EKSA E5 User manual
E5
Active Noise-cancelling Wireless Headphones
2
1
Hearing Safety:
1. To avoid hearing damage, please do not listen for a long time
at high volume.
2. Please cautiously use or stop using in potentially dangerous
situations.
3. Do not use the headphones while driving.
4. For your safety, please do not turn the volume too high while
running outside, so that you can hear your surroundings.
Operation Safety:
1. Avoid dropping.
2. Do not disassemble.
3. Keep away from children to avoid danger from improper use.
4. Do not submerge in water.
5. Do not use the device outdoor during thunderstorm.
6. Avoid operate in extreme temperatures, please use the device
within its operation temperature: -15°C(5°F)~55°C(131°F).
7. Use original or certified cables to charge.
8. Do not use any corrosive cleaner/oil to clean the headphones.
Safety Instructions What’s in the box?
EN
E5
Active Noise-cancelling Wireless Headphones
警告/注意
www.eksa.net
info@eksa.net
2
1
Hearing Safety:
1. To avoid hearing damage, please do not listen for a long time
at high volume.
2. Please cautiously use or stop using in potentially dangerous
situations.
3. Do not use the headphones while driving.
4. For your safety, please do not turn the volume too high while
running outside, so that you can hear your surroundings.
Operation Safety:
1. Avoid dropping.
2. Do not disassemble.
3. Keep away from children to avoid danger from improper use.
4. Do not submerge in water.
5. Do not use the device outdoor during thunderstorm.
6. Avoid operate in extreme temperatures, please use the device
within its operation temperature: -15°C(5°F)~55°C(131°F).
7. Use original or certified cables to charge.
8. Do not use any corrosive cleaner/oil to clean the headphones.
Safety Instructions What’s in the box?
EN
E5
Active Noise-cancelling Wireless Headphones
警告/注意
www.eksa.net
43
At a Glance
How to use?
Hold Multi-function Button for 3 seconds to turn on the
headphones, and then the device enters the paring mode.
(Indication light turns blue)
Hold Multi-function Button for 3 seconds to turn off the
headphones.
Press to adjust volume. Long press to skip to
next/previous song.
Press and hold the volume up and down buttons
simultaneously for 5 second to clear the Bluetooth pairing
record.
Press Multi-function Button to play/pause music.
Hold the ANC button for one second to turn on/off Active
Noising cancelling(Indication light turns green)
Press Multi-function Button to answer/end call.
Double press Multi-function Button to reject coming call /
activate the Siri voice control function.
Charging cable: please use the included USB-C charging cable
to charge the battery, another charging cable may damage the
headphones.
Note:This product supports charging voltage of 5-9V, and it
will start charging protection once over 9V. The battery will not
be charged if over 9V, please use the correct charger.
ANC Button
ANC Indicator
LED Indicator
Multi-function Button
Volume Down/Previouse Song
Volume Up/Next Song
USB-C Charging/AUX Port
WARNING
The in-flight plug adaptor lets you enjoy balanced sound from the in-flight entertainment
system while travelling in a plane.
The In-flight adaptor is NOT MEANT to charge your device. Plugging the in-flight adaptor into
a AC Power Socket to charge the headphones will cause severe damage to the device.
43
At a Glance
How to use?
Hold Multi-function Button for 3 seconds to turn on the
headphones, and then the device enters the paring mode.
(Indication light turns blue)
Hold Multi-function Button for 3 seconds to turn off the
headphones.
Press to adjust volume. Long press to skip to
next/previous song.
Press and hold the volume up and down buttons
simultaneously for 5 second to clear the Bluetooth pairing
record.
Press Multi-function Button to play/pause music.
Hold the ANC button for one second to turn on/off Active
Noising cancelling(Indication light turns green)
Press Multi-function Button to answer/end call.
Double press Multi-function Button to reject coming call /
activate the Siri voice control function.
Charging cable: please use the included USB-C charging cable
to charge the battery, another charging cable may damage the
headphones.
Note:This product supports charging voltage of 5-9V, and it
will start charging protection once over 9V. The battery will not
be charged if over 9V, please use the correct charger.
ANC Button
ANC Indicator
LED Indicator
Multi-function Button
Volume Down/Previouse Song
Volume Up/Next Song
USB-C Charging/AUX Port
WARNING
The in-flight plug adaptor lets you enjoy balanced sound from the in-flight entertainment
system while travelling in a plane.
The In-flight adaptor is NOT MEANT to charge your device. Plugging the in-flight adaptor into
a AC Power Socket to charge the headphones will cause severe damage to the device.
Easy Pairing
1. Hold Power Button for 3 seconds to turn on the
headphones, and then the device enter paring mode.
2. Keep the headphones and your Bluetooth device as close
as possible during the pairing process.
