Electrolux EKG 603301 User manual

Gas Cooker
EKG 603301
instruction booklet
RU
Руководство по
эксплуатации
Газоэлектрическая плита

Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future.
The Electrolux ambition is to offer a wide variety of quality products that make
your life more comfortable.
You find some examples on the cover in this manual. Please take a few minutes
to study this manual so that you can take advantage of the benefits of your new
machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind.
Good luck!

4electrolux
Guide to Use the instructions
The following symbols will be found in the text to guide you throughout the
Instructions:
Safety Instructions
)Step by step instructions for an operation
Hints and Tips
Environmentalinformation
This appliance complies with the following E.E.C. Directives:
• 2006/95 (Low Voltage Directive);
• 89/336(Electromagnetical Compatibility Directive);
• 90/396 (Gas Appliance Directive);
• 93/68 (General Directives);
and subsequent modifications.
Contents
Important safety information 5
Control Panel 9
Using the hob 11
Using the Gas oven 14
Using the Fan Gas Oven 17
When using the oven for the first 18
time
The electronic minute minder 19
Hints and tips for using the oven 22
Suggestions for gas burners 27
Cooking table 28
Cleaning and maintenance 30
Something not working 35
Service and spare parts 45
European guarantee 46
Technical data 36
Instructions for the installer 37
Electrical connection 44
For the user For the installer

electrolux 5
Important safety information
These warnings have been given for the safety of you and others. We
therefore ask you to carefully read the procedures of installing and using
this cooker.
Installation
• Thework of installationmust be carried
out by competent and qualified
installers according to the regulations
in force.
• Any modifications to the domestic
electrical mains which may be
necessary for the installation of the
appliance should be carried out only
by competent personnel.
• Ensure that air can circulate around
the gas appliance. Poor ventilation
can produce a lack of oxygen.
• This appliance is not connected to a
combustion products evacuation
device. It must be installed and
connected in accordance with current
installation regulations. Particular
attention shall be given to the relevant
requirements regarding ventilation.
• The use of a gas cooking appliance
results in the production of heat and
moisture in the room in which it is
installed. Ensure that the kitchen is
wellventilated: keep naturalventilation
holes open or install a mechanical
ventilation device (mechanical
extractor hood).
• Prolonged intensive use of the
appliance may call for additional
ventilation, for example opening of a
window, or more effective ventilation,
for example increasing the level of
mechanical ventilation where present.
• Avoid installation of the cooker near
inflammable material (e.g. curtains,
tea towels, etc.).
• Supply the appliance with the type of
gas stamped on the relevant adhesive
label situated in the immediate vicinity
of the gas connection tube.
• The appliance has to be placed on the
floor and it cannot be placed on a
base.
People Safety
• This appliance has been designed for
use by adults. Take care, therefore,
that children do not attempt to play
with it.
• The appliance remains hot for a long
timeafterbeingswitchedoff.Supervise
children at all times, paying attention
that they do not touch surfaces or
remain in the vicinity of the appliance
when in use or when not completely
cooled.
• This appliance is not intended for use
by children or other persons whose
physical, sensory or mental
capabilities or lack of experience and
knowledge prevents them from using
the appliance safely without
ENGLISHENGLISH
ENGLISHENGLISH
ENGLISH

6electrolux
supervision or instruction by a
responsible person to ensure that
they can use the appliance safely.
During Operation
• This product is intended for the
cooking of food and must not be used
for other purposes.
• It is dangerous to modify, or attempt
to modify, the characteristics of this
appliance.
• The appliance becomes very hot with
use, and retain their heat for a long
period after use. Care should be taken
to avoid touching heating elements
inside the oven.
•Always stand back from the oven
when opening the oven door
during cooking or at the end of it
to allow any build up of steam or
heat to release.
• Unstable or deformed pans should
not be placed on the burners or plates
in order to avoid accidents caused by
upsetting or boiling over.
• Particular care should be taken when
cooking with oil or fat.
• If the appliance is fitted with a cover,
its function is to protect the surface
from dust when closed and to accu-
mulatesplashes of grease when open.
Do not use for other purposes.
• Always clean the cover before closing.
• Leave the burners and/or plates to
cool before closing.
• All the covers, in plate glass or enamel,
are removable to facilitate cleaning.
•Always ensure that the knobs are
in the « 0 » or « z» (Stop) position
when the appliance is not in use.
• Always insert the dripping pan when
using the grill or when cooking meat
on the grid. Pour a little water into the
dripping pan to avoid grease burning
and creating unpleasant smells.
• Always use oven gloves to remove
dishes from the oven.
• The oven accessories should be
washed before using for the first time.
• Take care when using cleaning
products in spray form: never direct
the spray onto the resistance or the
thermostat bulb.
• If, when placing food in the oven, or
when removing it, a large quantity of
oil, juice, etc. spills onto the bottom of
the oven, re-clean before starting to
cook to avoid unpleasant smoke and
also the possibility of these
substances catching fire.
• For reasons of hygiene and safety
this appliance must always be kept
clean. A build up of grease or other
food can cause fires.
• This appliance cannot be cleaned
with steam or with a steam cleaning
machine.
• Do not use harsh abrasive cleaners or
sharp metal scraper to clean the oven
door glass since they can scratch the
surface, which may result in shattering
of the glass.
• The gas oven becomes hot with the
movement of air. The holes on the
bottom of the oven must never be
obstructed. Do not cover the sides of
the oven with aluminium foil, in
particularthe lower part of the opening.

