Electrolux 5995502399 User manual

Publication #5995502399 Revision B September 2009
Technical Service Manual
French Door Bottom Freezer Refrigerator
Dispenser and Non-Dispenser Models

Basic Information
1-1
Safe Servicing Practices For All Appliances
Avoid personal injury and/or property damage by observing important Safe Servicing Practices.
Following are some limited examples of safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to complete the repair in a safe and
satisfactory manner.
2. Always use the correct Replacement Parts as indicated in the parts documentation. Substitutions may defeat
compliance with Safety Standards Set For Home Appliances. Do not exceed maximum recommended wattage
on light bulb replacements. Doing so could blow fuses and/or damage transformers.
3. Before servicing or moving an appliance:
• Remove power cord from the electrical outlet, trip circuit breaker to the OFF position, or remove fuse.
• Turn off water supply if applicable.
• Turn off gas supply if applicable.
4. Never interfere with the proper operation of any safety device.
5. Use ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE. Substitutions may defeat
compliance with Safety Standards Set For Home Appliances.
6. GROUNDING: The standard color coding for safety ground wires is GREEN, or GREEN with YELLOW
STRIPES. Ground leads are not to be used as current carrying conductors. It is EXTREMELY important that
the service technician reestablish all safety grounds prior to completion of service. Failure to do so will create
a hazard.
7. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges, high-temperature components,
and moving parts.
• All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from all metal
parts and panels.
• All safety grounds (both internal and external) are correctly and securely connected.
• All panels are properly and securely reassembled.
© 2008 Electrolux Home Products, Inc.
ATTENTION!!!
This service manual is intended for use by persons having electrical and mechanical training and a level
of knowledge of these subjects generally considered acceptable in the appliance repair trade. Electrolux
Home Products, Inc. cannot be responsible, nor assume any liability, for injury or damage of any kind
arising from the use of this manual.

