User’s Manual
Color Display Monitor
FlexScan
F520

2CONTENTS
CONTENTS
PRECAUTIONS ................................................................3
INTRODUCTION ............................................................... 7
About This Manual................................................................ 7
Controls & Connectors ......................................................... 7
Package Contents ................................................................ 7
1 INSTALLATION ............................................................8
1-1 Connecting the monitor to the PC ................................. 8
1-2 Setting the resolution..................................................... 9
2 SCREEN ADJUSTMENT ........................................... 10
2-1 How to use the ScreenManager .................................. 10
2-2 Adjustments and Settings............................................ 10
2-3 Shortcut Keys .............................................................. 14
2-4 Adjustment Lock.......................................................... 14
3 TROUBLESHOOTING ............................................... 15
4 CLEANING ................................................................. 18
5 SPECIFICATIONS ...................................................... 19
Copyright© 1999 by EIZO NANAO CORPORATION. All rights reserved. No part of this manual may
be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic,
mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information
confidential unless prior arrangements are made pursuant to EIZO NANAO CORPORATION's receipt
of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please
note that EIZO monitor specifications are subject to change without notice.
ENERGY STAR is a U.S. registered mark.
Apple and Macintosh are registered trademarks of Apple Computer, Inc.
VGA is a registered trademark of International Business Machines Corporation.
DPMS is a trademark and VESA is a registered trademark of Video Electronics Standards Association.
Windows is registered trademark of Microsoft Corporation.
ScreenManager, PowerManager, QuickSet, i·Sound and i·Station are trademarks of EIZO NANAO CORPORATION.
FlexScan, SuperErgoCoat and EIZO are registered trademarks of EIZO NANAO CORPORATION.

PRECAUTIONS 3
E
IMPORTANT!
* This product has been adjusted specifically for use in the region to which it was originally shipped.
The performance of the product, (i.e. picture geometry, picture positioning and color convergence
and purity in the case of color monitors) is optimally adjusted to the earth's magnetic field of the
specific destination. If operated outside the region to which it was originally shipped, the product
may not perform as stated in the specifications.
* The manufacturer is not responsible for damage or malfunction caused by improper connection.
The power cord should be connected directly to a standard wall power outlet.
Location of the Caution Statements
PRECAUTIONS
IMPORTANT!
To ensure personal safety and proper maintenance. Please read this
section and the caution statements on the monitor (refer to the
figure above).
This manual uses the safety symbols below. They denote critical
information.
Please read them carefully.
Indicates a prohibited action.
Indicates to ground for safety.
WARNING
Failure to abide by the information in a WARNING may result in serious
injury and can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION may result in moderate
injury and/or property or product damage.
The equipment must be connected to a grounded main outlet.
Jordet stikkontakt skal benyttes når apparatet tilkobles datanett.
Apparaten skall anslutas till jordat nätuttag.

4PRECAUTIONS
WARNING
• If the monitor begins to emit smoke, smells like something is
burning, or makes strange noises, disconnect all power
connections immediately and contact your dealer for advice.
Attempting to use a malfunctioning monitor can be dangerous.
• Do not dismantle the cabinet or modify the monitor.
Dismantling the cabinet or modifying the monitor may result in electric
shock or burn.
• Keep small objects away from the monitor.
Small objects may accidentally fall through the ventilation slots into the
cabinet, leading to fire, shock, or equipment damage.
• Keep liquids away from the monitor.
Spillage into the cabinet may result in fire, electric shock, or equipment
damage. If an object or liquid falls/spills into the cabinet, unplug the
monitor immediately. Have the unit checked by a qualified service
engineer before using it again.
• Place the monitor on a strong, stable surface.
A unit placed on an inadequate surface may fall, resulting in injury or
equipment damage. If the monitor falls, disconnect the power
immediately and have the unit checked by a qualified service engineer
before using it again. Using a monitor after it has been dropped may
result in fire or electric shock.
• Keep the plastic packing bags away from children and infants.
Plastic bags can be dangerous. To avoid danger of suffocation, keep the
bag away from babies and children.
• Keep power terminal covers for the optional i ·Sound

