Elba TP-3815 User manual

THERMO POT
MODEL: TP-3815
TP-5012
Owner’s Manual
Please read this manual carefully before
operating your set.
Retain it for future reference
Record model number and serial number of
the set.
See the label attached on the set and quote this
information to your dealer when you require
service.
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate

SAFETY
Read this instruction manual carefully before operating the appliance and keep it for future
reference.
1. Never immerse the appliance in water or any other liquids, nor rinse it under the tap.
2. Check if the voltage indicated on the appliance corresponded to the local mains voltage before
you connect the appliance.
3. Do not use the appliance if the plug, the power cord or the appliance itself is damaged.
4. If the power cord is damaged, it must be replaced by the manufacturer or its service agent or
similarly qualified persons in order to avoid hazards.
5. Keep the power cord out of children. Do not let the power cord hang over the edge or the table or
worktop on which the appliance stands.
6. Wait until the appliance has cooled down before cleaning, removing or replacing the lid.
7. Take extreme care when removing the appliance if it contains hot water.
8. This appliance is not intended to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their
safety.
9. Children should be supervised to ensure that they do not play with the appliance.
10. Always use the appliance on a flat, stable and heat resistant surface to prevent the power
cord from coming into contact with hot surfaces.
11. Unplug the appliance before cleaning and when problems occur during dispensing.
12. Never over filling water into the water tank as it may cause splash! Refer to the “full”
water level mark in the water tank.
13. Keep hands or any part of your body from the water outlet for a second or two right after you
press the dispense button as hot water emitted from the water outlet may splash.
14. This appliance is for boiling water only.
15. This appliance is for domestic use only.
16. Do not use the appliance outdoor.
Warning: Never open the lid when water is boiling!

TO KNOW YOUR THERMO POT
CONTROL PANEL

USING THE THERMO POT FOR THE FIRST TIME
1. Wash and rinse water tank with water.
2. Fill water up to full mark.
3. Boil once and discard the water by pumping it out.
REMOVE AND ATTACH THE LID
Detach Lid
Place the handle towards the rear side of the thermo pot. Then open the lid by pulling up the lid
opening lever (caution: be careful of the steam from the steam vent). Position the lid at 45 degree
and pull out the lid from the hinge holder by pressing the hinge lock.
Note: Never remove the lid while the water is boiling.
Attach Lid
Place the handle towards the rear side of the thermo pot. Press the hinge lock, at the same time
insert the shaft of the hinge of the lid into the hinge holder. Ensure that the lid is attached properly
and close the lid until it clicks.
OPERATING THE APPLIANCE
To open the lid and boil water
Pull the lid opening lever up to open the lid and fill
water into the water tank.
Always fill water above the minimum water
level mark and below the maximum water
level mark.
Refer to the water level mark in the water
tank.
To close the lid
Close the lid by pressing down until it clicks.
Do not close the lid by force.
1. Insert the receptacle into the power inlet.
2. Then, insert the plug to the wall outlet.
WARNING: Do not power on the appliance if
the water tank is empty.
Connect the plug to the power inlet
horizontally.

BOIL
KEEP WARM
1. “Boil” indicator light will be on during
boiling process.
BOIL
KEEP WARM
2. It will switch to “keep warm “automatically
after the water is boiled.
Do not open the lid or dispense water while
the water is boiling.
Do not contact any parts of your body to the
steam vent.
Do not place cloth or any other items to
cover the steam vent.
Pouring hot water
1. Note: The hot water may not
dispense smoothly right after
boiling.
2. Press on the “DISPENSE” button to
dispense hot water.
CAUTION: Always keep hands or any parts
of your body from the water outlet for a
second or two right after you press the
dispense button.
Do not press the dispense button when the
inner water reservoir is empty.
You cannot dispense hot water by pressing
the dispense button, or cup switch if the
thermo pot is unplugged.
Refill water
When water reaches to “refill water” line, add
water for automatic re-boil.
Do not add water above maximum water
level mark.
Boil water below the refill mark may cause
malfunction.

CLEANING AND MAINTENANCE
1. Always allow appliance to cool down before cleaning.
2. Remember to unplug the plug from wall socket and power inlet.
3. Open the lid and pour out the remaining water in the water tank.
Wipe the lid and body with a damp cloth.
Never immerse any part of the thermo pot in
water.
Never splash water on the control panel.
Do not use abrasive materials to clean the
appliance.
To re-boil water under keep warm mode
It takes about 3 minutes to re-boil water
(with full water tank).
Before re-boiling the water, make sure the
water level is above the refill mark.
When adding water into the water tank, be
careful the hot steam from the steam vent
and water tank.
Once the re-boil button is pressed, the
boiling process will begin and you cannot
reset any button until it turns to keep warm
mode.
Do not press the re-boil button
continuously (after re-boiling process) as
it may cause malfunction.

Discoloration of the water tank and white
floating objects in the water tank.
Red rust-like spots, milky or black
discoloration, and white floating objects are
caused by minerals in the water and are not
caused by discoloration or deterioration of the
water tank itself. Although this is not a hygiene
problem, you are advisable to clean the water
tank periodically.
Cut a lemon into four pieces and wrap the
lemon in the cloth then put in the water tank.
Pour water up to the full level mark in the water
tank.
Boil the water and then retain the heat for about
one hour.
Pour out the water and use a nylon brush to
clean the water tank.
To remove the smell of the lemon, you can boil
the water again and dispose the water.
Stainless steel water reservoir. Wash the water tank with a sponge and then
rinse with clean water. IMPORTANT: Do not
use the following to clean the container.
Dish soap (this causes an unpleasant odor)
Scrubbing powder or scrubbing brushes (it will
damage the container and lid.)
Benzene (it will cause damaged to the plastic
of the lid)

HAZARDS
Do not immerse the thermo
pot, power cord or plug in the
water or other liquids to
prevent electric shock.
Do not place the thermo pot
on unstable surfaces.
Fill the water tank with tap
water (do not fill with milk or
any other liquids).
Do not fill the thermo pot with water above
the full mark inside the water tank or lower
than the minimum level to avoid damage to
the appliance.
Do not place the thermo pot on or near to hot
surface.

IMPORTANT GUIDELINES
WARNING: THIS APPLIANCE MUST BE EARTHED
The wires in this main are colored in accordance with the following code:
Green and yellow : Earth
Blue : Neutral
Brown : Live
If the colors above do not match those terminals identified of the plug, connect as follows:
The wire with the color of green and yellow must be connected to the terminal marked “E” or by the
earth symbol, green color or green and yellow color.
The wire with the color of blue must be connected to the terminal marked N or black color.
The wire with the color of brown must be connected to terminal marked L or red color.
(If terminals of plug are unmarked or if any doubt, kindly consult qualified electrician for assistance)
Direction to dispose the product
This marking indicates that this product should
not be disposed with other household wastes
throughout the nation. To prevent possible harm
to the environment or human health from
uncontrolled waste disposal, recycle if
responsibly to promote the sustainable reuse of
material resources. To return your used device,
please use the return and collection systems or
contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
