Electrolux EKK615A1OX User manual

EKK615A1OX
EN Cooker User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................5
3. PRODUCT DESCRIPTION................................................................................ 8
4. BEFORE FIRST USE......................................................................................... 9
5. HOB - DAILY USE............................................................................................ 10
6. HOB - HINTS AND TIPS.................................................................................. 11
7. HOB - CARE AND CLEANING.........................................................................11
8. OVEN - DAILY USE .........................................................................................12
9. OVEN - CLOCK FUNCTIONS.......................................................................... 13
10. OVEN - USING THE ACCESSORIES............................................................15
11. OVEN - HINTS AND TIPS.............................................................................. 16
12. OVEN - CARE AND CLEANING.................................................................... 20
13. TROUBLESHOOTING....................................................................................23
14. INSTALLATION.............................................................................................. 25
15. SAUDI ARABIA - CUSTOMER SERVICE ..................................................... 29
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Only a qualified person must install this appliance and
replace the cable.
•This appliance is intended for use up to an altitude of
2000 m above sea level.
•This appliance is not intended to be used on a ships,
boats or vessels.
•Do not install the appliance behind a decorative door
in order to avoid overheating.
ENGLISH 3

•Do not install the appliance on a platform.
•Do not operate the appliance by means of an external
timer or separate remote-control system.
•WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch
off the appliance and then cover flame e.g. with a lid
or a fire blanket.
•CAUTION: The cooking process has to be supervised.
A short term cooking process has to be supervised
continuously.
•WARNING: Danger of fire: Do not store items on the
cooking surfaces.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door or the glass of hinged
lids of the hob since they can scratch the surface,
which may result in shattering of the glass.
•Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot.
•Remove any spillage from the lid before opening. Let
the hob surface cool down before closing the lid.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years
of age shall be kept away unless continuously
supervised.
•Always use oven gloves to remove or put in
accessories or ovenware.
•Before maintenance cut the power supply.
•Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
www.electrolux.com4

Service Centre or similarly qualified persons to avoid
an electrical hazard.
•To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by
the manufacturer of the appliance in the instructions
for use as suitable or hob guards incorporated in the
appliance. The use of inappropriate guards can cause
accidents.
2. SAFETY INSTRUCTIONS
This appliance is suitable for the
following markets: SA
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• The kitchen cabinet and the recess
must have suitable dimensions.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• Parts of the appliance carry current.
Close the appliance with furniture to
prevent touching the dangerous parts.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
• Do not install the appliance adjacent
to a door or under a window. This
prevents hot cookware to fall from the
appliance when the door or the
window is opened.
• Make sure to install a stabilizing
means in order to prevent tipping of
the appliance. Refer to Installation
chapter.
2.2 Electrical Connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
ENGLISH 5

access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• Fully close the appliance door, before
you connect the mains plug to the
mains socket.
2.3 Gas connection
• All gas connections should be made
by a qualified person.
• Before installation, make sure that the
local distribution conditions (nature of
the gas and gas pressure) and the
adjustment of the appliance are
compatible.
• Make sure that there is air circulation
around the appliance.
• The information about the gas supply
is on the rating plate.
• This appliance is not connected to a
device, which evacuates the products
of combustion. Make sure to connect
the appliance according to current
installation regulations. Pay attention
to requirements regarding adequate
ventilation.
2.4 Use
WARNING!
Risk of injury and burns.
Risk of electrical shock.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and
oils when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food
remnants, can cause fire at a lower
temperature than oil used for the first
time.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
www.electrolux.com6