Basic Information
This Manual has been prepared to provide Electrolux Service Personnel with Operation
and Service Information for an Electrolux French Door Bottom Freezer Refrigerator.
Table of Contents
1-2
Section 1 Basic Information .......................................... 1-1
Table of Contents.............................................................. 1-2
Safe Servicing Practices For All Appliances ..................... 1-5
Important Safety Instructions............................................. 1-5
Child Safety ....................................................................... 1-5
Proper Disposal of Refrigerators/Freezers........................ 1-5
Major Appliance Warranty Information.............................. 1-6
Model Number Breakdown................................................ 1-7
Serial Number Breakdown ................................................ 1-7
Understanding Features and Terms ................................. 1-8
Dispenser Models Specifications ...................................... 1-9
Non-Dispenser Models Specifications............................... 1-10
Section 2 Installation ..................................................... 2-1
Location ............................................................................ 2-1
Installation Clearance ....................................................... 2-1
Installation Checklist ....................................................... 2-1
Electrical Information ........................................................ 2-2
Water Supply .................................................................... 2-3
Leveling ... ........................................................................ 2-5
To Adjust The Door Stop ................................................. 2-6
To Level The Doors Using The Adjustable Lower Hinge.. 2-6
To Adjust The Flipper Mullion .......................................... 2-7
Removing The Doors ...................................................... 2-7
Removing The Freezer Drawer......................................... 2-9
Door Handle Mounting Instructions .................................. 2-10
Section 3 Electronic Control .......................................... 3-1
Control Layout ................................................................... 3-1
Wave-Touch™ Display Operation .................................... 3-2
IQ-Touch™ Display Operation (Dispenser Models) ......... 3-3
IQ-Touch™ Display Operation (Non-Dispenser Models) . 3-4
Entering Service Mode (Non-Dispenser Models).............. 3-4
Setting Cooling Temperatures (Non-Dispenser Models) .. 3-4
Setting Cooling Temperatures ......................................... 3-5
Wave-Touch™ / IQ-Touch™ Sabbath Mode ................... 3-5
Wave-Touch™ / IQ-Touch™ Showroom Mode ............... 3-6
Wave-Touch™ / IQ-Touch™ Manual Defrost Mode ........ 3-6
Alarms ............................................................................... 3-7
Error Codes ...................................................................... 3-7
Ice and Water Troubleshooting Guide ............................. 3-8
Tests ................................................................................. 3-9
Failed Dispenser Troubleshooting Tests .......................... 3-10
Variable Capacity Compressor Electrical Components .... 3-11
To Check/Replace the Inverter ......................................... 3-11
Testing the Compressor.................................................... 3-12
Flow Chart 1...................................................................... 3-13
Flow Chart 2...................................................................... 3-14
Flow Chart 3...................................................................... 3-15
Flow Chart 4...................................................................... 3-16
Flow Chart 5...................................................................... 3-17
Flow Chart 6 & 7 .............................................................. 3-18
Flow Chart 8...................................................................... 3-19
Flow Chart 9, 10, 11 & 12 ................................................ 3-20
Temperature Resistance Chart For Negative
Temperature Coefficient Thermistors ............................... 3-21
Section 3 Electronic Control (continued)
Perfect Temp™Drawer ..................................................... 3-21
Service Mode For Perfect Temp™ Drawer ...................... 3-22
To Test Lighting System ................................................... 3-23
To Test the Freezer Compartment Lights ......................... 3-23
To Test the Fresh Food Compartment Lights................... 3-24
Voltage Flow Chart............................................................ 3-26
Section 4 Ice Maker......................................................... 4-1
Fresh Food Compartment Ice Maker Operation .............. 4-1
Defrost Water Drain........................................................... 4-2
Ice Cube Production.......................................................... 4-3
Freezer Recovery Mode.................................................... 4-4
Error Codes ....................................................................... 4-4
Diagnostic Service Mode ................................................. 4-4
Activation .......................................................................... 4-4
Deactivation....................................................................... 4-4
Testing .............................................................................. 4-4
Temperature Resistance Chart for NTC Thermistors ....... 4-5
Service Diagnostic Mode Test Sequence ......................... 4-5
No Ice Conditions.............................................................. 4-7
Flow Chart No Ice #1 ....................................................... 4-8
Flow Chart No Ice #2 ....................................................... 4-9
Flow Chart No Ice #3 ....................................................... 4-10
Flow Chart No Ice #4 ........................................................ 4-11
Flow Chart No Ice #5 ....................................................... 4-12
Flow Chart No Ice #6 ....................................................... 4-13
Flow Chart Test #48C ...................................................... 4-14
Flow Chart Test #49C ...................................................... 4-15
Flow Chart Test #50C ...................................................... 4-16
Flow Chart Test #51C ...................................................... 4-17
Flow Chart Test #52C ...................................................... 4-18
Flow Chart Test #54C ...................................................... 4-19
Flow Chart Test #55C ...................................................... 4-20
Flow Chart Test #56C ...................................................... 4-21
Flow Chart Test #57C ...................................................... 4-22
Flow Chart Test #58C ...................................................... 4-23
Flow Chart Test #59C ...................................................... 4-24
Flow Chart Test #60C ...................................................... 4-25
Flow Chart Test #61C ...................................................... 4-26
Flow Chart Test #62C ...................................................... 4-27
Flow Chart Test #63C ...................................................... 4-28
Flow Chart Test Ice t-3 Error .......................................... 4-29
Ice Maker Body and Switches........................................... 4-30
Ice Maker Frame and Auger Motor Components.............. 4-31
Ice Maker Evaporator Components .................................. 4-32
Ice Maker Mounted In The Freezer Compartment.......... 4-33
Ice Maker Components ................................................... 4-33
Installing Water Supply Line to Ice Maker....................... 4-35
Water Valve Switch – Water Fill Volume ........................ 4-35
Test Cycling Ice Maker.................................................... 4-35
Fault Diagnosis................................................................ 4-36
Operating Cycle Illustrations - Manual Cycle .................. 4-36
Freezer Compartment Ice Maker Electrical System ....... 4-37
Operating Cycle Illustrations - Electrical ......................... 4-37
Operating Cycle Illustrations - Mechanical...................... 4-43
Ice Maker Exploded View................................................ 4-45

