Electro-Voice Xi Series Xi-1191A User manual

Technical Specifications:
The Electro-Voice®Xi-1191A and Xi-1191AF subwoofer
loudspeaker systems are part of the Xi-A series and are
intended for high-level sound reinforcement for fixed-
installation and touring-sound applications. The Xi-
1191A(F) is a single 18-inch loudspeaker system designed
to be used with the Klark Teknik DN9848 as well as the
Electro-Voice Dx38 digital sound processor. These units
all provide frequency division, time delay and equalization,
and are appropriate for use with these subwoofers in
connection with other full-range Xi-A series products. The
Xi-1191A(F) is a vented-box design that utilizes a single
EVX-180B subwoofer. This subwoofer features a 102-mm
(4-inch) voice coil and an extremely high XMAX (maximum
linear excursion) for very-high sound pressure levels at
very-low frequencies. The Xi-1191A(F) enclosure is
constructed of 18-mm, 13-ply, birch plywood and is
available in a black or white textured-paint finish.The flying
system includes four full-track flying points (two on the top
and two on the bottom). Both flying (Xi-1191AF) and non-
flying (Xi-1191A) versions are available. The Xi-1191A(F)
loudspeaker system is an ideal choice for any professional
installation or regional touring application where accurate
low-frequency sound reproduction at high sound-pressure
levels is required.The Xi-1191A(F) with Dx38 Digital Signal
Processor create the ideal solution to subwoofer
applications where high acoustic power is required from
32 Hz to 160 Hz. The Xi-1191A(F) is designed specifically
to be used in conjunction with the full-range Xi-A systems
(such as Xi-1122A/85, Xi-1152A/64 & /94, Xi-1123A/106,
Xi-2123A/106, Xi-1153A/64, Xi-1183A/64, Xi-2153A/64, Xi-
1122MHA/64 and Xi-2122MHA/42).
General Description:
Xi-1191A, Xi-1191AF
18-InchTrue Subwoofer
Sound Reinforcement System
Key Features:
• EVX-180B Low-Frequency Driver: Excellent
Linear Excursion,SuperiorThermal Capability
• Available Flying (Xi-1191AF) and Non-Flying
(Xi-1191A)Versions
• Ring-Mode Decoupling / RMDTM
• Built-In L-Track Rigging
• Available in Black orWhite
• Footprint Identical to Xi-1153A, Xi-1183A,
Xi-2153A,Xi-2181A,Xi-2122MHA and
Xi-1122MHA
• Step-Down Tuning (28 Hz)
esnopseR.qerF
1
:)Bd3-(zH051-zH73
egnaR.qerF
1
:)Bd01-(zH061-zH23
:LPSdetaluclaCxaM)kaeP(Bd431
:egarevoClanoitceridinmO
:gnildnaHrewoPkaePW0042,suounitnoCW006
:ytivitisneSFLBd001
:ecnadepmIFLlanimoNsmho8
:recudsnarTFL,revirD)mm754("81B081-XVE)1(
:srotcennoCRPM8LN®nokaepSkirtueNowT
:lairetaMerusolcnEdoowylphcribylp-31,mm-81
:ellirGleetSAG61
:)DxWxH(miDmm957x685x419 )"9.92x"1.32x"0.63(
:)hcae(thgieWteN)sbl051(gk0.86
:thgieWgnippihS)sbl951(gk1.27
1 Half Space measurement with a Dx38 Controller

U.S.A.and Canada only.For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 8/2004
Part Number 38110-278 Rev.A
Architectural & Engineering Specs:
Dimension Drawings (Flying Version Shown):
Xi-1191APartNumbers
• 1147-3422 - Black
• 1147-3425 - White
Xi-1191AFPartNumbers
• 1147-3419 - Black
• 1147-3426 - White
The loudspeaker system shall be a low frequency system with performance controlled by the processors listed in this engineering data
sheet. The loudspeaker system shall have a single 18-inch low-frequency woofer. The woofer shall have an 8-ohm, 4-inch-diameter
voice coil constructed of aluminum wire, which shall be capable of handling a 600-watt shaped pinknoise signal with a 6-dB crest factor
for 8 hours (as per ANSI/EIA RS-426A & AES 2-1984).The loudspeaker system shall have a sensitivity of 100 dB (1 watt at 1 meter).The
loudspeaker system shall have an enclosure constructed of 18-mm, 13-ply birch plywood and shall have a vinyl-clad steel grille. The
flying version shall employ flying hardware of a “track” style and two tracks on the enclosure top and two tracks on the enclosure bottom.
The loudspeaker dimensions shall be 914 mm (36.00 in.) high, by 586 mm (23.07 in.) wide and 759 mm (29.88 in.) deep and shall
weigh 68.2 kg (150 lbs).
The loudspeaker shall be the Electro-Voice®Xi-1191A or Xi-1191AF.
Impedance:Frequency Response (Full & Half Space):
This Xi Loudspeaker should be suspended overhead only in accordance with the procedures and limitations specified in the
X-Array Xi Install Flying Manual and possible manual update notices. This system should be suspended with certified rigging
hardware by an authorized rigging professional and in compliance with local, state, and federal overhead suspension ordinances.
CAUTION
PerformanceMatch
• P3000 (RL) • CPS2.8 • Dx38
• P1200 (RL) • CPS2.11
Wiring/Connection Chart:
:FLnI1sniP tuO2sniP delellaraP4&3sniP srotcennoCneewteB