sound unit
away from children and infants.
Children and infants may accidentally swallow the covers and choke. If
swallowed, consult a doctor immediately.
•Use the enclosed power cord. If using the power cord other than
the enclosed one, use the following cord.
In USA and Canada, use a UL LISTED/CSA LABELED or CERTIFIED
power cord set meeting the following specifications.
* Rating: min. 125 V, 10 A * Length: max. 2.0 m * Type: SVT
* Plug type:NEMA 5-15P, Parallel blade, Grounding type, 125 V, 10 A
In Europe, use a proper European standard approved power cord
meeting the following specifications.
* Rating: min. 250 V, 10 A * Length: max. 2.0 m
*Type: H05VV-F 3G 1 mm2
Use a plug type approved by the country where you use
Failure to do so may cause fire or electric shock.
•The equipment must be connected to a grounded main outlet.
•Use the correct voltage.
The monitor is designed for use with a specific voltage only. Connection
to a different voltage may cause fire, electric shock, or other damage.
OK

PRECAUTIONS 5
E
•Do not overload your power circuit, as this may result in fire or
electric shock.
•For proper connections of the power cord, be certain to plug the
power cord to the provided monitor connector and directly to a
wall outlet.
By not doing so may result in fire or electric shock.
•Handle the power cord with care.
* Do not place the cord underneath the monitor or other heavy objects.
* Do not pull on the cord.
* Do not attempt to repair a damaged cord.
If the power cord becomes damaged, stop using it. Use of a damaged
cord may result in fire or electric shock.
•To disconnect the power cord, grasp the plug firmly and pull.
Never tug on the cord, doing so may cause damage and could result in
fire or electric shock.
CAUTION
•Disconnect the power cord, signal cables and remove the optional
i·Sound

sound unit and i·Station

USB hub (if applicable) when
moving the monitor.
Moving the monitor with the cord attached or lifting it by the i·Sound
sound unit or i·Station USB hub is dangerous. It may result in injury or
equipment damage.
•Handle with care when carrying the monitor
Note that the monitor is heavier at the front than at the rear. Do not
move it alone. Always work with another person.
The screen is optically coated to reduce glare. Keep hard objects (such as
buttons, tie pins, and other clothing accessories) away from the screen
surface to prevent scratches.
•Set the monitor in an appropriate location.
* Do not install in a dusty or humid environment.
* Do not place in a location where light shines directly on the screen.
* Do not place near heat generating devices or a humidifier.
•Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a
problem.
•Do not sit on the cabinet or place any heavy objects on the cabinet.
A unit with heavy objects on it may fall or be damaged and result in
injury.
•Do not block the ventilation slots on the cabinet.
*Do not place books or any other papers on the ventilation slots.
*Do not install the monitor in a closed space.
*Do not use the monitor laying down or upside down.
*Do not remove the tilt-swivel stand.
Using the monitor in this way blocks the ventilation slots and prevents
proper airflow, leading to fire or other damage.
OK
OK

6PRECAUTIONS
•Do not remove the tilt-swivel stand.
The stand is required to maintain clearance for the ventilation slots on the
bottom of the cabinet. Removing the stand will block these slots and may
result in fire or electric shock.
•Do not touch the plug with wet hands.
Touching the plug with wet hands is dangerous and can cause electrical
shock.
•At the end of the day or if you plan to leave the monitor unused for
an extended period, after turning off the power switch disconnect
the power cord from the wall socket so that no power connections
are made.
•Unplug the monitor before cleaning it.
Cleaning the monitor while it is plugged into a power outlet may result
in electric shock.
•When adjusting the viewing angle of the monitor, do not do so by
handling the sound unit or USB hub (if applicable).
Adjusting the monitor in this way may break the unit or cause bodily
injury.
Others
•Do not install the monitor within an area subject to strong magnetic
fields (for example, in the vicinity of a speaker, except the optional
i·Sound unit, or a high-voltage transformer). Magnetic fields can cause
noise, image shaking, and other distortions.
•Generally, for maximum viewing comfort position the monitor slightly
below eye level. Staring at the monitor for prolonged periods can cause
eye strain. Be sure to take adequate rests. (A 10-minute rest period each
hour is suggested.)
•Do not remove the covers to the power terminal for the optional i·Sound
speaker unit for any reason except to attach the unit.

