User’s Manual
Color LCD Monitor

English
2
SAFETY SYMBOLS
This manual uses the safety symbols below. They denote critical information. Please read them
carefully.
WARNING
Failure to abide by the information in a WARNING may result in serious injury and
can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION may result in moderate injury
and/or property or product damage.
Indicates a prohibited action.
Indicates to ground for safety.
Copyright© 2002 by EIZO NANAO CORPORATION. All rights reserved. No part of this
manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any
means, electronic, mechanical, or otherwise, without the prior written permission of Eizo Nanao
Corporation.
Eizo Nanao Corporation is under no obligation to hold any submitted material or information
confidential unless prior arrangements are made pursuant to Eizo Nanao Corporation's receipt of
written information. Although every effort has been made to ensure that this manual provides
up-to-date information, please note that EIZO monitor specifications are subject to change
without notice.
ENERGY STAR is a U.S. registered mark.
Apple and Macintosh are registered trademarks of Apple Computer, Inc.
VGA is a registered trademark of International Business Machines Corporation.
DPMS is a trademark and VESA is a registered trademark of Video Electronics Standards
Association.
Windows is a registered trademark of Microsoft Corporation.
ScreenManager and PowerManager are trademarks of Eizo Nanao Corporation.
FlexScan and EIZO are registered trademarks of Eizo Nanao Corporation.
As an ENERGY STAR®Partner, Eizo Nanao Corporation has determined that this
product meets the ENERGY STAR guidelines for energy efficiency.

English
TABLE OF CONTENTS 3
TABLE OF CONTENTS
PRECAUTIONS................................................................................... 4
1. INTRODUCTION ..................................................................................... 9
1-1. Features....................................................................................................... 9
1-2. Package Contents ........................................................................................ 9
1-3. Controls & Connectors ............................................................................. 10
2. CABLE CONNECTION ......................................................................... 12
2-1. Before connecting ...................................................................................... 12
2-2. Connecting the signal cable ....................................................................... 13
2-3. Sound Connections.................................................................................... 15
3. ScreenManager .................................................................................... 16
3-1. How to use the ScreenManager ................................................................. 16
3-2. Adjustments and Settings........................................................................... 17
3-3. Useful Functions........................................................................................ 18
4. ADJUSTMENT ...................................................................................... 20
4-1. Screen Adjustment..................................................................................... 20
4-2. Displaying a low resolutions...................................................................... 23
4-3. Color Adjustment...................................................................................... 25
4-4. Power-save Setup....................................................................................... 27
5. ATTACHING AN ARM STAND .............................................................. 29
6. TROUBLESHOOTING........................................................................... 30
7. CLEANING ............................................................................................ 33
8. SPECIFICATIONS................................................................................. 34
9. GLOSSARY........................................................................................... 36
APPENDIX/ANHANG/ANNEXE .................................................................. i

English
4PRECAUTIONS
PRECAUTIONS
IMPORTANT!
• This product has been adjusted specifically for use in the region to which it was
originally shipped. If operated outside the region to which it was originally shipped,
the product may not perform as stated in the specifications.
• To ensure personal safety and proper maintenance, please read this section and the
caution statements on the unit (refer to the figure below).
[Location of the Caution Statements]
WARNING
If the unit begins to emit smoke, smells like something is burning, or
makes strange noises, disconnect all power connections immediately
and contact your dealer for advice.
Attempting to use a malfunctioning unit can be dangerous.
Do not dismantle the cabinet or modify the unit.
Dismantling the cabinet or modifying the unit may result in electric shock or
burn.
Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards.

English
PRECAUTIONS
5
WARNING
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the cabinet
or spillage into the cabinet may result in fire, electric shock, or equipment
damage.
If an object or liquid falls/spills into the cabinet, unplug the unit immediately.
Have the unit checked by a qualified service engineer before using it again.
Place the unit on a strong, stable surface.
A unit placed on an inadequate surface may fall, resulting in injury or
equipment damage.
When the unit is dropped, please ask your dealer for advice. Do not continue
using a damaged unit. Using a damaged unit may result in fire or electric
shock.
SIG.SIG. AUTOAUTO ENT.ENT.
OK
Set the unit in an appropriate location.
Not doing so may cause damage and could result in fire or electric shock.
* Do not place outdoors.
* Do not place in the transportation system (ship, aircraft, trains, automobiles,
etc.)
* Do not install in a dusty or humid environment.
* Do not place in a location where the steam comes directly on the screen.
* Do not place near heat generating devices or a humidifier.
To avoid danger of suffocation, keep the plastic packing bags away
from babies and children.
Use the enclosed power cord and connect to the standard power outlet
of your country. Be sure to remain within the rated voltage of the
power cord.
Not doing so may result in fire or electric shock.
To disconnect the power cord, grasp the plug firmly and pull.
Never tug on the cord, doing so may cause damage and could result in fire or
electric shock.
OK