• Do not keep hot cookware on the
control panel.
• Do not let cookware boil dry.
• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.
• Do not activate the cooking zones
with empty cookware or without
cookware.
• Do not put aluminium foil on the
appliance or directly on the bottom of
the appliance.
• Cookware made of cast iron,
aluminium or with a damaged bottom
can cause scratches. Always lift these
objects up when you have to move
them on the cooking surface.
• Provide good ventilation in the room
where the appliance is installed.
• Use only stable cookware with the
correct shape and diameter larger
than the dimensions of the burners.
• Make sure the flame does not go out
when you quickly turn the knob from
the maximum to the minimum
position.
• Use only the accessories supplied
with the appliance.
• Do not install a flame diffuser on the
burner.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
2.5 Care and Cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance.
Disconnect the mains plug from the
mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Fat and food remaining in the
appliance can cause fire.
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
• Do not clean the burners in the
dishwasher.
2.6 Lid
• Do not change the specification of the
lid.
• Clean the lid regularly.
• Do not open the lid, when there are
spills on the surface.
• Before you close the lid turn all
burners off.
• Do not close the lid until the hob and
oven are completely cold.
• Glass lid can shatter, when heated (if
applicable).
• Keep the lid glass open, while the
oven is in operation (if applicable).
2.7 Internal light
• The type of light bulb or halogen lamp
used for this appliance is only for
household appliances. Do not use it
for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
ENGLISH 7

2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
• Flat the external gas pipes.
2.9 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
3. PRODUCT DESCRIPTION
3.1 General overview
2 3
5
6
7
8
1
9
1
2
3
4
5
4
1Electronic programmer
2Knob for the temperature
3Knob for the oven functions
4Knobs for the hob
5Heating element
6Lamp
7Turnspit hole
8Fan
9Shelf positions
3.2 Cooking surface layout
1 2
4 3
1Auxiliary burner
2Semi-rapid burner
3Semi-rapid burner
4Triple Crown burner
www.electrolux.com8

3.3 Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Baking tray
For cakes and biscuits.
•Turnspit
For roasting larger joints of meat and
poultry.
•Storage compartment
The storage compartment is below
the oven cavity. To use the
compartment, lift the lower front door
then pull it down.
WARNING!
The storage compartment
can become hot when the
appliance operates.
•Coffee pot (if applicable)
For coffee makers and small pans.
4. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
4.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial
position.
4.2 Setting the time
You must set the time before you
operate the oven.
The flashes when you connect the
appliance to the electrical supply, when
there was a power cut or when the timer
is not set.
Press the or to set the correct
time.
After approximately five seconds, the
flashing stops and the display shows the
time of day you set.
4.3 Changing the time
You cannot change the time
of day if the Duration or
End function operates.
Press again and again until the
indicator for the Time of Day function
flashes.
To set a new time, refer to "Setting the
time".
4.4 Preheating
Preheat the empty appliance to burn off
the remaining grease.
1. Set the function and the maximum
temperature.
2. Let the appliance operate for 1 hour.
3. Set the function and set the
maximum temperature.
4. Let the appliance operate for 15
minutes.
5. Set the function and set the
maximum temperature.
6. Let the appliance operate for 15
minutes.
Accessories can become hotter than
usual. The appliance can emit an odour
and smoke. This is normal. Make sure
that the airflow in the room is sufficient.
ENGLISH 9

5. HOB - DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Ignition of the hob burner
Always light the burner
before you put on the
cookware.
WARNING!
Be very careful when you
use open fire in the kitchen
environment. The
manufacturer declines any
responsibility in case of the
flame misuse.
The spark generator can
start automatically when you
switch on the mains, after
installation or a power cut. It
is normal.
In the absence of electricity
you can ignite the burner
manually.
Ignition of a hob burner with the
thermocouple
• For manual ignition put the flame near
the burner. Push the knob for the hob
down and turn it counterclockwise to
the maximum gas flow position .
• For integrated ignition on knob push
the knob for the hob down and turn it
counterclockwise to the maximum gas
flow position .
Keep the knob for the hob pushed for
equal or less than 10 seconds to let the
thermocouple warm up. If not, the gas
supply is interrupted.
Adjust the flame after it is regular.
WARNING!
Do not keep the knob
pushed for more than 15
seconds. If the burner does
not light after 15 seconds,
release the knob, turn it into
the off position and try to
light the burner again after
minimum 1 minute.
If after some tries the burner
does not light, check if the
crown and its cap are in the
correct position.
If the burner accidentally
goes out, turn the knob to
the off position and try to
light the burner again after
minimum 1 minute.
5.2 Burner overview
A
B
D
C
www.electrolux.com10

