HC-880 Coffee Grinder
OPERATING & SERVICE MANUAL


HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page2of12

2011.05Ver.1.2
WARNINGS
Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
givensupervisionorinstructionconcerninguseoftheappliancebyapersonresponsiblefor
theirsafety.
Childrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
Careisneededwhenhandlingcuttingbladesduringcleaning.
Ifthesupplycordisdamaged,itmustbereplacedbythemanufactureroritsserviceagent
orasimilarlyqualifiedpersoninordertoavoidahazard.

CorrectDisposalofthisproduct
Thismarkingindicatesthatthisproductshouldnotbedisposedwithotherhouseholdwastes
throughouttheEU.Topreventpossibleharmtotheenvironmentorhumanhealthfrom
uncontrolledwastedisposal,recycleitresponsiblytopromotethesustainablereuseof
materialresources.Toreturnyouruseddevice,pleaseusethereturnandcollectionsystems
orcontacttheretailerwheretheproductwaspurchased.Theycantakethisproductfor
environmentalsaferecycling.
WarrantyInformation
Themanufacturerprovideswarrantyinaccordancewiththelegislationofthecustomer'sowncountry
ofresidence,withaminimumof1year(Germany:2years),startingfromthedateonwhich
theapplianceissoldtotheenduser.Thewarrantyonlycoversdefectsinmaterialor
workmanship.Therepairsunderwarrantymayonlybecarriedoutbyanauthorizedservice
center.Whenmakingaclaimunderthewarranty,theoriginalbillofpurchase(with
purchasedate)mustbesubmitted.
Thewarrantywillnotapplyincasesof:
•Normalwearandtear
•Incorrectuse,e.g.Overloadingoftheappliance,useofnon‐approvedaccessories
•Useofforce,damagecausedbyexternalinfluences
•Damagecausedbynon‐observanceoftheusermanual,e.g.Connectiontoanunsuitable
mainssupplyornon‐compliancewiththeinstallationinstructions
•Partiallyorcompletelydismantledappliances

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page3of12

2011.05Ver.1.2
TABLEofCONTENTS


1)Preface………………………………………………………………….4.
2)TechnicalSpecifications..........................................4.
3)GeneralDescription………………………………………………5.
4)Unpackingandinstallation……………………………………5.
5)Operation……………………………………………………………..6.
6)Safetydevices……………………………………………………….8.
7)Safetyinstructions………………………………………………..8.
8)Maintenanceandservice………………………………………9.
9)Cleaning………………………………………………………………..9.



HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page4of12

2011.05Ver.1.2

1) PREFACE

CongratulationsforpurchasingtheHC‐880grocerygrinder.TheHC‐880isacommercial
appliancetobeusedingroceriescoffeeshops,coffeeroasters,espressobars,hotelsand
restaurants.HC‐880willgrindwholebeencoffeeandfillupcoffeebagswithvariable,user‐
selectable(fromsuperfinetocourse)coffeepowder.
Readthismanualfromcovertocoverbeforeusingtheapplianceasitcontainsimportant
instructionsforthesafety,operation,andmaintenanceoftheappliance.Keepthemanualin
asafeplaceforfutureuseandreference.
ThismanualbookandadditionaltechnicalsupportcanbedownloadedatHeyCafé’swebsite:
www.heycafe.com
Themanufacturerreservestherighttomodifytheapplianceandthemanualaccordingly.

2) TECHNICALSPECIFICATIONSofHC880

Dimensions:
Height:615mm,Width:180mm,Length:390mm
Weight:21Kg
Burrsdiameter:84mm
Basichopper’scapacity:600gr.Coffeebeans
Hopper’sextension:1300gr
ElectricalSpecifications:
USA:110V/60Hz
Europe:230V/50Hz
MaxCurrentconsumption:3.0A
Grindingcapacities:
13‐16Kg/hour

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page5of12

2011.05Ver.1.2
3) GeneralDescription

4) UNPACKINGANDINSTALLATION:




