Eizo DuraVision FDF4627W-IP User manual

Color LCD Monitor
Installation Manual
Important
Please read this “Installation Manual”, the “Instruction Manual” and
the “Setup Manual” carefully to familiarize yourself with safe and
effective usage.
• For the latest product information including the “Installation Manual”,
refer to our web site: http://www.eizoglobal.com
Software Version 4.3
Thank you for purchasing our Color LCD Monitor.

2
About this manual
Setup Manual Describes precautions and setup processes from network camera
connection to camera image display.
Instruction Manual Describes operation of network cameras and live image screen
menus, etc.
Installation Manual
(this manual)
Describes network camera registration and function setup, monitor
system setup, etc.
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.

3
Notice for this monitor
Notice for this monitor
About the Usage of This Product
This product is suited for displaying surveillance camera images.
This product has been adjusted specically for use in the region to which it was originally shipped. If the
product is used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
• Power cords provided with the product
• Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
About the LCD Panel
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may
appear on the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994 % or higher.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and
maintain a stable display.
When the screen image is changed after displaying the same image for extended periods of time, an
afterimage may appear. Use the screen saver or power save function to avoid displaying the same image for
extended periods of time. Depending on the image, an afterimage may appear even if it was displayed for
a short period of time. To remove such a phenomenon, change the image or keep the power turned off for
several hours.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker,
please contact your local EIZO representative.
Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such
as interference patterns, etc. If pressure is continuously applied to the LCD panel surface, the liquid crystal
may deteriorate or the LCD panel may be damaged. (If the pressure marks remain on the panel, leave the
monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD
panel. Do not attempt to brush with tissues as this may scratch the panel.

4Notice for this monitor
About the Installation
When installing the monitor in a rack, ensure that there is adequate space around the sides, back and top of
the monitor.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew
condensation may occur on the interior and exterior surfaces of the monitor. In that case, do not turn the
monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the
monitor.
If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to
the composition of the rubber. Check the desk surface before use.
About the Maintenance
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (For
details, refer to the Instruction Manual.).
Disclaimer
EIZO shall not be liable in any way to any person whatsoever for the occurrences described below.
1. Any incidental, special or consequential disruption or damage directly or indirectly arising in
connection with this product.
2. Any loss, damage or cost resulting from misuse or neglect.
3. Any malfunction or failure occurring after unauthorized disassembly, repair or alteration regardless
of its cause.
4. Any inconvenience, loss or damage caused by the inability to display images due to any reason or
cause including malfunctions or failures in this product.
5. Any failure or consequential inconvenience, loss or damage due to malfunction or failure of a
combined system that comprises this product and any third party products.
6. Any consequential claim for compensation or complaint based on privacy violation or any other
reason by individuals or entities recorded in the surveillance images which are made public for/by
whatever cause or used.
7. Any loss of registered data for whatever cause.
While this product displays camera surveillance images, the use of this product alone does not directly
prevent crime.
Cautions for Network Use
Because this product is used by connecting to networks, the following risks apply
1. Leakage of information through this product.
2. Unauthorized operation of this product by a malicious third party.
3. Interference or suspension of the use of this product by a malicious third party.
In order to prevent the above described damage, it is the user’s responsibility to implement adequate
network security measures including the measures described below.
• Use this product with a safety-ensured network by using a rewall or other network security
systems.
• Change the administrator password periodically.