Basic Information
1-3
Section 5 Water System .............................................. 5-1
Water System Operation ................................................ 5-1
Water Valve..................................................................... 5-1
Pure Souce Water Filters ............................................... 5-2
Water Tanks ................................................................... 5-2
Standard Depth Water Schematic .................................. 5-3
Counter Depth Water Schematic ................................... 5-3
Non-Dispenser Water Schematic.................................... 5-4
Testing Water Fill System. .............................................. 5-4
Resistance Check .......................................................... 5-4
Voltage Check ................................................................ 5-4
Digital Meter ................................................................... 5-4
Voltage Drop From Heater ............................................. 5-4
Valve Coil ....................................................................... 5-5
Voltage Readings Are Different Between Primary And
Secondary Valve Coils ................................................... 5-5
No Water at Door. ........................................................... 5-5
Diode Kit ......................................................................... 5-5
Checking Water .............................................................. 5-5
Ice Maker Valve ............................................................. 5-5
Chilled Water Valve ........................................................ 5-5
Low/No Voltage At Coil(s) .............................................. 5-5
Voltage Readings At Green Coil Of Secondary Valve ..... 5-6
Section 6 Component Teardown ................................... 6-1
Safety Warnings ................................................................ 6-1
Dispenser (Electrolux) ....................................................... 6-2
Frame ........................................................................... 6-2
Control Assembly .......................................................... 6-2
Dispenser (ICON).............................................................. 6-3
Frame ........................................................................... 6-3
Control Assembly .......................................................... 6-3
Control Removal (Non-Dispenser Models Only) ............... 6-4
Door Components
Door Handle................................................................... 6-5
Storage Bins .................................................................. 6-5
Dairy Compartment........................................................ 6-5
Tall Bottle Retainer ........................................................ 6-5
Door Mullion and Heater................................................ 6-6
Top Door Hinge Cover................................................... 6-6
Door Hinges and Door................................................... 6-7
Freezer Handle .............................................................. 6-8
Freezer Upper and Middle Basket................................. 6-8
Freezer Lower Basket.................................................... 6-8
Tilt Wire Shelf ................................................................ 6-9
Freezer Drawer ............................................................. 6-9
Door and Drawer Gaskets ............................................. 6-9
Toe Grille........................................................................... 6-9
Anti-tip Leg ....................................................................... 6-9
Eyebrow Trim ................................................................... 6-10
Fresh Food and Freezer Compartment Light Switch ........ 6-10
Humidity Sensor ................................................................ 6-10
Interior Components
Half and Full Spill Safe™ Shelf......................................... 6-11
Deli Keeper and Crisper.................................................... 6-11
Perfect Temp Drawer™..................................................... 6-11
User Interface Board and Touch Control....................... 6-12
NTC Thermistor and Wiring Harness ............................ 6-12
Control Unit.................................................................... 6-12
Control Board................................................................. 6-13
Damper .......................................................................... 6-13
Fan and Motor Assembly............................................... 6-13
Heater ............................................................................ 6-13
Section 6 Component Teardown (continued)
Fan and Motor Assembly............................................... 6-13
Heater ............................................................................ 6-13
Thermostat .................................................................... 6-14
LED Lighting .................................................................. 6-14
Damper.............................................................................. 6-14
Water Filter and Water Tank Cover .................................. 6-15
Water Filter Connection (Non Dispenser Models) ............ 6-15
Air Filter ............................................................................ 6-16
Fresh Food Compartment Thermistor............................... 6-16
Light Shield........................................................................ 6-17
Air Duct Removal (Non-dispensing Models) ..................... 6-17
Upper Light Fixture............................................................ 6-17
Freezer Compartment Light Switch................................... 6-17
Freezer Compartment Thermistor ..................................... 6-18
Freezer Compartment Thermistor Removal
(Non-dispenser Models) .................................................... 6-18
Upper and Lower Freezer Drawer Rails ........................... 6-18
Freezer Drawer Main Support Rail .................................. 6-18
LED Assembly................................................................... 6-19
Lighting Control ................................................................ 6-19
Evaporator Cover ............................................................. 6-20
Ice Maker Air Duct (Non-dispensing Models) ................... 6-20
Ice Maker (Non-dispensing Models) ................................. 6-20
Evaporator Fan Motor ....................................................... 6-21
Evaporator Defrost Thermostat......................................... 6-22
Defrost Heater For Evaporator.......................................... 6-22
Fresh Food Compartment Ice Maker
Ice Maker Control Cover................................................ 6-23
Ice Maker Control .......................................................... 6-23
Ice Bucket ..................................................................... 6-23
Ice Bin Housing ............................................................ 6-23
Ice Maker Left and Right Mold Switch .......................... 6-24
Bail Arm Ice Level Switch ............................................. 6-24
Ice Maker Drive Motor ................................................... 6-24
Ice Maker Gear Box ...................................................... 6-24
Ice Maker Side Plate ..................................................... 6-25
Ice Mold, Heater and Defrost Limiter for Finger Evap... 6-25
Ice Maker Defrost Heater .............................................. 6-26
Ice Maker Suction Line Thermistor ............................... 6-26
Dispenser Auger Motor & Solenoid Assembly .................. 6-27
To Test Auger Motor...................................................... 6-27
To Test Solenoid Assembly........................................... 6-27
Ice Maker Evaporator Fan Motor & Defrost Limit
Thermostat ........................................................................ 6-28
Ice Maker Frame Assembly .............................................. 6-28
Ice Auger and Crusher Assembly .................................... 6-29
Freezer Compartment Ice Maker
Ice Maker and Mounting Plate....................................... 6-30
Front Cover Removal..................................................... 6-30
Fill Trough and Bearing ................................................ 6-30
Ice Stripper .................................................................... 6-31
Ejector Blade ................................................................. 6-31
Motor and Switch Mounting Plate.................................. 6-31
Motor.............................................................................. 6-31
Water Fill Switch............................................................ 6-31
Hold Switch.................................................................... 6-31
Ice Maker Control Arm Shut-OFF Switch ...................... 6-31
Ice Maker Thermostat.................................................... 6-32
Thermal Cut-Out (TCO)................................................. 6-32
Mold Heater ................................................................... 6-33

