Electrolux T4190 User manual

487 05 42-91/EN
2010.05.28
Service manual
Tumble dryers
T4190
Type N1190
Compass Control
From machine no. 04190/0100000
Service manual in original language

3
Contents
Contents
Safety precautions ....................................................................................... 5
Technical data.............................................................................................. 7
Description of principal components ........................................................... 9
Description .............................................................................................. 9
Programs - Compass Control ................................................................. 9
Loading door ......................................................................................... 10
Knob operation...................................................................................... 10
Coin drop/card reader........................................................................... 10
Motor ..................................................................................................... 10
Periodic maintenance ............................................................................... 19
Functional inspection ............................................................................ 19
Maintenance.......................................................................................... 19
Optimizing the air flow ............................................................................... 21
Air flow................................................................................................... 21
Air volume.............................................................................................. 21
Adjusting the dryer ................................................................................ 22
Gas installation ...................................................................................... 23
Controls...................................................................................................... 27
Printed circuit board.............................................................................. 27
Connecting accessory systems ............................................................ 27
Connection to network/Central Panel ................................................... 28
Programming......................................................................................... 29
Replacement of PCB............................................................................. 30
Sensors and overheating thermostats. ...................................................... 33
Overview, inlet air .................................................................................. 33
Inlet air - Overheating thermostat.......................................................... 34
Inlet air - Thermistor element (PT100 sensor) ....................................... 35
Overview, outlet air................................................................................ 36
Outlet air - Overheating thermostat....................................................... 37
Outlet air - Thermistor element (NTC sensor)........................................ 38
Door switch ................................................................................................ 39
Loading door switch.............................................................................. 39
Motor and transmission ............................................................................. 41
Motor description .................................................................................. 41
Replacement fan module ...................................................................... 43
Heating....................................................................................................... 47
Electric heated dryers............................................................................ 47
Gas heated dryers ................................................................................. 50
Converting to another type of gas......................................................... 54
Gas error................................................................................................ 55
Drum with bearing...................................................................................... 57
Description ............................................................................................ 57

4Contents
Cabinet, door reversal................................................................................ 61
Door reversal ......................................................................................... 61
RMC ........................................................................................................... 63
RMC general.......................................................................................... 63
Pressure switch.......................................................................................... 65
The manufacturer reserves the right to make changes to design and
component specifications.

5
Safety Precautions
Safety Precautions
Do not dry unwashed items in the machine
The machine is not to be used if industrial chemicals have been used for cleaning.
Do not allow minors to use the machine.
Do not hose down the machine with water.
The machine's door lock must under no circumstances be bypassed.
Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in the
machine.
Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber
backed articles and clothes or pillows tted with foam rubber pads should not be
dried in the machine.
Fabric softeners or similar products should be used as specied by the fabric
softener instructions.
The machine may not be used to dry oor mops that contain polypropylene.
The nal part of a drying cycle occurs without heat (cool down cycle) to ensure that
the items are left at a temperature that ensures that the items will not be damaged.
WARNING. Never stop the machine before the end of the drying cycle unless all items
are quickly removed and spread out so that the heat is dissipiated.
Remove garments from the machine as soon as they are dried. This prevents them
from becoming creased and reduces the risk of spontaneous ignition.
If the machine develops a fault, this must be reported to the person in charge as soon
as possible. This is important both for your safety and that of others.
The machine must not be located where a door, sliding door, etc., can block the
machine's door
The machine is not intended to be used by people (including minors) with reduced
physical or mental capacity or lack of experience and knowledge. Such people must
be instructed in the use of the machine by a person who has responsibility for their
safety. Minors must be supervised to ensure that they do not play with the machine.
Adequate ventilation has to be provided to avoid the back ow of gases into the room
for appliances burning other fuels, including open res.
Gas heated tumble dryer:
The machine is not to be installed in rooms containing cleaning machines with
perchloroethylene, TRICHLOROETHYLENE or CHLOROFLUOROCONTAINING
HYDROCARBONS as cleaning agents.
If you can smell gas,
• Do not switch on any equipment
• Do not use electrical switches
• Do not use telephones in the building
• Evacuate the room, building or area
• Contact the person responsible for the machine
In order to prevent damage to the electronics (and other parts) that may occur as the
result of condensation, the machine should be placed in room temperature for 24 hours
before being used for the rst time.