E
7
INTRODUCTION
INTRODUCTION
About This Manual
This manual explains the precautions, specifications, and operation of your EIZO
monitor. Please read through this manual as it will help you to get the most out of
your monitor.
Controls & Connectors:
Front
Package Contents:
•If any of the above-listed items are missing or damaged, please contact your local
dealer for assistance.
Rear
Power connector
D-Sub mini 15 pin
input connector
QuickSet™Control pad
(hereinafter “Control pad”)
Power terminal covers for the
optional i·Sound sound unit
Power switch
Power indicator
Indicates the power-on status, as follows:
Solid green: Power is ON
Flashing green: PowerManager Mode 1
Advance Notice Mode
Yellow: PowerManager Mode 2
Flashing Yellow: Off Timer Mode
Power Cord User’s Manual
Warranty
Registration
Card
Signal Cable
(MD-C87/
MD-C100)

81 INSTALLATION
D-Sub
mini 15 pin
Signal Cable
(enclosed)
D-Sub
mini 15 pin
D-Sub 15 pin
Macintosh Adapter (Optional)
Macintosh
D-Sub
mini 15 pin
Signal Cable
(enclosed)
D-Sub
mini 15 pin Standard PC graphics board
1 INSTALLATION
1-1. Connecting the monitor to the PC
1)Be sure that the power switches of both the PC and the monitor are OFF.
2)Plug the signal cable into the connector at the rear of the monitor.
• When connecting the signal cable or cable adapter, first check that the shape at
the cable side matches the shape at the connecting side. After connecting,
secure the connection with the screw-in fasteners.
3)Plug the other end of the cable into the video connector on the rear of the PC. Refer
to the figures below.
Standard PC graphics board
• About Plug & Play
When your computer and display support VESA DDC, the suitable resolution
and the refresh rate are set by just plugging your display into the computer
without any manual settings.
Macintosh
An optional Macintosh adapter should be connected to the PC (if required) before
connecting the signal cable. Please consult EIZO dealer.
4)Plug the power cord into the power connector at the rear of the monitor. Then plug
the other end of the cord into a power outlet.

E
9
1 INSTALLATION
WARNING
• Use the enclosed power cord. If using the power cord other than the enclosed
one, use the following cord.
In USA and Canada, use a UL LISTED/CSA LABELED or CERTIFIED power cord set
meeting the following specifications:
* Rating: min. 125 V, 10 A * Length: max. 2.0 m * Type: SVT
* Plug type: NEMA 5-15P, Parallel blade, Grounding type, 125 V, 10 A
In Europe, use a proper European standard approved power cord meeting the
following specifications:
* Rating: min. 250 V, 10 A * Length: max. 2.0 m
*Type: H05VV-F 3G 1 mm2
Use a plug type approved by the country where you use
Failure to do so may cause fire or electric shock.
5)Turn on the monitor first, then the PC. The monitor’s power indicator will light up
(green). The monitor will warm up briefly, then display an image. Whenever
finishing your operation, turn off the PC and the monitor.
• If an image does not appear, refer to the “TROUBLESHOOTING” section on
page 15 for an advice.
1-2. Setting the resolution
The following look-up table shows the maximum (Non-interlaced) vertical refresh
rates for this model with regard to standard resolutions set forth by VESA. The
best way to see if the monitor will work with a given resolution and rate, is to
compare the vertical refresh rate of the graphics board to the monitor’s range (Refer
to the graphics board manual for specifications). If the refresh rate is within the
specified range of the monitor, it should operate properly.
Maximum Vertical Refresh rate (Hz)
640x480 800x600 1024x768 1280x1024 1600x1200
30-96 160 144 118 89 76
What is Resolution?
Resolution is expressed as the number of dots (pixels) displayed on the screen. A
larger number of dots produces a more sharply defined (a higher-resolution) image.
Note that for a given screen size the dot size decreases as the number of dots
increases: a 640 ×480 (dot ×line) resolution uses larger pixels than a 1024 ×768
resolution. The display size of a given font therefore varies according to the
resolution. Higher resolutions allow you to display more information on the screen.
Horizontal Scan
Frequency (kHz)

