Electrolux EW30GF65G - 30'' Gas Range User manual

Min-2-Max™Burner
Designed with a dual-flame sealed burner,
this cooktop offers the widest range of BTU
performance in the industry for the utmost
versatility – from a roaring 18,000-BTU boil to
a gentle 450-BTU simmer.
Sure-2-Fit™Convection Oven
with Hidden Bake Burner
Adjustable Luxury-Glide™oven racks are so smooth
and extend effortlessly. Luxury-Design™Lighting
ramp-up designer halogen lighting is as beautiful
as it is functional. Exclusive Luxury-Hold™oven
door stays put at whatever angle you place it.
Baking Options
Features 6 cooking modes and 10 cooking options
including our exclusive Perfect Turkey™button
for large holiday meals. Perfect Convect3™Third
Element European Convection System features
a variable 2-speed fan for more even cooking.
Perfect Pair™Oven
Our ranges feature a large main oven and a second
oven for the utmost cooking capacity. Use both
simultaneously to cook two different items at two
different temperatures.
Gas Freestanding Ranges
EW30GF65G S, EW30GF65G W, EW30GF65G B
Featuring Wave-Touch™Electronic Controls
30" GAS FREESTANDING RANGES
Sabbath Mode (Star-K®Certified)
Control Panel Features
Wave-Touch™Electronic Oven Control
Professional-Grade Burner Controls
Glass Front Display
Electronic Clock & Timer
Temperature Display
Automatic Oven (Delay, Cook & Off)
Cooktop Features
Min-2-Max™Dual-Flame Sealed Burner – 18,000 - 450 BTU
Sealed Power Burner – 14,000 BTU
Sealed Precision Burner – 9,500 BTU
Sealed Precision Burner – 5,000 - 850 BTU
Linear Flow Burner Valves
Seamless Cooktop
Continuous Grates with Deep-Well Top
Electric Pilotless Ignition
Oven Features
Capacity
Hidden Bake Burner
Bake Burner – 18,000 BTU
Broil Burner – 13,500 BTU
Convection Burner – 200 Watts
Cobalt Blue Interior
Self-Clean Options with Door Lock
Perfect Convect3™with Variable 2-Speed Fan
Cooking Modes –
Bake, Broil, Convection Bake, Convection Roast,
Keep Warm, Slow Cook
Cooking Options –
Perfect Turkey™, Defrost, Dehydrate, Bread Proof,
My Favorites, Multi-Stage Cooking, Temperature Probe,
Rapid Preheat, Delay Bake, Convection Convert
Luxury-Design™Lighting with Dual 40W Halogen Bulbs
Luxury-Glide™Racks
Conventional Racks
Convection Roasting Rack
Additional Features
Signature Soft-Arc Oven Door and Handle Design
Luxury-Hold™Oven Door
Extra-Large Glass Window
Perfect Pair™Lower Oven
Fully Extendable Drawer Glides
Adjustable Leveling Legs
Accessories
Porcelain Broiler Pan and Insert
Grill/Griddle
Wok Ring – 318254307
Simmer Plate – 318254206
Specifications
Oven Cavity Dimensions –
Height
Width
Depth
Overall Exterior Dimensions –
Height
Width
Depth (to Center of Arc)
(with 90° Door Open)
Gas/Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @120 Volts‡
Product Weight
Shipping Weight (Approx.)
‡For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and/or national electric and gas codes. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1
1
2
1
Yes
Yes
3
Yes
5.1 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
3
Yes
6
10
Yes
2
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Included
Included
Optional
Optional
18-5/8"
24-5/16"
19-1/2"
47-1/2"
29-7/8"
26-27/32"
47"
Right Bottom Rear
120V/60Hz/15A
1.8
260 Lbs.
300 Lbs.
electroluxappliances.com
Wall OvensWarmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsDishwashersRefrigerators
FreezersUnder Counter

30" Gas Freestanding Range Specifications
•
Product Weight – 260 Lbs.
•
Voltage Rating –120V/60Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 1.8kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120 Volts = 15 Amps
•
Always consult local and/or national electric and gas codes.
•
Range ships with 3/4" factory regulator.
•
Range is NOT Lp convertible — for Lp-only models see EW3LGF65GS,
EW3LGF65GW and EW3LGF65GB.
•
Overhead cabinetry should not exceed a 13" maximum depth.
•
Allow 30" minimum clearance between top of rangetop and bottom of
unprotected wood or metal overhead cabinetry.
•
Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum width
of appliance.
•
Allow 24" minimum clearance when bottom of wood or metal overhead
cabinet is protected by not less than 1/8" flame-retardant millboard
covered with not less than No.28 MGS sheet steel, 0.015" stainless
steel, 0.024" aluminum or 0.020" copper.
•
Allow 5" minimum clearance from edge of rangetop to nearest
combustible wall on either side of unit.
•
To reduce risk of fire when using overhead cabinetry, install range hood
that projects horizontally a recommended minimum of 5" beyond bottom
of cabinets.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
Wok Ring – (318254307).
•
Simmer Plate – (318254206).
Gas Freestanding Ranges
EW30GF65G S, EW30GF65G W, EW30GF65G B
High standards of quality at Electrolux Major Appliances mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EW30GF65G 01/08 © 2008 Electrolux Major Appliances, NA Printed in the U.S.A.
Side
Overall depth
including oven
door in 90°open
position – 47"
285/8"
263/8"
Front
357/8"
Adjustable
to
361/8"
297/8"
115/8"
471/2"
30"min.
13"
max.
25"
24"
5"min.
to nearest
combustible
wall (either
side of unit)
above 36"
height
301/8"
2"
15"
111/2"
Area allows for flush
installation with through-
the-floor connection
of pipe stub/shutoff valve
Area allows for flush
installation with through-
the-wall connection of
pipe stub/shutoff valve
and rear wall120V outlet
C
L
101/2"
7"
23"
18"min.
36"
stand.
34"
min.
Gas
connection
and power
supply
location
(right bottom
rear)