5
CONTENTS
CONTENTS
Notice for this monitor ......................................... 3
Disclaimer ................................................................. 4
Cautions for Network Use ....................................... 4
CONTENTS............................................................. 5
Chapter 1 Product overview.............................. 6
1-1. Features ......................................................... 6
●LCD panel ....................................................... 6
●Operation ........................................................ 6
●Communication with network cameras........... 6
●Compatible with Several Different Kinds
of Network Cameras ....................................... 6
●Equipped with a Function that Improves
the Quality of Surveillance Camera Images ... 6
●System Control................................................ 7
●Security ........................................................... 7
●Support............................................................ 7
1-2. SystemConguration .................................. 7
1-3. Supported Network Cameras...................... 8
Chapter2 Conguringfromthemonitor
screen ................................................ 9
2-1. BeforeConguration.................................... 9
2-2. Setting Screen..............................................10
●Basic operations.............................................10
2-3. Setting Network Cameras...........................12
●
To automatically discover network cameras ...12
●To manually register network cameras ..........15
●To set network camera functions ...................17
2-4. Setting Display Positions of Camera
Images.......................................................... 24
2-5. Setting Visibility Optimizer Function ....... 25
2-6. ConguringSystemSettings .................... 26
2-7. Setting User Information............................ 36
●To register new user information....................37
●To change user information .......................... 38
●To delete user information............................. 39
●Conguring Auto Login Settings ................... 40
2-8. Displaying Operation Logs.........................41
●To display log data .........................................41
●To save log data .............................................42
Chapter 3 ConguringfromaWebBrowser ... 43
3-1. BeforeConguration.................................. 43
3-2. WebControlScreen.................................... 44
●Basic Operations........................................... 44
3-3. Basic Information ....................................... 45
●System Information ....................................... 45
●System Status ............................................... 45
●Camera and Display Position / Date
and TimeSettings / Network Settings /
Communication Settings............................... 46
3-4. Setting Network Cameras...........................47
●To automatically detect cameras ...................47
●Load camera information .............................. 49
●Manual Registration of Cameras /
Changing Camera Information...................... 50
●Deleting Camera Information........................ 53
●Save Camera Information ............................. 53
3-5. Setting Display Positions of Camera
Images.......................................................... 54
●Setting Display Positions .............................. 55
●Other Display Settings .................................. 56
●Setting Visibility Optimizer function .............. 57
●Custom Screen Settings ............................... 58
3-6. ConguringSystemSettings .................... 59
●Date and Time............................................... 59
●Network Settings........................................... 62
●Communication Settings............................... 63
●Other System Settings .................................. 64
●Maintenance.................................................. 65
3-7. Setting User Information.............................71
●Adding User Information ................................71
●Changing User Information........................... 72
●To delete user information............................. 72
●Conguring Auto Login Settings ....................73
3-8. Displaying Operation Logs.........................74
●Displaying logs ...............................................74
●Displaying the system log ..............................74
3-9. Setting the Live Image Screen ...................75
●Live Image Screen Settings...........................76
●System Status Settings................................. 77
Chapter 4 Troubleshooting.............................. 78
4-1. Imaging problems....................................... 78
4-2. Setting Problems ........................................ 80
Chapter 5 Reference ........................................ 81
5-1. List of setting items.....................................81
Chapter 6 Glossary .......................................... 87
Appendix.............................................................. 89
Trademark ............................................................... 89
License .................................................................... 90
LIMITEDWARRANTY.......................................... 91
Recycling Information ........................................ 92

6Chapter 1 Product overview
Chapter 1 Product overview
This color LCD monitor can display images from up to 16 network cameras*1.
This manual describes network camera setup, monitor system setup and specications, etc.
For information on setup, refer to “Chapter 2 Conguring from the monitor screen” (page 9) and “Chapter
3 Conguring from a Web Browser” (page 43).
*1 A type of camera which converts images into network signals and transmits the signals.
1-1. Features
●LCD panel
• 46.0″ wide format LCD
• Supports a resolution of 1920 × 1080
• LCD panel with wide eld of view adopted
VA LCD panel with 178° horizontal and vertical viewing angles
• LED backlight LCD panel
No mercury, a hazardous substance, is used.
●Operation
• Can be operated remotely with the remote control.
• Equipped with Easy Setup function
Necessary settings for setup can be performed with a wizard.
●Communication with network cameras
• Receives input video signals from network cameras.
- Compatible with video compression formats H.264 and MJPEG.
- Up to 16 network cameras can be registered and displayed.
- Images from multiple network cameras can be displayed simultaneously (1- / 3- / 4- / 8- / 9- /
16- / custom screen display).
- Network cameras can be controlled from the monitor.
- Unicast and Multicast video signals can be displayed.
- Camera image display positions can be switched while displaying the images.
●Compatible with Several Different Kinds of Network Cameras
• Compatible with ONVIF Prole S
• Panasonic and AXIS network cameras can be set using the manufacturer specic protocols.
(When connecting Panasonic or AXIS network cameras)
●Equipped with a Function that Improves the Quality of Surveillance
Camera Images
• Provides display modes (DAY / NIGHT) suitable for surveillance camera images
• Equipped with EIZO original “Visibility Optimizer” technology
- Outline Enhancer function
This function adjusts the perceived resolution of the images so that the blurs are reduced and images are
displayed vividly and clearly.
- Low-light Correction function
This function analyzes the image and corrects the brightness for each pixel to make dark area of images
visible.
- Noise Reduction function
This function reduces the amount of block noise that occurs due to video compression.