3. Turn on Bluetooth function of your Bluetooth device.
Search headphones' Bluetooth signal on your Bluetooth
device, and select “E5” to pair it with your Bluetooth
device. The Indicator Light slowly flashes blue when the
headphones pair successfully.
4. lf you are asked for the Password/PIN code during the
pairing procedure, enter “0000” (four zeros).
Pair to The Second Bluetooth Device
1. Make sure the headphones have been connected to the
first Bluetooth device successfully. And the headphones are
not playing music.
2. Turn off the first device’s Bluetooth.
3. Turn on the second device’s Bluetooth, find the “E5” model
name and select it to pair with your device.
4. Turn on the first device’s Bluetooth and select “E5” pair
it again.
Restore factory setting
Press and hold the volume up and down buttons simultaneously
for 5 second to clear the Bluetooth pairing record.
65
Functions
ANC-Active Noise Cancelling :
Turn on ANC: Hold the ANC button for one second and the
ANC Indicator light on green.
Turn off ANC: Hold the ANC button for one second and the
ANC Indicator turns off.
AUX Wired Connection:
The headphones supports AUX input for wired external audio
source connection. Simply Power Off the headphones and plug
in the audio cable.(Note：Wired mode is not available when the
headphones ran out of battery)
NOTE: The buttons and microphone on EKSA E5 will not work
when connected as wired headphones.
NOTE: EKSA E5 only has one audio channel, if you want
to play music from another Bluetooth device, please pause the
current device's music first
Easy Pairing
1. Hold Power Button for 3 seconds to turn on the
headphones, and then the device enter paring mode.
2. Keep the headphones and your Bluetooth device as close
as possible during the pairing process.
3. Turn on Bluetooth function of your Bluetooth device.
Search headphones' Bluetooth signal on your Bluetooth
device, and select “E5” to pair it with your Bluetooth
device. The Indicator Light slowly flashes blue when the
headphones pair successfully.
4. lf you are asked for the Password/PIN code during the
pairing procedure, enter “0000” (four zeros).
Pair to The Second Bluetooth Device
1. Make sure the headphones have been connected to the
first Bluetooth device successfully. And the headphones are
not playing music.
2. Turn off the first device’s Bluetooth.
3. Turn on the second device’s Bluetooth, find the “E5” model
name and select it to pair with your device.
4. Turn on the first device’s Bluetooth and select “E5” pair
it again.
Restore factory setting
Press and hold the volume up and down buttons simultaneously
for 5 second to clear the Bluetooth pairing record.
65
Functions
ANC-Active Noise Cancelling :
Turn on ANC: Hold the ANC button for one second and the
ANC Indicator light on green.
Turn off ANC: Hold the ANC button for one second and the
ANC Indicator turns off.
AUX Wired Connection:
The headphones supports AUX input for wired external audio
source connection. Simply Power Off the headphones and plug
in the audio cable.(Note：Wired mode is not available when the
headphones ran out of battery)
NOTE: The buttons and microphone on EKSA E5 will not work
when connected as wired headphones.
NOTE: EKSA E5 only has one audio channel, if you want
to play music from another Bluetooth device, please pause the
current device's music first
78
Technical Specifcation
Product Name: E5
Bluetooth Version: V5.0
Battery Capacity: 920mAH
Input: 5V 470mA
Bluetooth Chipset: QCC3003
Noise Reduction Depth: -20~-25dB
Speaker: Φ40 mm
Charging Time: About 2.5 hours
Using Time 1: 40 hours (ANC+BT)
Using Time 2: 60 hours (BT only)
Using Time 3: 154 hours (ANC only)
Bluetooth Profile: A2DP AVRCP HFP HSP SPP DID PXP FM
BAS
Bluetooth Range: 10m/33ft
Net Weight: 250g
Impedance: 32Ω
Driver Diameter: 40mm
Frequency Response: 20Hz-20kHz
Specification
Pairing: Red and blue light flash alternately
Paired: Blue light flashes
Playing: Slow flashes blue light
Charging: Red light on
Full Charge: Red light turns off
Battery Low: Red light flashes with voice prompt
ANC Working: Green Light turns on
Indicator Light
Collapsible Design
78
Technical Specifcation
Product Name: E5
Bluetooth Version: V5.0
Battery Capacity: 920mAH
Input: 5V 470mA
Bluetooth Chipset: QCC3003
Noise Reduction Depth: -20~-25dB
Speaker: Φ40 mm
Charging Time: About 2.5 hours
Using Time 1: 40 hours (ANC+BT)
Using Time 2: 60 hours (BT only)
Using Time 3: 154 hours (ANC only)
Bluetooth Profile: A2DP AVRCP HFP HSP SPP DID PXP FM
BAS
Bluetooth Range: 10m/33ft
Net Weight: 250g
Impedance: 32Ω
Driver Diameter: 40mm
Frequency Response: 20Hz-20kHz
Specification
Pairing: Red and blue light flash alternately
Paired: Blue light flashes
Playing: Slow flashes blue light
Charging: Red light on
Full Charge: Red light turns off
Battery Low: Red light flashes with voice prompt
ANC Working: Green Light turns on
Indicator Light
Collapsible Design
9 10
Q & A
Why the headphones can't pair with my mobile phone?
