EKF SC2-PRESTO CompactPCI User manual

SC2-PRESTO
Product Information
SC2-PRESTO • CompactPCI ® Serial CPU Card
4th Generation Intel®Core™ Processor
Document No. 7046 • 19 June 2015

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
General
The SC2-PRESTO is a rich featured high
performance 4HP/3U CompactPCI®Serial CPU
board, equipped with a 4th generation Intel®
Core™ mobile processor (Haswell dual- or quad-
core). The SC2-PRESTO front panel is provided
with two Gigabit Ethernet jacks, two USB 3.0
receptacles, and two mDP connectors,
compliant with the DisplayPort 1.2 standard for
Multi-Stream-Transport (MST). Local expansion
mezzanine cards are available for additional I/O.
The SC2-PRESTO is equipped with up to 16GB
Low Power RAM with ECC support. 8GB
memory-down are provided for rugged
applications, and another 8GB are available via
the DDR3 ECC SO-DIMM socket. The on-board
SATA 6G RAID controller allows for powerful
mass storage solutions via the CompactPCI®
Serial backplane. Low profile SSD mezzanine
modules are available as on-board storage
solution, in addition.
SC2-PRESTO
© EKF -2- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
Feature Summary
General
<PICMG® CompactPCI® Serial (CPCI-S.0) CPU card
<Form factor single size Eurocard (board dimensions 100x1600mm2)
<Mounting height 3U
<Front panel width 4HP (8HP/12HP assembly with optional mezzanine side card)
<Front panel I/O connectors for typical system configuration (2 x USB3, 2 x DisplayPort, 2 x GbE)
<Backplane communication via PCI Express® Gen3, SATA 6G, USB 3.0, Gigabit Ethernet
<Local mezzanine expansion option (side card), COTS and custom specific boards
Processor
<4th Generation Intel® Core™ CPU Haswell (-Refresh) Mobile
<i7-4700EQ Processor 2.4/1.7GHz • 47W/37W TDP • Quad-Core • PCIe Gen 3
<i5-4400E Processor 2.7GHz • 37W TDP • Dual-Core • PCIe Gen 3
<i5-4422E Processor 1.8GHz • 25W TDP • Dual-Core • PCIe Gen 3
< i5-4402E Processor 1.6GHz • 25W TDP • Dual-Core • PCIe Gen 3
<i3-4110E Processor 2.4GHz • 25W TDP • Dual-Core • PCIe Gen 2
< i3-4100E Processor 2.4GHz • 37W TDP • Dual-Core • PCIe Gen 2
<i3-4112E Processor 1.8GHz • 25W TDP • Dual-Core • PCIe Gen 2
< i3-4102E Processor 1.6GHz • 25W TDP • Dual-Core • PCIe Gen 2
<Celeron 2000E Processor 2.2GHz • 37W TDP • Dual-Core • PCIe Gen 2
<Celeron 2002E Processor 1.5GHz • 25W TDP • Dual-Core • PCIe Gen 2
BIOS
<UEFI Phoenix® BIOS with ACPI
<Windows® and Linux supported (others on request)
Main Memory
<Integrated memory controller up to 16GB DDR3(L) 1600 +ECC
<DDR3(L) +ECC soldered memory up to 8GB
<DDR3(L) +ECC SO-DIMM memory module socket up to 8GB
© EKF -3- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
Feature Summary
Graphics
<Integrated HD Graphics Engine, 3 symmetric independent displays
<Enhanced Media Processing, DX11.1, OpenCL 1.2, OpenGL 3.2, JPEG, MJPEG, MVC, SVC, MPEG-2
<Front panel: Dual Mini-DisplayPort (mDP) or single VGA connector option
<3rd DisplayPort connector via mezzanine side card
<DisplayPort™ 1.2 Multi-Stream Transport (MST) - display daisy chaining
<Max Resolution 3200 x 2000 @60Hz (any DisplayPort), 1920 x 1200 (VGA)
<4k x 2k @24Hz supported for Blu-ray playback
<Integrated audio
Chipset
<Intel® QM87 Lynx Point Platform Controller Hub (PCH)
<8 x PCIe Gen2 5GT/s
<6 x SATA 6G
<10 x USB2, 4 x USB3
<LPC, Audio, Legacy
On-Board Building Blocks
<Additional on-board controllers, PCIe® based
<3 x Gigabit Ethernet controllers Intel® I210IT
<one of them supporting IEEE 1588-2008 Precision Time Protocol including PPS and PPM signals
<1 x Gigabit Ethernet PHY Intel® I217LM
<PCIe Gen2 packet switch 16-lane 16-port PLX 8618
<SATA 6G RAID controller Marvell® 88SE9230, ARM powered subsystem for host CPU offload