1.Afteropeninggrinder’spackage,makesurethattheapplianceisintactandthatthereis
novisibledamage.Ifthereisanydoubt,DONOTcontinuetheinstallationprocedureand
contactyourlocaldealerforfurtherassistance.
2.Unpacktheproductcarefully.Foryourconveniencewesuggeststoringallpackaging
materialswheretheycanbeusedinthefuture,whenevertheappliance’stransportation
isnecessary.
3.Placethegrinderonastableflatcounterinadryareaawayfromwaterorwatersplashes.
4.Openhopper’sbeanslidandvisuallyinspectthattherenoforeignobjectsofanykind
removeanyforeignobjectaccordingly.
5.Openthegrinder’scoffeeresiduetraytothedesiredopeningdistancebypullingtray’s
lockingknob.
6.Beforepluggingintheelectricalcord,makesure:
a)Theappliancevoltageandfrequencyrating(accordingtothebacksidelabel)isthe
sameasthesupplymains.
b)Thewallsocketisfittedwithanefficientgroundcontact.
c)DONOTplugtheapplianceintothesupplymainsifagroundsystemisnotavailable
inmainssocket,andwasnotpositivelycheckedtobeincompliancewith
national/localelectricalcodes.
d)ITISCOMPULSORYTOGROUNDTHEAPPLIANCE.
e)Themanufacturercannotbeheldresponsibleintheeventthatthisregulationisnot
compliedwith.
f)Thepowerconsumptionoftheappliance(accordingtothebacksidelabel)is
consistentwiththerelevantwallsocketcapacity.
g)Thewallsocketisprotectedagainstshort‐outsandpowersurges.
h)Donotuseextensioncables,plugadaptersformultiplesockets,ormakeshift
connections.
7.Plugintheappliance.
Beanshopperlid

Beanshopper
Coffeepowderoutletchute
Mainswitch
Grindingdial
Grinder’sbody
Coffeebagdetector
Residuetray Maintrayknob

Warning:Allappliances’technicalhandlingoperationssuchasinstallation,maintenance,
orserviceshouldbeperformedbycertifiedpersonnelorbyyourlocaldealer.

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page6of12

2011.05Ver.1.2
5) OPERATION
OPERATIONALCONTROLS
1.TheapplianceisequippedwithmainOFF/ON/RUNswitchlocatedonthefrontpanel.The
grinderwillnotrunaslongasacoffeepowderbagisnotpresentedunderpowder’s
chute.
2.Afterplacingacoffeepowderbagunderthepowder’schute,pushthemainswitchto
RUNposition,inordertostartgrinding.
3.InordertostopgrindingusershouldpushthemainswitchtoOFFposition.
4.Grindingsettingknobwillallowtheuserselectinghisdesiredgrindingprogramaccording
powder’scoarsenessrequirement.
5.Grindingcleaning(shaking)knoblocatedonthepowderchuterightside,shouldbe
pressedandreleasedfewtimesduringnormalgrindingoperationinordertoallow
completeemptyingthegrindinghouse.
6.Makesurethecoffeepowder’sbag’svolumeisbiggerthantheamountofgrindedcoffee
andiscompletelyopenwhilegrindingtoallowthepowderfallfreelyintothepowder’s
baginordertopreventbackcloggingofthecoffeegrinder.

FIRSTTIMEOPERATION:
1.Plugtheelectricalwireintowallsocket.
2.Slipanemptybagunderthepowderchuteandrestitfreelyonresiduetray(makesure
thebagisplacedhigherthanthebagpresenceswitch).
3.Selectcoarsestpositionofgrindingknob.
4.DONOTINTRODUCEWHOLEBEANSINTOTHEBEANSHOPPERYET.
5.StarttheHC880grinderbypressingthemainswitchfromOfftoONandthenfromONto
Run.LetthegrinderrunforfewminutesandthenturnitOFFbyswitchingtoOFF
position.
6.Repeatstep5andthistimechangethegrindingselectionstepbysteptillreachingfinest
position.Repeatitforseveraltimes.ObserveandlistentotheHC880grinder.Forany
abnormalorexcessivenoiserefertoyourlocaldealer.