Basic Information
1-4
Section 6 Component Teardown (continued)
Compressor Area Components......................................... 6-33
Water Valve....................................................................... 6-34
Compressor Area Mounting Tray ...................................... 6-34
Condenser Fan Assembly................................................. 6-34
Section 7 Sealed System................................................ 7-1
Safe Servicing Practices For All Appliances ...................... 7-2
Introduction......................................................................... 7-3
Compressor........................................................................ 7-3
Refrigeration Systems ........................................................ 7-3
Sealed System Repair........................................................ 7-3
Definitions........................................................................... 7-4
Equipment Needed for Evacuation & Recharging ............. 7-4
Charging Sealed Systems.................................................. 7-5
Soldering ............................................................................ 7-5
Basic Components ............................................................. 7-6
Recovering Refrigerant ...................................................... 7-7
Low/High Side Leak or Undercharge ................................. 7-8
Testing for Refrigerant Leaks............................................. 7-8
Checking For Internal Leaks .............................................. 7-8
Compressor Replacement.................................................. 7-9
Flushing The System With Nitrogen................................... 7-9
Installing a New Compressor ............................................. 7-10
Freezer Evaporator and Suction Line Replacement .......... 7-11
Freezer Heat Exchanger Replacement.............................. 7-13
Ice Maker Evaporator Replacement................................... 7-13
Ice Maker Heat Exchanger Replacement ......................... 7-14
Condenser Replacement.................................................... 7-15
Filter-Drier Installation ........................................................ 7-16
Pressure Regulator Removal ............................................. 7-17
Perimeter Hot Tube Repair Kit........................................... 7-18
Installing Evacuation and Recharging Equipment.............. 7-19
Evacuating the System....................................................... 7-20
Charging The System........................................................ 7-21
Final Leak Test.................................................................. 7-21
Dedicated Equipment ........................................................ 7-21
Vacuum Pump Maintenance ............................................. 7-22
Service Diagnostic Tips..................................................... 7-23
HFC 134a Comparison With CFC 12................................ 7-24
Inhalation Toxicity.............................................................. 7-24
Cardiac Sensitization......................................................... 7-24
Skin and Eye Contact........................................................ 7-24
Refrigerant Leaks .............................................................. 7-25
Spills or Leaks .................................................................. 7-25
Combustibility of HFC-134a .............................................. 7-26
Leak Testing...................................................................... 7-26
Bulk Delivery and Storage................................................. 7-26
Filling and Charging Operations........................................ 7-26
Refrigerant Recovery Systems.......................................... 7-26
Thermal Decomposition. .................................................. 7-26
R-134a Physical Properties............................................... 7-27
HFC-134a, CFC-12 Pressure
HFC-134a, CFC-12 Pressure Temperature Chart ........... 7-28
Glossary of Terms............................................................. 7-29
Section 8 Air Circulation ................................................ 8-1
Principals Of Automatic Defrost Operation ...................... 8-1
Air Circulation Patterns .................................................... 8-1
Section 9 Wiring Schematics ......................................... 9-1
ERF2500++ Control Schematic
PTD Board, Ice and Water Module ................................... 9-1
LED Power Board.............................................................. 9-2
Icemaker Control Board .................................................... 9-3
Freezer Compartment Ice Maker Schematic .................... 9-4
Wire Diagram # 2419801 Rev.C ....................................... 9-5
Wire Diagram # 2419559 Rev.C ....................................... 9-6
Wire Diagram # 242046100 Rev.A (Non-Dispenser)........ 9-7
Wire Diagram # 242046700 Rev.A (Non-Dispenser)........ 9-8