electrolux 7
• The appliance is heavy, move it
carefully.
• Before maintenance and cleaning
disconnect the appliance and allow to
cool.
• To facilitate ignition, light the
burners before placing pans on
the grid. After having lit the burners
check that the flame is regular.
• Always lower the flame or turn it off
before removing the pan.
• Ensurethat the oven grids are inserted
correctly.
• Only heat-resistant plates may be
placed in the drawer situated under
the oven.Do not put combustible
materials there.
Service
• In case of repairs, do not attempt to
correct yourself. Repairs carried out
by unqualified persons can cause
damage. Contact an authorized
Technical Assistance Centre and
insist an original spareparts.
Environmental
Information
• After installation, please dispose of
the packaging with due regard to
safety and the environment.
• When disposing of an old appliance,
make it unusable, by cutting off the
cable.
The symbol on the product or on
its packaging indicates that this product
may not be treated as household waste.
Instead it shall be handed over to the
applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. For more detailed information
about recycling of this product, please
contact your local city office, your
household waste disposal service or the
shop where you purchased the product.

8electrolux
MANUFACTURER:
ELECTROLUX POLAND SP. Z.O.O.
ul. Kazimierza Odnowiciela 28
58-100 Swidnica
It is very important that this
instruction book should be kept
safely for future consultation. If the
appliance should be sold or given to
another person, please ensure that
the booklet goes together with it,
so that the new owner can know of
the functions of the machine and
also be aware of the warnings.
These instructions are only for the
countries stated by the symbol
printed on the front cover of this
instruction book.

electrolux 9
C
°
1. Back left burner control knob
(semi-rapid)
2. Front left burner control knob
(rapid)
3. Front right burner control knob
(auxiliary)
4. Back right burner control knob
(semi-rapid)
5. Thermostat control knob
6. Gas oven and electric grill control
knob
7. Electronic Programmer
8. Grill function pilot light
Control Panel
5432
817
6

10 electrolux
The Oven Cavity
Electric Grill Oven Light
Gas Oven
Bottom Plate
Accessories
Baking Tray Oven Shelf Dripping Pan

electrolux 11
Control knobs on the front
panel
The knobs for using the gas hob of the
cooker are found on the control panel.
The regulation knobs could be turned in
anti-clockwise direction until the small
flame symbol, and vice-versa for the
larger symbol.
zNo gas supply
Maximum gas supply
Minimum gas supply
Ignition of gas burners
• To ignite a burner, before positioning
thesaucepan, pushthecorresponding
knob in completely and turn in an
anticlockwise direction to the
maximum position ( ).
• Once a flame has appeared, hold the
control knob pressed in for around 5
seconds so as to activate the Oven
Safety Device (Thermocouple).
• Upon ignition regulate the flame as
required.
• If after a few attempts the burner does
not ignite, check that the baffle and its
cap are correctly positioned.
• To interrupt the supply of gas, turn the
knob in a clockwise direction to the
position " z".
Duringcooking, when usingfats
or oils, take particular care as
they can, when over-heated,
self-ignite.
Using the hob

