Boneco U350 User manual

READ AND SAVE THESE INSTRUCTIONS
U350
MANUAL

19
en
INSTRUCTIONS FOR USE
BONECO U350

20
en TABLE OF CONTENTS
Technical data 21
Introduction 22
Valuable information about humidity 22
Items included 22
Overview and part names 23
Indicators on the display 24
Keypad 25
Preparation of the A250 AQUA PRO 26
A250 AQUA PRO preparation 26
On water hardness 26
Determining water hardness 26
Starting up and switching off 27
The right location 28
The right location 28
Humidity and ultrasonic 29
Save settings 29
“AUTO” comfort mode 29
Controlling humidity 29
Regulating performance 29
Comfort functions 30
Switching the heater on and off 30
Fragrance container 30
Timer functions 31
Setting the OFF timer 31
Setting the ON timer 31
Cleaning and maintenance 32
Care instructions 32
Descaling 33
Descaling the appliance 33
Cleaning the membrane 33
Clearing the cleaning message 33
Replacing Ionic Silver Stick® 34
How it works 34
Replacing Ionic Silver Stick® 34
Replacement 34

21
en
* During operation with pre-heating
Mains voltage 230 V / 50 Hz
Power consumption 110 W
Humidity output 500 g/h* (3.170 gal/day)
For rooms up to 60 m2/ 150 m3(645 sq ft / 5,300 cubic ft)
Water capacity 5.0 liters (1.32 gallons)
Dimensions L×W×H308×165×325mm (12.1×6.5×12.79 in.)
Weight (empty) 2.74 kg (6 lb)
Operation noise level <45 dB(A)
TECHNICAL DATA

22
en
ITEMS INCLUDED
BONECO U350 “CalcOff” cleaning and
descaling powder
Ionic Silver Stick®A7017
Water hardness test strips
A250 AQUA PRO
Congratulations on your purchase of the BONECO U350.
This high-performance ultrasonic humidifier keeps the
humidity at a comfortable level at all times.
The BONECO U350 is designed for convenient, fully au-
tomated operation. However, you can adjust all of its fea-
tures according to your preferences and requirements.
This manual shows you how you can create your own
comfortable climate.
VALUABLE INFORMATION ABOUT HUMIDITY
The right humidity is very important for our health. Dry
room air in winter leads to skin that cracks and itches. It
makes your eyes and throat feel dry while significantly af-
fecting physical comfort. Not only does this affect adults,
it is especially true for infants, small children and even
pets. Dry mucous membranes in winter also make us
more prone to colds and other infections.
The BONECO U350 makes these problems a distant
memory. Its intelligent automatic controls always keep
the humidity at the ideal level, even in large rooms with an
area of up to 60 square meters (645 square feet).
You will not want to give up your newly
gained comfort.
INTRODUCTION

1
2
4
7
6
8
9
3
1Cover
2Nozzle
3Flue
4Ionic Silver Stick®
5Touch display
6Cleaning brush
7A250 AQUA PRO
8Fragrance container
9Power supply
5
23
en
OVERVIEW AND PART NAMES

24
en
Overview of all indicators on the display
Symbol Meaning
Current or desired humidity 29
Fully automated operation 29
Heater turned on 30
Timer active 31
Value shows the current humidity 29
Value shows the desired humidity 29
Symbol Required action
Refill the water 32
Change the water in the appliance 32
Replacing Ionic Silver Stick®34
Cleaning required 33
INDICATORS ON THE DISPLAY

25
en
Keypad on the appliance
Button Function
Switching unit on and off 33
Regulating output 29
“AUTO” comfort mode 29
Switch heater on/off 30
Access the timer function 31
Change the humidity 29
KEYPAD

26
en
A250 AQUA PRO PREPARATION
1. Remove the packaging of the BONECO A250 AQUA PRO.
2. Rinse the A250 AQUA PRO for 2 minutes under cold
running water.
3. Screw the A250 AQUA PRO to the BONECO U350.
ON WATER HARDNESS
The BONECO U350 is supplied with an A250 AQUA PRO.
The granulate contained in it filters the lime out of the tap
water so that it is not released into the room air. Hard tap
water accelerates saturation of the granulate so that the
A250 AQUA PRO must be replaced earlier.
DETERMINING WATER HARDNESS
1. Dip the enclosed test strip into a glass of cold tap
water for 1 second.
2. Read the water hardness after one minute.
3. Refer to the table to determine the duration of effect
of the A250 AQUA PRO:
Dispose of the saturated A250 AQUA PRO with your
regular household waste.
The A250 AQUA PRO should not be used longer than
specified. White dust around the appliance is a sure indi-
cation that the A250 AQUA PRO has run its course. You
can obtain replacements from your BONECO specialist
dealer or our online store at www.shop.boneco.com
= 6 months
= 6 months
= 5 months
= 4 months
= 3 months
= 2 months
PREPARATION OF THE A250 AQUA PRO

27
en
5
3
1
4
2
6
Tap to switch on the BONECO U350.
Fill the tank with cold tap water.
Direct the mist into the open room.
Plug the power cord into a power outlet.
Select the desired output level using the button. Tap again to switch off the BONECO U350
entirely.
STARTING UP AND SWITCHING OFF

28
en
THE RIGHT LOCATION
The BONECO U350 releases more than half a liter of wa-
ter into the air per hour. This makes it important to set up
the appliance in the right location.
Do not place the BONECO U350 directly on the floor,
since the moisture from the mist can damage floor
surfaces such as parquet or delicate carpeting.
• Make sure that the unit stands about 30 centimeters
(one foot) away from the closest wall.
• Do not direct the mist toward the wall, plants, furniture
or other objects in order to prevent water condensation
from damaging them. Maintain a distance of at least
50cm (20 inches).
THE RIGHT LOCATION

