Electro-Voice Bass Module Sb122 User manual

Key Features:
• Very Compact and Lightweight --
Only 33 lbs/15.0 kg
• Integral handle
• 400Watt continuous,1,600Watt peak power
handling
• Parallel Neutrik Speakon high current input
connectors
• Cast frame EVS12SB 12-inch high excursion
subwoofer driver
• Integral low-pass filter -- No additional
amplifier or processor needed
SB122
12”400-Watt
Bass Module
General Description:
TheElectro-Voice®SB122bassmoduleisavery
compact,lightweight subwoofer systemthat is designed
to add bass enhancement to EV Sx and Zx Series
speakersystems. TheSB122combinesthe advantages
ofalong-throw12"wooferwithastrong, lightweight
compositeenclosure. Thelargeventprovideslessvent
compressionandturbulenceforincreasedlowfrequency
output. TheEVS12SBcastframetransducer created for
theSB122 usesthe samemotor and suspension design
as the EVS18S used in EV’s larger systems. With
nearlytwoinches of peak-to-peakexcursioncapability,
this is literally a twelve inch with the heart of an eighteen.
An integral low-pass filter allows the SB122 to be directly
connectedinparallel withafull-rangespeakerfortruly
impressivelow-end outputwithouttheneedforan
additionalamplifierandprocessor. Thefilteris transparent
below160Hz, allowingthe SB122 tobe usedas an
independentsubwooferinbiampapplicationswithoutthe
need to disable the internal filter. For maximum output in
biampapplicationsand protectionofthefull-rangesystem
whenrunningin parallel,a40HzHi-pass(subsonic)filter
isrecommended. The SB122featuresaconvenientpole
mount socket on top of the enclosure to allow a small full-
range speaker such as the Zx1 or Sx80 to be mounted on
the optionalASP-1 accessory pole, resulting in a
compact system than sounds much bigger than it looks.
Technical Specifications:
esnopseR.qerF
1
:)Bd3-(zH541-zH25
egnaR.qerF
1
:)Bd01-(zH002-zH34
dednemmoceR :ycneuqerFssaP-hgiH zH04
ytivitisneS
1
:)m1/W1LPS(Bd99
:LPSdetaluclaCxaMBd131
:).tnoC(gnildnaHrewoPsttaW004
:)kaeP(gnildnaHrewoPsttaW006,1
:recudsnarTFL)mm503(ni21,BS21SVE
revossorCdednemmoceR :pmaiB,egnaRycneuqerF zH061-zH08
:ecnadepmIsmhO8
:srotcennoC4LNnokaepSkirtueN)2(
:)DxWxH(miD"3.21x"9.61x"1.32 )mm213xmm924xmm685(
:thgieWteN)gk0.51(sbl33
:thgieWgnippihS)gk5.61(sbl4.63
1 Half Space measurement.

Accessories:
• 302055-000 ASP-1,Adjustable Sub Pole
• 5912525 PDSx,CarryingBag
• 302053-001 TSS-1,TripodStand
Performance Match:
• Q66PowerAmplifier
SB122 Part Number:
• 302013-001 SB122, Black Finish
• 302013-002 SB122, White Finish
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 3/2006
PartNumber 38110-535 Rev1
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
Dimension Drawing:Frequency Response:
WARNING: The SB122 is very
lightweight and has a small footprint.
Do not attempt to pole-mount a
speaker system larger than a Zx1 or
Sx80 on the SB122.
