vertical 160°, Horizontal 160° (CR: 10 or more)
Dot Pitch 0.264 mm
Horizontal Scan Frequency Analog: 24.8 - 80 kHz
Digital: 31 - 64 kHz
Vertical Scan Frequency Analog: 50 - 75 Hz (Non-interlace)
Digital: 59 - 61 Hz (Non-interlace)
(VGATEXT: 69 - 71 Hz)
Resolution 1280 dots × 1024 lines
Max. Dot Clock Analog: 135 MHz
Digital: 108 MHz
Max. Display Colors 16.77 million colors
Display Area (H × V) 337.9 mm (13.30 inch) × 270.3 mm (10.64 inch)
Power Supply 100 - 120 VAC ±10% 50/60 Hz, 0.65 A
200 - 240 VAC ±10% 50 Hz, 0.4 A
Power Consumption *1Maximum (usually): 35W (speaker not working) / 38W (speaker working)
*2Maximum (usually): 35W
Power saving mode: 1 W or less (for single signal input with no line input connector
connected)
Input Signal Connectors DVI-D connector, D-sub mini 15-pin connector
Analog Input Signal (Sync) H/V Separate, TTL, positive/negative
Analog Input Signal (Video) Analog, positive (0.7 Vp-p/75 Ω)
Digital Signal Transmission
System TMDS (Single Link)
Video Signal Memory Analog signal: 26 (preset: 21)
Audio output*1Speaker output: 0.3W + 0.3W (16Ω, THD: 10% or less)
Headphone output: 2mW + 2mW
Plug & Play VESA DDC 2B/EDID structure 1.3
Dimensions (including stand)
(Width) × (Height) × (Depth)
mm (inch)
Tilt stand : 363(14.3) × 382(15) × 188(7.4)
Height adjustable stand : 363(14.3) × 389.5(15.3) - 489.5(19.3) × 205(8.1)
ArcSwing 2 stand : 363(14.3) × 280(11) - 406.5(16) × 200(7.9)
EZ-UP stand:
363mm(14.3) × 320-490mm(12.6-19.3) × 246.8-274.8mm(9.7-10.8)
Movable range Tilt Tilt stand : –5° - 30°
Height adjustable stand : 0° - 35°
ArcSwing 2 stand : –5° - 60°
EZ-UP stand : 0° - 25°
Swivel Tilt stand : –
Height adjustable stand : 172°
ArcSwing 2 stand : 172°
EZ-UP stand : 172°
Adjustable
height Tilt stand : – Height adjustable stand : 100 mm
ArcSwing 2 stand : 104 mm
EZ-UP stand : 170 mm
Rotation Tilt stand : –
Height adjustable stand : 90°
ArcSwing 2 stand : –
EZ-UP stand : –10° - 92°
*1 Model for built-in speaker
*2 Model for no mount speaker
S1701 1/5

P.2
Specifications Sheet
S1701 2/5
Dimensions (main unit)
(Width) × (Height) × (Depth)
mm (inch)
363(14.3) × 300(11.8) × 59(2.32)
Mass (including stand) Tilt stand : 4.7 kg (10.4 lbs.)
Height adjustable stand : 5.9 kg (13.0 lbs.)
ArcSwing 2 stand : 5.7 kg (12.6 lbs.)
EZ-UP stand : 7.5 kg (16.5 lbs.)
Mass (Main unit) 3.9 kg (8.6 lb)
Environmental Conditions Operating temperature: 0 °C - 35 °C (32 °F - 95 °F)
Storage temperature: –20 °C - 60 °C (–4 °F - 140 °F)
Relative humidity: 30% - 80% (no condensation)
Main default settings (factory settings)
BrightRegulator Disabled
FineContrast Mode Custom
Off Timer Disabled
Language English
Outside Dimensions (Tilt stand)
5°
30°
382(15)
188(7.4)
218(8.6)
82(3.23) 300(11.8)
272.2(10.7)
150(5.9)
339.8(13.4)
363(14.3)
36(1.42)
59(2.32) 100(3.9)
100(3.9)
unit : mm (inch)
Outside Dimensions (Height adjustable stand)
unit : mm (inch)
30
58 (2.28)
89.5~189.5 (3.52~7.5)
59(2.32)
36(1.42)
300(11.8)
272.2(10.7)
216(8.5) 172(6.8)
205(8.1)
320(12.6)
118(4.7)
100(3.9)100(3.9) 100(3.9)
65.1(2.56)
100(3.9)
131.5(5.2) 131.5(5.2)
339.8(13.4)
363(14.3)
389.5~489.5(15.3~19.3)
423(16.7)