English
6PRECAUTIONS
WARNING
The equipment must be connected to a grounded main outlet.
Not doing so may result in fire or electric shock.
Use the correct voltage.
* Do not overload your power circuit, as this may result in fire or electric
shock.
* The unit is designed for use with a specific voltage only. Connection to
another voltage than specified in this User’s Manual may cause fire, electric
shock, or other damage.
* Do not overload your power circuit, as this may result in fire or electric
shock.
Handle the power cord with care.
* Do not place the cord underneath the unit or other heavy objects.
* Do not pull on or tie the cord.
If the power cord becomes damaged, stop using it. Use of a damaged cord
may result in fire or electric shock.
Never touch the plug and power cord if it begins to thunder.
Touching them may result in electric shock.
When attaching an arm stand, please refer to the user’s manual of the
arm stand and install the unit securely with the enclosed screws.
Not doing so may cause the unit to become unattached, which may result in
injury or equipment damage. When the unit is dropped, please ask your dealer
for advice. Do not continue using a damaged unit. Using a damaged unit may
result in fire or electric shock. When reattaching the tilt stand, please use the
same screws and tighten them securely.
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the
eyes or mouth.
If any part of the skin or body comes in direct contact with the panel, please
wash thoroughly. If some physical symptoms result, please consult your
doctor.
Follow local regulation or laws for safe disposal.
The backlight of the LCD panel contains mercury.

English
PRECAUTIONS
7
CAUTION
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the unit
with the cord attached is dangerous. It may result in injury or equipment
damage.
When handling the unit, grip the bottom of the unit firmly with both
hands ensuring the panel faces outward before lifting.
Dropping the unit may result in injury or equipment damage.
SIG.SIG. AUTOAUTO ENT.ENT.
OK
Do not block the ventilation slots on the cabinet.
* Do not place books or any other papers on the ventilation slots.
* Do not install the unit in a closed space.
* Do not use the unit lying down or upside down.
Using the unit in these ways blocks the ventilation slots and prevents proper
airflow, leading to fire or other damage.
Do not touch the plug with wet hands.
Touching them may result in electric shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a
problem.
Periodically clean the area around the plug.
Buildup of dust, water, or oil on the plug may result in fire.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in electric
shock.
If you plan to leave the unit unused for an extended period, disconnect
the power cord from the wall socket after turning off the power switch
for the safety and the power conservation.

English
8PRECAUTIONS
LCD Panel
In order to suppress the luminosity change by long-term use and to maintain
the stable luminosity, use of a monitor in lower brightness is recommended.
The screen may have defective pixels. These pixels may appear as slightly light
or dark area on the screen. This is due to the characteristics of the panel itself,
and not the product.
The backlight of the LCD panel has a fixed life span. When the screen becomes
dark or begins to flicker, please contact your dealer.
Do not press on the panel or edge of the frame strongly, as this will result in
damage to the screen. There will be prints left on the screen if the pressed
image is dark or black. If pressure is repeatedly applied to the screen, it may
deteriorate or damage your LCD panel. Leave the screen white to decrease the
prints.
Do not scratch or press on the panel with any sharp objects, such as a pencil or
pen as this may result in damage to the panel. Do not attempt to brush with
tissues as this may scratch the LCD panel.