29
en
SAVE SETTINGS
The BONECO U350 saves the last-used settings when it
is switched off. However, if the appliance is disconnected
from the power supply for a few seconds, it will start in
the operating mode.
“AUTO” COMFORT MODE
In mode the humidification is controlled automati-
cally and the humidity is set to 50%. As soon as the hu-
midity or the ultrasonic is manually adjusted, however,
the appliance leaves mode.
To return to mode, tap the symbol once.
The heater can be switched on or off without the appli-
ance leaving mode. mode also remains ac-
tive when setting the timer.
CONTROLLING HUMIDITY
The humidity can be set between 30% and 70%. In the
“Co” setting (for “Continuous”), the ultrasonic runs re-
gardless of the measured humidity. This means it does
not switch off until the tank is empty or the appliance is
switched off.
1. Tap the symbol. The current humidity indicator
starts flashing.
2. While the indicator is flashing, tap the symbol
again until the desired humidity is set.
The value is applied after a few seconds. The indicator
stops flashing.
REGULATING PERFORMANCE
1. Tap the symbol multiple times until the desired
level appears on the display.
The symbol on the display indicates which of the three
levels (low/medium/high) has been selected:
HUMIDITY AND ULTRASONIC

30
en
SWITCHING THE HEATER ON AND OFF
The BONECO U350 is equipped with a heater that can be
turned on and off. It warms the outgoing mist up to ap-
proximately 35 °C (95 °F), so that the room temperature
stays at a comfortable level.
It takes a few minutes until the heater reaches its full
output.
1. Tap the symbol once to switch on or off the
heater.
FRAGRANCE CONTAINER
Commercially available scented aromatic substances for
humidifiers can be added to the fragrance container on
the back of the BONECO U350.
Never add the aromatic substance directly into the
water tank or water base; doing so will damage the
BONECO U350 and void the warranty!
1. Press down on the fragrance container to unlock the
drawer.
2. Sprinkle the cotton wadding in the drawer with the
fragrance of your choice.
COMFORT FUNCTIONS

31
en
The timer function lets you determine how long the
BONECO U350 should run before it switches off auto-
matically (OFF timer).
Alternatively, you can specify a time for when the appli-
ance should switch on automatically (ON timer). For ex-
ample, you can use this function to activate the BONECO
U350 before you return home, so that when you get back
you have the perfect home climate waiting for you.
SETTING THE OFF TIMER
1. Switch on the BONECO U350.
2. Select the desired settings.
3. Tap the symbol multiple times until the desired
run time is displayed.
Now the BONECO U350 will run for the specified time and
then switch off.
4. To deactivate the OFF timer early, switch the
BONECO U350 off and back on as needed.
SETTING THE ON TIMER
1. Switch off the BONECO U350.
2. Tap the symbol multiple times until the desired
standby time is displayed.
The BONECO U350 switches on after the defined time and
operates with the selected settings.
3. To deactivate the ON timer early, switch the BONECO
U350 off and back on as needed.
TIMER FUNCTIONS

32
en
CARE INSTRUCTIONS
With time and use, the performance of the Ionic Silver
Stick®decreases and scale builds up on the inner parts of
the BONECO U350. Stagnant water can also impair clean-
liness and lead to unpleasant odors. This means regular
maintenance and cleaning is necessary to ensure clean
and unimpaired operation.
Recommended cleaning and maintenance intervals vary
depending on air and water quality, and operating time.
Use a soft, damp cloth to clean the exterior.
Always unplug the unit from the power outlet before
cleaning.
Interval Task
Daily Check the water level; add water if necessary
After 1 week without operation Empty and clean the BONECO U350
Every 2 weeks Clean the water base and water tank
Every 2-6 months Replacing the A250 AQUA PRO
Yearly Replace the Ionic Silver Stick®
CLEANING AND MAINTENANCE

33
en
DESCALING THE APPLIANCE
1. Switch off the BONECO U350.
2. Empty the water base and the water tank.
3. Take out the Ionic Silver Stick®.
4. Mix 1 bag of CalcOff with 0.5 liters (a quarter gallon)
of water and pour the mixture into the water tank,
one half to the left and right each.
5. Wait 30 minutes to allow the solution to take effect.
6. Rinse the water tank with tap water. Remove re-
maining lime residue, if any, using a scrub brush.
CLEANING THE MEMBRANE
Stubborn limescale residue on the membrane can be re-
moved using the yellow cleaning brush stored inside the
BONECO U350.
Never clean the membrane using sharp objects or
aggressive cleaning agents; doing so can damage
the BONECO U350 and voids the warranty!
CLEARING THE CLEANING MESSAGE
After completion of cleaning, delete the message by
pressing the button and holding it for 2 seconds.
DESCALING

34
en REPLACING IONIC SILVER STICK®
HOW IT WORKS
The Ionic Silver Stick®prevents the growth of bacteria in
water, making a vital contribution to health and cleanli-
ness. The Ionic Silver Stick®is also subject to wear and
has to be replaced regularly.
The display indicates an upcoming need to replace the
Ionic Silver Stick®with this symbol:
REPLACING IONIC SILVER STICK®
1. Take off the water tank.
2. Take out the used Ionic Silver Stick®and dispose of
it with your regular household waste.
3. Insert the new Ionic Silver Stick®.
4. Press and hold the button for 2 seconds to clear
the notification symbol (see left column).
REPLACEMENT
The Ionic Silver Stick®is included with the BONECO U350.
You can obtain replacements from your BONECO special-
ist dealer or our online store at www.shop.boneco.com.

www.boneco.com
BONECO is a registered trademark of BONECO AG, Switzerland
V-00
