Elation ACL 360 MATRIX User manual

ACL 360 MATRIX™
user manual 
ELATION |
ACL 360 MATRIX™
|
user manual

www.elationlighting.com
2ACL 360 MATRIX™ User Manual Ver 1
©2015 ELATION PROFESSIONAL all rights reserved. Information, specifications,
diagrams, images, and instructions herein are subject to change without notice.
ELATION PROFESSIONAL logo and identifying product names and numbers herein
are trademarks of ELATION PROFESSIONAL. Copyright protection claimed includes
all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this
document may be trademarks or registered trademarks of their respective
companies and are hereby acknowledged. All non-ELATION brands and product
names are trademarks or registered trademarks of their respective companies.
ELATION PROFESSIONAL and all affiliated companies hereby disclaim any and all
liabilities for property, equipment, building, and electrical damages, injuries to any
persons, and direct or indirect economic loss associated with the use or reliance of
any information contained within this document, and/or as a result of the improper,
unsafe, insufficient and negligent assembly, installation, rigging, and operation of
this product.
DOCUMENT VERSION
Please check www.elationlighting.com for the latest revision/update of this manual.
Date Document
Version
Software
Version
DMX
Channel
Modes
Notes
8/21/15 1
IU01: ≥1.04
2U01: ≥1.04
3U01: ≥1.04
4U01: ≥1.04
17 / 19 / 115 Initial release.
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
[phone] |[phone] fax |www.elationlighting.eu |[e-mail]
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 |323-832-9142 fax | www.elationlighting.com |[e-mail]

www.elationlighting.com
3ACL 360 MATRIX™ User Manual Ver 1
CONTENTS
General Information
4
Warranty
6
Safety Instructions
7
General Guidelines
8
Fixture Overview
9
Fixture Installation
10
Fixture Menu
13
DMX Channel Functions And Values
18
Error Codes
28
Cleaning and Maintenance
29
Technical Specifications
30
Optional Accessories
33

www.elationlighting.com
4ACL 360 MATRIX™ User Manual Ver 1
GENERAL INFORMATION
INTRODUCTION
Congratulations, you have just purchased one of the most innovative and
reliable lighting fixtures on the market today! This fixture has been designed to
perform reliably for years when the guidelines in this booklet are followed. Please
read and understand the instructions in this manual carefully and thoroughly
before attempting to operate this unit. These instructions contain important
information regarding safety during use and maintenance.
UNPACKING
Every fixture has been thoroughly tested and has been shipped in perfect
operating condition. Carefully check the shipping carton for damage that may
have occurred during shipping. If the carton appears to be damaged, carefully
inspect your unit for damage and be sure all accessories necessary to
operate the unit have arrived intact. In the event damage has been found or
parts are missing, please contact our customer support team for further
instructions. Please do not return this unit to your dealer without first contacting
customer support at the number listed below. Please do not discard the shipping
carton in the trash. Please recycle whenever possible.
BOX CONTENTS
(2) Omega Brackets
(1) powerCON Cable
Manual & Warranty Card

www.elationlighting.com
5ACL 360 MATRIX™ User Manual Ver 1
CUSTOMER SUPPORT
Elation Professional®provides a customer support line, to provide set up help and
to answer any question should you encounter problems during your set up or
initial operation. You may also visit us on the web at www.elationlighting.com for
any comments or suggestions. For service related issue please contact Elation
Professional®.
ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST
Voice: 323-582-3322 Fax: [phone]
E-mail: [email protected]
ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
Voice: [phone] Fax: [phone]
E-mail: [email protected]
WARRANTY REGISTRATION
Please complete and mail in the enclosed warranty card or register online:
http://www.elationlighting.com/Login.aspx to validate your purchase. All
returned service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number must be
clearly written on the outside of the return package. A brief description of the
problem as well as the R.A. number must also be written down on a piece of
paper and included in the shipping container. If the unit is under warranty, you
must provide a copy of your proof of purchase invoice. Items returned without a
R.A. number clearly marked on the outside of the package will be refused and
returned at customer’s expense. You may obtain a R.A. number by contacting
customer support.
IMPORTANT NOTICE!
There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself; doing so will void your manufactures warranty. Damages resulting from
modifications to this fixture and/or the disregard of safety and general user
instructions found in this user manual void the manufactures warranty and are
not subject to any warranty claims and/or repairs.

