Electro-Voice Xlc Series Xlc-127 User manual

Key Features:
•Control with Predictability
•Compact, Lightweight
•Fast, Simple Integrated Rigging
•Bi-Amp or Tri-Amp Operation
•True 3-Way Design
•LAPS Aiming Software
• 120°Horizontal Full-Range Line-Array
•DH2T-16, or ND6-16 HF Options
•Quik-RigTM or Fixed Installation Rigging
XLC-127, XLC-127+,
XLCi-127, XLCi-127+
3-Way, High-Output
Compact Line-Array
Element
GeneralDescription:
EV engineers have defined a new group of compact
line array elements, the XLC. It is comprised of three
components, XLC 127 full range, XLC 127+ full range with
D6-16 large format high frequency transducers and
the XLC 118 sub cabinet. The XLC 127 is a 3-way design
utilizing a 12" vented LF, 2 x 6.5" MB transducers on a
120° horizontal waveguide, and 2 x DH2T-16 HF
transducers combining through a Hydra to a 120° x 7°
waveguide. The XLC 127 can be used in tri-amp mode,
or bi-amp 3-way using the sophisticated internal passive
MB to HF network. The asymmetrical box design was
optimized to produce a symmetrical polar pattern with a
uniform power response. Designed for use in groups of
four or more the XLC 127 delivers predictability and
control. Combined with an advanced integrated rigging
system, one-man installations are a reality. The XLC
127 systems can also be ground stacked. Ideal for
applications ranging from live reinforcement to
performing arts venues to houses of worship, to sports
facilities, XLC gives you the power to make it happen.
The XLC 127+ uses two D6-16, 3 in., high-output,
neodymium compression drivers, replacing the standard
DH2T-16 drivers. The XLC 127+ is recommended when
performance requirements demand higher output. The
D6-16 is also used in EVs X-Array and X-Line systems
creating a family of identically voiced loudspeakers for
any mobile or permanent sound application. XLC can
deliver unprecedented performance, particularly in
difficult acoustical environments. LAPS modeling
software provides quick results for array configurations
and rigging information.
Technical Specifications:
721-CLX+721-CLX
esnopseR.qerF
1
:)Bd3-(zHk81-zH56
egnaR.qerF
1
:)Bd01-(zHk02-zH05
LPSdetaluclaCxaM
1
:kPBd141,.tnoCBd531
:egarevoClatnoziroH°021
:egarevoClacitreVelbanifeDerawtfoS,tnadnepeDyarrA
:)sepyThtoB(gniggiR,stnemercni°1,munimulAevitpaCylluF
rotcaFytefaS1ot8htiwstnemele61
:gnildnaHrewoPFLkaePW0021,.tnoCW003
:gnildnaHrewoPBMkaePW008,.tnoCW002
:gnildnaHrewoPFH,.tnoCW08
kaePW023
,.tnoCW051
kaePW006
rewoPFH/BMpmaiB
:gnildnaH
kaePW008,.tnoCW002
)FH/BM/FL(ytivitisneS
1
:Bd011/101/59
:qerFrevossorcBMotFLzH005
:qerFrevossorcFHotBM)evitcAroevissaP(zH0061
:dnabssaPFL
:reifilpmAdednemmoceR
smho8,TS21LD"21x1
0002PVE
:dnabssaPBM
:reifilpmAdednemmoceR
,smho8,56MD"5.6x2
0002PVE
:dnabssaPFH
:reifilpmAdednemmoceR
,61-T2HDx2
smho8
0002PVE
,61-6DNx2
,smho8
0002PVE
:dnabssaPFH/BMpmaiB
:reifilpmAdednemmoceR
,smho8
0002PVE
:srotcennoC8LNx2
:lairetaMerusolcnEarutuF/wdoowylphcribylp-31
:ellirGtniaptaocredwophtiwleetsdetalpcniZ
:cepSlatnemnorivnE018LIM,42PI925CEI
giR-kiuQ
MT
:)DxWxH(miD
:)DxWxH(miDllatsnI
"5.22x"93x"52.41
)mm275x099x263(
"5.22x"5.63x"52.41
)mm275x729x263(
giR-kiuQ(thgieWteN
MT
:)
:)llatsnI(
)gk7.25(sbl611
)gk4.05(sbl111
)gk4.05(sbl111
)gk1.84(sbl601
thgieWgnippihS
giR-kiuQ(
MT
:)
:)llatsnI(
)gk0.55(sbl121
)gk7.25(sbl611
)gk7.25(sbl611
)gk4.05(sbl111
1 Full Space Measurement of 4 Elements.

BlockDiagram:
DimensionDrawings(inches/metric):
PerformanceMatch:
• XLC-118 - Subwoofer Loudspeaker System
• XLC-118i - Subwoofer Install Loudspeaker System
• P3000 - Precision SeriesTM Power Amplifier
• P2000 - Precision SeriesTM Power Amplifier
• P3000RL - Precision SeriesTM Remote Control Power Amplifier
• P1200RL - Precision SeriesTM Remote Control Power Amplifier
• Dx38 - Digital Sound System Controller
• DN9848 - Digital Sound Controller
• XLC-127 Cover - Protective Cover for Transporting
• XCOV4 Cover - Protective Cover Fits 4 XLC-127’s for Transporting
• XFD-127 - Front Dolly for Rigging and Transporting
• XBD - 4-Tall Bottom Dolly for Rigging and Transporting
• XLC Series Quik-RigTM Grid A1 - Grid for Hanging XLC Line-Arrays
• XLCi Series Fixed Installation Grid A2 - Grid for Hanging XLCi
Line-Arrays
XLC-127 /XLC-127+ Part Numbers:
• XLC-127 - 301282-001
• XLC-127+ - 301302-001
• XLCi-127 - 301386-001
• XLCi-127+ - 301387-001
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 3/2003
Part Number 38110-144 Rev D
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