P.3
Specifications Sheet
Outside Dimensions (ArcSwing 2 stand)
5
25
300(11.8)
272.2(10.7)
200(7.9)
100(3.9)
100(3.9)
339.8(13.4)
363(14.3)
59
(2.32)
36(1.42)
280~406.5(11~16)
294(11.6)
2.2(0.09) 280(11)
106.5(4.2)
unit : mm (inch)
Outside Dimensions (EZ-UP stand)
unit : mm (inch)
Ǿ240(9.4)
246.8(9.7)
100(3.9)
100(3.9)
28(1.1) 76.9(3.03)
170(6.7)
20(0.79)
57(2.24)
36(1.42)
59(2.32)
118.4(4.7)
25q
363(14.3)
340(13.4)
300(11.8)
500.2(19.7)
272.4(10.7)
158.5(6.2)
190(7.5) 340(13.4)
170(6.7)
131.5(5.2) 131.5(5.2)
334(13.1)
100(3.9)100(3.9)
6+.6
#FLWUVCDNGJGKIJV
S1701 3/5

P.4
Specifications Sheet
Connector Pin Assignment
• DVI-D connector
12345678
910 11 12 13 14 15 16
19 20 2117 18 22 23 24
Pin No. Signal Pin No. Signal Pin No. Signal
1 TMDS Data 2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data 2+ 10 TMDS Data1+ 18 TMDS Data0+
3 TMDS Data2/4 Shield 11 TMDS Data1/3 Shield 19 TMDS Data0/5 Shield
4 NC* 12 NC* 20 NC*
5 NC* 13 NC* 21 NC*
6 DDC Clock (SCL) 14 +5V Power 22 TMDS Clock shield
7 DDC Data (SDA) 15 Ground (return for +5V,
Hsync and Vsync) 23 TMDS Clock+
8 NC* 16 Hot Plug Detect 24 TMDS Clock-
(NC*: No Connection)
• D-sub mini 15-pin connector
51
3
42
876
9
10
12
1314
15 11
Pin No. Signal Pin No. Signal Pin No. Signal
1 Red 6 Red ground 11 Ground
2 Green 7 Green ground 12 Data (SDA)
3 Blue 8 Blue ground 13 H. Sync
4 Ground 9 NC* 14 V. Sync
5 NC* 10 Ground 15 Clock (SCL)
(NC*: No Connection)
Option List
Cleaning Kit EIZO ScreenCleaner
S1701 4/5

P.5
Specifications Sheet
Resolutions
●For analog signal input
Resolution Vertical Scan
Frequency Dot clock Remarks
640 × 400 56 Hz
135 MHz (Max.)
NEC PC-9801
640 × 400 70 Hz NEC PC-9821
640 × 480 67 Hz Apple Macintosh
640 × 480 less than 75 Hz VGA, VESA
720 × 400 70 Hz VGATEXT
800 × 600 less than 75 Hz VESA
832 × 624 75 Hz Apple Macintosh
1024 × 768 less than 75 Hz VESA
1152 × 864 75 Hz VESA
1152 × 870 75 Hz Apple Macintosh
1280 × 960 60 Hz VESA
1280 × 960 75 Hz Apple Macintosh
*1280 × 1024 less than 75 Hz VESA
●For digital signal input
Resolution Vertical Scan
Frequency Dot clock Remarks
640 × 480 60 Hz
108 MHz (Max.)
VGA
720 × 400 70 Hz VGATEXT
720 × 480 60 Hz VESA Safe Mode
800 × 600 60 Hz VESA
1024 × 768 60 Hz VESA
*1280 × 1024 60 Hz VESA
*Recommended resolution (Use this resolution.)
S1701 5/5
Return to Cover page