www.elationlighting.com
6ACL 360 MATRIX™ User Manual Ver 1
LIMITED WARRANTY
A. Elation Professional® hereby warrants, to the original purchaser, Elation Professional® products to
be free of manufacturing defects in material and workmanship for a period of two years (730 days),
and Elation Professional® product rechargeable batteries to be free of manufacturing defects in
material and workmanship for a period of six months (180 days), from the original date of purchase.
This warranty excludes discharge lamps and all product accessories. This warranty shall be valid only
if the product is purchased within the United States of America, including possessions and territories. It
is the owner’s responsibility to establish the date and place of purchase by acceptable evidence, at
the time service is sought.
B. For warranty service, send the product only to the Elation Professional® factory. All shipping
charges must be pre-paid. If the requested repairs or service (including parts replacement) are within
the terms of this warranty, Elation Professional® will pay return shipping charges only to a designated
point within the United States. If any product is sent, it must be shipped in its original package and
packaging material. No accessories should be shipped with the product. If any accessories are
shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or
damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the product serial number and/or labels are altered or removed; if the
product is modified in any manner which Elation Professional® concludes, after inspection, affects
the reliability of the product; if the product has been repaired or serviced by anyone other than the
Elation Professional® factory unless prior written authorization was issued to purchaser by Elation
Professional®; if the product is damaged because not properly maintained as set forth in the product
instructions, guidelines and/or user manual.
D. This is not a service contract, and this warranty does not include any maintenance, cleaning or
periodic check-up. During the periods as specified above, Elation Professional® will replace
defective parts at its expense, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of Elation Professional® under
this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at
the sole discretion of Elation Professional®. All products covered by this warranty were manufactured
after January 1, 1990, and bare identifying marks to that effect.
E. Elation Professional® reserves the right to make changes in design and/or performance
improvements upon its products without any obligation to include these changes in any products
theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory
supplied with the products described above. Except to the extent prohibited by applicable law, all
implied warranties made by Elation Professional® in connection with this product, including
warranties of merchantability or fitness, are limited in duration to the warranty periods set forth above.
And no warranties, whether expressed or implied, including warranties of merchantability or fitness,
shall apply to this product after said periods have expired. The consumer’s and/or dealer’s sole
remedy shall be such repair or replacement as is expressly provided above; and under no
circumstances shall Elation Professional® be liable for any loss and/or damage, direct and/or
consequential, arising out of the use of, and/or the inability to use, this product.
G. This warranty is the only written warranty applicable to Elation Professional® products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.

www.elationlighting.com
7ACL 360 MATRIX™ User Manual Ver 1
SAFETY INSTRUCTIONS
This fixture
is an extremely sophisticated piece of electronic equipment. To
guarantee a smooth operation, it is important to follow the guidelines in this
manual. The manufacturer of this device will not accept responsibility for
damages resulting from the misuse of
this fixture due to the disregard of the
information printed in this manual.
This device falls under PROTECTION CLASS 1
. It’s essential this device be
grounded properly. Only qualified personnel should
perform all electrical
connections.
INDOORS USE ONLY!
DO NOT EXPOSE FIXTURE RAIN AND MOISTURE!
UNPLUG POWER BEFORE SERVICING FIXTURE!
DO NOT PLUG FIXTURE INTO A DIMMER PACK!
NEVER TOUCH FIXTURE DURING OPERATION, AS IT MAY BE HOT!
NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!
For proper operation, follow the Installation guidelines described in this manual. Only qualified
and certified personnel should perform installation of this fixture and only the original rigging parts
(brackets) included with this fixture should be used for installation. Any modifications will void the
original manufactures warranty and increase the risk of damage and/or personal injury.
Never look directly into the light source of this fixture to prevent risk of injury to your retina, which
may induce blindness. Those suffering from EPILEPSY should avoid looking directly into the light
source of this unit at all times.
The fan and air inlets must remain clean and never blocked. Allow approx. 6” (15cm) between
this fixture and other devices or a wall for proper cooling.
Always disconnect from main power source before performing any type of service and/or
cleaning procedure. Only handle the power cord by the plug end, never pull out the plug by
tugging the wire portion of the cord.
Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If
the power cord is damaged, replace it immediately with a new one of similar power rating.