7
Chapter 1 Product overview
●System Control
• You can register a network camera and congure the live image screen using your web browser
• Possible to save and load the settings data
You can save the settings data to a USB storage device or to a PC and load the data.
●Security
• Alert display
You can have an alert displayed on the live image screen when communication with a network camera is lost.
●Support
• A 2-year long-term warranty for 24-hour continuous use
1-2. SystemConguration
Communicating with network cameras, it can display video on the monitor, and operate cameras.
FDF4627W-IP
Ethernet
Network camera*1
Network hub
HDMI device*2
(Network video recorder etc.)
*1 Up to 16 network cameras can be registered.
*2 Use an HDMI device (e.g. network video recorder) if necessary.

8Chapter 1 Product overview
1-3. Supported Network Cameras
This product supports the following network cameras:
• Panasonic i-pro series network cameras
• AXIS network camera
• ONVIF Prole S-compatible network cameras
Attention
• Supported network cameras vary depending on the monitor’s software version. Check the software version of
the monitor you are using, then check our website (http://www.eizoglobal.com) for details on supported network
cameras. For information on how to check the software version, refer to “2-6. Conguring System Settings” (page
26).
• For installation and settings of network cameras, also check the network camera’s manual.
Note
• You can access network camera images by specifying the URI to verity the network camera connections. For
details, see “Manual Registration of Cameras / Changing Camera Information” (page 50).

9
Chapter 2 Conguring from the monitor screen
Chapter 2 Conguringfromthemonitor
screen
You can congure and operate network cameras from the monitor screen. To congure from your web
browser, see “Chapter 3 Conguring from a Web Browser” (page 43). Operating and setting the monitor
can be implemented by using either the Remote Control, or a USB mouse. To use a USB mouse, connect
the mouse to the USB downstream port at the back of the monitor.
2-1. BeforeConguration
To congure from the monitor screen, you need to be logged in to the system.
Conguration of this product is allowed only by ADMIN level users.
Be sure to log in to the system with a user account of this level.
Procedure
1. Press on the front of the monitor or on the remote control.
The power indicator lights up blue and the live image screen is displayed.
(For information on the live image screen, refer to the Instruction Manual.
2. Select (Login) under “System”.
The login screen is displayed.
5
2
3
4
3. Enter a username and a password.
4. Select “Login”.
The display changes back to the live image screen.
5. Select (Setting).
The setting screen is displayed.
(For information on the setting screen, see “2-2. Setting Screen” (page 10).
Note
• See “Entering characters” (page 11) for the character entry method.
• The following user information is set by default:
- Username: “admin”
- Password: “admin”
- User Level: “ADMIN”
• For information on user settings, see “2-7. Setting User Information” (page 36).
• It is recommended that you log out after completing the setup, so as to prevent a third party from operating
the network camera or altering the settings.
• When the Auto Login settings are congured, you can log in to the system without the username and
password. For details, see “Conguring Auto Login Settings” (page 40).

10 Chapter 2 Conguring from the monitor screen
Attention
• When the monitor power is turned off while the user is logged in, the user is logged out from the system
automatically. In such a case, you cannot display the web interface in your web browser.
2-2. Setting Screen
The setting screen is used for various settings such as network camera registration and monitor system
settings.
●Basic operations
List of setting items The setting screen of the selected item is displayed.
Item Operation method
To select an item Press the / / / buttons.
To conrm a selected item Press .
To change a setting With setting buttons:
Press . (Excluding zoom in / out and position adjustment)
With list box:
1. Press .
The list box is highlighted in green.
2. Select the setting with or .
3. Press .
To return to the previous menu level Press .
Note
• When canceling a setting change in process, press .
To exit the setting screen 1. Select “Exit” from the list of setting items with .
2. Press .
Attention
• While settings are being applied (registered) to the system, a “Setting” (“Registering”) message is displayed.
Do not turn off the monitor while the message is displayed. Otherwise, setting information may be lost.