P.6
Specifications Sheet
Specifications (S1721)
LCD Panel 17-inch (43 cm) TFT color LCD with anti-glare hard coating
Viewing angle: Vertical 178°, Horizontal 178° (CR: 10 or more)
Dot Pitch 0.264 mm
Horizontal Scan Frequency Analog: 24.8 - 80 kHz (Automatic)
Digital: 31 - 64 kHz
Vertical Scan Frequency Analog: 50 - 75 Hz (Automatic)
Digital: 59 - 61 Hz
(VGATEXT: 69 - 71 Hz)
Resolution 1280 dots × 1024 lines
Max. Dot Clock Analog: 135 MHz
Digital: 108 MHz
Max. Display Colors 16.77 million colors
Display Area (H × V) 337.9 mm (13.30 inch) × 270.3 mm (10.64 inch)
Power Supply 100 - 120 VAC ±10% 50/60 Hz, 0.65 A
200 - 240 VAC ±10% 50 Hz, 0.4 A
Power Consumption *1Maximum (usually): 35W (speaker not working) / 38W (speaker working)
*2Maximum (usually): 35W
Power saving mode: 1 W or less (for single signal input with no line input connector
connected)
Input Signal Connectors DVI-D connector, D-sub mini 15-pin connector
Analog Input Signal (Sync) H/V Separate, TTL, positive/negative
Analog Input Signal (Video) Analog, positive (0.7 Vp-p/75 Ω)
Digital Signal Transmission
System TMDS (Single Link)
Video Signal Memory Analog signal: 26 (preset: 21)
Audio output*1Speaker output: 0.3W + 0.3W (16Ω, THD: 10% or less)
Headphone output: 2mW + 2mW
Plug & Play VESA DDC 2B/EDID structure 1.3
Dimensions (including stand)
(Width) × (Height) × (Depth)
mm (inch)
Tilt stand : 363(14.3) × 382(15) × 188(7.4)
Height adjustable stand : 363(14.3) × 389.5(15.3) - 489.5(19.3) × 205(8.1)
ArcSwing 2 stand : 363(14.3) × 280(11) - 406.5(16) × 200(7.9)
EZ-UP stand:
363mm(14.3) × 320-490mm(12.6-19.3) × 246.8-274.8mm(9.7-10.8)
Movable
range Tilt Tilt stand : –5° - 30° Height adjustable stand : 0° - 35°
ArcSwing 2 stand : –5° - 60°
EZ-UP stand : 0° - 25°
Swivel Tilt stand : –
Height adjustable stand : 172°
ArcSwing 2 stand : 172°
EZ-UP stand : 172°
Adjustable
height Tilt stand : – Height adjustable stand : 100 mm
ArcSwing 2 stand : 104 mm
EZ-UP stand : 170 mm
Rotation Tilt stand : –
Height adjustable stand : 90°
ArcSwing 2 stand : –
EZ-UP stand : –10° - 92°
*1 Model for built-in speaker
*2 Model for no mount speaker
S1721 1/5