10 2 SCREEN ADJUSTMENT
2 SCREEN ADJUSTMENT
2-1. How to use the ScreenManager
Entering the ScreenManager
Press the ENTER key to display the ScreenManager Main menu.
Making the Adjustments and Settings
1)Select the desired icon using the Arrow keys, and then press the ENTER key to
display the each adjustment/setting menu.
2)Use the Control pad (the four Arrow keys and the ENTER key) to make the
required adjustments and settings.
Save & Exit
1)To save settings and return to the Main menu, press the ENTER key.
2)To exit the ScreenManager, select the Exit icon (or push the down Arrow key twice)
and press the ENTER key.
2-2. Adjustments and Settings
•Allow the monitor to stabilize for at least 30 minutes before making image
adjustments.
Main menu
Adjustment menu

E
11
2 SCREEN ADJUSTMENT
Contrast/
Brightness Adjusts: a) Contrast (left/right)
b) Brightness (up/down)
·When a white text against a black
background (e.g., DOS text) is used, setting
the brightness at its maximum is
recommended because a dark setting will
result in eye strain due to high character
contrast.
Size
Position
Tilt
Parallelogram/
Trapezoidal
Moiré
Side-
Pin Balance/
Side-
Pincushion
Function (Arrow Keys Used)
Adjusts: Horizontal image size (left/right)
Vertical image size (up/down)
Adjusts: Screen position
Adjusts: Side-pin balance (left/right)
Side-pincushion (up/down)
·Tilts: image sides to sides (left/right)
·Expands: top side/bottom side, shirnking the
other side (up/down)
Tilts: the image (left/right)
Adjusts: horizontal moiré(left/right)
Adjusts: vertical moiré(up/down)
What is moiré?
Moirérefers to an interference pattern of
dark wavy lines on the screen. It is not a
defect, but rather an interference
phenomenon caused by the relationship
between the phosphor layout and the
imaging signal. Moiréis often an indication
of a good focus level. Moiréis particularly
noticeable when using a light-gray or every-
other-dot pattern background. Although
moirécan not be eliminated, it can be
reduced with the moiréreduction feature.
OSD

12 2 SCREEN ADJUSTMENT
PowerManager (VESA DPMS, OffTimer)
What is PowerManager?
The PowerManager feature automatically reduces the monitor’s power
consumption during idle periods. The EIZO PowerManager functions comply
with the VESA DPMS standard.
As an ENERGY STAR®Partner, EIZO NANAO CORPORATION has determined that this
product meets the ENERGY STAR®guidelines for energy efficiency.
•Do your part to conserve energy, turn off the monitor when your finished using
it. Complete energy use can only be stopped by disconnecting the monitor
from the power supply.
•When the monitor is in a power saving mode, the optional EIZO i·Sound
speaker unit will turn off.
•Off Timer will work while PowerManager is active, but there will be no advance
notice before the monitor's power switches off.
PowerManager ·VESA DPMS
·Off Timer
(Refer to the text below)
Default settings are as follows.
·Contrast/Brightness:100%/60%
·Moiré(Horizontal): 0%
(Vertical): 0%
·Color: 9,300K
·PowerManager: VESA DPMS = On
Off Timer = Disable
·Video Level 0.7 V
Reset
Function (arrow keys usd)
OSD
Video Level Adjusts: Video Level
Set the video level to adapt the output
level of the computer or the graphics
board.
Color Adjusts: Color temperature
Temperature can be set from 6,500 K to
9,300 K, in 500 K increments.
·Each monitor is slightly different, if two
monitors are set to the same color
temperature value (i.e. 6,500K), they
may not necessarily look the same.

E
13
2 SCREEN ADJUSTMENT
VESA DPMS
What is VESA DPMS?
The acronym VESA stands for “Video Electronics Standards Association,”and
DPMS stands for “Display Power Management Signaling.”DPMS is a com-
munication standard that PCs and graphics boards use to implement power
savings at the monitor side.
Set-up Procedure
1)First, make the appropriate settings for the PC.
2)Select VESA DPMS icon in the ScreenManager’s PowerManager menu.
3)Select “On”.
Power saving method of VESA DPMS and the monitor
VESA DPMS utilizes four signals: ON, STAND-BY, SUSPEND, and OFF. The
monitor detects these signals from the graphics board and executes power-saving
accordingly, as shown in the table below.
Signal Screen LED Power consumption
ON Operation Green 80 W (normal)
STAND-BY Blank Green 80% of normal
SUSPEND Blank (Mode 1) Flashing green less than 10 W
OFF Blank (Mode 2) Yellow less than 3 W
Off Timer
What is Off Timer?
The Off Timer function allows the user to set the time in which the monitor
will be in operation, called the “On Period”and automatically shifts the
operation into the “Off Timer Mode”when the set “On Period”expires. The
energy consumption of the monitor in the “Off Timer Mode”is as low as the
one of the monitor in “PowerManger Mode 2”although no setting PC to
operate the Off Timer function is required.
Set-up Procedure
1)Select the “Off Timer”icon.
2)Select “Enable”.
3)Press the right/left key to adjust how long (1 to 23 hours) the monitor should
be in the “On Period”.
Advance notice (LED flashing green) will be given 15 minutes before the monitor
automatically enters the “Off Timer Mode”.