GRINDINGCOFFEE:
1.Plugtheelectricalwireintowallsocket.
2.Purethedesiredamountofbeansintothehopper(forquantitiesof600grusethe
hopperextension),afterdoingso,completelyclosehopperlid.
3.Selectthedesiredgrindingprogramonthegrindingknob.
4.Slipanemptybagunderthepowderchuteandrestitfreelyonresiduetray(makesure
thebagisplacedhigherthanthebagpresenceswitch).
5.PressmainswitchfromOfftoONandthentoRun(theswitchreturntoONpositionby
itself).
6.Whilegrindingpullandreleasegrindingcleaningknob2‐3timesperminute.
7.Whengrindingiscompleted,switchthemainswitchtoOFFpositionorsimplypullout
thecoffeebag,bothactionswillstopgrindingoperation.

Operationintervals:
Itisanormaloccurrencethatduringlonggrindingperiodsthegrindingchamberwillheatup.
Inordertoachievebestgrindingresults,itisrecommendedtogrindcoffeeinshortintervals
ofnolongerthan10minutesgrindingperperiodof15‐20minutes.


HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page7of12

2011.05Ver.1.2
ADJUSTMENTSOFGRINDINGOPERATION:

HC880wasfactorytunedfordifferenttypesofcoffeepowders,fromfinestTurkishcoffeeto
coarsesthandfiltercoffee.Neverthelesssomechangesintuningmayoccurincourseoftime
andafterthoroughcleaningprocedures.Ifyoufeelyourgrinderisoutoftune(either
squeakingnoiseonfinestscaleorgrindingpowderistoocoarseonfinestscale)pleaserun
throughthefollowingprocedure.
BeforestartingtheretuningprocedureoftheHC880youshouldreadthecompletesetof
instructionsandunderstanditcompletely.
1. Placeanemptybagorboxunderthepowderchute(makesuretoactivatethebag
switch).
2. Turnonthegrinder
3. Emptythemachinecompletelybygrindinganycoffeebeansleft‐overandbypulling
andreleasingthecleaningleverforseveraltimeswhilechangingthedialposition
fromendtoendfewtimesuntilnomorepowderiscomingout.
4. PositionthegrindingdialknobonTurkishcoffeeandturnofftheGrinder.
5. Usingflatscrewdriverremovethelogoshieldofthegrindingknob.
6. Usecrossedscrewdrivertoreleasetheknob’smainscrew,andpullouttheknob.
7. Thebrassinternalknobwillbeexposed.
8. Observethecurrentpositionoflinemarkoninternalknobrelativelytotheline
marksongrindingcover.(possiblyuseamarkertomarkthispositiononthe
grinder’scover)
9. TurnONthegrinder,then:
a. IfthegrinderwassqueakingonTurkishcoffeeposition,turntheinternal
knob1‐2notchestotheleft(CCW)anduntilnoiselevelofoperationis
regular.
b. IfyoufeelthatthegrindingisnotfineenoughonTurkishcoffeeposition,
thenrotatetheinternalknob1‐2notchestotheright(CW)andcontinue
rotating(CW)untilyouhearthemetaltometalsqueakingnoisethenopen
again(CCW)untilitissilentagain.
10. REMARK:iffromsqueakingpositiontosilentarearequiresmorethan4notcheson
theinternalknobitmeansthemachineneedtobeexaminedbyatechnician.Call
yourtechniciananddonotcontinueandoperatethegrinderuntilitisthoroughly
examined.
11. TurnOFFthegrinder,re‐assembletheknobonTurkishcoffeeposition,tightenthe
screwandplacetheLogocoverbackintoitsposition.
12. Checkthegrinderbygrindingcoffeebeanstovarioustypesofcoffeepowderand
repeattheentireprocessifnecessary.


HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page8of12

2011.05Ver.1.2
6) SAFETYDEVICES

1. Thermaloverloadprotection:
Inordertoeliminatetheriskoffire,themotorisequippedwithanover‐heatprotection
devicewhichwillcut‐offthemotor’spowersupplyshoulditreachahightemperature.
Intheeventthatthethermalprotectionistrippedasaresultofmalfunction(e.g.:jammed
blades,wornoutbearings,foreignobjectingrindingchamber,etc.)theappliancemain
switchshouldbeturnedoffimmediatelyandthemainpowerplugmustbedisconnected.
Forfurtherhandlingofthedevicecontactyourlocalserviceprovider,andallowthe
appliancetocooldownbeforeanyfurthermaintenance.
Intheeventthatthethermalprotectionistrippedasaresultofalongcontinuousoperation
allowtheappliancetocooldown.Resetthethermalcutoffprotectionbyunpluggingthe
maincablefromthesocket.Onthefirstoperationafterresettingatrippedover‐heat
protectiondeviceobservethegrindingqualityandnoiselevel,andifthereareany
irregularitiesshutdowntheapplianceandcallacertifiedtechnicianforacompleteanalysis
oftheappliance.
2. Beansconveyorandgrindingchambersafetycover:
Thegrindingchambercanbeahazardousareaiftheproperprecautionsaren’tobserved.
Thebeanshopperisequippedwithhandsandfingerssafetyprotector.Neverremovethe
safetyprotectorwhiletheHC880grinderispluggedin.
3. Bagpresenceswitch:
AbagpresenceswitchwasinstalledInordertoavoidforeignbodiesplungedintothe
grindinghousefrompowder’soutletdirectionandinordertoavoidaccidentalgrindof
beanswithoutcollectingbagforthepowder.
NeveroperatetheHC880grinderwhenthebagpresenceswitchisdisassembledor
bypassed

7) SAFETYINSTRUCTIONS

1. NEVEROPERATETHEGRINDERIFTHEBEANHOPPERISNOTFULLYSECUREDTOTHE
GRINDER’SBODY.BEFOREREMOVINGTHEHOPPERFORANYREASONMAKESURETO
DISCONNECTTHEPOWERSUPPLY.
2. NEVERCLEARFOREIGNOBJECTSFROMTHEBEANSCONVEYORORBEANSHOPPERWHEN
THEAPPLIANCEISPLUGGEDINTOAPOWERSOCKET.
3. BEFOREANYMAINTENANCE,EVENFORCLEANING,ALWAYSDISCONNECTTHEPOWER
SUPPLY.
4. Neverattempttoinsertyourfingersoranyforeignobjectsintothegrindingchamberor
blades.
5. BeawarethatgrindingbladescontinuerotatingforashortwhileafterswitchingOFFthe
applianceandthegrindingoperationhasended.
6. Intheeventthattheappliancehasamalfunctionorthebladesneedtobereplaced,do
notattempttoservicetheappliancebyyourself.
7. Donotchangeortamperwiththeappliance.
8. Donotusetheappliancebarefootorifyourhandsorfeetaredamp.
9. Donotusethecablewiretopullanddisconnectthepowerplug.
10.Alwayskeeptheappliancedry(internallyandexternally).
11.Neverputgrindedcoffeeintothehopper.
12.Neverattemptgrindinganythingelseotherthancoffeebeans.

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page9of12

2011.05Ver.1.2

8) MAINTENANCEANDSERVICE



Followingthisrulewillensurelong‐lastingandreliableperformanceofyourappliance.
Checkthestateofthegrindingbladesperiodically(approximatelyevery100kgofgrinded
coffee).Goodconditionbladeswillresultinahighqualitygrindandpreventtheappliance’s
over‐heating.Replacegrindingbladesevery400kgofgrindedcoffee(withnormalhardness
blades).

Beawareoftheappliance’snoiselevel.Incasethenoiselevelishigherthannormalor
irregularnoisesarecomingfromwithintheappliance,getcertifiedpersonneltoperforman
overallcheckoftheappliance.

9) CLEANING

BEFOREANYCLEANINGROUTINEDISCONNECTTHEAPPLIANCEPOWERSUPPLY.
NEVERUSERUNNINGWATERTOCLEANTHEMAINBODYANDPOWDERSHUT.
USEONLYPERFECTLYCLEANCLOTHSORBRUSHESTOCLEANTHEAPPLIANCE.
DONOTUSEABRASIVECLEANINGPRODUCTSASTHEYMAYWEAROUTTHEAPPLIANCE
COATING.
Cleaningthebeanhopper
1. Takeoffthebeanhopper(byreleasingBeanHopperscrews)
2. Rinseitthoroughlywithwaterandsoap.
3. AsthebeanshopperismadeofABS,useonlyliquiddetergent(freeofabrasive
components)andsoftsponge.
4. Beforereinstallingthebeanshopperbacktoitsposition,makesureitisdried
thoroughly.