P.7
Specifications Sheet
S1721 2/5
Dimensions (main unit)
(Width) × (Height) × (Depth)
mm (inch)
363(14.3) × 300(11.8) × 59(2.32)
Mass (including stand) Tilt stand : 4.7 kg (10.4 lbs.)
Height adjustable stand : 5.9 kg (13.0 lbs.)
ArcSwing 2 stand : 5.7 kg (12.6 lbs.)
EZ-UP stand : 7.5 kg (16.5 lbs.)
Mass (Main unit) 3.9 kg (8.6 lb)
Environmental Conditions Operating temperature: 0 °C - 35 °C (32 °F - 95 °F)
Storage temperature: –20 °C - 60 °C (–4 °F - 140 °F)
Relative humidity: 30% - 80% (no condensation)
USB*3 Standard Rev. 2.0 compliant
Port Upstream port × 1
Main default settings (factory settings)
BrightRegulator Disabled
FineContrast Mode Custom
Off Timer Disabled
Language English
Outside Dimensions (Tilt stand)
5°
30°
382(15)
188(7.4)
218(8.6)
82(3.23) 300(11.8)
272.2(10.7)
150(5.9)
339.8(13.4)
363(14.3)
36(1.42)
59(2.32) 100(3.9)
100(3.9)
unit : mm (inch)
Outside Dimensions (Height adjustable stand)
unit : mm (inch)
30
58 (2.28)
89.5~189.5 (3.52~7.5)
59(2.32)
36(1.42)
300(11.8)
272.2(10.7)
216(8.5) 172(6.8)
205(8.1)
320(12.6)
118(4.7)
100(3.9)100(3.9) 100(3.9)
65.1(2.56)
100(3.9)131.5(5.2) 131.5(5.2)
339.8(13.4)
363(14.3)
389.5~489.5(15.3~19.3)
423(16.7)
*3 Model with built-in USB port

P.8
Specifications Sheet
Outside Dimensions (ArcSwing 2 stand)
5
25
300(11.8)
272.2(10.7)
200(7.9)
100(3.9)
100(3.9)
339.8(13.4)
363(14.3)
59
(2.32)
36(1.42)
280~406.5(11~16)
294(11.6)
2.2(0.09) 280(11)
106.5(4.2)
unit : mm (inch)
Outside Dimensions (EZ-UP stand)
unit : mm (inch)
Ǿ240(9.4)
246.8(9.7)
100(3.9)
100(3.9)
28(1.1) 76.9(3.03)
170(6.7)
20(0.79)
57(2.24)
36(1.42)
59(2.32)
118.4(4.7)
25q
363(14.3)
340(13.4)
300(11.8)
500.2(19.7)
272.4(10.7)
158.5(6.2)
190(7.5) 340(13.4)
170(6.7)
131.5(5.2) 131.5(5.2)
334(13.1)
100(3.9)100(3.9)
6+.6
#FLWUVCDNGJGKIJV
S1721 3/5

P.9
Specifications Sheet
Connector Pin Assignment
• DVI-D connector
12345678
910 11 12 13 14 15 16
19 20 2117 18 22 23 24
Pin No. Signal Pin No. Signal Pin No. Signal
1 TMDS Data 2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data 2+ 10 TMDS Data1+ 18 TMDS Data0+
3 TMDS Data2/4 Shield 11 TMDS Data1/3 Shield 19 TMDS Data0/5 Shield
4 NC* 12 NC* 20 NC*
5 NC* 13 NC* 21 NC*
6 DDC Clock (SCL) 14 +5V Power 22 TMDS Clock shield
7 DDC Data (SDA) 15 Ground (return for +5V,
Hsync and Vsync) 23 TMDS Clock+
8 NC* 16 Hot Plug Detect 24 TMDS Clock-
(NC*: No Connection)
• D-sub mini 15-pin connector
51
3
42
876
9
10
12
1314
15 11
Pin No. Signal Pin No. Signal Pin No. Signal
1 Red 6 Red ground 11 Ground
2 Green 7 Green ground 12 Data (SDA)
3 Blue 8 Blue ground 13 H. Sync
4 Ground 9 NC* 14 V. Sync
5 NC* 10 Ground 15 Clock (SCL)
(NC*: No Connection)
• USB port (Model with built-in USB port)
Upstream
Contact No. Signal Remarks
1 VCC Cable power
2 – Data Serial data
3 + Data Serial data
4 Ground Cable ground
Option List
Cleaning Kit EIZO ScreenCleaner
S1721 4/5

