Electrolux EHD36020U User manual

user manual
Induction hob
EHD36020U

We were thinking of you
when we made this product

electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class
product from Electrolux, which hopefully
will provide you with lots of pleasure in
the future. The Electrolux ambition is to
offer a wide variety of quality products
that make your life more comfortable.
You will find some examples on the cov-
er in this manual. Please take a few min-
utes to study this manual so that you
can take advantage of the benefits of
your new machine. We promise that it
will provide a superior User Experience
delivering Ease-of-Mind. Good luck!

4electrolux contents
Contents
Operating Instructions 5
Safety instructions 5
Description of the Appliance 7
Operating the appliance 10
Tips on Cooking and Frying 20
Cleaning and Care 24
What to do if … 26
Disposal 28
Installation Instructions 29
Assembly 30
Installing more than one
Frontline hob 34
Guarantee/Customer Service 40
Service 42
T
he following symbols are used in this user information:
1
Warning! This must be read! Important advice for the safety of persons and
information on avoiding damage to the appliance
3General information and advice
2Information on environmental protection
zDangerous voltage

operating instructions electrolux 5
Operating Instructions
Safety instructions
Please comply with these instructions. If
you do not, any damage resulting is not
covered by the warranty.
Correct use
•This appliance is not intended for
use by children or other persons
whose physical, sensory or mental
capabilities or lack of experience and
knowledge prevents them from us-
ing the appliance safely without su-
pervision or instruction by a
responsible person to ensure that
they can use the appliance safely.
•Do not leave the appliance unattend-
ed during operation.
•This appliance should be used only
for normal domestic cooking and fry-
ing of food.
•The appliance must not be used as a
work surface or as a storage surface.
•Additions or modifications to the ap-
pliance are not permitted.
•Do not place or store flammable liq-
uids, highly inflammable materials or
fusible objects (e.g. plastic film, plas-
tic, aluminium) on or near the appli-
ance.
Children’s safety
•Small children must be kept away
from the appliance.
•Only let bigger children work on the
appliance under supervision.
•To avoid small children and pets un-
intentionally switching the appliance
on, we recommend activation of the
child safety device.
General safety
•The appliance may only be installed
and connected by trained, registered
service engineers.
•Built-in appliances may only be used
after they have built in to suitable
built-in units and work surfaces that
meet standards.
•In the event of faults with the appli-
ance or damage to the glass ceramic
(cracks, scratches or splits), the ap-
pliance must be switched off and
disconnected from the electrical
supply, to prevent the possibility of
an electric shock.
•Repairs to the appliance must only
be carried out by trained registered
service engineers.
Safety during use
•Overheated fats and oils can ignite
very quickly. Warning! Fire hazard!
•There is the risk of burns from the
appliance if used carelessly.
•Remove stickers and film from the
glass ceramic.
•Cables from electrical appliances
must not touch the hot surface of the
appliance or hot cookware.
•Switch the cooking zones off after
each use.

6electrolux safety instructions
Safety when cleaning
•For cleaning, the appliance must be
switched off and cooled down.
•For safety reasons, the cleaning of
the appliance with steam jet or high-
pressure cleaning equipment is not
permitted.
How to avoid damage to the appli-
ance
•The glass ceramic can be damaged
by objects falling onto it.
•The edge of the glass ceramic can
be damaged by being knocked by
the cookware.
•Cookware made of cast iron, cast
aluminium or with damaged bottoms
can scratch the glass ceramic if
pushed across the surface.
•Objects that melt and things that boil
over can burn onto the glass ceramic
and should be removed straighta-
way.
•To avoid damaging cookware and
glass ceramics, do not allow sauce-
pans or frying pans to boil dry.
•Do not use the cooking zones with
empty cookware or without cook-
ware.

description of the appliance electrolux 7
Description of the Appliance
Cooking surface layout
Control panel layout
Induction cooking
zone 1400 W
with power function 1800 W
Induction cooking
zone 2300 W
with power function 3700 W
Frontline strip
Control panel
Child lock pilot
light
Heat setting
indicator Warm up pilot
light
Warm up pilot
light Heat setting
indicator
Child lock
Heat setting
selection
Automatic warm-up
function/Power
function
Automatic warm-up
function/
Power function Heat setting selection
Timer indicator
Timer selection
On/Off pilot
light
On/Off
Timer