Security
<Trusted Platform Module (Option)
<TPM 2.0 for highest level of certified platform protection
<Infineon Optiga™ SLB 9665 cryptographic processor
<Conforming to TCG 2.0 specification
<Meets Microsoft Windows 8 boot time and performance criteria
© EKF -4- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
Feature Summary
Front Panel I/O (4HP)
<2 x Gigabit Ethernet RJ45 (1 = PCH & I217LM - iAMT, 2 = I210IT)
<2 x DisplayPort (from processor integrated HD graphics engine, mDP style receptacles, optional cable
connector retainer available)
<2 x USB 3.0
CompactPCI® Serial Backplane Resources
<PICMG® CPCI-S.0 CPU card & system slot controller
<16 x PCIe Gen3 8GT/s (2 links x 8 for two fat pipe slots, derived directly from the Intel® Core™ CPU
<6 x PCIe Gen2 5GT/s (6 links x 1 for peripheral slots)
<3 x SATA 6G (from PCH)
<4 x SATA 6G (Marvell hardware RAID controller)
<4 x USB2, 2 x USB3 (from PCH)
<2 x Gigabit Ethernet (I210IT networking controllers)
Local Expansion
<Mezzanine side card connectors for optional local expansion
<P-EXP - 2 x USB 2.0 & Legacy (from PCH)
<P-DP3 - 3rd DisplayPort video (from Intel® Core™ CPU)
<P-HSE - 3 x SATA 6G & 4 x USB 2.0 (from PCH)
<P-PCIE - PCIe Gen2 5GT/s 1 link x 4 lanes (from on-board PCIe® switch)
<4HP Low profile mezzanine module options
<CFast™ Card with C41-CFAST mezzanine module
<SATA 1.8-Inch Solid State Drive with C42-SATA mezzanine module
<Dual mSATA SSD with C47-MSATA mezzanine module
<Dual M.2/NGFF SATA SSD 2230 - 2280 size with C48-M2 mezzanine module
<Custom specific module design
<8HP/12HP Mezzanine side card options
<SCS-TRUMPET - 3rd DisplayPort F/P connector, RS-232, 2 x USB3, on-board 2.5-Inch SATA SSD or 2 x
M.2/NGFF SATA SSD module sockets 2230 - 2280
<Variety of other side cards available
<Custom specific side card design
© EKF -5- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
Feature Summary
SC2-PRESTO
Environmental & Regulatory
<Suitable e.g. for industrial, transportation & instrumentation applications
<Designed & manufactured in Germany
<ISO 9000 certified quality management
<Long term availability
<Rugged solution
<Coating, sealing, underfilling on request
<Lifetime application support
<RoHS compliant 2002/95/EC
<Operating temperature 0°C to +70°C
<Operating temperature -40°C to +85°C (industrial temperature range) on request
<Storage temperature -40°C to +85°C, max. gradient 5°C/min
<Humidity 5% ... 95% RH non condensing
<Altitude -300m ... +3000m
<Shock 15g 0.33ms, 6g 6ms
<Vibration 1g 5-2000Hz
<MTBF 11.7 years (SC2-680D)
<EC Regulatory EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1)
© EKF -6- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
P1
P2
P3
P4
P5
P6
CompactPCI® Serial • © EKF • ekf.com
HSE
EXP
PCIE
SDVO/DP
Dual
GbE
VGA
DP
2
DP
1
2 x
USB
3.0
CompactPCI® Serial
Connectors P1-P6
System Slot
up to 40 x PCIe
© EKF • ekf.com
8 x GE
7 x SATA
7 x USB3
4 x USB2
8
x PE (1)
x PE (2)
4
3 x USB2
I/O (DP)
4
4 x PE (5)
4
x PE (6)
x PE (4)
4 x PE (3)
4 x PE (8)
4
Clk PE (1-8)
x PE (7)
4 x PE (1)
1 x SATA
1 x USB2/3
Sideband
Power
General Backplane Connector Assignment
According to PICMG® CPCI-S.0
CompactPCI® Serial
While mechanically compliant to CompactPCI®
Classic, CompactPCI® Serial (PICMG® CPCIS.0)
defines a completely new card slot, based on
PCI Express®, SATA, Gigabit Ethernet and USB
serial data lines. Up to 6 high-speed backplane
connectors P1 - P6 are provided on a system
slot controller such as the SC2-PRESTO, which
can be considered as a root hub with respect to
most signal lines. A passive backplane is used
for distribution of a defined subset of I/O
channels from the system slot to each of up to
eight peripheral slots in a CompactPCI® Serial
system.