6

7
Technical data
Technical data - type T4190
Heating Electric Gas
Drum volume: 190 litres 190 litres
Weight net: 103 kg 103 kg
Drum: Diameter 680 mm 680 mm
Depth 555 mm 555 mm
Revolutions per minute 50 rpm 50 rpm
Capacity: Factor 1:25 7.5 kg 7.5 kg
Factor 1:33 5.8 kg 5.8 kg
Heat effect: Electric heating: 6.0 kW 6.6 kW
8.0 kW 8.0 kW
Air consumption: Heat effect 6.0 kW / 6.6 kW 270 m3/h 270 m3/h
Heat effect 8.0 kW / 8.0 kW 290 m3/h 290 m3/h
Piping: Evacuation Ø 125 Ø 125
Gas piping: ISO 7/1 R 1/2
Pressure drop:
Evacuation 6.0 kW / 6.6 kW 380 Pa 380 Pa
8.0 kW / 8.0 kW 350 Pa 350 Pa
Sound power level: Lw<68 dB (A) <68 dB (A)

8Technical data
Technical data - motor specifications
Dryer with reversal:
Fan motor:
Effect 140 W
Revolutions per minute: 50 Hz 2660 rpm
60 Hz 2860 rpm
Drum motor:
Effect 130 W
Revolutions per minute: 50 Hz 2730 rpm
60 Hz 3330 rpm

9
Description of principal components
Description
Dryer type T4190 is available as electric and gas heated.The dryer has a vent into
the open air.
Programs - Compass Control
The dryer has a microprocessor. The microprocessor control has different functions
including:
• Drum reversing for less tangling of large items.
• Service program for adjustment parameters eg. temperatur, cool-down time.
• Dryer functions monitoring - errors occurred during the program sequence are
registered in the log. Some of the error codes are shown on the display at the same
time.
• RMC (Residual Moisture Control), the dryer stops automatically when the clothes have
reached the required residual moisture level.
Display
Knob operation
for program
selection
Door

10 Description of principal components
Loading door
Normally the dryer has a right-hinged door.
The door is, however, reversible (see section "cabinet, door reversal").
A door switch ensures that the dryer stops automatically if the dryer is opened during the
program sequence, see section "door switch".
Knob operation
Turn and select by using the knob and the following appears:
• Program selection
• Start button
• Language selection
Coin drop / card reader
The dryer is available with a factory-installed coin drop, a factory-installed card-start
system, or it can be prepared for field installation of a card start system.
On vending models, insertion of a coin or card buys an owner-programmed drying time.
Motor
The dryer has two motors, motor 1 operates the blower and motor 2 operates the drum.

11
Description of principal components
410
12
9
3
8
7
6
2
5
1
11
10
10
4
10
12
9
38
7
2
5
1
6
1. B1 Connection terminal
2. Ext Connection max.
1,25A 200-240V AC
3. TR1 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Relay (fan)
9. Cn X/Y Capacitor
10. RC RC unit
11. C Motor operating capacitor
12. F10 Fuse F10A
200-240V 3AC
200-230V 1AC
1. B1 Connection terminal
2. Ext Connection max
1,25A 230-240V AC
3. TR1 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. RL Relay (door)
7. F10 Fuse F 6.3 A
8. C Motor operating
capacitor
9. Cn X/Y Capacitor
10. RC RC unit

12
410
10
11
9
3
8
7
6
2
5
1
4
10
10
10
10
8
7
6
39
2
5
1
10
1. B1 Connection terminal
2. Ext Connection max 100 mA
110V AC
3. TR1 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Contactor (fan)
9. Cn X/Y capacitor
10. RC RC unit
400-480V
3 AC without N
1. B1 Connection terminal
2. Ext Connection max
1,25A 230V AC
3. TR1 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Relay (fan)
9. Cn X/Y Capacitor
10. RC RC unit
11. C Motor operating capacitor
400-480V
3 AC + N
Description of principal components

13
Description of principal components
83
1
6
7
7
4
6
893
7
7
4
1
5
2
2
6
1. B1 Connection terminal
2. Ext Connection max.
1,25A 200-240V AC
3. TR1 Transformer
4. K1 Contactor (drum right)
5. K2 Contactor (drum left)
6. K3 Relay (fan)
7. RC RC unit
8. C Motor operating capacitor
(Fan)
1. B1 Connection terminal
2. Ext Connection max.
1,25A 200-240V AC
3. TR1 Transformer
4. K1 Contactor (drum right)
5. K2 Contactor (drum left)
6. K3 Relay (fan)
7. RC RC unit
8. C2 Motor operating capacitor
(fan)
9. C1 Motor operating capacitor
(drum)
200-240V 3AC
400-415V 3 AC with N
230-240V 1 AC

14 Description of principal components
1
2
3
7
7
7
4
5
6
1. B1 Connection terminal
2. Ext Connection max.
100 mA 110V
3. TR1 Transformer
4. K1 Contactor (drum right)
5. K2 Contactor (drum left)
6. K3 Contactor (fan)
7. RC RC unit
400-480V 3 AC-
without N