Basic Information
1-5
Important Safety Instructions
Safety Precautions
Do not attempt to install, operate or service the unit until
you have read the safety precautions in this manual.
Safety items throughout this manual are labeled with a
Danger, Warning, or Caution based on the risk type.
Definitions
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible
injury or death.
General Safety
• Do not store or use gasoline or other flammable
liquids near this or any other appliance.
Read product labels for warnings regarding
flammability and other hazards.
• Do not operate the refrigerator in the presence of
explosive fumes.
• Avoid contact with any moving parts of the automatic
ice maker.
• Remove all staples from the carton to avoid injury.
Staples can also damage finishes if they come in
contact with other appliances or furniture.
Child Safety
Packing Materials:
• Packing cartons covered with rugs, bedspreads,
plastic sheets, or stretch wrap may become airtight
chambers and can quickly cause suffocation.
• Destroy or recycle the product’s carton, plastic bags,
and any other exterior wrapping material immediately
after the refrigerator is unpacked. Children should
never play with these items.
Child Entrapment and Suffocation:
• These problems are not limited to the past.
Whether junked, abandoned, or temporarily stored
(even for a few hours), unattended refrigerators and
freezers are dangerous. Please take the precautions
listed below.
Proper Disposal of Refrigerators/Freezers
Electrolux Home Products Inc. strongly encourages
responsible appliance recycling/disposal methods.
Check with your utility company or visit
www.recyclemyoldfridge.com for more information
on recycling your old refrigerator.
Before you recycle or dispose of your old refrigerator/
freezer:
• Remove the doors.
• Leave the shelves and baskets in place so children
may not easily climb inside.
• Have refrigerant and compressor oil removed by a
qualified service technician.
DANGER INDICATES AN IMMINENTLY
HAZARDOUS SITUATION WHICH, IF NOT AVOIDED,
WILL RESULT IN DEATH OR SERIOUS INJURY.
WARNING INDICATES A POTENTIALLY
HAZARDOUS SITUATION WHICH, IF NOT AVOIDED,
COULD RESULT IN DEATH OR SERIOUS INJURY.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
Indicates installation, operation, or maintenance
information which is important but not hazard
related.

Basic Information
1-6
Major Appliance Warranty Information
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will repair or
replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used, and
maintained in accordance with the provided instructions. In addition, the cabinet liner and sealed refrigeration system (compressor,
condenser, evaporator, dryer or tubing) of your appliance is covered by a two through five year limited warranty. During the 2nd
through 5th years from your original date of purchase, Electrolux will repair or replace any parts in the cabinet liner and sea led
refrigeration system which prove to be defective in materials or workmanship when such appliance is installed, used, and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in ordinary
household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are
not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs, handles, or
other cosmetic parts.
11. Pickup and delivery costs; your appliance is designed to be repaired in the home.
12. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or
mileage expense for service calls to remote areas, including the state of Alaska.
13. Damages to the finish of appliance or home incurred during transportation or installation, including but not limited to floors,
cabinets, walls, etc.
14. Damages caused by: services performed by unauthorized service companies; use of parts other than genuine Electrolux
parts or parts obtained from persons other than authorized service companies; or external causes such as abuse, misuse,
inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE REPAIR OR REPLACEMENT AS
PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT
NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH
AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED
WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED
WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS.YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should service be
required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under this warranty must be
obtained by contacting Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA, Puerto Rico and Canada. In the USA and Puerto Rico, your appliance is warranted by
Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by
Electrolux Canada Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for
service and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or
specifications as described or illustrated are subject to change without notice.
USA
1-877-435-3287
Electrolux Major Appliances North America
P.O. Box 212378
Augusta, GA 30907
Canada
1-800-265-8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada L5V 3E4

