Elecom EC-DC01 User manual

This product has a function to distinguish between Apple products and other
equipment. Therefore, charging is performed using optimum conditions,
regardless of the type of connected equipment or cable. However, when two
ports are used simultaneously, the output may be limited depending on the total
value of output requested.
This product does not include a USB connector cable. Please purchase one
separately.
The USB ports can only connect to Type-A terminals. Also, please be careful
with regard to front-rear orientation when inserting the connector.
The product is dedicated to purposes of power supply / charging, and data can
neither be transmitted nor received.
Depending on the conditions and status at the time of use, the charging speed
may decrease, or power supply / charging may not be possible. If such an
problem occurs when using multiple simultaneous connections, please
disconnect one device at a time and monitor progress while in use.
Some car models may not be fitted with compatible accessory sockets.
Please check that the internal diameter of the accessory socket is within the
range of φ20.8 mm to φ22 mm / φ0.81 to φ0.86 inches.
Charging function cannot be guaranteed for all devices fitting the connection. Be
sure to confirm your device is compatible prior to use.
We recommend use in conjunction with a commercially available extension
socket or similar when the device cannot be securely fixed because of spatial
restrictions around the accessory socket.
This product is designed for use in cars manufactured for the Japanese market.
This product is a precision instrument. Do not subject it to severe impacts or
handle it roughly as this may cause malfunction.
Be sure to read the instruction manual prior to use, and store it carefully with a
receipt that can be used to confirm the date of purchase.
When this product is in use, noise, or interference, may become audible in music
being played with the car audio system.
The image on the package is for representational purposes only, and may differ
slightly from the actual product.
This product is for negatively earthed vehicles only. Do not use with vehicles
which are positively earthed.
The fuse for this product is not replaceable.
Devices requiring an output power greater than a single port’s rated 5V/2.4A
cannot be used. Furthermore, a combined output of greater than 2.4A for both
ports cannot be sourced. For iPads or tablet computers, make sure that only one
device is connected at any time.
Product number: EC-DC01
Manual Car Charger for iPhone/Android
ENGLISH
Product specifications USB port
Attention
USB port x 2
Input voltage DC 12V / 24V
Output DC 5V maximum total current 2.4A
Each port maximum 2.4A
Temperature range for use 0°C to 40°C / 32°F to 104°F
(No condensation allowed)
Storage temperature range -20°C to 60°C /-4°F to 140°F
(No condensation allowed)
Main unit size (W x D x H) Approximately 30 x 61 x 30 mm
Approximately 1.18 x 2.40 x 1.18 inches
Maximum Total Output 5V / 2.4A
Connector specications
iPhone
Smartphone
iPhone
Smartphone
Auto charge control
Maximum Total Output
Auto charge control
The high-performance IC (integrated circuit)
mounted in the USB port recognizes connected
devices and achieves the fastest charge by
optimizing the output power.
Connected
devices are
automatically
recognized for
fastest charging
5V/2.4A high output
A total combined charging current of
2.4A may be sourced from the two
ports.
12V/24V inputs supported
In addition to normal cars, it can be
used with 24V vehicles such as
trucks.
Equipped with power
confirmation LED
When this product is turned on, the
cigar charger LED will light blue.
Two devices may be charged
simultaneously from the two ports
Since the product has two USB
ports, it is possible to charge two
devices.
[Connection diagram]
Simultaneous charging
of two devices.
This product
Connection to accessory socket
Connects to
your USB cables

Safety precautions
Operating this product and any devices connected to it while driving is
highly dangerous, and this should not be attempted under any
circumstances.
Immediately disconnect this product from the accessory socket and
stop use if you notice abnormalities such as strange smells or smoke
coming from the product.
Be sure not to damage the cable as this can result in fire or electrical
cut-off.
Stop the car and check the safety of the surroundings prior to operation.
Please be aware of the following precautions.
Do not use or store this product in places where the temperature or humidity is high,
in places prone to static electricity or with large amounts of dust.
When connected for charging whilst simultaneously using high power consumption
applications or functions, the connector terminal may become hot.
Depending on the terminal, the heating may cause charging or certain functions to
stop, so in such cases, resume use after the terminal temperature has dropped.
Charging may fail due to deterioration of the batteries in connected devices.
If the battery in the connected device is fully depleted, it may take time to start
charging or charging may not start at all.
If charging does not start at all, then charge using the device’s dedicated charger.
When disconnecting the connector, grasp the connecting part, and not the cable,
before pulling it directly out.
