E36EC70F.tif CE36EC70FSS1.eps ME36EC70FSS1.eps 318046816.eps
Product No. E36EC70FSS2
38066463760S2
Series 36" elec
Color stainless
Market North America
Wiring Diagram 318046816
Owner's Guide 318200635
Installation Instructions 318201432
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995480406
06/12/08
(EN/SERVICE/BJH)
377
ELECTRIC COOK-TOP
RANGE
Model No.
E36EC70F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.
Publication No: 5995480406 E36EC70FSS2
12/06 2
CONTROL PANEL
E36EC70FSS2 Publication No: 5995480406
# Functional Parts 3 12/06
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
16 # 318282526 Main Top Assy, glass/steel, black/stainless, w/touch control
19 # 318353600 Panel Assembly, glass, w/controls
62 # 316056000 Terminal Block
77 316247900 Spacer, power board, (4)
77A 316114100 Spacer, (2)
97 # 316442113 Board, power, relay
97A# 316442042 Board, power, UIB
* # 318078557 Box & wires assy
* # 318083050 Harness, wiring, interface
* 5304400192 retainer wire
Publication No: 5995480406 E36EC70FSS2
12/06 4
MAIN TOP/SURFACE UNITS
E36EC70FSS2 Publication No: 5995480406
# Functional Parts 5 12/06
* Non-Illustrated Parts
MAIN TOP/SURFACE UNITS
POS. NO PART NO. DESCRIPTION
1 318354100 Shield, heat
2 318344520 Insulation, Elements
3 318371400 Cover, deflector
15# 318198830 Element, surface, 6", 1200 W, (2)
15A# 318198934 Element, surface, 6/9, 1700/2700W, dual radiant
15B# 318297804 Element, surface, triple, 800/900/1000
16 # 318282526 Main Top Assy, glass/steel, black/stainless, w/touch control
17 318371510 Bracket, insulation
20 318121910 Bracket, retainer
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303323130 Screw, 8 x 1/4, (4)
46 318354000 Box, burner
52 318122006 Spring, element mtg, small
52A 318122011 Spring, element mtg, 1200W/1800W
52B 318122010 Spring, element mtg, 3000W
57 318354300 Box, service
* 5303307980 Screw, 8-32 x 0.437, (4)
58 318371310 Insulation
60 318371600 Deflector, air
87 318354400 Bracket, cable
159 318371710 Deflector, heat
* 5303211311 Screw, 8 x 0.500
164 318252901 Support, box, (6)
* 3131048 Screw, 8 x 5/8, (6)
170 318124913 Screen, thermal, (4)
172 318344521 Insulation, screen, (4)
188 318014110 Spacer, (6)
* # 318199467 Harness, wiring, main
* 318163602 Cleaner, stainless steel
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303311306 Screw, 8-18 x 0.375, (8)
* 5303323140 Screw, ground, 10-32 x 0.375
Publication No: 5995480406 E36EC70FSS2
12/06 6
WIRING DIAGRAM