Basic Information
1-7
Counter-Depth Standard-Depth
Brand Brand
Electrolux
W - Wave Touch
I - IQ Touch
W - Wave Touch
I - IQ Touch
Electrolux
Control Type Control Type
Capacity Capacity
Product Type
Style/Feature Level
Year of Introduction
Color
Product Type
Style/Feature Level
Year of Introduction
Color
23 - Cubic Feet 28 - Cubic Feet
BC - Counter Depth /
French Door
BS - Standard Depth /
French Door
50-99 - Deluxe Scale with 99
Being the Highest
50-99 - Deluxe Scale with 99
Being the Highest
K - 2009 K - 2009
B - Black
S - Stainless Steel
W - White
B - Black
S - Stainless Steel
W - White
Brand
Control
Type Type
Capacity
Product
Style/
Level
Year
Color
Feature
Brand
Control
Type Type
Capacity
Product
Style/
Level
Year
Color
Feature
Counter
Depth
Standard
Depth
noitacifitnedItcudorP
rotaregirfe
R=A
srezeerF=B
srehsaW=C
sreyrD=D
sr
etneCyrdnuaL
=E
s
egnaR=F
rehsawhsiD =
H
evaworciM=P/G
r
e
ifidimuhe
D
=
N
4A11
22
3345
Model Number Breakdown
Serial Number Breakdown

1-8
Basic Information
Toe Grille
Wire Diagram
Behind Toe Grille
SpillSafe TM
Shelves
Dairy Compartment
Ice Bin Ice Maker
SpillSafe TM
Shelves
Freezer Baskets
(top basket select
models only)
Perfect Temp TM Drawer (PTD)
(select models)
or Deli Drawer
(with humidity slides)
Crisper
Drawer
Crisper
Drawer
Air
Filter
Water
Filter
Adjustable
Hinges
(select models)
Incandescent Light
(
select models
)
LED Light (select models)
Tilt Can
Bin
Special Items
Rack
(inside PTD)
(select models)
LED Light
(select models)
Freezer LED Light (select models)
Flipper Guide
Flipper
Mullion
Wire Tilt-Out Shelf
(inside freezer drawer)
Freezer
Mounting Screws
Understanding Features and Terms
Electrolux refrigerators are designed for optimal convenience and storage flexibility. The illustration below is
provided to assist you with familiarizing yourself with product features and terminology.
NOTE: Features may vary according to model. Dispenser model is shown without freezer drawer cover.

1-9
Basic Information
Models With Dispenser and Fresh Food Compartment Ice Maker
PERFORMANCE DATA NO LOAD & NO DOOR OPENINGS AT 37°/0° CONTROL SETTING
Type A with Run/Start Capacitor 65°F (18°C) Ambient 90°F (32°C) Ambient
Operating Time 74 to 84% 100%
Freezer Temperature -5° to 2° F
-20° to -17° C
-1° to 3° F
-18° to -16° C
Refrigerator Temperature 34° to 39° F
1° to 4° C
34° to 39° F
1° to 4° C
Low Side Pressure
(cut-in)
5 to 12 psi
34 to 83 kPa N/A
Low Side Pressure
(cut-out)
-2 to 2 psi
-14 to 14 kPa
-2 to 2 psi
-14 to 14 kPa
High Side Pressure
(last 1/3 cycle)
85 to 95 psi
586 to 655 kPa
120 to 135 psi
827 to 931 kPa
Wattage (last 1/3 cycle) 45 to 55 60 to 70
Amps (running) .6 to 1.1 .7 to .9
Base Voltage 115 vac (127 vac max)
DEFROST
Cabinet Size Thermostat Heater
Cut-in Cut-out Watts Ohms
23’ SD, 28’ SD, 23’ CD 25° F (-4° C) 47° F (8° C) 500 31
Electronic Timer - (ADC) Defrost 24 minutes every 6 - 96 hours of compressor run time.
CONDENSERFAN MOTOR
Watts RPM Amps
3.1 1100 CW Opposite Shaft 0.03 Running
ICEMAKER SPECIFICATIONS
SPECIFICATIONS