Most CompactPCI® Serial peripheral slot cards
require only the backplane connector P1, which
comprises PCIe, SATA and USB signals, resulting
in a concise and inexpensive peripheral board
design. More powerful peripheral cards profit
from two so called Fat Pipe slots (PCIe x 8).
The SC2-PRESTO is a native CompactPCI® Serial
CPU card, suitable for usage in a pure CPCI
Serial environment. Due to its generous
backplane capabilities (22 x PCI Express® lanes,
6 x USB, 7 x SATA/RAID, 2 x GbE), very powerful
industrial systems can be built.
© EKF -7- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC - • Resources w. 1+8 Slots Backplane2PRESTOR.1 (SystemSlotLe
f
t)
©EKF • ekf.com
3 x SATA (PCH)
4 x SATA (RAID)
1 x USB3 (2)
2 x USB2 (5-6)
PE Gen3 x 8 (2)
PE Gen3
½ x 8 (1)
2 x USB2 (3-4)
I/O
4 x PE (3-6)
Gen2
4 Links x 1
Clk PE (1-8)
2 x PE (7-8)
Gen2
2 Links x 1
GbE
(1-2)
GbE
(1)
GbE
(2)
PE Gen3
½ x 8 (1)
1 x USB3 (1)
Sideband
PE Gen3 x 8
USB3
PE Gen3 x 8
SATA 3G (PCH)
USB3
SC2-
PRESTO
Fat Pipe
Slot
PE Gen2 x 1
SATA 6G (RAID)
USB2
PE Gen2 x 1
SATA 6G (PCH)
PE Gen2 x 1
SATA 6G (RAID)
USB2
Fat Pipe
Slot
Peripheral
Slot
Peripheral
Slot
Peripheral
Slot
Peripheral
Slot
Peripheral
Slot
Peripheral
Slot
P1
P2
P3
P4
P5
P6
PE Gen2 x 1
SATA 6G (PCH)
PE Gen2 x 1
SATA 6G (RAID)
USB2
PE Gen2 x 1
SATA 6G (RAID)
USB2
PER
1
SYS
123456789
PER
2
PER
3
PER
4
PER
5
PER
6
PER
7
PER
8
Backplane Resources SC2-PRESTO (System Slot Left)
www.ekf.com/s/sc2/img/sc2_backplane.pdf
© EKF -8- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
8 + 1 Slots CompactPCI® Serial Backplane
Related Information
SC2-PRESTO Home www.ekf.com/s/sc2/sc2.html
SC2-PRESTO User Guide www.ekf.com/s/sc2/sc2_ug.pdf
General Information CompactPCI® PlusIO & CompactPCI® Serial
CompactPCI® Serial Concise Overview www.ekf.com/s/serial_concise.pdf
CompactPCI® Serial All You Need to Know www.ekf.com/s/smart_solution.pdf
CompactPCI® Serial Home www.ekf.com/s/serial.html
CompactPCI® PlusIO Home www.ekf.com/p/plus.html
© EKF -9- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO
4th Generation
Intel® Core™ i7 CPU
EKF ekf.com©•
P1
P2
P3
P4
P5
P6
SC2-PRESTO CompactPCI Serial EKF ekf.com•®•©•
HSE
3 x SATA 6G
(PCH)
4 x USB
LPC USB
SMBus
HD Audio
EXP
PCI Express®
Gen2
1 x 4
PCIE
Flat-
Panel
Video
DP 3
DP
To p S i d e
Connector Assembly
Front Panel - Mezzanine - Backplane
Dual
GbE
VGA
DP
2
DP
1
2 x
USB
3.0
PE Gen3 x 8 (2)
PE Gen3 ½ x 8 (1)