www.elationlighting.com
8ACL 360 MATRIX™ User Manual Ver 1
GENERAL GUIDELINES
NEVER OPEN THIS FIXTURE WHILE IN USE!
During the initial operation of this fixture, a light smoke or smell may emit from the
interior of the fixture. This is a normal process and is caused by excess paint in the
interior of the casing burning off from the heat associated with the lamp and will
decrease gradually over time.
This fixture is a professional lighting effect designed for INDOOR / DRY LOCATIONS
ONLY on stage, in nightclubs, theatres, etc.
Please make sure there are NO FLAMMABLE MATERIALS close to the fixture while
operating, to prevent any fire hazard.
The fixture must be installed in a location with adequate ventilation, at least 1.5
feet (.5m) from adjacent surfaces. Be sure no air ventilation slots are blocked.
DO NOT attempt installation and/or operation without knowledge how to do so.
DO NOT permit operation by persons who are not qualified to operate this type
of fixture. Most damages are the result of operations by nonprofessionals.
Consistent operational breaks may ensure the fixture will function properly for
many years to come.
DO NOT shake fixture, avoid brute force when installing and/or operating fixture.
Always install the fixture with an appropriate safety cable. When installing the
fixture in a suspended environment, always use mounting hardware that is no less
than M10 x 25 mm, also be sure the hardware is insert in the pre-arranged screw
holes in the bracket of the fixture.
Use the original packaging and materials to transport the fixture in for service.
DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power
and allow approximately 15 minutes for the fixture to cool down before replacing
or serving.

www.elationlighting.com
9ACL 360 MATRIX™ User Manual Ver 1
FIXTURE OVERVIEW
1: LCD Control Display 6: Fuse
2: DC Switch 7: powerCON IN
3: UP, DOWN, LEFT, RIGHT, ENTER Buttons 8: 3pin, 5pin DMX IN
4: MODE Button 9: 3pin, 5pin DMX OUT
5: NET IN/OUT (RJ45 Ethernet) 10: powerCON OUT
1
2
3
4
6
7
8
9
10
5

www.elationlighting.com
10 ACL 360 MATRIX™ User Manual Ver 1
FIXTURE INSTALLATION
FLAMMABLE MATERIAL WARNING
Keep fixture at least 5.0 ft (1.5m) away from any
flammable materials, decorations, pyrotechnics, etc.
ELECTRICAL CONNECTIONS
A qualified electrician should be used for all
electrical connections and/or installations.
CAUTIONS
For added protection, mount the fixture in areas outside walking paths, seating
areas, or in areas were unauthorized personnel might reach the fixture.
Ambient operating temperature range for this fixture is 5° to 113°F. (-15° to 45°C)
Do not use the fixture under or above this temperature.
Before mounting the fixture to any surface, make sure the installation area can
hold a minimum point load of 10 times the weight of the fixture.
Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable.
Never stand directly below the device when mounting, removing or servicing.

www.elationlighting.com
11 ACL 360 MATRIX™ User Manual Ver 1
MOUNTING POINTS
Overhead mounting requires extensive experience, including amongst others
calculating working load limits, installation material being used, and periodic
safety inspection of all installation material and the device. If you lack these
qualifications, do not attempt the installation yourself. Improper installation can
result in bodily injury.
Fixture is fully operational in the specific mounting positions as illustrated below.
SAFETY CABLE
Always use a Safety Cable whenever installing this fixture in a suspended
environment to ensure the fixture will not drop if the clamp fails.

www.elationlighting.com
12 ACL 360 MATRIX™ User Manual Ver 1
POWER LINKING
Max number of units that can be power linked is 3 units @110V and 6 units @240V.
CLAMP MOUNTING
The fixture provides a unique mounting assembly (2x Omega Brackets) that
integrates the bottom of the base. (See the illustration below). When mounting this
fixture to truss be sure to secure an appropriately rated clamp to the included
Omega Brackets using a M10 screw fitted through the center hole of the Omega
Bracket. Be sure to attach an appropriate Safety Cable (not included) to the fixture
using the safety cable rigging point integrated in the base assembly.
SECURING
Regardless of the rigging option you choose for your fixture always be sure to secure
your fixture with a safety cable. The fixture provides a built-in rigging point for a
safety cable. Be sure to only use the designated rigging point for the safety cable
and never secure a safety cable to a carrying handle.