C
D
A
B
A. Burner cap
B. Burner crown
C. Ignition candle
D. Thermocouple (if applicable)
5.3 Turning the burner off
To put the flame out, turn the knob to the
off position .
WARNING!
Always turn the flame down
or switch it off before you
remove the pans from the
burner.
6. HOB - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Cookware
WARNING!
Do not put the same pan on
two burners.
WARNING!
Do not put unstable or
damaged pots on the burner
to prevent from spill and
injury.
CAUTION!
Make sure that pot handles
are not above the front edge
of the cooktop.
CAUTION!
Make sure that the pots are
placed centrally on the
burner in order to get
maximum stability and to get
lower gas consumption.
6.2 Diameters of cookware
WARNING!
Use cookware with
diameters applicable to the
size of burners.
Burner Diameter of cook‐
ware (mm)
Triple Crown 160 - 240
Semi-rapid 140 - 240
Auxiliary 120 - 180
6.3 Energy saving
• If it is possible, always put the lids on
the cookware.
• When the liquid starts to boil, turn
down the flame to barely simmer the
liquid.
7. HOB - CARE AND CLEANING
WARNING!
Refer to Safety chapters.
7.1 General information
• Clean the hob after each use.
• Always use cookware with clean
bottom.
ENGLISH 11

• Scratches or dark stains on the
surface have no effect on how the hob
operates.
• Use a special cleaner applicable for
the surface of the hob.
• Wash stainless steel parts with water,
and then dry them with a soft cloth.
7.2 Cleaning the hob
•Remove immediately: melted plastic,
plastic foil, sugar and food with sugar.
If not, the dirt can cause damage to
the hob. Take care to avoid burns.
•Remove when the hob is
sufficiently cool: limescale rings,
water rings, fat stains, shiny metallic
discoloration. Clean the hob with a
moist cloth and non-abrasive
detergent. After cleaning, wipe the
hob dry with a soft cloth.
• To clean the enamelled parts, cap
and crown, wash them with warm
soapy water and dry them carefully
before you put them back on.
7.3 Cleaning the spark plug
This feature is obtained through a
ceramic ignition candle with a metal
electrode. Keep these components well
clean to prevent difficult lighting and
check that the burner crown holes are
not obstructed.
7.4 Pan supports
The pan supports are not
resistant to washing in a
dishwasher. They must be
washed by hand.
1. Remove the pan supports to easily
clean the hob.
Be very careful when
you replace the pan
supports to prevent the
hob top from damage.
2. After you clean the pan supports,
make sure that they are in correct
positions.
3. For the burner to operate correctly,
make sure that the arms of the pan
supports are aligned with the centre
of the burner.
7.5 Periodic maintenance
Speak to your local Authorised Service
Centre periodically to check the
conditions of the gas supply pipe and the
pressure adjuster, if fitted.
8. OVEN - DAILY USE
WARNING!
Refer to Safety chapters.
8.1 Activating and deactivating
the appliance
It depends on the model if
your appliance has lamps,
knob symbols or
indicators:
• The lamp turns on when
the appliance operates.
• The symbol shows
whether the knob controls
one of the cooking zones,
the oven functions or the
temperature.
• The indicator turns on
when the oven heats up.
1. Turn the knob for the oven functions
to select an oven function.
2. Turn the knob for the temperature to
select a temperature.
3. To deactivate the appliance, turn the
knobs for the oven functions and
temperature to the off position.
8.2 Safety thermostat
Incorrect operation of the appliance or
defective components can cause
dangerous overheating. To prevent this,
the oven has a safety thermostat which
interrupts the power supply. The oven
activates again automatically when the
temperature drops.
www.electrolux.com12