11
Chapter 2 Conguring from the monitor screen
Entering characters
1. Press .
The text eld is highlighted in green.
2. Press the number buttons ( 0 to 9 ).
Press a button consecutively to change over to the character next in order. For the order of character entry,
refer to the table shown below.
Button Input characters
00-_:. / (space)
11
2a b c AB C 2
3d e f D E F 3
4g h i GHI 4
5jklJK L 5
6m n o M N O6
7pqr s P Q R S 7
8t u v T U V 8
9wxyzWX Y Z 9
To enter a new character, press .
To delete a character, press .
3. Press .
Note
• Entering network addresses
Network address text elds are separated by [.] (a period mark).
- When a three-digit number is entered, the cursor automatically moves to the next entry position.
- When entering a two-digit or one-digit number, press to move to the next entry position.
• When using a USB mouse
- When you enter a period “.”, the cursor moves to the next entry position.
- To enter characters, click “Keyboard” on the character entry screen. Then click the keys on the displayed
keyboard to enter characters.
Attention
• The remote control cannot be used to select the character entry screen keyboard.

12 Chapter 2 Conguring from the monitor screen
2-3. Setting Network Cameras
●To automatically discover network cameras
Discover network cameras on the network automatically and register them to the system.
This procedure is for setting network cameras connected after performing “Easy Setup” upon initial
startup of the monitor.
Attention
• Only the network cameras installed in the same subnet as the monitor are detected. If a network camera is
installed in a different subnet, the camera must be registered manually (see “To manually register network
cameras” (page 15)).
• When network cameras are not detected by automatic discovery, see “Chapter 4 Troubleshooting” (page
78).
• For information on “Easy Setup”, refer to the Setup Manual.
Procedure
1. Select “Auto Discovery”.
2. Select “Camera Discovery” and press .
3. Select the camera type using or , then press .
Displays registered network cameras.
4. Select “Start” and press .
1
24
The camera user authentication screen is displayed.
5. Enter the “Username” and “Password” of the user who has administrator’s rights, specied in the
network camera.
The following values are entered as the default settings. Change the settings if necessary. Please contact
your system administrator for the username and password.
- Username: “admin”
- Password: “12345”

13
Chapter 2 Conguring from the monitor screen
6. Select “OK” and press .
5
6
Automatic discovery is started and a “Searching” message is displayed. When the search is completed, the
discovered network cameras are added to the list. A subsequent result is displayed in the detection results
for camera discovery.
Discovery Results Description
Blank When there is no information update for the registered network cameras,
or one is not connected
New When there is an unregistered network camera, or information was
updated for a registered network camera
Duplicate When there is a network camera with a duplicate IP address

14 Chapter 2 Conguring from the monitor screen
7. Select “Apply”.
The setting complete screen is displayed. Select “OK”.
7
Note
Panasonic network camera
• The settings of the newly detected network camera can be changed.
Select the network camera whose settings you want to change at “Camera Name” and then select
“Settings”. Congure the items on the displayed setting screen. The items that can be set differ depending
on the network camera.
• When registered automatically, stream and channel for accessing the network camera are automatically
set to the following values. You can change the settings in “Manual Registration” (refer to “To manually
register network cameras” (page 15).) Please contact your system administrator for your username and
password to access the network camera.
- Stream: “2”
- Channel: “1”
- RS485 PTZ Control: “Off”*1
*1 Only set “RS485 PTZ Control” to “On” when connecting an external device to the network
camera using a RS485 cable.
AXIS network camera
• When executing automatic detection with an incorrect user name or password, “------” is displayed for the
model name.
• When a detected IP address is a duplicate of a registered network camera, but the username and
password are correct, ‘Model Name – MAC Address’ is displayed, and “------” is displayed for the model
name.

15
Chapter 2 Conguring from the monitor screen
●To manually register network cameras
Register network cameras manually for cases described below.
• When a network camera is installed in a subnet differing from the subnet of the monitor
• When settings such as network settings of a registered network camera have been changed
• When registering a video encoder which supports multiple channels
Procedure
1. Select “Manual Registration”.
A list of network cameras currently registered is displayed.
Registered cameras are displayed.
1
2
3
2. Select the network camera to congure at “Camera Name”.
When registering a network camera installed in a subnet differing from the subnet of the monitor, select an
available number (with no network camera registered). For a network camera that is already registered,
select the network camera of which to change settings.
3. Select “Settings”.
The network camera setting screen is displayed.