12 electrolux
In the absence of electricity,
ignition can occur without the
electrical device; in this case
approach the burner with a flame,
push the relevant knob down and
turn it anti-clockwise until it
reaches the "maximum" position.
To ensure maximum burner efficiency,
you should only use pots and pans with
a flat bottom fitting the size of the burner
used (see table).
Burner} minimum maximum
diameter diameter
Large (rapid) 180 mm. 260 mm.
Medium (semi-rapid) 120 mm. 220 mm.
Small (auxiliary) 80 mm. 160 mm.
A- Burner cap
B- Burner crown
C - Ignition candle
D- Thermocouple
FO 0204

electrolux 13
Recommended pottery
Remember that a wide-bottomed pan
allows a faster cooking than a narrow
one. Always use pots which properly fit
what you have to cook.
Particularly make sure that the pans are
not too small for liquids, since these
could easily overflow.
Moreover, the pans should not be too
large for a faster cooking. In fact, grease
and juices may spread on the bottom
and burn easily.
It is better to use non-openable moulds
for baking cakes. In fact, an openable
mould lets juices and sugar leak
through, falling on the bottom of the oven
and consequently burning on the bottom
of the baking tray, making cleaning
difficult.
Avoid putting plastic-handled pans in the
oven as they are not heat-proof.
You should use oans with the right
diameter to fit the burner, in order to
make the most out of it, thus reducing
gas consumption.
It is also advisable to cover any boiling
casserole and, as soon as the liquid
starts boiling, lower the flame enough
to keep the boiling point.
Pots must not enter the control
zone.
Make sure pots do not protrude
over the edges of the cooktop
and that they are centrally
positioned on the rings in order
to obtain lower gas
consumption.

14 electrolux
Using the Gas Oven
Oven safety device
The gas oven features a thermocou-
ple; if for any reason the flame should
extinguish, the device will stop the gas
flow.
Always cook with the ovenAlways cook with the oven
Always cook with the ovenAlways cook with the oven
Always cook with the oven
door closed.door closed.
door closed.door closed.
door closed.
During cooking, the doorDuring cooking, the door
During cooking, the doorDuring cooking, the door
During cooking, the door
should be opened as little asshould be opened as little as
should be opened as little asshould be opened as little as
should be opened as little as
possible to avoid heat loss,possible to avoid heat loss,
possible to avoid heat loss,possible to avoid heat loss,
possible to avoid heat loss,
and excessive fueland excessive fuel
and excessive fueland excessive fuel
and excessive fuel
consumption.consumption.
consumption.consumption.
consumption.
)To ignite the oven gas burner:
1. Press the gas oven control
knob, turn it to 240 and wait
for the flame to come on. This
may take 10-15 seconds. Do
not release the knob until the
burner ignites. It is possible to
check the flame through the
holes in the bottom of the oven.
2. Upon ignition, keep the knob
pressed for about 5/10
seconds, then release it and
turn it to the required setting.
If the oven burner does not light
even after 15 seconds:
1. Release the gas oven control
knob and turn it to the “Off
position”.
2. Open the oven door and wait
for at least one minute before
trying to light the oven burner
again.
If the oven burner accidentally
goes out, turnthe gas oven
knob to the “Off” position
andwait at least one minute
before trying to lightthe burner
again.
)
The gas oven and the electric
grill cannot beused at the
same time. The ignition of the
gas oven burner prevents the
electric grill control knob to
operate.
When cooking with the oven
and with the grill, leave the lid
open in order to avoid
overheating.
Do not keep the control knob
pressed for more than 15
seconds.
If the burner does not light
even after 15 seconds, release
the control knob, turn it the
„off“ position and wait for at
least one minute before trying
to light the burner again.

electrolux 15
Electric grill
Press and turn the knob clockwise until
the stop position is reached , at the
same time the grill control light will come
on. Place the dripping pan under the wire
shelf so as to prevent fat from dripping
on the bottom of the oven.
Grill function control light
The grill control light will come on when
the oven control knob is turned to symbol
. The light will remain on until the
correct temperature is reached. It will
then cycle on and off to show the grill
heating element temperature is being
maintained.
Oven light
The oven light will be on without any
cooking function.
Thermostat Control Knob
Turn the thermostat control knob anti-
clockwise to select temperatures between
1 and 8. (table pag.29)
1
2
3
4
5
6
7
8
Oven Fan - It can be used in
combination with the gas oven burner
(“Fan cooking” function).
Controls