P.10
Specifications Sheet
Resolutions
●For analog signal input
Resolution Vertical Scan
Frequency Dot clock Remarks
640 × 400 56 Hz
135 MHz (Max.)
NEC PC-9801
640 × 400 70 Hz NEC PC-9821
640 × 480 67 Hz Apple Macintosh
640 × 480 less than 75 Hz VGA, VESA
720 × 400 70 Hz VGATEXT
800 × 600 less than 75 Hz VESA
832 × 624 75 Hz Apple Macintosh
1024 × 768 less than 75 Hz VESA
1152 × 864 75 Hz VESA
1152 × 870 75 Hz Apple Macintosh
1280 × 960 60 Hz VESA
1280 × 960 75 Hz Apple Macintosh
*1280 × 1024 less than 75 Hz VESA
●For digital signal input
Resolution Vertical Scan
Frequency Dot clock Remarks
640 × 480 60 Hz
108 MHz (Max.)
VGA
720 × 400 70 Hz VGATEXT
720 × 480 60 Hz VESA Safe Mode
800 × 600 60 Hz VESA
1024 × 768 60 Hz VESA
*1280 × 1024 60 Hz VESA
*Recommended resolution (Use this resolution.)
S1721 5/5
Return to Cover page

P.11
Specifications Sheet
Specifications (S1731)
LCD Panel 17-inch (43 cm) TFT color LCD with anti-glare hard coating
Viewing angle: Vertical 178°, Horizontal 178° (CR: 10 or more)
Dot Pitch 0.264 mm
Horizontal Scan Frequency Analog: 24.8 - 80 kHz (Automatic)
Digital: 31 - 64 kHz
Vertical Scan Frequency Analog: 50 - 75 Hz (Automatic)
Digital: 59 - 61 Hz
(VGATEXT: 69 - 71 Hz)
Resolution 1280 dots × 1024 lines
Max. Dot Clock Analog: 135 MHz
Digital: 108 MHz
Max. Display Colors 16.77 million colors
Display Area (H × V) 337.9 mm (13.30 inch) × 270.3 mm (10.64 inch)
Power Supply 100 - 120 VAC ±10% 50/60 Hz, 0.7 A
200 - 240 VAC ±10% 50 Hz, 0.4 A
Power Consumption *1Maximum (usually): 39W (speaker not working) / 42W (speaker working)
*2Maximum (usually): 39W
Power saving mode: 1 W or less (for single signal input with no USB device or line
input connector connected)
Input Signal Connectors DVI-D connector, D-sub mini 15-pin connector
Analog Input Signal (Sync) H/V Separate, TTL, positive/negative
Analog Input Signal (Video) Analog, positive (0.7 Vp-p/75 Ω)
Digital Signal Transmission
System TMDS (Single Link)
Video Signal Memory Analog signal: 26 (preset: 21)
Audio output*1Speaker output: 0.3W + 0.3W (16Ω, THD: 10% or less)
Headphone output: 2mW + 2mW
Plug & Play VESA DDC 2B/EDID structure 1.3
Dimensions (including stand)
(Width) × (Height) × (Depth)
mm (inch)
Tilt stand : 363(14.3) × 382(15) × 188(7.4)
Height adjustable stand : 363(14.3) × 389.5(15.3) - 489.5(19.3) × 205(8.1)
ArcSwing 2 stand : 363(14.3) × 280(11) - 406.5(16) × 200(7.9)
EZ-UP stand:
363mm(14.3) × 320-490mm(12.6-19.3) × 246.8-274.8mm(9.7-10.8)
Movable
range Tilt Tilt stand : –5° - 30° Height adjustable stand : 0° - 35°
ArcSwing 2 stand : –5° - 60°
EZ-UP stand : 0° - 25°
Swivel Tilt stand : –
Height adjustable stand : 172°
ArcSwing 2 stand : 172°
EZ-UP stand : 172°
Adjustable
height Tilt stand : – Height adjustable stand : 100 mm
ArcSwing 2 stand : 104 mm
EZ-UP stand : 170 mm
Rotation Tilt stand : –
Height adjustable stand : 90°
ArcSwing 2 stand : –
EZ-UP stand : –10° - 92°
*1 Model for built-in speaker
*2 Model for no mount speaker
S1731 1/5