www.elationlighting.com
13 ACL 360 MATRIX™ User Manual Ver 1
FIXTURE MENU
ON-BOARD SYSTEM MENU
The fixture comes with an easy to navigate system menu. The next section will detail
the functions of each command in the system menu.
LCD MENU CONTROL PANEL
The control panel (see image below) located on back of the fixture allows you to
access the main menu and make all necessary adjustments to the fixture. During
normal operation, pressing MODE button once will access the fixture’s main menu.
Once in the main menu you can navigate through the different functions and
access the sub-menus with the UP, DOWN, RIGHT, and LEFT buttons. Once you reach
a field that requires adjusting, press the ENTER button to activate that field and use
the UP and DOWN buttons to adjust the field. Pressing the ENTER button once more
will confirm your setting. You may exit the main menu at any time without making
any adjustments by pressing the MODE/ESC button.
NOTE: To access the LCD Menu Control Display via the internal battery, press and
hold the DC SWITCH button for 3 seconds. The LCD Menu Control Display will shut
OFF automatically about 1 minute from the last button press.
INFORMATION DISPLAYED DURING INITIAL POWER ON
When the fixture is initially powered ON, the display shows the following information:
Software Update
Please Wait...
Motor Reset
Please Wait...

www.elationlighting.com
14 ACL 360 MATRIX™ User Manual Ver 1
ELATION© ACL 360 MATRIX™
S Y S T E M M E N U
Specifications and features are subject to change without any prior written notice.
MAIN MENU
SUB MENU
OPTIONS / VALUES
(Default Settings in BOLD)
DESCRIPTION
Receive
Set DMX Address A001~AXXX DMX Address Setting
User Mode
User Mode
Standard, Basic, Extend, User A, User B, User C
Set DMX Channel Mode
Edit A Max. Chan
:
Fade Time
Edit User Defined
Channel Assignments
Edit B
Edit C
Function
Status
Remote Add
ON/OFF
Address Via DMX
NoDMX Mode Hold / Auto / Blackout Fucntion If NO DMX Detected
Pan Invert ON/OFF Pan Reverse Movement
TiltInvert
ON/OFF
Tilt Reverse Movement
Pan Degree 630/540 Pan Degree Select
Feedback
ON/OFF
Movement Feedback
Move. Spd Speed 1~ 4 Movement Mode Select
Stand By
OFF, 01M~99M,
15M
Stand By Mode
Fixture ID
ServicePIN
PIN=XXX
Service PIN 050
RDM PID XXXXX RDM PID Code
UnitIPAddr
XXX.XXX.XXX.XXX.
Enter Fixture's IP Address
Universe 000-255 Enter Universe Number
Fan. Set
Auto, High, Low
Set Head Fan Speed
ProtocolSet ArtNet, Kling-Net Fans Speed Select
Net Switch
ON/OFF
Activate NET OUT Port.
LCD. Set
Backlight 02~60m 05m LCD Backlight Shut Off Time
FlipDisplay
ON/OFF
Flip Display 180º
Key Lock ON/OFF Control Buttons Key Lock
Disp Flash
ON/OFF
Display flashes when NO DMX
Dim Curve Standard, Stage, TV, Architectur, Theatre Set Dimmer Curve Mode
Temp. C/F
Celsius/Fahrenheit
(4<?4A0CDA4'F8C274CF44=PP
Init. Effect PAN =XXX Initial Effect Position
Disp. Set
Chan. Value
PAN...
Value of each Channel Displayed
Slave Set Slave 1, Slave 2, Slave 3 Set Slave Mode Preset
Auto.Pro
Alone, Master
Set Auto Program Mode
DFSE ON/OFF Restore Factory Settings
Information
Time. Info
Current
XXXX (Hours)
Fixture Run Time From Power ON
Total Time XXXX (Hours) Fixture Total Run Time
Last Clear
XXXX (Hours)
Clear Fixture Last Run Time
Timer PIN PIN= 066 Enter PIN to Acess Clear Last. Menu
Clean Last
ON / OFF
Reset Fixture Last Run Time
Temp. Info Head Temp.
XXX C° / F °
Temperature in Fixture Head
Error. Info
Reset Error Message
Model. Info ACL 360 Bar Display Model Name
Software Version
1U01:
≥V1.12
Software Versions2U01: ≥V1.06
3U01:
≥V1.12
Error Info Error Record 1 ~ Error Record 10 Pan....