15
Description of principal components
1. B1 Connection terminal
2. Ext Connection max. 1,25A 200-240V AC
3. T11 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Contactor (fan)
9. Cn X/Y Capacitor
10. C Motor operating capacitor (fan)
11. F10 Fuse F10A
12. S2 Air pressure switch
13. A24 Distribution card
230-240V 3AC
200V 3AC
1. B1 Connection terminal
2. Ext Connection max. 1,25A 200V AC
3. T11 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Contactor (fan)
9. Cn X/Y Capacitor
10. C Motor operationg capacitor (fan)
11. F10 Fuse F10A
12. S2 Air pressure switch
13. A24 Distribution card
From machine No. 4190/0106772

16 Description of principal components
1. B1 Connection terminal
2. Ext Connection max. 1,25A 230-240V AC
3. T11 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Contactor (fan)
9. Cn X/Y Capacitor
10. C Motor operating capacitor (fan)
11. F10 Fuse F10A
12. S2 Air pressure switch
13. A24 Distribution card
14. C Motor operating capacitor (drum)
15. Distr. Connectors, heating
230-240V 1AC
400-415V 3AC+N
1. B1 Connection terminal
2. Ext Connection max. 1,25A 230V AC
3. T11 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Contactor (fan)
9. Cn X/Y Capacitor
10. C Motor operationg capacitor (fan)
11. F10 Fuse F10A
12. S2 Air pressure switch
13. A24 Distribution card

17
Description of principal components
1. B1 Connection terminal
2. Ext Connection max. 100mA 110 AC
3. T11 Transformer
4. K9 Contactor, heat
5. K4 Contactor, heat
6. K1 Contactor (drum right)
7. K2 Contactor (drum left)
8. K3 Contactor (fan)
9. Cn X/Y Capacitor
10. S2 Air pressure switch
11. A24 Distribution card
200-240V 3AC
400-415V 3AC + N
1. B1 Connection terminal
2. Ext Connection max. 1,25A 200-240V AC
3. T11 Transformer
4. K1 Contactor (drum right)
5. K2 Contactor (drum left)
6. K3 Contactor (fan)
7. C Motor operationg capacitor
(fan)
8. S2 Air pressure switch
9. A24 Distribution card
400-480V 3AC without N

18 Description of principal components
1. B1 Connection terminal
2. Ext Connection max. 1,25A 200-240V AC
3. T11 Transformer
4. K1 Contactor (drum right)
5. K2 Contactor (drum left)
6. K3 Contactor (fan)
7. C Motor operating capacitor
(drum)
8. C Motor operating capacitor
(fan)
9. S2 Air pressure switch
10. A24 Distribution card
1. B1 Connection terminal
2. Ext Connection max. 100mA 110V
3. T11 Transformer
4. K1 Contactor (drum right)
5. K2 Contactor (drum left)
6. K3 Contactor (fan)
7. S2 Air pressure switch
8. A24 Distribution card
230-240V 1AC
400-480V 3AC without N

19
Periodic maintenance
40 mm
1
2
Functional inspection
Functional inspection comprises:
1. Checking the door switch.
2. Test run.
1. Check the door switch
Check whether the safety lock works. The drum
must stop when the door is opened. When the
door is closed again, the tumbler must not start
until the start button is pressed.
2. Test run
Check that the fan, drum rotation and heat all
stop when the door is opened max. 40 mm.
Maintenance
The following should be carried out at regular
intervals, depending on the frequency of use.
Daily
• Check that the drum stops when the door is
opened.
• Check that the lint screen under the door has been
cleaned. Use a soft brush or your hand, fig. 2.
• Check that the lint screen is not damaged.
• Check that the tumble dryer will not start until the
start/stop button has been activated.

20
Monthly
Dryer with RMC
In order for the residual humidity control to work
in an optimal manner it is important that the lift
rolls inside the drum and the glide surfaces for
the graphite carbon are cleaned.
If these surfaces are not cleaned the automatic
residual humidity control can be degraded resul-
ting in the garment being damper than required
at the conclusion of the programme.
See g. 1.
Cleaning
Wipe off/clean drum and lifters with citric acid
(Acidum citricum). If soap/softener residue re-
mains, it is recommended also to use a coarse
sponge.
Cleaning intervals depend on the operational
usage. Cleaning must howeverbe carried out at
least once each month.
It is recommended that the glide surfaces are
cleaned every third to sixth month or as re-
quired. See g. 2.
Quarterly/Semi-annually
• Check that the fresh-air intake at the rear of the
tumble is not clogged by lint or blocked in any
other way.
• Check that the filter is not broken.
• If the filter is defective it needs replacing.
• At least once a year a skilled expert should
check the inside wearing parts of the tumble
dryer and clean them of lint.
1
Maintenance
The area surrounding the dryer
Fresh-air intake to the room
Check that the fresh-air intake to the room and
the exhaust ducts/pipes from the room are not
clogged by lint/dust or blocked in any other way.
Dryer area
Check that the dryer area is clear and free
from combustible materials, gasoline and other
flammable vapours and liquids.
2
Periodic maintenance