8electrolux description of the appliance
Touch Control sensor fields
The appliance is operated using Touch
Control sensor fields. Functions are
controlled by touching sensor fields and
confirmed by displays and acoustic sig-
nals.
Touch the sensor fields from above,
without covering other sensor fields.
Sensor field Function
On / Off To switch the appliance on and off
Increase settings To increase heat settings
Reduce settings To reduce heat settings
Timer Timer selection
Increase settings To increase Timer time
Reduce settings To reduce Timer time
Child lock Locking control panel for children
Power Switching the power function on and off

description of the appliance electrolux 9
Displays
Residual heat indicator
Warning! Risk of burns from residu-
al heat. After being switched off, the
cooking zones need some time to
cool down. Look at the residual heat
indicator h.
Residual heat can be used for melt-
ing and keeping food warm.
The induction cooking zones create
the heat required for cooking directly in
the base of the cookware. The glass ce-
ramic is merely heated by the residual
heat of the cookware.
The cooling fan switches itself on and
off depending upon the temperature of
the electronics.
Display Description
¾Cooking zone is switched off
uKeep warm setting Keep warm setting is set
¿- ÇHeat settings Heat setting is set
eFault Malfunction has occurred
hResidual heat Cooking zone is still hot
lChild safety device Child safety device is engaged
pPower Power function is switched on
_Automatic switch off Switch off is active.

10 electrolux operating the appliance
Operating the appliance
Use the induction cooking zones
with suitable cookware.
Switching the appliance on and off
After switching on, within approx.
10 seconds a heat setting or a func-
tion must be set, otherwise the ap-
pliance automatically switches
itself off.
Setting the heat setting
Control panel Display Pilot light
Switch on Touch for 2 seconds ¾/ hlights up
Switch off Touch for 1 second h/ none goes out
Control panel Indicator
To increase Touch uto Ç
To decrease Touch Çto ¾
To switch off Touch and at the same time ¾

operating the appliance electrolux 11
Automatic warm-up function and Power function
The sensor field controls the Power
function and the automatic warm-up
function. Both functions make more
power available to the cooking zone for
a short time.
Function Pre-condition Result
Automatic warm-up
function
A heat setting from ¿to Æis
set Appliance heats up on heat setting Çuntil the
heat setting set is
reached
Power function Heat setting ¾or Çis set Appliance heats up for a
maximum of 10 minutes
on heat setting p.

12 electrolux operating the appliance
Using the automatic warm-up function
All cooking zones are equipped with an
automatic warm-up function. The auto-
matic warm-up function sets the cook-
ing zone to the highest setting for a
certain period of time and then automat-
ically switches back to the cooking set-
ting that was originally set.
If during the automatic warm up a
higher heat setting is selected, e.g.
from Áto Ã, the automatic warm
up is adjusted.
The length of time that the automatic
warm up function operates depends on
the heat setting selected.
Automatic warm-up
function
Sensor field Pilot light
To switch on Touch for 1 second at
heat setting ¿to Æ
is lit throughout the au-
tomatic warm up period
To switch off Touch for 1 second goes out
Heat setting Length of the automatic warm up [min:sec]
v 0:10
1 0:10
2 0:10
3 3:10
4 5:50
5 10:10
6 2:00
7 2:30
8 2:50
9 ---

operating the appliance electrolux 13
Switching the power function on and off
The power function makes more
power available to the induction cooking
zones, e.g. to bring a large quantity of
water to the boil quickly.
The power function is activated for
10 minutes. After that the induction
cooking zone automatically switches
back to heat setting 9.
If the power function has ended, the
cooking zones automatically switch
back to the heat setting set previ-
ously.
Power Management
The cooking zones of the cooking sur-
face have a maximum power available
to them.
So that the Power function can always
be carried out, Power Management may
reduce the power of the other cooking
zone.
Example: heat setting 9 is selected on a
cooking zone. The Power function is
switched on for the other cooking zone.
The Power function is performed, but
heat setting 9 on one cooking zone and
Power function on the other cooking
zone exceeds the maximum output for
both. Therefore Power Management re-
duces the first cooking zone that was
switched on from 9 to 7, for example,
and the display for this cooking zone al-
ternates between 9 and 7 and then re-
mains on the current maximum of 7.
(Whether the display alternates between
9 and 7 or 9 and 6 or other values, de-
pends on the appliance type and the
size of the cooking zone.)
Control panel Pilot light/Indicator
To switch on Touch with heat setting
set to 0or 9
lights up, p
To switch off Touch goes out, 9
Touch goes out, 9

14 electrolux operating the appliance
Using the child safety device
The child safety device prevents unin-
tentional use of the appliance.
The child safety device can only be
switched on and off, if the appliance
is switched on, but no cooking zone
has a heat setting set.
Activating the child safety device
If you want to use a locked cooking
zone (indicator l), an acoustic sig-
nal sounds.
Step Control panel Indicator/Signal
1. Switch on the appliance
(Do not set a heat setting)
¾
2. Touch l
Appliance switches off. The child safety device is activated.

operating the appliance electrolux 15
Overriding the child safety device
The child safety device can be released
in this way for a single cooking session;
it remains activated afterwards.
After overriding the child safety de-
vice, a heat setting or a function
must be set within
approx. 10 seconds, otherwise the
appliance automatically switches it-
self off.
Deactivating the child safety device
Step control panel Indicator/Signal
1. Switch on the appliance l
2. and touch any one of the
cooking zones
acoustic signal
Until the appliance is next switched off, it can be used as normal.
Step Control panel Indicator/Signal
1. Switch on the appliance l
2. Touch 0lights up
Appliance switches off. The child safety device is deactivated.