www.elationlighting.com
15 ACL 360 MATRIX™ User Manual Ver 1
ELATION© ACL 360 MATRIX™
S Y S T E M M E N U
Specifications and features are subject to change without any prior written notice.
MAIN MENU
SUB MENU
OPTIONS / VALUES
(Default Settings in BOLD)
DESCRIPTION
Test
Reset. M Reset of Pan/Tilt Motors
Test. Chan
Test Functions
Panel. Ctrl Fine Adjustments
Calibrate
Password
Password= 050
Calibration of Motors and LEDs
Program
Select. Pro
Auto Pro Part1 = Program 1~9 (Program 1)
Select Programs To Be Run
Auto Pro Part2 = Program 1~9 (Program 2)
Auto Pro Part3 = Program 1~9 (Program 3)
Edit. Pro
Program 1
Program Test
Testing Program
: Step 01=SCxxx Program In Loop
Program 9
Step 64=SCxxx
Save and Exit
Edit. Sce
Scene 001
~
Scene 250
Pan,Tilt,…… Save and Automatically Return
--Fade Time--
--Scene Time-- Manual Scenes Edit
Input By Outside
Stores Scenes via Ext DMX Console
Sce. Input XX~XX Automatic Scenes Recorder
Function - Status - Remote Add
When ON, define the desired DMX address of fixture via an external controller.
1. Connect the fixture to the external controller and power ON.
2. Set the DMX value of Channel 1 on the controller to (7).
3. Set the DMX value of Channel 2 on the controller to (7) or (8).
When set to (7), the DMX address can be set between (1) and (255).
When set to (8), the DMX address can be set between (256) and (511).
4. Using Channel 3 on the controller set the desired DMX address of the fixture.
Example 1:
If the desired DMX address is 57, set Channel 1 to a value of (7), set Channel 2 to
a value of (7), and then set Channel 3 to a value of (57).
Example 2:
If the desired DMX address is 420, set Channel 1 to a value of (7), set Channel 2 to
a value of (8), and then set Channel 3 to a value of (164). (256+164=420)
5. After setting Channel 3 to the desired DMX address value, wait for approximately
20 seconds for the fixture to complete the address reset function.

www.elationlighting.com
16 ACL 360 MATRIX™ User Manual Ver 1
Function – Fixture ID - RDM PID
Select various submenus via RDM.
RDM stands for "Remote Device Management", which provides the ability to control
the device remotely while connected to a DMX-bus. ANSI E1.20-2006 by ESTA
specifies the RDM standard as an extension of the DMX512 protocol. Manual settings
like adjusting the DMX starting address are no longer needed. This is especially useful
when the device is installed in a remote area.
RDM ready and conventional DMX devices can be operated in one DMX line. The
RDM protocol sends its own packages in the DMX512 data feed and does not
influence conventional devices. If DMX splitters are used and RDM control is to be
used, these splitters must support RDM. The number and type of RDM parameters
depend on the RDM controller being used.
Function - Dim Curve
Select desired DIMMER MODE (Standard, Stage, TV, Architectural, Theatre).

www.elationlighting.com
17 ACL 360 MATRIX™ User Manual Ver 1
Test – Calibrate
ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION.
This function allows small adjustments to be made to the effect wheels to
compensate for ware or in the event a sensor has been knocked slightly out of
place. Because improper use of this function can result in undesired operation this
function has been password protected. The password is 050 and must be entered
each time the calibration menu function is entered. Because calibration is an
extremely delicate procedure, instructions on performing this action are left out of
this manual. For a first time calibrator, please contact our customer support team for
step-by-step instructions.