8.3 Cooling fan
When the appliance operates, the
cooling fan activates automatically to
keep the surfaces of the appliance cool.
8.4 Oven functions
Sym‐
bol
Oven function Application
Off position The appliance is off.
Conventional Cooking To bake and roast food on one shelf position.
Bottom Heat To bake cakes with crispy bottom and to preserve
food.
Top Heat To brown bread, cakes and pastries. To finish
cooked dishes.
Grilling with Turnspit To grill meat, including kebabs and smaller pieces
of meat.
True Fan Cooking To bake on up to two shelf positions at the same
time and to dry food.
Set the temperature 20 - 40 °C lower than for
Conventional Cooking.
Defrost This function can be used for defrosting frozen
foods, such as vegetables and fruits. The defrost‐
ing time depends on the amount and size of the
frozen food.
9. OVEN - CLOCK FUNCTIONS
9.1 Electronic programmer
Display
A B C
A. Function indicators
B. Time display
C. Function indicator
ENGLISH 13

Buttons
Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.
Clock functions table
Clock function Application
TIME OF DAY To set, change or check the time of day.
DURATION To set how long the appliance operates.
END To set when the appliance deactivates.
TIME DELAY To combine DURATION and END function.
MINUTE MIND‐
ER
To set countdown time. This function has no effect on
the operation of the appliance. You can set the MINUTE
MINDER at any time, also when the appliance is off.
Setting the DURATION
1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the DURATION
time.
The display shows .
4. When the time ends, flashes and
an acoustic signal sounds. The
appliance deactivates automatically.
5. Press any button to stop the acoustic
signal.
6. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
Setting the END
1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the time.
The display shows .
4. When the time ends, flashes and
an acoustic signal sounds. The
appliance deactivates automatically.
5. Press any button to stop the signal.
6. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
Setting the TIME DELAY
1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the time for
DURATION.
4. Press .
5. Press or to set the time for
END.
6. Press to confirm.
www.electrolux.com14

Appliance turns on automatically later on,
works for the set DURATION time and
stops at the set END time. At the set time
an acoustic signal sounds.
7. The appliance deactivates
automatically. Press any button to
stop the signal.
8. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
Setting the MINUTE MINDER
1. Press again and again until
starts to flash.
2. Press or to set the necessary
time.
The Minute Minder starts automatically
after 5 seconds.
3. When the set time ends, an acoustic
signal sounds. Press any button to
stop the acoustic signal.
4. Turn the knob for the oven functions
to the off position.
Cancelling the clock functions
1. Press the again and again until
the necessary function indicator
starts to flash.
2. Press and hold .
The clock function goes out after some
seconds.
10. OVEN - USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
10.1 Inserting the accessories
Wire shelf:
Put the shelf between the guide bars of
the shelf support. The front and back
bars should be placed upwards.
Tray:
Do not push the baking tray
all the way to the back wall
of the cavity. This prevents
the heat from circulating
around the tray. The food
may be burnt, especially in
the rear part of the tray.
Push the tray or deep pan between the
guide bars of the shelf support. Make
sure it does not touch the back wall of
the oven.
10.2 Using the turnspit
WARNING!
Be careful when you use the
turnspit. The forks and the
spit are sharp. There is a
risk of injury.
WARNING!
Use oven gloves when you
remove the turnspit. The
turnspit and the grill are hot.
There is a risk of burns.
ENGLISH 15