16 electrolux operating the appliance
Using the timer
All cooking zones can use each use one
of the two timer functions at the same
time.
If a heat setting is set on this cook-
ing zone in addition to a countdown
timer, the cooking zone is switched
off after the time set has elapsed.
Selecting the cooking zone
Function Condition Outcome after time
has elapsed
Safety cut-out When a heat setting is set acoustic signal
0lights up
Cooking zone switches
off
Countdown timer When cooking zones are not
used
acoustic signal
0lights up
Step Control panel Display
1. Touch once Pilot light for the back cooking
zone flashes
2. Touch once Pilot light for the front cooking
zone flashes

operating the appliance electrolux 17
Setting the time
If other timer functions are set, after
a few seconds the shortest remain-
ing time of all the timer functions is
displayed and the corresponding pi-
lot light flashes.
Switching off the Timer function
Changing the time
Step Control panel Indicator
1. Select cooking zone Pilot light for the selected cooking zone
flashes
2. Touch or 0to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel Display
1. Select a cooking
zone Pilot light of the selected cooking zone flashes more quickly.
Remaining time is displayed
2. Touch for the cooking
zone selected
The remaining time counts down to 00.
Simultaneoulsy touch
and for the cooking
zone selected
00 is displayed.
The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Step Control panel Indicator
1. Select cooking zone Pilot light of the selected cooking zone
flashes faster
Time remaining is displayed
2. Touch or 01 to 99 minutes
After a few seconds, the pilot light flashes more slowly.
The time is set.
The time counts down.

18 electrolux operating the appliance
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected
flashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. Touch Acoustic signal to acknowledge.
Acoustic signal stops.

operating the appliance electrolux 19
Automatic switch off
Cooking surface
•If after switching on the cooking sur-
face, a heat setting is not set for a
cooking zone within approx. 10 sec-
onds, the cooking surface automati-
cally switches itself off.
•If one or more sensor fields are cov-
ered for longer than approx. 10 sec-
onds, e.g. by a pan placed upon it, a
signal sounds and the cooking sur-
face switches off automatically.
•If all cooking zones are switched off,
the cooking surface automatically
switches itself off after approx. 10
seconds.
Control panel
Moisture (e.g. a wet cloth) or liquid
boiling over onto the control panel
immediately switches all cooking
zones off.
Induction cooking zones
•In the case of overheating (e.g. when
a saucepan boils dry) the cooking
zone automatically switches itself off.
_is displayed. Before being used
again, the cooking zone must be set
to 0and cooled down.
•If cookware that is not suitable is
used, flights up in the display and
after 2 minutes the indicator for the
cooking zone switches itself off.
•If one of the cooking zones is not
switched off after a certain time, or if
the heat setting is not modified, the
relevant cooking zone switches off
automatically. _is displayed. Before
being used again, the cooking zone
must be set to 0.
Heat setting Switches off after
v, 1 - 26 hours
3- 45 hours
54 hours
6- 91.5 hours

20 electrolux tips on cooking and frying
Tips on Cooking and Frying
Information on acrylamides
According to the latest scientific
knowledge, intensive browning of
food, especially in products con-
taining starch, can constitute a
health risk due to acrylamides.
Therefore we recommend cooking
at the lowest possible temperatures
and not browning foods too much.
Cookware for induction cooking zones
Cookware material
Cookware for induction cooking
zones is labelled as suitable by the
manufacturer.
Suitability test
Cookware is suitable for induction cook-
ing, if …
•... a little water on an induction cook-
ing zone set to heat setting 9 is heat-
ed within a short time.
•... a magnet sticks to the bottom of
the cookware.
Certain cookware can make noises
when being used on induction cook-
ing zones. These noises are not a
fault in the appliance and do not af-
fect operation in any way.
Bottom of the cookware
The bottom of the cookware should be
as thick and flat as possible.
Cookware material Suitable
Steel, enamelled steel yes
Cast iron yes
Stainless steel if appropriately labelled by the manufacturer
Aluminium, copper, brass ---
Glass, ceramic, porcelain ---