P.12
Specifications Sheet
S1731 2/5
Dimensions (main unit)
(Width) × (Height) × (Depth)
mm (inch)
363(14.3) × 300(11.8) × 59(2.32)
Mass (including stand) Tilt stand : 4.7 kg (10.4 lbs.)
Height adjustable stand : 5.9 kg (13.0 lbs.)
ArcSwing 2 stand : 5.7 kg (12.6 lbs.)
EZ-UP stand : 7.5 kg (16.5 lbs.)
Mass (Main unit) 3.9 kg (8.6 lb)
Environmental Conditions Operating temperature: 0 °C - 35 °C (32 °F - 95 °F)
Storage temperature: –20 °C - 60 °C (-4 °F - 140 °F)
Relative humidity: 30% - 80% (no condensation)
USB*3 Standard Rev. 2.0 compliant
Port Upstream port × 1
Main default settings (factory settings)
BrightRegulator Disabled
FineContrast Mode Custom
Off Timer Disabled
Language English
Outside Dimensions (Tilt stand)
5°
30°
382(15)
188(7.4)
218(8.6)
82(3.23) 300(11.8)
272.2(10.7)
150(5.9)
339.8(13.4)
363(14.3)
36(1.42)
59(2.32) 100(3.9)
100(3.9)
unit : mm (inch)
Outside Dimensions (Height adjustable stand) unit : mm (inch)
30
58 (2.28)
89.5~189.5 (3.52~7.5)
59(2.32)
36(1.42)
300(11.8)
272.2(10.7)
216(8.5) 172(6.8)
205(8.1)
320(12.6)
118(4.7)
100(3.9)100(3.9) 100(3.9)
65.1(2.56)
100(3.9)131.5(5.2) 131.5(5.2)
339.8(13.4)
363(14.3)
389.5~489.5(15.3~19.3)
423(16.7)
*3 Model with built-in USB port

P.13
Specifications Sheet
Outside Dimensions (ArcSwing 2 stand)
5
25
300(11.8)
272.2(10.7)
200(7.9)
100(3.9)
100(3.9)
339.8(13.4)
363(14.3)
59
(2.32)
36(1.42)
280~406.5(11~16)
294(11.6)
2.2(0.09) 280(11)
106.5(4.2)
unit : mm (inch)
Outside Dimensions (EZ-UP stand)
unit : mm (inch)
Ǿ240(9.4)
246.8(9.7)
100(3.9)
100(3.9)
28(1.1) 76.9(3.03)
170(6.7)
20(0.79)
57(2.24)
36(1.42)
59(2.32)
118.4(4.7)
25q
363(14.3)
340(13.4)
300(11.8)
500.2(19.7)
272.4(10.7)
158.5(6.2)
190(7.5) 340(13.4)
170(6.7)
131.5(5.2) 131.5(5.2)
334(13.1)
100(3.9)100(3.9)
6+.6
#FLWUVCDNGJGKIJV
S1731 3/5

P.14
Specifications Sheet
Connector Pin Assignment
• DVI-D connector
12345678
910 11 12 13 14 15 16
19 20 21
17 18 22 23 24
Pin No. Signal Pin No. Signal Pin No. Signal
1 TMDS Data 2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data 2+ 10 TMDS Data1+ 18 TMDS Data0+
3 TMDS Data2/4 Shield 11 TMDS Data1/3 Shield 19 TMDS Data0/5 Shield
4 NC* 12 NC* 20 NC*
5 NC* 13 NC* 21 NC*
6 DDC Clock (SCL) 14 +5V Power 22 TMDS Clock shield
7 DDC Data (SDA) 15 Ground (return for +5V,
Hsync and Vsync) 23 TMDS Clock+
8 NC* 16 Hot Plug Detect 24 TMDS Clock-
(NC*: No Connection)
• D-sub mini 15-pin connector
51
3
42
876
9
10
12
1314
15 11
Pin No. Signal Pin No. Signal Pin No. Signal
1 Red 6 Red ground 11 Ground
2 Green 7 Green ground 12 Data (SDA)
3 Blue 8 Blue ground 13 H. Sync
4 Ground 9 NC* 14 V. Sync
5 NC* 10 Ground 15 Clock (SCL)
(NC*: No Connection)
• USB port (Model with built-in USB port)
Upstream
Contact No. Signal Remarks
1 VCC Cable power
2 – Data Serial data
3 + Data Serial data
4 Ground Cable ground
Option List
Cleaning Kit EIZO ScreenCleaner
S1731 4/5