1-10
Basic Information
PERFORMANCE DATA NO LOAD & NO DOOR OPENINGS AT 37°/0°
CONTROL SETTING
Variable Speed Compressor 65°F (18°C) Ambient 90°F (32°C) Ambient
Operating Time 32 to 40% 100%
Freezer Temperature -6° to 6° F
-21° to -14° C
-6° to 6° F
-21° to -14° C
Refrigerator Temperature 33° to 46° F
0.5° to 8° C
33° to 46° F
0.5° to 8° C
Low Side Pressure
(cut-in)
5 to 12 psi
34 to 83 kPa N/A
Low Side Pressure
(cut-out)
-2 to 2 psi
-14 to 14 kPa
-2 to 2 psi
-14 to 14 kPa
High Side Pressure 85 to 95 psi
586 to 655 kPa
120 to 135 psi
827 to 931 kPa
Wattage 40 to 55 60 to 70
Amps (running) .5 to 1.1 .7 to .9
Base Voltage 115 vac (127 vac max)
DEFROST SPECIFICATIONS
Cabinet Size Thermostat Heater
Cut-in Cut-out Watts Ohms
23’ SD, 28’ SD, 23’ CD 25° F
(-4° C)
47° F
(8° C)
500 26
Electronic Timer - (ADC) Defrost 24 minutes every 6-96 hours of compressor run time.
CONDENSER FAN MOTOR
Watts RPM Amps
3.1
(Energy Star, some models)
1100 CW
Opposite Shaft 0.03 Running
ICE MAKER SPECIFICATIONS
Electrical 115 vac (127 vac max)
Thermostat Opens at 48° F (9° C), Closes at 15° F (-9° C)
Heater Voltage 85 vac
ICE MAKER CONNECTOR PLUG CONNECTIONS
Wire Number Wire Color Connects to:
1 Green/Yellow Ground
2 Yellow Water Valve
3 Black Line
4 Light Blue Neutral
Models With Freezer Compartment Ice Maker And Without
Dispenser

2-1
Installation Information
Required Tools
You will need the following tools:
Location
• Choose a place that is near a grounded, non-GFCI,
electrical outlet. Do Not use an extension cord or an
adapter plug.
• If possible, place refrigerator out of direct sunlight
and away from the range, dishwasher, or other heat
sources.
• The refrigerator must be installed on a floor that is
level and strong enough to support a fully loaded
refrigerator.
• Consider water supply availability for models
equipped with an automatic ice maker.
Installation Clearance
• Allow the following clearances for ease of
installation, proper air circulation, plumbing and
electrical connections:
Sides & Top: 3/8 inch (9.5 mm)
Back: 1 inch (25.4 mm)
NOTE: If your refrigerator is placed with the door hinge
against a wall, you may have to allow additional space
so the door can be opened wider.
Door Opening
NOTE: The refrigerator doors are designed to shut by
themselves within a 20 degree opening.
The refrigerator should be positioned to allow easy
access to a counter when removing food. For best use
of refrigerator drawers and freezer baskets, the
refrigerator should be in a position where both can be
fully opened.
DO NOT install the refrigerator where the
temperature will drop below 55°F (13°C) or rise
above 110°F (43°C). The compressor will not be
able to maintain proper temperatures inside the
refrigerator. DO NOT block the toe grille on the
lower front of your refrigerator. Sufficient air
circulation is essential for the proper operation of
your refrigerator.
Doors
Handles are secure and tight
Door seals completely to cabinet on all sides
Freezer door is level across the top
Leveling
Refrigerator is level, side-to-side and tilted 1/4”
(6mm) front-to-back
Toe grille is properly attached to refrigerator
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to refrigerator
No water leaks present at all connections -
recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser operates correctly
Front filter must be flush with filter housing
(select models)
Final Checks
Shipping material removed
Fresh food and freezer temperatures set
Crisper humidity controls set
Registration card sent in
Installation Checklist

Installation Information
2-2
Electrical Information
• The refrigerator must be plugged into its own
dedicated 115 Volt, 60 Hz, AC-only non-GFCI
electric outlet. The power cord of the appliance is
equipped with a three-prong grounding plug for your
protection against electrical shock hazards. It must
be plugged directly into a properly grounded three-
prong receptacle. The receptacle must be installed in
accordance with local codes and ordinances. Consult
a qualified electrician. Do not use an extension cord
or adapter plug.
• If the power cord is damaged, it should be replaced
by the manufacturer, service technician, or a
qualified person.
• Never unplug the refrigerator by pulling on the power
cord. Always grip the plug firmly and pull straight out
from the receptacle to prevent
damaging the power cord.
• To avoid electrical shock, unplug the refrigerator
before cleaning and before replacing a light bulb or
LED light.
• Performance may be affected if the voltage varies
by 10% or more. Operating the refrigerator with
insufficient power can damage the compressor.
Such damage is not covered under your warranty.
• Do not plug the unit into an outlet controlled by a
wall switch or pull cord to prevent the refrigerator
from being turned off accidentally.
YOU MUST FOLLOW THESE GUIDELINES TO
ENSURE THAT THE REFRIGERATOR’S SAFETY
MECHANISMS ARE OPERATING CORRECTLY.
To turn off power to your refrigerator, unplug the
power cord from the wall outlet.
Power cord with
3-prong grounded plug
Grounding Type
Wall Receptacle
DO NOT, under any
circumstances, cut,
remove, or bypass
the grounding plug.

