Electro-Voice Phoenix PX2181 User manual

Technical Specifications:
The Electro-Voice®PX2181 is a high efficiency dual 18”
subwoofer system that is part of the Electro-Voice®
Phoenix Series and is intended for high output low
frequency sound reinforcement in fixed-installation and
portable sound applications. The PX2181 is configured
for biamping, and can be used with the PX2122 and
PX2152 for full range touring systems with extended LF.
The PX2181 uses dual DVX3180 woofers, a high
efficiency 18-inch woofer with forced air cooling. The
DVX3180’s are coupled to a low frequency horn for
maximum efficiency and punch. The enclosure is
constructed of 18-mm, 13-ply plywood, using tongue and
groove joints and EVCoat for long term durability.
The enclosure is designed to be placed in vertical and
horizontal configurations, and alignment cups are
placed in the enclosure to array multiple subwoofers.
Three PX2122’s can be placed on top of the PX2181 in
the horizontal configuration. A caster accessory is
available on the PX2181 for easy mobility.
A switch on the PX2181 allows connection of both
woofers to one amplifier channel in parallel mode, and
to be used with each woofer to an amplifier channel in
dual mode. In dual mode, three PX2181s can be
connected to two amplifier channels for maximum
flexibility.
General Description:
PX2181
Dual 18” Low-Frequency
Horn-Loaded Sub-ScoopTM
Loudspeaker System
Key Features:
• Dual Horn-Loaded DVX3180 18”LF
Transducers with Forced Air Cooling
• 1000W Continuous (4000W Peak) Power
Handling
• High-Efficiency Sub-ScoopTM Design
• Dual/Parallel Mode Selectable
• Very High Sensitivity,141 dB Maximum SPL
• Integral Mounting Points on Rear Panel for
Optional Wheel/Caster Kit
• Enclosure is Stackable in Both Horizontal
andVertical Orientations
esnopseR.qerF
1
:)Bd3-(zH061-zH54
egnaR.qerF
1
:)Bd01-(zH081-zH04
:ycneuqerFssapiH.ceRzH23
:ytivitisneSlaixA)m1/W1(Bd501
LPSdetaluclaCxaM
1
:Bd141
:egarevoClatnoziroHlanoitceridinmO
:egarevoClacitreVlanoitceridinmO
:rewoPmetsySdetaRkaePW0004,suounitnoCW0001
:srecudsnarTFLsrevirD)mm754(.ni81,0813XVD)2(
revossorCdednemmoceR :ycneuqerF zH521-zH08
:ecnadepmIlanimoNsmhO4
:srotcennoCs'4LNnokaepSkirtueN)2(
:lairetaMerusolcnEtaoCVEkcalBhtiwdoowylPmm81
MT
:ellirGAG61,detaoCredwoPretseyloP ogoLelbatatoRhtiwleetSdezinavlaG
:)DxWxH(miDmm857xmm965xmm9121 )58.92x"24.22x"00.84(
:thgieWteN)sbl5.091(gk5.68
:thgieWgnippihS)sbl7.802(gk8.49
1 Half Space measurement.

200001000010001005020
70
80
90
100
110
Frequency (Hz)
Sensitivity (dB)
Half Space, 125 HzLow Pass
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone],Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 10/2006
Part Number 38110-528 Rev. B
Frequency Response:
Block Diagram (Parallel Mode):
Dimension Drawings:
Front View
Top View
Right View
PX2181PartNumber
• 302015-001 PX2181, 18” Subwoofer, Black Finish
PerformanceMatch
• 302009-001 PX2122, 45° x 30° Horn, Black Finish
• 302011-001 PX2152, 60° x 45° Horn, Black Finish
• 302017-001 PX1122M, 90° x 45° Horn, Black Finish
• D170401 CP4000S, 120V, 1400W x 2, Compact
Precision Series Amplifier
• D170348 DX38, Digital Loudspeaker Processor
Accessories
• ASY000004-001 PX-D2, Dolly Kit for PX2181
Rear View
Block Diagram (Dual Mode):
DiagramNote:
This wiring results in
positive acoustic
pressure with a
positive voltage at
the input because
the woofers are
physically reversed.
DiagramNote:
This wiring results in
positive acoustic
pressure with a
positive voltage at
the input because
the woofers are
physically reversed.