Cleaningthegrindingchamber
BeforestartingthethoroughcleaningprocedureoftheHC880youshouldreadthecomplete
setofinstructionsandunderstanditcompletely.
1. Placeanemptybagorboxunderthepowderchute(makesuretoactivatethebag
switch).
2. Emptythemachinecompletelybygrindinganycoffeebeansleft‐overandbypulling
andreleasingthecleaningleverforseveraltimeswhilechangingthedialposition
fromendtoendfewtimesuntilnomorepowderiscomingout.
3. PositionthegrindingdialknobonTurkishcoffeeandturnofftheGrinder.
4. Usingflatscrewdriverremovethelogosignofthegrindingknob.
5. Usecrossedscrewdrivertoreleasetheknob’smainscrew,andpullouttheknob.
6. Theinternalknobwillbeexposed,observeandmemorizethecurrentpositionof
linemarkoninternalknobrelativelytothelinemarksongrindingcover.
7. Useacrossscrewdrivertoreleasethe4screwsthatsecurethegrindingfrontcover.
8. Pullouttheentirefrontcover.Itisthegrindingfrontcover,grindinghouseand
shafts.

Warning:Allappliances’technicalhandlingoperations,suchasinstallation,maintenance,
orserviceshouldbeperformedbycertifiedpersonnelorbyyourlocaldealer.

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page10of12

2011.05Ver.1.2

9. Pulloutthefrontbladeholderassembly.Payattentiontothespringattheendof
thebeansconveyor,itshouldbekeptfortheaftercleaningassemblyprocess.
10. Usebrushandclothstocleanallthepartsthoroughly(donotuseflushingwateras
partsmaygetcorroded)
a. Donotusesharpobjectstoscrapecoffeeresidueoffoftheblades.
b. Examinebothoftheblades’conditionandreplacethemifnecessary.
c. Thereplacementandassemblyofanewsetofbladesisadelicatetask.Only
skilledtechnicalpersonnelshouldbeallowedtoperformbladeremovaland
assembly.
11. Cleantheexposedgrindingarea.
12. Beforere‐assemblingthepartslightlygreasethemotorshaftwithfoodgradegrease.
13. Makeyourassemblywaybackinoppositeorder(steps9‐5)
14. Beforeassemblythemainknobcheckandifnecessaryrecalibrateappliance’stuning
(refertoADJUSTMENTSOFGRINDINGOPERATION,pg.7)
15. Afterallcleaningandreplacingtasksarethroughmakesuretoassembleallofthe
partsandsafetyscrewsthesamewayastheyweredisconnected.Ifanythingdoes
notfitbacktogetherorthereareleftoverparts,donotattempttooperatethe
appliance,callfortheassistanceofyourtechnician.Startworkinggraduallyand
observeanyirregularnoiseorbehavioroftheappliance.
16. Advisewithyourlocaltechnicalsupportforanyirregularnoiseorgrindingproblems.

Ifamorethoroughcleaningisrequired,thentheoperationmustbeperformedbyaskilled
technician.
Toensurelonglastinggrinderandgreatfreshtasteofcoffee,thecleaningprocedureas
describedaboveshouldberepeatedroutinelyandatleastoncepermonthorasnecessary
accordingthegrinder’susageandqualityofbeans.





END

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page11of12

2011.05Ver.1.2

Add your remarks here:
No. date Event remark

HC‐880–Manualbook


ELAN(Shanghai)IndustryandTradingCO.,LTD. Page12of12

2011.05Ver.1.2


Importantdetailsandtelephonenumbers:

Localdealeraddress:________________________________________________________________


Telephonenumber:____________________Faxnumber:_______________________


Technicianmobilenumber:____________________name:__________________


Coffeebeanssupplierdetails:__________________________________________________________


Telephonenumber:____________________Faxnumber:_______________________
