Electrolux EIGD50LIW Installation instructions

Gas Front Load Dryer
EIGD50L IW
Featuring IQ-Touch™Electronic Controls
electroluxappliances.com
Largest Capacity Dryer1
Dry the most in one load with
8.0 cu. ft. capacity.
Fast Dry Cycle2
Eighteen minutes to dry.
IQ-Touch™Controls
The IQ-Touch™control panel offers all
the cycles/options you need– including a
“My Favorite” setting.
“My Favorite” Setting
A setting you can customize to meet your
needs, so the option you want is available
at the touch of a button.
27" GAS FRONT LOAD DRYER
Capacity I.E.C.
Features
Signature Soft-Arc Door Design
IQ-Touch™Electronic Controls with LCD Display
Gentle Tumble™Dry System
Luxury-Quiet™Sound System
Luxury-Design®Lighting
Luxury-Dry™System
Touch-2-Open™/(Close) Door
Exact Dry™Moisture Sensor
Painted Dryer Drum
Tumble Speed (RPM)
Reversible Door
Adjustable Leveling Legs
NSF®Certified
Cycles
Fast Dry, My Favorite (1), Heavy Duty,
Bulky/Bedding, Mixed Load, Towels, Normal,
Casual, Delicate, Touch Up, Timed Dry
Options
Temperature Selections
Electronic Auto Dry System
Manual Timed Dry Selections
End-of-Cycle Chime
Installation Options
Freestanding, Under Counter*,
Stacked (Above Washer), Pedestal, Hidden (In Closet),
Second Floor, 4-Way Dryer Venting
Accessories
Luxury-Glide
®
Touch-2-Open
™
/(Close) Pedestal –
Island White – PN# EPWD15IW
Dryer Stacking Kit – PN# STACKIT4X
LP Gas Conversion Kit – PN# PCK4300
Mobile Home Installation Kit – PN# 137067200
Drying Rack – PN# 137453000
Specifications
Color –
Island White
Product Dimensions –
Height (Without 15" Pedestal)
(With 15" Pedestal)
Width
Depth (to Center of Arc Including Door and Exhaust)
(with 90° Door Open)
Maximum Exhaust Duct Length3(Ft.)
Gas/Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @120 Volts‡
Amps@120 Volts
Heating Element (BTU/HR)
Shipping Weight (Approx.)
*Side-by-Side units in under-counter installation require custom-built countertop and/or cabinetry.
‡For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and national electric & gas codes. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
8.0 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
50
Yes
Yes
Yes
11
5
Yes
5
Adjustable
Yes
Optional
Optional
Optional
Optional
Optional
IW
38"
53"
27"
31-1/2"
50-5/8"
125
Bottom Center Rear/
Bottom Right Rear
120V/60Hz/ 15A
0.835
9.0
20,000
140 Lbs.
1Based on manufacturer specifications.
2Fast time based on smallest load / Fast Wash and Fast Dry cycles selected for various load compositions.
3Rigid metal duct preferred, semi-rigid optional and allow deductions for elbows and vents. Refer to
Installation Guide on web for additional information.
Optional Luxury-Glide
®
Touch-2-Open
™
Pedestal Shown
Island White
Island White
EIGD50L IW
Wall OvensRefrigerators Warmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsFreezersUnder Counter
Washers / Dryers Dishwashers /
Kitchen Cleanup

Gas Front Load Dryer
EIGD50L W
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EIGD50L 03/12 © 2012 Electrolux Home Products, Inc.
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Gas Dryer Specifications
•
Product Weight – 130 Lbs.
•
An electrical supply with grounded three-prong receptacle is required.The
power supply circuit must be installed in accordance with current edition
of National Electrical Code (ANSI/NFPA 70) and local codes & ordinances.
(Do not use same circuit as washer.)
•
Voltage Rating –120V/60Hz/15 Amps
•
Amps @120 Volts = 9.0 Amps
•
Connected Load (kW Rating) @120 Volts = 0.835kW
•
Equipped with 120V 3-wire power supply cord, approx. 60" long.
•
Always consult local and national electric & gas codes.
•
Can be installed alone, with or without optional 15" drawer pedestal, or
stacked above matching Electrolux Washer, which requires installation of
optional dryer stacking kit. (For installation details, refer to instructions
included with optional pedestal or stacking kit or on web.)
•
Can be built in with matching Electrolux Washer in under-counter,
recessed or closet installation. Installations requiring countertop and/or
cabinetry will require custom building. (Refer to Built-In Installations on
this page for cutout dimensions. For additional installation details, refer to
Product Installation Guide on web.)
•
Closet installation requires vented door with 2 unobstructed louvered
openings, minimum 60 sq.in. each, located 3" from top and bottom of
door. Full-length120 sq.in. opening also acceptable. Allow 1" clearance
between door and fronts of units.
•
Do NOT install in area exposed to dripping water or outdoor weather
conditions, or where gasoline or other flammables, including automobiles,
are kept or stored.
•
Floor MUST be solid with 1" maximum slope. To ensure vibration or
movement does not occur, reinforcement of floor may be necessary.
Do NOT install on carpeted surface.
•
Dryer MUST exhaust to outside of building, NOT into any concealed space.
•
Dryer equipped for 4-way venting and approved for up to 125-foot-
equivalent of duct length, determined by length of run and number of
elbows needed.
•
Exhaust installation requires minimum 4"-diameter rigid or semi-rigid
metal duct with approved, unobstructed vent hood having swing-out
damper(s). If installing rigid metal duct (preferred), do not exceed
MAXIMUM venting run length of 125 ft., allow deductions for elbows and
vents. If installing semi-rigid metal duct, do not exceed MAXIMUM venting
run length of 8 ft., always allow deductions for elbows and vents (Refer to
Product Installation Guide on web for additional information). Do NOT use
flexible plastic or metal foil duct and use shortest run possible.
•
Gas supply line should be 1/2" pipe and MUST have individual shutoff valve.
•
Leveling legs supplied to level dryer properly and reduce excessive
noise and vibration.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
Drawer Pedestals – Island White (PN# EPWD15IW).
•
Dryer Stacking Kit – (PN# STACKIT4X).
•
Mobile Home Installation Kit – (PN# 137067200).
•
Drying Rack – (PN# 137453000).
•
LP Gas Conversion Kit – (PN# PCK4300).
