Elan PSP6 User manual

INSTALLATION
MANUAL
SPEAKER PRECISION PANEL
+
--
+
--
+
--
+
--
+
--
+
--
HOME SYSTEMSTM

ELAN HOME SYSTEMS PSP6 INSTALLATION MANUAL
© ELAN Home Systems 2004 • All rights reserved. Page 1
Introduction
The PSP6 Speaker Precision Panel provides a clean and easy way to
connect in-wall wire runs from up to six pairs of speakers (twelve
speakers total) to a system’s amplifier(s).
The PSP6 features six pairs of gold-plated binding posts that
accommodate up to 12 AWG speaker wire, banana plugs, pins, and
spade lugs on both front and rear of the panel.
The PSP6 is one of ELAN’s 1/2 frame Precision Panels. Two 1/2
frame panels can be mounted in one PF2 Precision Panel Frame,
giving the flexibility to mix and match Precision Panels needed to
complete a neat, problem-free trim-out.
The PSP6 is perfect when installing Z•660 six-channel power
amplifiers!
Table of Contents
Introduction ........................................................ 1
Features ............................................................. 1
Installation ...........................................................2-3
PF2 Precision Panel Frame .............................. 2
Mounting the PSP6 to the PF2 .........................2
Trim-Out ............................................................. 3
Connections ........................................................4
Warranty .................................................... Back Page
Features
• 1/2 Frame Speaker Precision Panel
• Six Gold-Plated Five-Way Binding Posts
• Connect Up To Six Pairs of Speakers
• Fits in PF2 Precision Panel Frame (required for installation)

PSP6 INSTALLATION MANUAL ELAN HOME SYSTEMS
Page 2 © ELAN Home Systems 2004 • All rights reserved.
Screw
Screw
Scre
w
Scre
w
PF2 Front
Front
+
--
+
--
+
--
+
--
+
--
+
--
Installation
PF2 Precision Panel Frame
The PF2 accommodates any two 1/2 frame Precision Panels.
The kit includes a full-size Precision Panel frame, an insert with pre-
drilled holes for the mounting of two 1/2 frame Precision Panels,
mounting screws, and a blank 1/2 frame plate to cover an unused
half of the frame. PBKT6P new-construction brackets are available,
or the PF2 can easily be retro-fitted using the four clamping legs
attached to the frame, which clamp the panel securely to drywall.
Note: The PF2 is required for the installation of all 1/2 frame
Precision Panels.
Mounting the PSP6 to the PF2
Each 1/2 frame Precision Panel mounts from the back of the PF2.
Use four included screws inserted from the front of the PF2 as
shown below.

ELAN HOME SYSTEMS PSP6 INSTALLATION MANUAL
© ELAN Home Systems 2004 • All rights reserved. Page 3
Installation (continued)
Trim-Out
All system wire runs are pulled through the PF2 frame. Lay the PSP6
front panel (attached to the PF2) on the floor in front of the frame
and make all connections. Dress the wires in neat bundles and then
carefully place the PSP6/PF2 back into the frame and secure using
the four included screws.
Wire Runs

PSP6 INSTALLATION MANUAL ELAN HOME SYSTEMS
Page 4 © ELAN Home Systems 2004 • All rights reserved.
Connections
Use high-quality speaker cables to connect the binding posts on
the front panel of the PSP6 to the speaker terminals on the system’s
amplifier(s). Make sure that proper +/- polarity is maintained!
Connect in-wall speaker wire runs to the binding posts on the rear
of the PSP6.
Note: ELAN recommends the use of our BJACK banana plugs for
quick, sure connection of all speakers!
Front
Rear
To Speakers
To Amp
14-18 AWG
Speaker Wire Banana Plugs
PSP6
Side View

ELAN HOME SYSTEMS PSP6 INSTALLATION MANUAL
© ELAN Home Systems 2004 • All rights reserved. Page 5
ELAN 1/2 Frame Precision Panels
ELAN’s new 1/2 frame Precision Panels save time and make sense
out of complex wiring tasks. Add reliability and simplicity to your
installs by using them in every job!
PVSE
The PVSE Precision Panel makes
it easy to connect up to six ELAN
Electronic Volume Controls to
any ELAN system, and is also
the perfect trim-out solution for
Electronic Volume Controls in any
stand-alone system!
PZ600
The PZ600 Precision Panel
allows the connection of phone
service, page, Doorbell and
Override signals, relays and
door stations to the Z•600
Communications Controller and
ELAN S Series controllers.
PV8
The PV8 Video Precision Panel
provides a clean and easy way
to connect up to 8 runs of
coaxial cable to the System12
A/V Controller or Z•880 Video
Controller.
PF2
The PF2 Precision Panel Frame
accommodates any two 1/2
frame Precision panels3. This
kit includes a full-sized
Precision panel frame, a blank
1/2 frame plate to cover any
unused half of the frame, and
all mounting hardware.
Required for use with all 1/2
frame Precision Panels.
TRIGGERS
12 4356ALL
12VDC / 1.5A
IR IN
IR OUT
12 4356ALL
12 4356ALL
RELAY TELCO
DS1 PHONE
DS2 CONTROL VCO
PAGE/DB
OUT
DB1 DB2
Z600
PRECISION
PANEL
+12 VDC PWR

P/N 9900565 REV: A
ELAN HOME SYSTEMS L.L.C. ("ELAN") warrants the PSP6 Precision Panel
to be free from defects in materials and workmanship for the period of
two years (2 years) from date of purchase. If within the applicable warranty
period above purchaser discovers that such item was not as warranted
above and promptly notifies ELAN in writing, ELAN shall repair or replace
the item at the company's option. This warranty shall not apply (a) to
equipment not manufactured by ELAN, (b) to equipment which shall have
been installed by other than an ELAN authorized installer, (c) to installed
equipment which is not installed to ELAN's specifications, (d) to equipment
which shall have been repaired or altered by others than ELAN, (e) to
equipment which shall have been subjected to negligence, accident, or
damage by circumstances beyond ELAN's control, including, but not limited
to, lightning, flood, electrical surge, tornado, earthquake, or other
catastrophic events beyond ELAN's control, or to improper operation,
maintenance or storage, or to other than normal use of service. With
respect to equipment sold by, but not manufactured by ELAN, the warranty
obligations of ELAN shall in all respects conform to the warranty actually
extended to ELAN by its supplier. The foregoing warranties do not cover
reimbursement for labor, transportation, removal, installation or other
expenses which may be incurred in connection with repair or replacement.
Except as may be expressly provided and authorized in writing by ELAN,
ELAN shall not be subject to any other obligations or liabilities whatsoever
with respect to equipment manufactured by ELAN or services rendered by
ELAN.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL
OTHER EXPRESSED AND IMPLIED WARRANTIES EXCEPT WARRANTIES
OF TITLE, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
ATTENTION: TO OUR VALUED CONSUMERS
To ensure that consumers obtain quality pre-sale and after-sale
support and service, ELAN Home Systems products are sold
exclusively through authorized dealers. ELAN products are not sold
online. The warranties on ELAN products are NOT VALID if the
products have been purchased from an unauthorized dealer or an
online E-tailer. To determine if your ELAN reseller is authorized,
please call ELAN Home Systems at [phone].
Limited Warranty
2428 Palumbo Drive Lexington, KY 40509
www.elanhomesystems.com