16 Chapter 2 Conguring from the monitor screen
4. Congure the items.
For setting details, contact your system administrator.
4
5
Item Detail Setting range
Camera Name Enter the camera name. When selecting ‘Execute’
for ‘Obtain Camera Name,’ the camera name is
automatically obtained from the network camera.
• Panasonic network camera: Camera Name
• AXIS network camera: Camera Name
• Network camera compatible with the “ONVIF”
protocol: Camera model number, manufacturer
name, etc.
Alphanumeric characters
(up to 24 characters)
IP Address Enter the network camera IP address. 0.0.0.0 to 255.255.255.255
HTTP Port Enter the network camera HTTP port number. 1 to 65535
Protocol Select the protocol for controlling the camera. Panasonic / AXIS / ONVIF
Stream*1 Set the number of the stream for delivering
camera images. Select a stream supported by the
connected network camera.
CH1 to CH4
Channel*1 Select the channel of the analog encoder. Set to "1"
if the network camera does not support the channel
function.
CH1 to CH4
RS485 PTZ Control*1 Controls the brightness, automatic focus adjustment,
pan, tilt and zoom for devices that are connected to
the network camera via a RS485 cable.
On / Off
Username*2 Enter the username to use when accessing network
cameras.
Alphanumeric characters and
symbols
(up to 32 characters)
Password*2 Enter the password to use when accessing network
cameras.
Alphanumeric characters and
symbols
(up to 32 characters)
*1 Supported only when compatible with the Panasonic protocol.
*2 Enter the username with administrator rights and the password.

17
Chapter 2 Conguring from the monitor screen
5. Select “Apply”.
The setting complete screen is displayed. Select “OK”.
Attention
• If you want to change the set values using the remote control, press the button, then enter the values
(for details see “Entering characters” (page 11)).
• Depending on the network camera type, the “Model No.” displayed on the setting screen may differ from
when the camera is discovered automatically and when it is registered manually.
• Only set “RS485 PTZ Control” to “On” when connecting an external device to the network camera using a
RS485 cable.
Note
• With manual registration, network settings of a camera cannot be changed. When changing the network
settings of a camera, check the network camera’s manual.
●To set network camera functions
Set the network camera functions from the monitor.
Procedure
1. Select “Function Settings”.
Displays current
settings.
1
2
3
2. Select the network camera to congure at “Camera Name”.
3. Select a function.
The setting screen for the selected function is displayed.
Attention
• The network camera set to “DirectUri” can be registered or congured only from the Web browser. It cannot
be registered or congured from the monitor screen. For the registration and conguration of the network
camera set to “DirectUri”, refer to “Manual Registration of Cameras / Changing Camera Information” (page
50).

18 Chapter 2 Conguring from the monitor screen
Camera Information Display
Select to display or not display the camera information and time of the network camera settings on
the camera images.
Attention
• It is not possible to congure the network camera when its “Protocol” is set to “ONVIF”,“AXIS”, or “DirectUri”.
2
1
1. Congure the items.
Item Detail Setting range
Camera Information Display Set whether or not to display camera information. On / Off
Time Display Set whether or not to display the time. 12h / 24h / Off
Display Position Set the display position of the camera information
and time.
Upper Left / Upper Right /
Lower Left / Lower Right
2. Select “Apply”.
The setting complete screen is displayed. Select “OK”.
Clock Settings
1. Synchronizes the time of the network camera with the time of the monitor.
Select “Execute” to synchronize the clock.
Video Settings
Set the Image Quality of transmitted images for the network camera.
Note
• This product supports H.264 and MJPEG (ONVIF only) video compression formats.
Attention
• When devices such as recorders are connected to a network camera, the display and recording of such
devices may be affected.
• It is not possible to congure the network camera when its “Protocol” is set to “DirectUri”.