English
1. INTRODUCTION
9
1. INTRODUCTION
Thank you very much for choosing an EIZO Color Monitor.
1-1. Features
• Dual inputs compliant
• DVI (p.36) Digital input (TMDS (p.37)) compliant.
• Horizontal scanning frequency: 24.8 - 80 kHz (Digital input: 31.5 - 64 kHz)
Vertical scanning frequency: 50 - 85 Hz Vertical (1280 x 1024 ~ 75 Hz)
Vertical (Digital) of 60 Hz (VGA text: 70 Hz)
Resolution: 1280 dots x 1024 lines
• Auto Adjustment compliant
• ColorManagement function incorporated
• Support to sRGB (p.37) standard
• Built-in speaker system
1-2. Package Contents
Please contact your local dealer for assistance if any of the listed items are missing or
damaged.
•LCD Monitor
•Power Cord
•Signal cable (MD-C87 or MD-C100)
•Stereo mini-jack cable
•User’s Manual
•ScreenManager Quick Reference
•LIMITED WARRANTY
•Mounting Screws: M4 x 12 (mm)
NOTE
• Please retain the packing materials for future transference.

English
10 1. INTRODUCTION
1-3. Controls & Connectors
Front
S I G .S I G . AUTOAUTO ENT.ENT.
(4) (5) (6) (7)
(8) (9)
(3)
(1)
(2)
SIG. AUTO ENT.
(1) ScreenManager
(2) Speaker*1
Volume Control Press the right and left buttons.
Mute Press the up or down button for a while after
pressing the right or left button to display the
volume control bar.
Press the right or left button to mute off.
(3) Headphone jack (stereo mini-jack)
(4) Input signal selection button
(5) Auto Adjustment Button
(6) Enter Button
(7) Control Buttons (Up, Down, Left, Right)
(8) Power Button
(9) Power Indicator*2
Blue Operation
Yellow Power saving
Flashing yellow (2
times for each)
Power save mode Digital only
Off Power off
*1 Regarding the sound connection, see page 15.
*2 Regarding the power indicator for the “Off Timer”, see page 18.
Control Panel

English
1. INTRODUCTION
11
Rear
(11)
(10) (12) (13)
(14)
(15)
(16)
(10) DVI-D Input Connector (Signal 1)
(11) D-Sub mini 15 pin Input Connector (Signal 2)
(12) External line in (stereo mini-jack)
(13) Power Connector
(14) Security Lock Slot*3
(15) 4 Holes for Mounting an Arm-Stand*4
(16) Stand (Detachable) *4
*3 Allows for connection of a security cable. This lock supports Kensington’s
MicroSaver security system.
For further inforamation, please consult:
Kensington Technology Group
2855 Campus Drive, San Mateo, CA 94403 USA
Tel: [phone], x3348
Intl: 650-572-2700, x3348 / Fax: [phone]
http://www.kensington.com
*4 The LCD monitor can be used with an optional arm stand by removing the stand
(see page 29).
Bottom

English
12 2. CABLE CONNECTION
2. CABLE CONNECTION
2-1. Before connecting
Before connecting your monitor to the PC, change the display screen settings (resolution
(p.36) and frequency) in accordance with the charts below.
NOTE
• The lower display modes like 640x 480, automatically enlarge to the maximum
display mode (1280 x 1024), and some lines of the characters may become fuzzy. In
this case, use <Smoothing> function (p.22) to make the lines clear. Using the
<Screen Size> function in the <Others> menu enables to change the screen size
(p.22).
• When your computer and display support VESA DDC, the suitable resolution and
the refresh rate are set by just plugging your display into the computer without any
manual settings.
Analog Input
Resolution Frequency Remarks
640 x 480 ~85 Hz VGA, VESA
720 x 400 70 Hz VGA TEXT
800 x 600 ~85 Hz VESA
832 x 624 75 Hz Apple Macintosh
1024 x 768 ~85 Hz VESA
1152 x 864 75 Hz VESA
1152 x 870 75 Hz Apple Macintosh
1280 x 960 60 Hz VESA
1280 x 960 75 Hz Apple Macintosh
1280 x 1024 ~75 Hz VESA
Digital Input
Resolution Frequency Remarks
640 x 480 60 Hz VGA
720 x 400 70 Hz VGA TEXT
800 x 600 60 Hz VESA
1024 x 768 60 Hz VESA
1280 x 1024 60 Hz VESA