CAUTION!
The maximum weight
permitted on the turnspit is
4.5 kg.
A B C
D
A. Support hook
B. Forks
C. Spit
D. Handle
The support hook is installed
in the top of the oven cavity.
You can leave the support
hook in the oven, when the
turnspit is not active.
1. Open the oven door.
2. Put the turnspit handle into the spit.
3. Put the baking tray on the lowest
shelf level.
4. Snap out one end of the support
hook from the oven ceiling A and let
it hang on the other end.
A
5. Install the first fork on the spit, then
put the meat on the turnspit and
install the second fork.
Make sure that the meat is in the
middle of the spit.
6. Use the screws to tighten the forks.
7. Put the tip of the spit into the turnspit
hole.
Refer to "Product description"
chapter.
8. Put the front part of the spit on the
support hook.
9. Remove the turnspit handle.
10. Turn the knob for the oven functions
to the turnspit position .
11. Set the necessary temperature.
12. Make sure that turnspit rotates.
13. Close the oven door.
The turnspit does not stop if you
open the oven door.
Turn off the grill. Install the turnspit
handle. Carefully remove the turnspit and
the roasting pan from the oven.
11. OVEN - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
www.electrolux.com16

11.1 General information
• The appliance has five shelf positions.
Count the shelf positions from the
bottom of the appliance floor.
• The appliance has a special system
which circulates the air and constantly
recycles the steam. With this system
you can cook in a steamy
environment and keep the food soft
inside and crusty outside. It
decreases the cooking time and
energy consumption to a minimum.
• Moisture can condense in the
appliance or on the door glass panels.
This is normal. Always stand back
from the appliance when you open the
appliance door while cooking. To
decrease the condensation, operate
the appliance for 10 minutes before
cooking.
• Clean the moisture after each use of
the appliance.
• Do not put the objects directly on the
appliance floor and do not put
aluminium foil on the components
when you cook. This can change the
baking results and cause damage to
the enamel.
11.2 Baking
• Your oven may bake or roast
differently to the appliance you had
before. Adapt your usual settings
such as temperature, cooking time
and shelf position to the values in the
tables.
• Use the lower temperature the first
time.
• If you cannot find the settings for a
special recipe, look for the similar
one.
• You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
• Cakes and pastries at different
heights do not always brown equally
at first. If this occurs, do not change
the temperature setting. The
differences equalize during the baking
procedure.
• Trays in the oven can twist during
baking. When the trays become cold
again, the distortions disappear.
11.3 Baking cakes
• Do not open the oven door before 3/4
of the set cooking time is up.
• If you use two baking trays at the
same time, keep one empty level
between them.
11.4 Cooking meat and fish
• Use a deep pan for very fatty food to
prevent the oven from stains that can
be permanent.
• Leave the meat for approximately 15
minutes before carving so that the
juice does not seep out.
• To prevent too much smoke in the
oven during roasting, add some water
into the deep pan. To prevent the
smoke condensation, add water each
time after it dries up.
11.5 Cooking times
Cooking times depend on the type of
food, its consistency, and volume.
Initially, monitor the performance when
you cook. Find the best settings (heat
setting, cooking time, etc.) for your
cookware, recipes and quantities when
you use this appliance.
11.6 Cooking tables
The time does not include
preheating.
ENGLISH 17

Casseroles
Food Quantity
(kg)
Oven function Temper‐
ature
(°C)
Time
(min)
Shelf po‐
sition
Lasa‐
gna 1)
1.5 - 2.5 True Fan Cooking 190 50 - 55 2
Cannelloni
1)
1.5 - 2.5 True Fan Cooking 190 50 - 55 2
Potato
gratin
1)
1.5 - 2.5 True Fan Cooking 170 65 - 70 2
Macaroni
oven
1)
1.5 - 2.5 True Fan Cooking 180 40 - 50 2
Kebab Ha‐
la
1.5 - 2.5 True Fan Cooking 180 45 - 50 2
1) Preheat the oven for 10 minutes.
Meat & Poultry
Food Quantity
(kg)
Oven function Temper‐
ature
(°C)
Time
(min)
Shelf
position
Sheep 1.5 - 2.5 True Fan Cooking 200 90 - 120 2
Chicken 1.0 - 1.8 Conventional cooking 230 90 -
1001)
2
Duck 1.8 - 2.5 True Fan Cooking 220 90 - 120 2
Goose 2.5 - 3.0 True Fan Cooking 220 100 -
160
2
Rabbit 1.0 - 1.5 True Fan Cooking 180 90 - 120 2
Beef 1.2 - 1.8 True Fan Cooking 250 90 - 120 2
1) Turn over after 45 min.
Fish
Food Quantity
(kg)
Oven function Temper‐
ature
(°C)
Time
(min)
Shelf po‐
sition
Pike 0.8 - 1.5 True Fan Cooking 170 60 - 80 2
Dorade 0.4 - 0.7 True Fan Cooking 170 40 - 60 2
Trout 0.5 - 1.0 True Fan Cooking 180 25 - 30 2
www.electrolux.com18