2 x USB2 (3-4)
PE Gen3 ½ x 8 (1)
1 x USB3 (1)
Sideband
Power
3 x SATA (PCH)
4 x SATA (RAID)
1 x USB3 (2)
2 x USB2 (5-6)
4 x PE (3-6)
Gen2
4 Links x 1
Clk PE (1-8)
2 x PE (7-8)
Gen2
2 Links x 1
GbE
(1-2)
J-GP
J-RTC
J-MFG
P-HSE
P-USB
P-FPH
P-ETH
P-DP3
P-EXP P-PCIE
P-DP1
P-DP2
P-VGA
SC2-PRESTO • Connector Assembly
Local Expansion
The SC2-PRESTO is equipped with a set of high-
speed local expansion interface connectors,
which can be optionally used to attach a
mezzanine side board. A variety of expansion
cards is available, e.g. providing legacy I/O such
as RS-232, and additional PCI Express® based
I/O controllers such as SATA, USB 3.0 and
Gigabit Ethernet, and also a third video output.
Most mezzanine side cards can accommodate
in addition a 2.5-inch drive. Typically, the
SC2-PRESTO and the related side card would
come as a readily assembled 8HP unit. As an
alternate, MicroSATA or mSATA SSD based low
profile mezzanine mass-storage modules are
available that fit into the SC2-PRESTO 4HP
envelope.
www.ekf.com/s/sc2/img/sc2_draft_mezzanine.pdf
Related Documents Mezzanine Modules and Side Cards
C4* Series
Mezzanine Storage Modules
www.ekf.com/c/ccpu/c4x_mezz_ovw.pdf
SCS-TRUMPET Mezzanine Side Card www.ekf.com/s/csc/scs.html
© EKF -10- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO w. SCS-TRUMPET Mezzanine Side Card 8HP Assembly
© EKF -11- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO Local Expansion I/F Connectors
© EKF -12- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO w. C47-MSATA Mezzanine Module 4HP Assembly
C47-MSATA • Low Profile Dual-SSD Mezzanine Module
© EKF -13- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO w. C48-M2 SATA Mezzanine Storage Modul 4HP Assembly
C48-M2 • Low Profile Dual M.2 SATA SSD Mezzanine Module
© EKF -14- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO w. C41-CFAST Mezzanine Module 4HP Assembly
SC2-PRESTO w. C42-SATA Mezzanine Module 4HP Assembly
© EKF -15- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
SC2-PRESTO w. C44-SATA Mezzanine Module 8HP Assembly
SC2-PRESTO w. C45-SATA Mezzanine Module 8HP Assembly
© EKF -16- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
8HP Assembly w. SCS-TRUMPET Side Card & 2.5-Inch SATA SSD
8HP Assembly w. SCS-TRUMPET Side Card & Dual M.2 SATA SSD
© EKF -17- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
Block Diagram
www.ekf.com/s/sc2/img/sc2_blk.pdf
DP3
Mezzanine
Side Card