English
2. CABLE CONNECTION 13
2-2. Connecting the signal cable
NOTE
• Be sure that the power switches of both the PC and the monitor are OFF.
1. Plug the signal cable into the connector at the rear of the monitor
and the other end of the cable into the video connector on the PC.
After connecting, secure the connection with the screw-in fasteners.
Analog Input
Signal Cable Connector PC
Signal Cable (enclosed)
Video Output
Connector D-Sub
mini 15 pin
• Standard graphics card
• Macintosh G3 (Blue & White) /
G4
Signal Cable (enclosed) +
Macintosh Adapter
(Optional)
Video Output
Connector D-Sub
15 pin
• Macintosh
Digital Input
Signal Cable Connector PC
FD-C04 (Optional)
Video Output
Connector DVI
Digital Graphics card
NOTE
• The L665 is not compatible with a Power Macintosh G4/G4 Cube ADC (Apple
Display Connector).
Power Cord
Power Cord

English
14 2. CABLE CONNECTION
2. Plug the power cord into the power connector on the rear of the
monitor. Then, plug the other end of the cord into a power outlet.
WARNING
Use the enclosed power cord and connect to the standard
power outlet of your country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may result in fire or electric shock.
The equipment must be connected to a grounded main
outlet.
Not doing so may result in fire or electric shock.
3. Turn on the monitor's main power and then switch on the PC's
power.
The monitor’s power indicator will light up (blue).
If an image does not appear, refer to the “6. TROUBLESHOOTING” (p.30) for
advice.
Whenever finished, turn off the PC and the monitor.
NOTE
• Adjust brightness of the screen depending on the brightness of your environment.
Too dark or too bright of a screen can cause eyestrain.
• Be sure to take adequate rests. A 10-minute rest period each hour is suggested.

English
2. CABLE CONNECTION 15
2-3. Sound Connections
NOTE
• Always switch the monitor and audio devices or computers off whenever connecting
or disconnecting any audio devices (computer or CD player) to the monitor.
• Use the enclosed stereo mini-jack cable for connecting audio devices or computers
to the monitor.
1. Connect the stereo mini-jack cable to the external line in of the
monitor.
2. Connect the other side of stereo mini-jack cable to the line out of
audio devices.
Sound control
Audio performance is available by connecting the headphone to the Headphone jack
(When headphones are connected, no sound can be heard from the speakers).
SI G .S I G . AUTOAUTO ENT.ENT.
Volume control
Volume control Press the right and left buttons.
Mute Press the up or down button for a while after pressing the right or left button
to display the volume control bar.
Mute off Press the right or left button.
NOTE
• <Sound> menu of the ScreenManager also controls the sound.
Computer or
CD Player

English
16 3. ScreenManager
3. ScreenManager
3-1. How to use the ScreenManager
S I G .S I G . AUTOAUTO ENT.ENT.
SIG. AUTO ENT.
1. Entering the ScreenManager
Push the Enter button once to display the main menu of the ScreenManager.
[Main Menu ]
2. Making Adjustments and Settings
(1) Select the desired sub menu icon using the Control buttons and push the Enter
button. The sub menu appears.
(2) Use the Control buttons to select the desired setting icon and push the Enter
button. The setting menu appears.
(3) Use the Control buttons to make all required adjustments and push the Enter
button to save the settings.
3. Exiting the ScreenManager
(1) To return to the main menu, select the <Return> icon or push the down button
twice, followed by the Enter button.
(2) To exit the ScreenManager, select <Exit> icon or push the down button twice,
followed by the Enter button.
NOTE
• Double clicking the Enter button at any time also exits the ScreenManager menu.
Auto Adjustment button Enter button
Control Buttons
Left, Down, Up, Right

English
3. ScreenManager
17
3-2. Adjustments and Settings
The following table shows all the ScreenManager’s adjustment and setting menus.
“*” indicates adjustments of analog input only and “**” indicates digital input only.
Main menu Sub menu Reference
Clock *
Phase *
Position *
Smoothing
Screen
Contrast
/Brightness
4-1. Screen Adjustment (p.20)
Range Adjustment *
Color Mode
•Custom
Temperature
Saturation
Hue
Gain
Reset
ColorManagement
•sRGB
4-3. Color Adjustment (p.25)
Volume Control the sound volume.Sound
Mute Mute the sound.
DVI DMPM **
VESA DPMS *
PowerManager
Sound
4-4. Power-save Setup (p.27)
Screen Size
Border Intensity
4-2. Displaying a low resolutions (p.23)
Input Signal Set the input signal selection of
automatic or manual (p.19)
Off Timer Set the monitor’s off timer to on or off
(p.18)
VGA Selection Select the display mode. (p.31)
Menu Position Adjust the menu position.
Translucent Set the transparency of the menu.
Menu Off Timer Set the menu displaying time.
Others
Reset Return to the factory default settings.
(p.35)
Information Information Review the ScreenManager’s settings,
model name, serial number and usage
time*1.
Language English, German,
French, Spanish,
Italian, Swedish and
Japanese
Select the ScreenManager’s language.
*1 Due to the inspection on the factory, the usage time may not “0 hour” at shipping.