P.15
Specifications Sheet
Resolutions
●For analog signal input
Resolution Vertical Scan
Frequency Dot clock Remarks
640 × 400 56 Hz
135 MHz (Max.)
NEC PC-9801
640 × 400 70 Hz NEC PC-9821
640 × 480 67 Hz Apple Macintosh
640 × 480 less than 75 Hz VGA, VESA
720 × 400 70 Hz VGATEXT
800 × 600 less than 75 Hz VESA
832 × 624 75 Hz Apple Macintosh
1024 × 768 less than 75 Hz VESA
1152 × 864 75 Hz VESA
1152 × 870 75 Hz Apple Macintosh
1280 × 960 60 Hz VESA
1280 × 960 75 Hz Apple Macintosh
*1280 × 1024 less than 75 Hz VESA
●For digital signal input
Resolution Vertical Scan
Frequency Dot clock Remarks
640 × 480 60 Hz
108 MHz (Max.)
VGA
720 × 400 70 Hz VGATEXT
720 × 480 60 Hz VESA Safe Mode
800 × 600 60 Hz VESA
1024 × 768 60 Hz VESA
*1280 × 1024 60 Hz VESA
*Recommended resolution (Use this resolution.)
S1731 5/5
Return to Cover page

P.16
Specifications Sheet
Specifications (S1901)
LCD Panel 19-inch (48 cm) TFT color LCD with anti-glare hard coating
Viewing angle: Vertical 160°, Horizontal 160° (CR: 10 or more)
Dot Pitch 0.294 mm
Horizontal Scan Frequency Analog: 24.8 - 80 kHz
Digital: 31 - 64 kHz
Vertical Scan Frequency Analog: 50 - 75 Hz (Non-interlace)
Digital: 59 - 61 Hz (Non-interlace)
(VGATEXT: 69 - 71 Hz)
Resolution 1280 dots × 1024 lines
Max. Dot Clock Analog: 135 MHz
Digital: 108 MHz
Max. Display Colors 16.20 million colors
Display Area (H × V) 376.3 mm (14.81 inch) × 301.0 mm (11.85 inch)
Power Supply 100 - 120 VAC ±10% 50/60 Hz, 0.8 A
200 - 240 VAC ±10% 50 Hz, 0.45 A
Power Consumption *1Maximum (usually): 42W (speaker not working) / 45W (speaker working)
*2Maximum (usually): 42W
Power saving mode: 1 W or less (for single signal input with no line input connector
connected)
Input Signal Connectors DVI-D connector, D-sub mini 15-pin connector
Analog Input Signal (Sync) H/V Separate, TTL, positive/negative
Analog Input Signal (Video) Analog, positive (0.7 Vp-p/75 Ω)
Digital Signal Transmission
System TMDS (Single Link)
Video Signal Memory Analog signal: 26 (preset: 21)
Audio output*1Speaker output: 0.3W + 0.3W (16Ω, THD: 10% or less)
Headphone output: 2mW + 2mW
Plug & Play VESA DDC 2B/EDID structure 1.3
Dimensions (including stand)
(Width) × (Height) × (Depth)
mm (inch)
Tilt stand : 405(15.9) × 416(16.4) × 205(8.1)
Height adjustable stand : 405(15.9) × 406.5(16) - 506.5(19.9) × 205(8.1)
ArcSwing 2 stand : 405(15.9) × 288(11.39) - 423.5(16.69) × 200(7.9)
EZ-UP stand:
405mm(15.9) × 347.7-507mm(13.7-20.0) × 246.8-277.6mm(9.7-10.9)
Movable range Tilt Tilt stand : –5° - 30°
Height adjustable stand : 0° - 35°
ArcSwing 2 stand : –5° - 60°
EZ-UP stand : 0° - 25°
Swivel Tilt stand : –
Height adjustable stand : 172°
ArcSwing 2 stand : 172°
EZ-UP stand : 172°
Adjustable
height Tilt stand : – Height adjustable stand : 100 mm
ArcSwing 2 stand : 104 mm
EZ-UP stand : 154 mm (Tilt : 0°)
Rotation Tilt stand : –
Height adjustable stand : 90°
ArcSwing 2 stand : –
EZ-UP stand : –10° - 92°
*1 Model for built-in speaker
*2 Model for no mount speaker
S1901 1/5