Pizza
Food Quantity
(kg)
Oven function Temper‐
ature
(°C)
Time
(min)
Shelf
position
Thin
1)
1.0 - 1.2 True Fan Cooking 240 20 - 25 1
Thick
1)
1.4 - 1.5 True Fan Cooking 210 25 - 30 1
Calzone
1)
1.4 - 1.5 True Fan Cooking 170 30 - 35 1
1) Preheat the oven for 10 minutes.
Cakes
Food Quantity
(kg)
Oven function Temper‐
ature
(°C)
Time
(min)
Shelf
position
Flat cake
1)
0.6 - 1.0 True Fan Cooking 180 25 - 30 3
Flat cake
1)
1.2 - 2.0 True Fan Cooking 150 40 - 45 2 and 4
Sponge
cake
1.0 - 1.5 True Fan Cooking 150 90 - 95 2
Feter
Mshalted
1)
1.0 - 1.5 True Fan Cooking 190 40 - 45 2
Salty cake
1)
1.0 - 1.2 True Fan Cooking 180 50 - 60 2
Yeast cake
1)
1.0 - 1.5 True Fan Cooking 180 45 - 50 2
1) Preheat the oven for 10 minutes.
Grilling
Food Quantity (kg) Oven function Time (min) Shelf posi‐
tion
Sheep
chops1)
0.7 - 1.2 Grilling 20 - 25 3
Ribs
1)
1.0 - 1.2 Grilling 45 - 60 3
Burgers
1)
2.0 - 2.5 Grilling 15 - 20 3
ENGLISH 19

Food Quantity (kg) Oven function Time (min) Shelf posi‐
tion
Mackerel
1)
1.2 - 1.5 Grilling 20 - 25 3
Toast brown‐
ing
1)
0.3 - 0.5 Grilling 5 - 6 4
Toast Hawai
1)
0.5 - 1.0 Grilling 15 - 20 3
1) Preheat the oven for 5 minutes.
Revolving frying
Food Quantity (kg) Oven function Time (min) Shelf posi‐
tion
Sheep on
skewer
1.5 - 2.0 Grilling with Turn‐
spit
100 - 120 Turnspit
Chicken on
skewer
1.2 - 1.8 Grilling with Turn‐
spit
95 - 100 Turnspit
12. OVEN - CARE AND CLEANING
WARNING!
Refer to Safety chapters.
12.1 Notes on cleaning
• Clean the front of the appliance with a
soft cloth with warm water and a
cleaning agent.
• To clean metal surfaces, use a
dedicated cleaning agent.
• Clean the appliance interior after each
use. Fat accumulation or other food
remains may result in a fire.
• Clean stubborn dirt with a special
oven cleaner.
• Clean all accessories after each use
and let them dry. Use a soft cloth with
warm water and a cleaning agent.
• If you have nonstick accessories, do
not clean them using aggressive
agents, sharp-edged objects or a
dishwasher. It can cause damage to
the nonstick coating.
12.2 Stainless steel or
aluminium appliances
Clean the oven door with a
damp cloth or sponge only.
Dry it with a soft cloth.
Do not use steel wool, acids
or abrasive materials as they
can damage the oven
surface. Clean the oven
control panel with the same
precautions.
12.3 Removing the shelf
supports
To clean the oven, remove the shelf
supports.
1. Pull the front of the shelf support
away from the side wall.
www.electrolux.com20