English
18 3. ScreenManager
3-3. Useful Functions
Adjustment Lock
Use the “Adjustment Lock” function to prevent any accidental changes.
Locked function • Auto adjustment button adjustments and settings in the
ScreenManager.
Unlocked function • Adjustment of contrast and brightness by the control buttons.
• Sound control by the control buttons.
• Input signal selection button
• To lock
Switch off the monitor’s power by the power switch. Press on the Auto adjustment
button while switching on the monitor’s power.
• To unlock
Switch off the monitor’s power by the power switch, then hold down the Auto
adjustment button once again and turn the power back on.
Off Timer
The off timer function causes the monitor to automatically enter a power off state after
a predetermined amount of time has lapsed. This function was created to reduce
afterimage (p.36) characteristics that are particular to LCD monitors when the monitor
screen is left on for a long period without use.
[Procedure]
(1) Select <Off Timer> in the ScreenManager <Others> menu.
(2) Select “Enable” and press the right and left buttons to adjust the “On Period” (1 to
23 hours).
[Off timer system]
PC Monitor LED
On Period (1H - 23H) Operation Blue
Last 15 min. in "On period" Advance Notice *1 Blue Flashing
"On period" expired Power off Off
*1 Advance notice (LED flashing blue) will be given 15 minutes before the monitor
automatically enters the “Power Off” mode. To delay entering the “Power Off” mode, press
the power switch during the advance notice period. The monitor will continue to operate for
an additional 90 minutes.
[Procedure]
Press the power switch.
NOTE
• The off timer function works while the PowerManager is active, but there is no
advance notice before the monitor’s power is switched off.

English
3. ScreenManager
19
EIZO Logo disappearing function
When switching on the power button on the front panel, the EIZO logo is displyed for a
while. If you desire to display or undisplay this logo, use this function. (Default is logo
appearing.)
• To undisplay
Switch off the monitor’s power by the power switch, then hold down the Enter
button once again and turn the power back on.
• To display
Switch off the monitor’s power by the power switch, then hold down the Enter
button once again and turn the power back on.
Automatically selecting the input signal function
The monitor will automatically detect the inputted signal of either the connection for
display.
Connecting two PCs to the monitor
When the one computer is switched off or entering the power saving mode, the monitor
will automatically dislay the other signal.
Use the ScreenManager to switch the input selection to manual.
[Procedure]
(1) Select <Input Signal> in the <Others> menu.
(2) Select <Manual>.

English
20 4. ADJUSTMENT
4. ADJUSTMENT
The monitor displays the digital input image correctly based on its pre-setting
data. Adjust the contrast and brightness (p.22).
4-1. Screen Adjustment
Screen adjustments for the LCD monitor should be used in suppressing screen flickering
and also for adjusting the screen to its proper position. There is only one correct
position for each display mode. It is also recommended to use the ScreenManager
function when first installing the display or whenever changing the system.
Adjustment Procedure
NOTE
• Allow the LCD monitor to stabilize for at least 20 minutes before making image
adjustments.
1. Push the Auto adjustment button on the front panel.
The message “Your setting will be lost, if you press again now.” appears and
remains on the screen for 5 seconds. While the message is on the screen, push the
Auto adjustment button again to automatically adjust the clock, phase, and screen
position. If you do not wish to do adjust the screen, do not push the Auto
adjustment button again.
If the appropriate screen can not be made by using the Auto adjustment
button, adjust the screen through the following procedures. If the
appropriate screen can be made, proceed to step 4.
2. We recommend setting the desktop pattern to that as shown in the
diagram below.
NOTE
• More precise adjustment is available for using the “Screen Adjustment
program” utility software. It can be downloaded from the EIZO homepage
(http://www.eizo.com/).