I
/
O
VGA
DP 1.2 MST
QM87
Mobile
PCH
Next
Gen
Front
Panel
I/O
GbE
1
DP1
Front Panel Stuffing Alternates -
either Mini DisplayPort or VGA
USB3
GbE
PHY
SPI
Flash
GbE
2
PCIe Gen2
Switch
Simplified Block Diagram
SC2-PRESTO
PICMG CompactPCI Serial
®®
System Slot Controller
SPI
LPC
Option
USB2/3
USB2
/
3
USB2 USB2
2+10
LPC
/
Audio
/
SMB
/
GPIO
4
2
2
2
Backplane
CompactPCI
Serial
DP2
DDR3 ECC Soldered
DDR3 ECC SODIMM
DMI2
5GT/s
FDI
4th Gen ECC
ISG Mobile
CPU
2
/
4-Core
8
DDR3(L) 1600
Dual Channel
up to 16GB
P1 P2
FatPipe1
PCIe Gen3
8
2+4
4 6 4
6
P2
Fat Pipe 2
GbE
2
SATA
RAID
0/1/10 AES
42
2
GbE GbE
PCIe Gen3 PCIe Gen2
SATA 6G
GbE
NIC
GbE
NIC
PCIe
PCIe
GbE MAC
PCIe Gen2
DP 1.2 MST
1
USB3
PCIe Gen2
3 3
SATA 6G (2) SATA 3G (1)
•
9230 8618
SLB9665
2 x
I210IT
I210IT
Intel® 4th Gen Platform
Shark Bay
Haswell
i7-4700EQ
4C
1.7GHz
37W
i5-4400E 2C 2.7GHz 37W i5-4402E 2C 1.6GHz 25W i3-4100E 2C 2.4GHz 37W i3-4102E 2C 1.6GHz 25W
Lynx Point
TPM
2.0
SATA 6G (4) SATA 3G (2)
•
SATA 6G (2) SATA 3G (1)
•
I217LM
© EKF -18- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
GbE
SC2-PRESTO
Dual - mDP
HD
GEB
RST
2
SC2-PRESTO
VGA
© • •EKF draft - do not scale ekf.com
V
G
A
GbE
HD
GEB
RST
PG
GP
USB 3.0USB 3.0
PG
GP
mDP
1
Option Screw-Locked mDP Cable Connectors
Front Panel Options
© EKF -19- ekf.com

SC2-PRESTO • CompactPCI®Serial CPU Board • 4th Generation Intel® Core™ Processor
Sample Front Panel Options 8HP
1. Typical assembly, dual-USB 3.0, DisplayPort, 3.5mm stereo audio in/out, 2 x USB 2.0
2. Bottom RS-232 male D-Sub 9-pin (COM-A) replaces two USB 2.0 jacks
3. Top RS-232 male D-Sub 9-pin (COM-B) replaces dual-USB 3.0 and DisplayPort connectors
4. Center USB 2.0 receptacle replaces both 3.5mm stereo audio jacks
©
•
•
E
K
F
dr
a
ft - do
n
ot sc
a
le e
k
f.co
m
USB 3.0
mDP
SC2-PRESTO
Dual - mDP
HD
EB
RB
DP2
2
DP1
1
GbE
PG
GP
A
U
D
I
O
OUT
IN
USB 3.0
SCS-TRUMPET
STD
S
1
2
DP
D
U
S
B
1
© • •EKF draft - do not scale ekf.com
USB 3.0
mDP
SC2-PRESTO
Dual - mDP
HD
EB
RB
DP2
2
DP1
1
GbE
PG
GP
A
U
D
I
O
OUT
IN
C
O
M
A
USB 3.0
SCS-TRUMPET
1 x RS-232
1
2
DP
S
D
2
© • •EKF draft - do not scale ekf.com
USB 3.0
mDP
SC2-PRESTO
Dual - mDP
HD
EB
RB
DP2
2
DP1
1
GbE
PG
GP
C
O
M
A
C
O
M
B
USB
SCS-TRUMPET
2 x RS-232 / USB2
S
D
4
© • •EKF draft - do not scale ekf.com
USB 3.0
mDP
SC2-PRESTO
Dual - mDP
HD
EB
RB
DP2
2
DP1
1
GbE
PG
GP
A
U
D
I
O
OUT
IN
C
O
M
A
SCS-TRUMPET
2 x RS-232 / AUDIO
C
O
M
B
S
D
3
© EKF -20- ekf.com