If this product becomes dirty, wipe clean with a soft cloth containing a small amount
of water or diluted neutral detergent.
Do use benzene or thinners as this may result in deformation or discoloration.
Disposal should be in accordance with the regulations of the local governing
authority.
The usage, appearance or similar of this product may be changed without prior
notice for purposes of improvement.
For vehicle models in which the accessory socket is continuously energized, please
be sure to remove this product from the accessory socket when it is not in use,
unless the battery will be dead.
Do not use with the engine stopped as this may exhaust the battery.
When connected for charging, the charging time may be lengthened depending on
applications started, function usage status, battery condition.
Also, even with genuine equipment and with identically rated output values, exact
specifications differ, so there may be differences in charging times.
Be sure to observe the following precautions in order to ensure safe and correct use.
Never attempt to disassemble or remodel this product as this may result
in fire, electric shock, burn injuries or malfunction.
In addition, our company cannot accept any responsibility or guarantee
for disassembled or remodeled products.
Do not insert your fingers or other objects into the accessory socket as
this may cause electric shock or short circuit, and can be extremely
dangerous.
Never allow this product to get wet as this may result in fire, electric
shock or malfunction.
This product contains small parts,
which may cause suffocation if placed in the mouth.
Use and store this product out of reach of small children.
For safety reasons, please do not install in places which will interfere
with driving, or with the operation or effectiveness of the air bag.
Be sure to insert this product into the accessory socket after having
started the car engine, as there is a risk of fire or damage to the product.
DANGER
WARNING
Do not use when dust or foreign objects are present in the accessory
socket as this may cause electrical failure or fire.
We can accept no responsibility or guarantee for incidental damages
due to using this product, such as the malfunction of connected
equipment, corruption or loss of stored data, or missed opportunities
due to communication failures or similar.
Be sure to make copies / backups for all types of memory prior to use.
This product may become hot during use but this does not mean it is
faulty.
Please take care when handling.
Depending on the model, the actual voltage may be 30V or more for 24V
vehicles.
Use of this product with such a vehicle may result in failure so we
recommend that you measure the voltage in your vehicle prior to use.
This product may stop in models where the voltage drops suddenly as
the engine stops, such as idling stop cars.
In such cases, switch off the idling stop function when using the product.
CAUTION
Keep in mind that the cigarette lighter function may be adversely
affected if this product is left inserted in the accessory socket for a long
period of time.
Car Charger for iPhone/Android
Manual, Safety precautions, and Compliance with regulations
1st edition, December 12, 2017
©2017 ELECOM Co., Ltd. All Rights Reserved.
MSC-EC-DC01_ver.111
A customer who purchases outside Japan should contact the local retailer in the country of purchasefor enquiries. In “ELECOM CO., LTD. (Japan)” , no customer support is available
forenquiries about purchases or usage in/from any countries other than Japan. Also, no foreign language other than Japanese is available. Replacements willbe made under stipulation
of the Elecom warranty, but arenot available from outside of Japan.
· In order to make improvements to this product, the design and specifications are subject to change without prior notice.
· iPad, iPhone and iPod are trademarks of Apple inc. registered in the United States and other countries.
· Apple inc. assumes no responsibility for the functioning, safety, or conformity to standards for this product.
· All company names, product names and standard names displayed on this product’s packaging are, in general, trademarks or registered trademarks of their respective companies
and groups.
ELECOM Singapore Pte. Ltd
33 UBI AVENUE 3 # 03-56. VERTEX SINGAPORE (408868)
TEL : +65 6347 - 7747
FAX : +65 6753 - 1791
ELECOMCO., LTD.
www.elecom.co.jp/global/
ELECOM Korea Co., Ltd.
5F Suam Bldg. 1358-17, Seocho2-dong, Seocho-gu,
Seoul 137-862, Korea
TEL : +82 (0) 2 - 1588 - 9514
FAX : +82 (0) 2 - 3472 - 5533
www.elecom.co.kr
ELECOM Sales Hong Kong Ltd.
2/F, Block A, 2-8 Watson Road, Causeway Bay, Hong Kong
TEL : [phone] - 3600
FAX : [phone] - 3300
email : [email protected]
新宜麗客(上海)商貿有限公司
上海市徐汇区肇嘉浜路1065甲号1603H室
電話 : +86 (0) 40 - 0867 - 3568
www.elecom.cn
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditios: (1) this device may not
cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause
undesired operation.
This product contains a chemical known to
the State of California to cause cancer and
birth detects or other reproductive harm.