Please check whether your headphones are in pairing mode
or reconnection mode, check if Bluetooth search function
of your Bluetooth device has been turned on. And then go
to Bluetooth menu of your Bluetooth device, delete/forget
the headphones, and reconnect the headphones.
Why headphones can't be turned on?
Please double check battery status of your headphones.
Can I replace battery for the headphones?
No. these headphones use built-in non detachable
Li-Polymer battery. lt can't be replaced.
Can l use the headphones while driving?
For your safety, we strongly recommend you to not use
headphones to avoid distraction while driving.
Why the headphones sometimes disconnect with Bluetooth
device within 10 meters?
Please check if there is any metal material within relatively
close range may interfere Bluetooth connection. Because
Bluetooth is a radio technology that is sensitive to objects
between the headphones and its connected devices.
and its connected devices.
Why I cannot hear any voice from my computer or
mobile phone?
Please check if the output channel of your computer
support A2DP profle. And please check the volume of
your headphones, as well as computer/mobile phone.
Why am I unable to use the headphones to control
volume of select track of APP in my mobile phone?
Due to configuration of different application software, the
headphones may not totally compatible with some
applications.
What can I do if the Bluetooth is crashed?
(Cannot close or open)
Please reset headphone Bluetooth by inserting audio cable
into audio jack then removing it.
Why the Bluetooth is turned off when I use the audio
cable to connect?
This is our special set. All Bluetooth feature buttons stop
working and Bluetooth should be turned off when users
insert audio cable into jack. Don't worry, the Bluetooth will
be available when the audio cable is moved.
Why does the headphones not work when using audio cable?
If the battery of the headphones is completely dead, it cannot
be used in the wired state. Please after charging the
headphones for 10 minutes and then use the audio cable to
enter wired mode.
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
9 10
Q & A
Why the headphones can't pair with my mobile phone?
Please check whether your headphones are in pairing mode
or reconnection mode, check if Bluetooth search function
of your Bluetooth device has been turned on. And then go
to Bluetooth menu of your Bluetooth device, delete/forget
the headphones, and reconnect the headphones.
Why headphones can't be turned on?
Please double check battery status of your headphones.
Can I replace battery for the headphones?
No. these headphones use built-in non detachable
Li-Polymer battery. lt can't be replaced.
Can l use the headphones while driving?
For your safety, we strongly recommend you to not use
headphones to avoid distraction while driving.
Why the headphones sometimes disconnect with Bluetooth
device within 10 meters?
Please check if there is any metal material within relatively
close range may interfere Bluetooth connection. Because
Bluetooth is a radio technology that is sensitive to objects
between the headphones and its connected devices.
and its connected devices.
Why I cannot hear any voice from my computer or
mobile phone?
Please check if the output channel of your computer
support A2DP profle. And please check the volume of
your headphones, as well as computer/mobile phone.
Why am I unable to use the headphones to control
volume of select track of APP in my mobile phone?
Due to configuration of different application software, the
headphones may not totally compatible with some
applications.
What can I do if the Bluetooth is crashed?
(Cannot close or open)
Please reset headphone Bluetooth by inserting audio cable
into audio jack then removing it.
Why the Bluetooth is turned off when I use the audio
cable to connect?
This is our special set. All Bluetooth feature buttons stop
working and Bluetooth should be turned off when users
insert audio cable into jack. Don't worry, the Bluetooth will
be available when the audio cable is moved.
Why does the headphones not work when using audio cable?
If the battery of the headphones is completely dead, it cannot
be used in the wired state. Please after charging the
headphones for 10 minutes and then use the audio cable to
enter wired mode.
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
Q:
A:
11 12
Please sign up for EKSA warranty service at www.eksa.net. EKSA warrants
that this product, for 2 years from the date of retail purchased by the
original end-user. And it is delivered from EKSA authorized reseller, in
original package, in new condition and is free from any defects in
manufacturing and workmanship. We will repair or replace (using new or
refurbished replacement product) any defective product within a
reasonable period and free of charge.
This warranty does not cover defects resulting from improper or
unreasonable use or maintenance; failure to follow operating instructions;
accidents; excess moistures;insects; lightning; unautho-rized alteration or
modification of original condition; damage caused by inadequate packing
or shipping procedures; loss of, damage to or corruption of stored data;
damage caused by use with non-EKSA products; the product that requires
modification or adaptation to enable it to operate in any country other
than the country for which it was designed, manufactured, approved
and/or authorized, or repair of products damaged by their modifications;
and products purchase from unauthorized dealers.
