Electrolux 970-6874 Instruction Manual

970-68612.eps T20G0097.eps T20V0231.eps T20T0205.eps T20D0061.eps
SEARS CANADA
Product No. 970-687420
Series 30" f/s elec
Color white
Market Canada
Owner's Guide 316417286
Installation Instructions 316259203
Service Data Sheet 316458450
Electrolux Major Appliances
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4 Publication No.
5995502852
07/10/24
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
970-6874
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995502852 970-687420
10/07 2
BACKGUARD

970-687420 Publication No: 5995502852
# Functional Parts 3 10/07
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316416100 Shield, backguard, rear wall
13A 316095502 Switch, infinite, warmer
14 316022500 Light/Lamp, indicator, 125 V
15 316411403 Support, backguard, white, RH
15A 316411402 Support, backguard, white, LH
19 316402715 Panel, backguard, white
20 # 316462802 Controller, electronic, ES535
20A 316419801 Overlay, clock, white, ES515
27 5303935217 Switch, simmer select, push button, w/white bezel
28 316219300 Button, simmer select, white
31 316442400 Knob, control, white
31A 316442403 Knob, warm zone, white
31B 316442409 Knob, dual control, white
31C 316442406 Knob, simmer, white
46 316437800 Lens-light/lamp, indicator, clear
54 # 316436000 Switch, infinite, small element
54A# 316436001 Switch, infinite, large element
54B# 316238200 Switch, infinite, triple
56 316234012 Shield, backguard, white, inner
69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg
77 316247900 Spacer, power board, (3)
77A 316114100 Spacer, (4)
97 316418101 Board, cooktop lockout
97A 316429301 Board, simmer select
100 5303289910 Screw, 8A, 1", power board mtg
* # 316525609 Harness, wiring, lockout
* 316417286 Owners Manual
* 316458450 Service Tech Sheet, w/wiring diagrm
* 316259203 Instructions, installation
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995502852 970-687420
10/07 4
BODY

970-687420 Publication No: 5995502852
# Functional Parts 5 10/07
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401800 Panel, main back
3 316400116 Panel, bodyside, white, RH
3 316400117 Panel, bodyside, white, LH
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316498900 Leveling Leg Assy, metal, front, (2), bracket & leg
6A 316425800 Rack, oven, w/handle
6B 316425700 Rack, oven sump
8 316400601 Panel, oven bottom
8* 316064600 Support, oven bottom
8A 316411104 Base, bake element
9 316081900 Pan, broilerOPTIONAL ACCESS0RY
10 316082000 Insert, broiler panOPTIONAL ACCESS0RY
12 316445500 Switch, oven light, door frame
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
26 316409000 Shield, warmer side, (2)
33A 316402100 Shield, rear wall, lower
37 # 316490000 Probe, oven temp
39 # 318113108 Cord, electric
42 316400702 Shield, wool, lower
43 3131732 Screw, 8-18 x 1.438, oven bottom
44 316517600 Spacer, oven door
45 316234100 Shield, wire, vent tube
57 316457800 Cover, access
58 316403802 Insulation, oven sump
58A 316406600 Insulation, oven wrapper
58B 316406500 Insulation, oven back
59 316208401 Vent Tube, assembly, w/catalyst
59A 316208304 Tube, oven vent, upper
62 5303935061 Terminal Block Kit
62* 316205500 Nut, hex flange, 3/8 10-32
66 # 316203301 Element, broil
67 316413800 Element, bake, hidden
68 316404000 Support, element, broil
71 316422304 Shield, rear wall
77 316456700 Glide, warmer drawer, outer/RH & LH, (2)
86 316530700 Receptacle, hinge
86* 316418901 Screw, trilobe, 10-32 x 5/16"
87 316081202 Bracket, cable mtg
88 316203500 Rod, auto latch
89 # 316464301 Motor-latch
106 316404100 Bracket, motor mtg.
107 316026701 Cover, fan
108# 316415800 Motor, fan
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
151 316404600 Shield, bodyside
161# 316211603 Element, convection fan, 350 W
170 5303935180 Anti-tipKit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
* # 316506240 Wiring Harness, main
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 Screw, 8-18 x 0.5, black
* 316021132 Screw, 8-18 X 11/16, black
* 316089500 Screw, 10-16 x .486
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black
* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995502852 970-687420
10/07 6
TOP/DRAWER

970-687420 Publication No: 5995502852
# Functional Parts 7 10/07
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316408901 Drawer, warmer
2 316403303 Liner, drawer
4 316403509 Panel, drawer front, white
13 316415002 Glide, warmer, inner RH
13A 316415001 Glide, warmer, inner LH
15 # 318178110 Element, surface, 6", 1200, (2), radiant
15A# 316465001 Element-surface, 6"/9", 3000W, dual radiant
15B# 316464901 Element-surface dual, 1700W/2700W
15C# 318198832 Element, surface, warmer, 100 W
16 316456274 Main Top, smooth top, white
26 316427600 Channel, element support, (2)
26A 316498200 Bracket-support, chassis, aluminum
26B 316214200 Bracket, chassis support, front
39 316235407 Handle, drawer, white
52 316461700 Clip, element mtg
81 # 316437300 Element, warmer drawer
82 316093200 Bracket, element mtg
83 316093300 Shield, terminal, warmer drawer
84 316093501 Thermo disc, warmer drawer
85 316425900 Rack, warmer drawer
86 316095800 Clip, hold down, warmer element
87 316091900 Base, warmer drawer
* # 316466732 Harness-wiring, surface
* 316001917 Harness, warmer drawer
* 316112100 Cleaner, cooktop
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995502852 970-687420
10/07 8
DOOR

970-687420 Publication No: 5995502852
# Functional Parts 9 10/07
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3 5303935243 Trim kit-door, 3 sided, white, w/tape
4 316427007 Glass, oven door, white, outer
6 316503801 Shield, wool
7 316513000 Insulation, oven door
8 316502500 Glass, door, inner, (2)
9 316503607 Liner, oven door
10 316433300 Screw, 10-14 x 2.125", handle mtg.
10B 316008401 Washer, 3/4 OD x 1/4 ID, steel
12 316405000 Seal, oven door
16 316502600 Glass, door, airwash
17 316502101 Spacer, door glass, (2)
20 316533800 Plate, distribution, load
23 316530600 Hinge, oven door
23* 316418900 Screw, sims lp, #8-32 x 5/16", black
39 316443601 Handle, oven door, white
40 316530401 Bracket, airwash glass, (2)
52 316468500 Cap, door trim, white
60B 316021110 Screw, 8-18 x 0.5, black
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303285179 Screw, wafer head, 8-32T x 0.500, black