P.17
Specifications Sheet
S1901 2/5
Dimensions (main unit)
(Width) × (Height) × (Depth)
mm (inch)
405(15.9) × 334(13.1) × 61.5(2.42)
Mass (including stand) Tilt stand : 6.0 kg (13.2 lbs.)
Height adjustable stand : 7.2 kg (15.9 lbs.)
ArcSwing 2 stand : 7.0 kg (15.4 lbs.)
EZ-UP stand : 8.8 kg (19.4 lbs.)
Mass (Main unit) 5.2 kg (11.5 lb)
Environmental Conditions Operating temperature: 0 °C - 35 °C (32 °F - 95 °F)
Storage temperature: –20 °C - 60 °C (-4 °F - 140 °F)
Relative humidity: 30% - 80% (no condensation)
Main default settings (factory settings)
BrightRegulator Disabled
FineContrast Mode Custom
Off Timer Disabled
Language English
Outside Dimensions (Tilt stand)
5°
30°
416(16.4)
82(3.23) 334(13.1)
303(11.9)
164(6.5)
378.4(14.9)
405(15.9)
205(8.1)
241(9.5)
38.5(1.52)
61.5
(2.42) 100(3.9)
100(3.9)
unit : mm (inch)
Outside Dimensions (Height adjustable stand)
unit : mm (inch)
30
303(11.9)
37(1.46)
334(13.1)
406.5~506.5(16~19.9)
72.5~172.5(2.85~6.8)
439(17.3)
61.5(2.42)
38.5(1.52)
172(6.8)
131.8(5.2)
117(4.8)
117(4.8) 100(3.9)
65.1(2.56)
100(3.9)
152.5(6) 152.5(6)
378.4(14.9)
405(15.9)
320(12.6)
205(8.1)
226(8.9)

P.18
Specifications Sheet
Outside Dimensions (ArcSwing 2 stand)
5
25
334(13.1)
303(11.9)
100(3.9)
100(3.9)
378.4(14.9)
405(15.9)
288~423.5(11.3~16.7)
289(11.4)
310(12.2)
2.2(0.09)
38.5(1.52)
61.5(2.42)
89(3.5)
200(7.9)
unit : mm (inch)
Outside Dimensions (EZ-UP stand)
unit : mm (inch)
S1901 3/5

P.19
Specifications Sheet
Connector Pin Assignment
• DVI-D connector
12345678
910 11 12 13 14 15 16
19 20 21
17 18 22 23 24
Pin No. Signal Pin No. Signal Pin No. Signal
1 TMDS Data 2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data 2+ 10 TMDS Data1+ 18 TMDS Data0+
3 TMDS Data2/4 Shield 11 TMDS Data1/3 Shield 19 TMDS Data0/5 Shield
4 NC* 12 NC* 20 NC*
5 NC* 13 NC* 21 NC*
6 DDC Clock (SCL) 14 +5V Power 22 TMDS Clock shield
7 DDC Data (SDA) 15 Ground (return for +5V,
Hsync and Vsync) 23 TMDS Clock+
8 NC* 16 Hot Plug Detect 24 TMDS Clock-
(NC*: No Connection)
• D-sub mini 15-pin connector
51
3
42
876
9
10
12
1314
15 11
Pin No. Signal Pin No. Signal Pin No. Signal
1 Red 6 Red ground 11 Ground
2 Green 7 Green ground 12 Data (SDA)
3 Blue 8 Blue ground 13 H. Sync
4 Ground 9 NC* 14 V. Sync
5 NC* 10 Ground 15 Clock (SCL)
(NC*: No Connection)
Option List
Cleaning Kit EIZO ScreenCleaner
S1901 4/5