Please contact info@eksa.net soonwith order number in
e-commerce website after you discover a product defect
(or should have discovered it, if such product defect was
obvious);
In order to get professional solutions from OneOdio, please give a
detailed explanation of how the damage occurred.
This limited warranty gives you specific legal rights, and you
also may have other rights that vary from state to state or
country to country. Some places do not allow limitations on
implied warranties or the exclusion or limitation of incidental
or consequential damages, so the above limitations or
exclusions may not apply to you. Thank you for choosing
EKSA. We hope you enjoy our product. Do you like the
purchase experience in our store? We'd appreciate it if you
can share your fair product review and feedback. If you are
you can contact us via HongKong Customer Center: +852 6940
4955 (Mon to Fri 9:00 am- 6:30 pm, UTC+8 HKT) India Customer
Center: +91 84319 76061 (Mon to Sat IST 9:30 am-6:00 pm) so
that we may a ddress your concerns before you leave a product
review.
If you can’t connect the headset/headphones to your devices, please
ask us for complete FAQ guidance. You can find the solution finally.
Depending on your head/ear size/shape, it may be a little tight (feels
like“on ear") for someone to wear which is designed to avoid sound
leakage. In case of that and to get both audio and wearing comfort,
please take off the headphone every 1~2 hours to get your ears
relaxed and protect them from the muggy environment in use.
Please follow us on Facebook @EKSA Global,Twitter, Instagram, and
YouTube @EKSAtech for new product release and promotion info.
repair or replace (using new or refurbished replacement
parts) any defective parts within a reasonable period
of time and free of charge.
Email us at info@eksa.net with faulty products. Please attach the video
and the description of the product. We could solve the problem with
more details timely. Those who email with videos and detailed
descriptions will be awarded with 1 gift products.
In the event damage has occurred to products, you must follow these
instructions:
11 12
Please sign up for EKSA warranty service at www.eksa.net. EKSA warrants
that this product, for 2 years from the date of retail purchased by the
original end-user. And it is delivered from EKSA authorized reseller, in
original package, in new condition and is free from any defects in
manufacturing and workmanship. We will repair or replace (using new or
refurbished replacement product) any defective product within a
reasonable period and free of charge.
This warranty does not cover defects resulting from improper or
unreasonable use or maintenance; failure to follow operating instructions;
accidents; excess moistures;insects; lightning; unautho-rized alteration or
modification of original condition; damage caused by inadequate packing
or shipping procedures; loss of, damage to or corruption of stored data;
damage caused by use with non-EKSA products; the product that requires
modification or adaptation to enable it to operate in any country other
than the country for which it was designed, manufactured, approved
and/or authorized, or repair of products damaged by their modifications;
and products purchase from unauthorized dealers.
Please contact info@eksa.net soonwith order number in
e-commerce website after you discover a product defect
(or should have discovered it, if such product defect was
obvious);
In order to get professional solutions from OneOdio, please give a
detailed explanation of how the damage occurred.
This limited warranty gives you specific legal rights, and you
also may have other rights that vary from state to state or
country to country. Some places do not allow limitations on
implied warranties or the exclusion or limitation of incidental
or consequential damages, so the above limitations or
exclusions may not apply to you. Thank you for choosing
EKSA. We hope you enjoy our product. Do you like the
purchase experience in our store? We'd appreciate it if you
can share your fair product review and feedback. If you are
you can contact us via HongKong Customer Center: +852 6940
4955 (Mon to Fri 9:00 am- 6:30 pm, UTC+8 HKT) India Customer
Center: +91 84319 76061 (Mon to Sat IST 9:30 am-6:00 pm) so
that we may a ddress your concerns before you leave a product
review.
If you can’t connect the headset/headphones to your devices, please
ask us for complete FAQ guidance. You can find the solution finally.
Depending on your head/ear size/shape, it may be a little tight (feels
like“on ear") for someone to wear which is designed to avoid sound
leakage. In case of that and to get both audio and wearing comfort,
please take off the headphone every 1~2 hours to get your ears
relaxed and protect them from the muggy environment in use.
Please follow us on Facebook @EKSA Global,Twitter, Instagram, and
YouTube @EKSAtech for new product release and promotion info.
repair or replace (using new or refurbished replacement
parts) any defective parts within a reasonable period
of time and free of charge.
and the description of the product. We could solve the problem with
more details timely. Those who email with videos and detailed
descriptions will be awarded with 1 gift products.
In the event damage has occurred to products, you must follow these
instructions:
E5
Active Noise-cancelling Wireless Headphones
Other manuals for E5
1
Table of contents
Other EKSA Wireless Headphones manuals