16 electrolux
Manual ignition (in case of
lack of electrical supply)
1. Open the oven door.
2. Hold a flame near the hole in the
bottom of the oven cavity as shown
in figure
3. At the same time press the gas oven
control knob and turn it anti-clock-
wise until the maximum temperature
("8") is reached.
It is possible to check the flame
through the holes in the bottom of the
oven.
4. When the oven burner is lit, keep the
gas oven control knob for approxi-
mately 10-15 seconds.
5. Release the control knob and then
gently close the oven door. To adjust
the temperature, turn the knob to the
required setting after a few minutes.
If the oven burner accidentally
goes out or does not light,
turn the oven knob to "z" and
wait at least one minute
before trying to light the burner
again.
)
hole for manual
ignition

electrolux 17
Using the Fan Gas OvenUsing the Fan Gas Oven
Using the Fan Gas OvenUsing the Fan Gas Oven
Using the Fan Gas Oven
The air inside the oven is heated
by the gas burner and the fan
circulates hot air to maintain an
even temperature inside the oven.
The advantage of cooking with this
function is energy saving through:
zFaster Preheating
As the fan oven quickly reaches tem-
perature, it is not usually necessary to
preheat the oven although you may
find that you need to allow an extra 5-
7 minutes on cooking times. For reci-
pes which require higher tempera-
tures, best results are achieved if the
oven is preheated first, e.g. bread,
pastries, scones, souffles, etc.
zLower Temperatures
Fan oven cooking generally requires
lower temperatures than conven-
tional cooking.
Follow the temperatures recom-
mended in the cooking chart. Re-
member to reduce temperatures by
about 20°C-25°C for your own reci-
pes which use conventional cooking.
zEven Heating for Baking
The fan oven has uniform heating on
all shelf positions. This means that
batches of the same food can be
cooked in the oven at the same time.
However, the bottom shelf may brown
slightly quicker than the upper one.
This is quite usual. There is no mix-
ing of flavours between dishes.
Always cook with the oven
door closed.
When cooking with the fan gas
oven, leave the lid open in
order to avoid overheating.
To use the Fan Gas Oven:
1. Light the oven gas burner as
described in “Using the Gas
Oven”, steps 1 and 2.
2. Upon ignition, turn the “Light-
Grill & Fan” control knob to
position .
The oven fan will start as soon
as the oven cavity reaches the
required cooking temperature.
)

18 electrolux
When using the oven for the first
time
Beforeusingtheappliance,remove
all packaging, both inside and
outsidetheappliance, including the
advertisinglabelsandanyprotective
film.
When using the oven for the first time:
a) Ignite the gas oven burner and set
the gas oven control knob to "8".
b) allow the oven to run empty for
approximately 45 minutes;
c) open a window for ventilation.
During this time, an unpleasant odour
may be emitted. This is absolutely
normal, and is caused by residues of
manufacturing.
Once this operation is carried out, let
the oven cool down, then clean the oven
cavity with a soft cloth soaked in warm
soapy water.
This procedure should be repeated with
the grill function for approximately
5-10 minutes.
Before cooking for the first time, carefully
wash the oven accessories.
To open the oven door, always
catch the handle in its central
part.

electrolux 19
When the electricity
is first switched on,
the display will show
12.00 and the time
indicator neon will
flash.
The electronic minute minder
Press the increase
button until the
correct time is
showing.
If necessary press
the decrease button
to help set the
correct time.
5 sec
The time indicator
neon will flash for
5 seconds then go
out.
The increase and decrease
control buttons operate slowly at
first and then more rapidly. They
should be pressed separately.
In the event of an interuption of the
electricity supply, the clock will stop and
you will not be able to use the main oven.
This oven has a 24-hour clock.
To set the countdown
The ‚Countdown‘ gives an audible
reminder at the end of any period of
cooking.
Press the selector control button until
the countdown indicator neon is
illuminated and the display reads 0.00
Press the increase button. Release the
button once the interval to be timed is
reached e.g. 30 minutes.

20 electrolux
If necessary press
the decrease button
to achieve the
correct time
interval.
This must be
completed within 5
seconds of first
pressing the selector
control button.
To cancel the countdown
The sound and the
countdown indicator neon
can be stopped by
pressing any button, then
the display reverts to the
time of day
During the operation
of the countdown the
remaining time period
will show in the
display
At the end of the timed
period a sound will be
heard intermittently and
the countdown indicator
neon will flash for up to 2
minutes.
Press the selector
control button until
the countdown
indicator neon
flashes.
Press the decrease
button until 0.00 is
shown in the
display.
The countdown
indicator neon will
continue to flash for
a few seconds and
then return to the
time of day.