www.elationlighting.com
18 ACL 360 MATRIX™ User Manual Ver 1
DMX CHANNEL FUNCTIONS AND VALUES
ELATION© ACL 360 MATRIX™
DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL VALUE FUNCTION
BASIC STAND EXTEND
1 1 1 PAN MOVEMENT [8 BIT]
0-255
PAN Movement 630/540
2 2 PAN FINE MOVEMENT [16 BIT]
0-255
Fine Control of PAN Movement
2 3 3 TILT MOVEMENT [8 BIT]
0-255 TILT Movement
4 4 TILT MOVEMENT [16 BIT]
0-255 Fine Control of TILT Movement
3 5 5
PAN CONTINUOUS MOVEMENT
0-127 NO FUNCTION
128-189 PAN Clockwise from FAST to SLOW
190-193 NO Rotation
194-255 PAN Counter-Clockwise from SLOW to FAST
4 6 6
TILT CONTINUOUS MOVEMENT
0-127 NO FUNCTION
128-189
TILT Clockwise from FAST to SLOW
190-193 NO Rotation
194-255 TILT Counter-Clockwise from SLOW to FAST
5 7 RED (ALL LEDs)
0-255 0 to 100%
6 8 GREEN (ALL LEDs)
0-255 0 to 100%
7 9 BLUE (ALL LEDs)
0-255 0 to 100%
8 10 WHITE (ALL LEDs)
0-255 BLUE FINE Adjustment
7 *RED - LED 1
0-255 0 to 100%
8 *GREEN - LED 1
0-255 0 to 100%
9 *BLUE - LED 1
0-255 0 to 100%
10 *WHITE - LED 1
0-255 0 to 100%
11 *RED - LED 2
0-255 0 to 100%
12 *GREEN - LED 2
0-255 0 to 100%
13 *BLUE - LED 2
0-255 0 to 100%
14 *WHITE - LED 2
0-255 0 to 100%

www.elationlighting.com
19 ACL 360 MATRIX™ User Manual Ver 1
ELATION© ACL 360 MATRIX™
DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL VALUE FUNCTION
BASIC STAND EXTEND
15 *RED - LED 3
0-255 0 to 100%
16 *GREEN - LED 3
0-255 0 to 100%
17 *BLUE - LED 3
0-255 0 to 100%
18 *WHITE - LED 3
0-255 0 to 100%
19 *RED - LED 4
0-255 0 to 100%
20 *GREEN - LED 4
0-255 0 to 100%
21 *BLUE - LED 4
0-255 0 to 100%
22 *WHITE - LED 4
0-255 0 to 100%
23 *RED - LED 5
0-255 0 to 100%
24 *GREEN - LED 5
0-255 0 to 100%
25 *BLUE - LED 5
0-255 0 to 100%
26 *WHITE - LED 5
0-255 0 to 100%
27 *RED - LED 6
0-255 0 to 100%
28 *GREEN - LED 6
0-255 0 to 100%
29 *BLUE - LED 6
0-255 0 to 100%
30 *WHITE - LED 6
0-255 0 to 100%
31 *RED - LED 7
0-255 0 to 100%
32 *GREEN - LED 7
0-255 0 to 100%
33 *BLUE - LED 7
0-255 0 to 100%
34 *WHITE - LED 7
0-255 0 to 100%

www.elationlighting.com
20 ACL 360 MATRIX™ User Manual Ver 1
ELATION© ACL 360 MATRIX™
DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL VALUE FUNCTION
BASIC STAND EXTEND
35 *RED - LED 8
0-255 0 to 100%
36 *GREEN - LED 8
0-255 0 to 100%
37 *BLUE - LED 8
0-255 0 to 100%
38 *WHITE - LED 8
0-255 0 to 100%
39 *RED - LED 9
0-255 0 to 100%
40 *GREEN - LED 9
0-255 0 to 100%
41 *BLUE - LED 9
0-255 0 to 100%
42 *WHITE - LED 9
0-255 0 to 100%
43 *RED - LED 10
0-255 0 to 100%
44 *GREEN - LED 10
0-255 0 to 100%
45 *BLUE - LED 10
0-255 0 to 100%
46 *WHITE - LED 10
0-255 0 to 100%
47 *RED - LED 11
0-255 0 to 100%
48 *GREEN - LED 11
0-255 0 to 100%
49 *BLUE - LED 11
0-255 0 to 100%
50 *WHITE - LED 11
0-255 0 to 100%
51 *RED - LED 12
0-255 0 to 100%
52 *GREEN - LED 12
0-255 0 to 100%
53 *BLUE - LED 12
0-255 0 to 100%
54 *WHITE - LED 12
0-255 0 to 100%