14 2 SCREEN ADJUSTMENT
To Delay Entering the “Off Timer Mode”
To delay entering the “Off Timer Mode”, press any keys on the front panel
located to the left of the power switch during the “Advance notice Mode”. The
monitor will continue to operate for an additional 90 minutes. There will be
another advance notice for 15 minutes as described. Delayed entrance into the
“Off Timer Mode”can be extended as many times as desired.
What is ENERGY STAR?
“ENERGY STAR”is a set of power saving guidelines issued by the U.S.
Environmental Protection Agency (EPA). The guidelines apply to PC systems and
peripherals.
2-3. Shortcut Keys
Before entering the ScreenManager, brightness and contrast can be adjusted directly
by moving the Control pad. To record the new setting and exit the ScreenManager,
press the Enter key. (The brightness and contrast functions are also available in the
ScreenManager “contrast/brightness”menu.)
2-4. Adjustment Lock
The ScreenManager operation can be disabled by holding down the up arrow key
on the control pad while switching on the monitor’s power. This will disable
(“lock”) the ScreenManager, protecting from accidental changes. To unlock the
buttons: switch the power off, then hold down the up arrow key on the control pad
once again and turn the power back on.
Note that brightness and contrast can be adjusted using the shortcut keys even
while the Control pad is locked. After making such an adjustment, push the
ENTER key to clear the brightness/contrast adjustment menu from the screen.
Brightness Up
Brightness Down
Contrast
Down Contrast
Up
Up Arrow Key of
the Control Pad
Power Switch

E
15
3 TROUBLESHOOTING
3 TROUBLESHOOTING
Troubleshooting
If a problem persists even after applying the suggested remedies, contact an
EIZO dealer.
Problems
1) Indicator status: OFF
2) Indicator status: GREEN
3) Indicator status: GREEN
(flashing)
4) Indicator status: YELLOW
5) Indicator status: YELLOW
(flashing)
6) Following message appears.
7) Following message appears.
(Example)
Points to check with possible solutions
Check that the power cord is correctly connected.
Check brightness and contrast settings. Minimum
settings will cause screen to be blank.
Try pressing a key on the keyboard, or clicking the
mouse. (The monitor may be in a power saving mode.)
Try pressing a key on the keyboard, or clicking the
mouse. (The monitor may be in a power saving mode.)
Try pressing any keys on the front panel, or switch the
monitor off and then on. (The monitor may be in “Off
Timer Mode”.)
If the problem persists, switch off the monitor power for a
few minutes, then switch it back on and try again.
Check that the PC is switched ON.
Check that the signal cable is properly connected to the
graphics board or PC.
Check that the graphics board is correctly inserted in
the PC.
Use the graphics board’s utility software to change the
frequency setting. (Refer to the manual of the graphics
board.)
•Whenever an error signal message appears, the signal frequency will be displayed in red.
•Error messages shown above will remain on the screen for 30 seconds. An error
message may not appear at all if the signal frequency is extremely high or extremely low.