19
Chapter 2 Conguring from the monitor screen
WhenusingaPanasonicnetworkcamera
2
1
1. Congure the items.
Item Detail Setting range
Aspect Ratio Set the H.264 aspect ratio.*1 Network camera imaging mode
Resolution Set the H.264 resolution. According to the network camera
specication
Refresh Interval Set the refresh interval*2 of H.264 images.
0.2s / 0.33s / 0.5s / 1s / 2s / 3s / 4s / 5s
Transmission Priority Set the transmission mode of H.264
images.
Constant Bit Rate / Frame Rate / Best
Effort
Frame Rate (When the mode is set to “Frame Rate” at
“Transmission Priority”.)
Set the frame rate (image update interval)
of H.264 images.*3
1fps / 3fps / 5fps / 7.5fps / 10fps / 12fps /
15fps / 20fps / 30fps
Bit Rate (Max.) Set the maximum H.264 image bit rate. 64kbps / 128kbps / 256kbps / 384kbps /
512kbps / 768kbps / 1024kbps /
1536kbps / 2048kbps / 3072kbps /
4096kbps / 8192kbps
Bit Rate (Min.) (When the mode is set to “Best Effort” for
“Transmission Priority”.)
Set the minimum H.264 image bit rate.
64kbps / 128kbps / 256kbps / 384kbps /
512kbps / 768kbps / 1024kbps /
1536kbps / 2048kbps / 3072kbps /
4096kbps / 8192kbps
Image Quality (When the mode is set to “Constant Bit
Rate” or “Best Effort” for “Transmission
Priority”.)
Set the H.264 image quality.
Low (prioritize motion) / Normal / Fine
(prioritize image quality)
*1 When “1920” is selected for “Resolution”, the aspect ratio is xed to 16:9. The aspect ratio cannot be
set when the network camera “Stream” is set to a value other than “1”.
*2 For H.264 images, the differential data between the full screen frame data and previous frame are
sent periodically. “Refresh Interval” refers to the interval for sending these full screen frame data.
Shortening this interval improves the stability of image quality but also increases the load on the
network. “Refresh Interval” refers to the interval at which the full screen data is transmitted. Shortening
this interval improves the image quality but also increases the load on the network.
*3 The shorter the interval, the shorter the update interval and the smoother the display, but also the larger
the load on the network.
2. Select “Apply”.
The setting complete screen is displayed. Select “OK”.
Attention
• To display the multicast stream of Panasonic network cameras, congure multicast on the camera.
• When you change the “Aspect Ratio,” the network camera imaging mode will change. Depending on the
imaging mode, the image quality of other recording devices or display devices may be impacted. Check the
impact of changes to the imaging mode before conguring the settings.

20 Chapter 2 Conguring from the monitor screen
WhenusinganAXISnetworkcamera
2
1
1. Congure the items.
Item Detail Setting range
Video Stream Select the display mode for screens that display
network camera images.
According to the camera
specication
Stream Prole Select the prole that the network camera has. According to the camera
specication
Compression Format Select the compression format. H.264 (Fixed)
Resolution Set the resolution of H.264 images. According to the camera
specication
Frame Rate Set the frame rate (image update interval) of
H.264 images.
According to the camera
specication (Maximum possible
values 30fps)
Rotation*1 Show the rotational direction of the network
camera image.
According to the camera
specication
GOP Length Set the GOP length for video. I-frame Interval
(only when H.264 is selected)
Bit Rate (Max.) Set the maximum H.264 image bit rate. According to the camera
specication (Maximum possible
values 8192 kbps)
Priority Set the preference for video compression. None / Frame Rate / Quality
Transmission Mode Select the transmission method for AXIS
camera images.
Unicast / Multicast
Multicast Address*2Show the multicast address for multicast
transmission of H.264 images.
224.0.0.0 to 239.255.255.255
Multicast Port*2Show the multicast port number for multicast
transmission of H.264 images.
1824 to 65534 even numbers
only
Multicast TTL*2Show the network TTL value for multicast
transmission of H.264 images.
According to the camera
specication
*1 For details on rotation settings, refer to the network camera user’s manual.
*2 Displays when “Transmission Mode,” or “Multicast” is selected.
2. Select “Apply”.
The setting complete screen is displayed. Select “OK”.
Attention
• To display the multicast stream of AXIS network cameras, congure multicast on the camera.
