Electro-Voice TG5 User manual

General Description:
Key Features:
• Up to 2 x 1900W into 2 Ohms
• Grounded Bridge Class-H Design
• Microprocessor Controlled
• Front LCD-Panel for Operation
Mode Set-Up and Monitoring
• Slot for Optional IRIS-NetTM Compatible
Control Module
• Complete Protection Package
• Only 14.2 kg (31.4 lbs)
• Designed and Manufactured in Germany
TG5
Ultra-High Performance
Two-Channel
PowerAmplifier
Technical Specifications:
The TG-5 Tour Grade amplifier has a microprocessor
controlled operation management system that provides
useful features such as compound thermal management
(preventing the unit from switching off in excessive thermal
environment), automatic mains voltage detection and a
circuit breaker control that allows the TG-5 to operate on a
30A (120V) or 16A (230V) circuit breaker with normal music
signals.
The TG-5 uses a grounded bridge 3-step class-H topology
to ensure the highest acoustic performance and reliability.
The TG Series also offers the power and transient response
to drive subwoofers and along with the low distortion for
critical HF signals. The high capacity switch-mode power
supply provides the headroom needed to ensure high
dynamic outputs and reliable operation on extreme low
loads.
Optional IRIS-Net™ (Intelligent Remote & Integrated
Supervision-Network™ ) Modules available for the TG-5
amplifiers enable state-of-the-art DSP, remote control,
networking and unique system supervision – down to an
individual loudspeaker component. IRIS-Net™ software is
an expandable, open architecture application that operates
underWindows™andsupportsEthernet,CobraNet™,CAN-
Bus, USB, and RS-232 interfaces. Several modules are
availableincludingthe:RCM-26(DSP,AES/EBUinput,GPIO,
CANBus), RCM-28 (DSP, GPIO, COBRA-Net™) and the
RCM-20 (no DSP, CAN-Bus) The modules enable different
levels of control and monitoring of the amplifier. The
connection of the TG-5 to a PC running IRIS-Net software
can be achieved using a UCC-1 USB-CAN interface and/or
a N8000 digital matrix.
ecnadepmIdaoLmhO8mhO4mhO2
rewoPtuptuOdnabdiM.xaM lennahClauD,zHk1,zHk1=DHT W058W0541W0091
rewoPtuptuOdetaR.xaM zHk02…zH02,%1,0,DHT W006W0021-
rewoPtuptuOdegdirB.xaM zHk1,%1=DHT ---
ytivitisneStupnI )smhO8@rewoPdetaR( uBd7+/6+/0 )elbahctiwS(
rewoPtuptuOdetaRtaDHT%50,0<
)zHk7,zH06(ETPMS-DMI%50,0<
leveLtupnI.xaM)smrV57.9(uBd22+
)rewoPtuptuOdetaR,zHk1(klatssorCBd08-<
)zHk1.fer(esnopseRycneuqerF)Bd1±(zHk03-zH01
ecnadepmItupnIsmhOk02
)zHk1(rotcaFgnipmaD004>
etaRwelS/V03µs
)niaGBd23,dethgiew-A(oitaRN/SBd901
dethgiew-A,esioNtuptuOuBd07-<
ygolopoTegatStuptuOdednuorGH-ssalC egdirB
stnemeriuqeRrewoProzH06/05,V042-001 zH06/05,V001
noitpmusnoCrewoP [e-mail]8/1 W0001
gnilooC,raeR-ot-tnorF snaFegatS-5
stimiLerutarepmeTtneibmAC°04+-C°5+ )F°501-F°04(
)DxHxW(snoisnemiDmm215x1.88x384 "51.02x"64.3x"91
thgieW)sbl4.13(gk2.41

12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 6/2006
Part NumberLIT-0000XX Rev1
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
Dimension Drawings:
Rear View:
Front View Top View
All Dimensions
inMillimeters
Side ViewRear View
TG5PartNumber:
TG5, 120V -- D170379
Accessories:
RCM-26IRIS-NetCompatible
Remote Control Module --
D170362