16 3 TROUBLESHOOTING
Problems
8) The entire screen appears too
dark or bright.
9) The image vibrates on the
screen.
Points to check with possible solutions
Adjust the contrast and brightness using the
ScreenManager. See page 10.
Output level from the computer may not conform the
monitor. Please set the video level using the
ScreenManager. See page 12.
Some signal timing can be the cause of this problem. To
correct this, turn off the monitor, then hold down the
AUTO-SIZING button and “down”arrow key while
turning on the monitor again. This will change the
signal timing and brighten the screen. If the above
operation si repeated the screen becomes dark again.
Use of the “Moiré” adjustment may cause a slight.
vibration. To eliminate the vibration, set the adjustment
level to lower percentage or 0%. See page 11.
Check that the signal cable is properly connected to the
graphics board or PC.
Check that the graphics board is correctly mounted in
the PC.
The monitor may be located close to a device that is
generating a magnetic field. Such devices include
speakers (other than the EIZO optional i·Sound
speaker), electric motors, high-voltage cables, and other
monitors. It may be solved by switching off or moving
the interfering device, or by relocating the monitor.
If the volume level of the EIZO optional i·Sound speaker
is too high, it may, in some cases, cause a slight vibra-
tion. To eliminate, turn down the volume of the speaker.
•An unstable signal from the graphics board may be the cause of the above problem when
using the monitor with a high resolution or in a high refresh mode. (The video signal from
the graphics board might be made irregular due to the use of a high speed dot clock.)
Change the resolution or the refresh rate to another setting.

E
17
3 TROUBLESHOOTING
Flicker
The term “flicker”refers to noticeable shimmering that occurs when the image on the
screen is redrawn (“refreshed”) too slowly. A refresh rate of 80 Hz means the image is
redrawn 80 times per second. Most people will notice flicker at image refresh rates as high
as 60 or 70 Hz, whereas refresh rates of 72 Hz or above usually is not noticeable. Flicker
is known to be the cause of visual fatigue.
Problems
10) Moirépatterns are
distracting.
11)The image is flickering.
12)•The entire screen appears
bluish or reddish.
•Color purity is not
uniform.
•Misconvergence of colors.
(red, green, blue)
13)Control Pad “ENTER key”
does not operate.
Points to check with possible solutions
Reduce the moiréusing the ScreenManager’s “Moiré”
adjustment menu following the procedure below.
1) Set the desktop to an every-other-dot pattern so that
moiréwill be visible.
2) Go to the ScreenManager’s “Moiré” menu and adjust
so that moirébecomes almost unnoticeable. See page
11.
3) Change to a different desktop background to reduce
moiréeven further.
Change the horizontal and vertical dimensions of the
desplay area.
Change the selected desktop or wallpaper pattern to
any solid color pattern. For detailed information on
how to change these patterns, refer to the
documentation for the PC and operating system.
Flicker will occur with interlaced scanning, or
non-interlaced scanning with a low refresh rate. All
EIZO monitors are capable of reproducing high refresh
rates for non-interlaced scanning. If a problem occurs
when using a non-interlaced signal, try adjusting the
graphics board to increase the refresh rate (if possible).
Refer to the graphics board manual for information.
The CRT is not warmed up. Allow 30 minutes for the
monitor to stabilize.
The Adjustment Lock is probably on. To unlock: switch
off the monitor power, then hold down the down arrow
key of the control pad and switch the monitor back on.
See page 14.
Explanation of the Characteristics of CRTs
When the monitor is not fully warmed up, the screen may look slightly colored, e.g.
reddish or bluish. This phenomenon is due to the unstableness of the electron gun during
its warm-up period. Please wait for about 30 minutes until the monitor stabilizes in order
to gain its proper color.

18 4 CLEANING
WARNING
•Keep liquids away from the monitor.
Spillage into the cabinet may result in fire, electric shock, or equipment
damage.
If an object or liquid falls/spills into the cabinet, unplug the monitor
immediately. Have the unit checked by a qualified service engineer
before using it again.
Using the monitor in this condition could cause serious injury or
equipment damage.
CAUTION
•To ensure safety, always unplug the monitor before cleaning it.
Failure to do so may result in electric shock.
•Periodically clean the area around the plug.
Buildup of dust, water, or oil on the plug may result in fire.
•Never use thinner, benzene, alcohol (ethanol, methanol, or
isopropyl alcohol), abrasive cleaners, or other strong solvents, as
these may cause damage to the cabinet or CRT.
Periodic cleaning is recommended to keep the monitor looking new and
to prolong its operational lifetime. Clean the cabinet and CRT areas as
follows:
Cabinet
To remove stains, wipe the cabinet with a soft, lightly moistened cloth
using a mild detergent. Do not spray wax or cleaner directly onto the
cabinet.
CRT Surface
The CRT surface can be cleaned with a soft cloth, such as cotton or
lens paper.
If necessary, stubborn stains can be removed by moistening part of a
cloth with water to enhance its cleaning power.
4 CLEANING

E
19
5 SPECIFICATIONS
5 SPECIFICATIONS
Electrical Specifications
CRT 45 cm (17 inch) class, 90°deflection Invar Shadow Mask
with Anti- Reflective SuperErgoCoat®
CRT AG Pitch 0.26 mm
Scan Frequency(Horizontal): 30 kHz-96 kHz (Automatic)
Scan Frequency (Vertical): 50 Hz-160 Hz (Automatic)
Max. Active Display Area 318 mm (H) ×238 mm (V) (12.5”(H) ×9.3”(V))
(Viewable image size: 397 mm (15.6”))
* Display size can be set by the user through microprocessor
control panel.
* The actual size displayed can be dependent on the graphics
board or PC utilized.
Power Supply 100-120 VAC±10%, 50/60 Hz, 1.1 A
220-240 VAC±10%, 50 Hz, 0.55 A
Power Consumption
Normal/Max.: 80 W/95 W (with EIZO optional speaker attached)
PowerManager Mode 1: Less than 10 W
PowerManager Mode 2: Less than 3 W
Input Connector D-Sub mini 15-pin
Recommended Resolution 1024 dots ×768 lines
Input Signal(Sync): •H/V Separate, TTL, Positive/Negative
•H/V Composite, TTL, Positive/Negative
•Sync on Green 0.3 Vp-p, Negative
Input Signal(Video): •Analog 0.7 Vp-p/75 Ω, Positive
Plug & Play VESA DDC1/2B
Mechanical Specifications
Dimensions 410 mm (W) ×413 mm (H) ×439 mm (D)
(16.1”(W) × 16.3” (H) × 17.3” (D))
Weight 17.0 kg (37.5 lbs.)
Environmental Specifications
Temperature operating: 0°C to 35°C (32°F to 95°F)
storage: -20°C to 60°C (-4°F to 140°F)
Humidity 30% to 80% R.H. Non-condensing
Certifications and Standards
100-120 VAC range UL/C-UL, FCC-B, DHHS, TÜV Rheinland/Ergonomics
Approved, TCO’99, EPA Energy Star®Program
220-240 VAC range CE, CB, TÜV Rheinland/GS, TÜV Rheinland/Ergonomics
Approved, TCO’99, EPA Energy Star®Program
E

20 5 SPECIFICATIONS
Pin Assignment (D-Sub mini 15 pin connector)
Pin No. Signal Pin No. Signal Pin No. Signal
1 Red video 6 Red ground 11 Ground
(shorted)
2 Green video 7 Green ground 12 Data
3 Blue video 8 Blue ground 13 H. Sync
4 Ground 9 No pin 14 V. Sync
5 No pin 10 Ground 15 Clock
(shortened)
Preset Timing
8 factory presets shown below have been registered in the monitor’s microprocessor.
Resolution Frequencies Interlace Sync Polarity Video Signal
fH (kHz) fV (Hz) Level
VGA 720 ×400 31.47 70.09 Non H/Negative 0.7V(p-p)/75Ω
(text) V/Positive
VGA 640 ×480 31.47 59.94 Non H/Negative 0.7V(p-p)/75Ω
V/Negative
VESA 640 ×480 37.50 75.00 Non H/Negative 0.7V(p-p)/75Ω
V/Negative
VESA 800 ×600 46.88 75.00 Non H/Positive 0.7V(p-p)/75Ω
V/Positive
VESA 1024 ×768 60.02 75.03 Non H/Positive 0.7V(p-p)/75Ω
V/Positive
VESA 1024 ×768 68.68 85.00 Non H/Positive 0.7V(p-p)/75Ω
V/Positive
VESA 1280 ×1024 80.00 75.00 Non H/Positive 0.7V(p-p)/75Ω
V/Positive
VESA 1280 × 1024 91.15 85.02 Non H/Positive 0.7(p-p)/75Ω
V/Positive
318
(12.5)
74.5
(2.9)
410
(16.1)
238
(9.3)
ø265
(10.4)
ø
46.9
(1.8) 439
(17.3)
302.1
(11.9)
413
(16.3)
124
(4.9)
FRONT VIEW SIDE VIEW TOP VIEW
Dimensions mm
(iches)