Installation Information
2-3
Water Supply
The automatic ice & water dispenser on the refrigerator
requires a permanent water supply to function correctly.
During installation, establish this water supply by
connecting a copper tube from the household water
system to a valve at the rear of the refrigerator.
Requirements:
• Access to a cold water line with pressure of 30-100
psi. (System supplied with cold water only.)
• Copper tubing with ¼ inch (6.4mm) Outside
Diameter (OD). Length is the distance from the rear
of the refrigerator to your household water supply
line plus seven (7) feet (2.1 meters).
• A shut-off valve for the connection between your
household water line and the refrigerator supply line.
DO NOT use a self-piercing shut-off valve.
• A compression nut and ferrule (sleeve) for the water
supply connection at the rear of your refrigerator.
NOTE: Kits are available that provide all materials for a
water supply installation.
To connect the water supply to the rear of your
refrigerator (See Figures 2-1, 2-2 and 2-3):
1. Ensure that the refrigerator is unplugged.
2. Flush the supply line until water is clear by placing
the end of the copper tube in a sink or bucket and
opening the shut-off valve.
3. Remove and discard the plastic cap from the water
valve inlet at the rear of your refrigerator.
4. If you use copper tubing - Slide brass compression
nut, then ferrule (sleeve) onto water supply line.
Push water supply line into water valve inlet as far
as it will go (¼ inch / 6.4 mm). Slide ferrule (sleeve)
into valve inlet and finger tighten compression nut
onto valve. Tighten another half turn with a wrench;
DO NOT over tighten. See Figure 2-1 or Figure 2-2
depending on model..
If you use stainless steel tubing - The nut and
ferrule are already assembled on the tubing. Slide
compression nut onto valve inlet and finger tighten
compression nut onto valve. Tighten another half
turn with a wrench; DO NOT over tighten. See
Figure 2-3.
5. With steel clamp and screw, secure water supply line
(copper tubing only) to rear panel of refrigerator as
shown.
6. Coil the excess copper tubing (about 2½ turns)
behind your refrigerator as shown. Arrange coiled
tubing to avoid vibration or wear against other
surfaces.
7. Open water supply shut-off valve and tighten any
connections that leak.
8. Prime the water supply system according to the
directions.
9. Non-Dispenser Models - To turn ice maker on, lower
wire signal arm.
NOTE: Your refrigerator’s water supply system includes
several tubing lines, a water filter, a water valve and a
water tank. To ensure that your water dispenser works
properly, this system must be completely filled with water
when your refrigerator is first connected to the household
water supply line.
To avoid property damage:
• Copper or Stainless Steel braided tubing is
recommended for the water supply line. Water
supply tubing made of ¼ inch plastic is not
recommended to be used. Plastic tubing greatly
increases the potential for water leaks, and the
manufacturer will not be responsible for any
damage if plastic tubing is used for supply line.
• Ensure water supply and installation comply
with state and local laws and regulations.
• For proper dispenser operation, recommended
water supply pressure should fall between 30
psi and 100 psi. Excessive pressure may cause
water filter to malfunction.
• DO NOT install water supply tubing in areas
where temperatures fall below freezing.
Check with your local building authority for
recommendations on water lines and associated
materials prior to installing your new refrigerator.
Depending on your local/state building codes,
Electrolux recommends for homes with existing
valves its Smart Choice® water line kit 5305513409
(with a 6 ft. Stainless Steel Water Line) and for
homes without an existing valve, Electrolux
recommends its Smart Choice water® line kit
5305510264 (with a 20 ft. Copper Water Line with
self-tapping saddle valve). Please refer to www.
frigidaire.com/store for more information.

Installation Information
2-4
2 Tubes
To Water Tank
1 Tube
1 Tube
To Ice
Maker
To Door
Steel
Clamp
Brass
Compression
Nut
Ferrule
(Sleeve)
Copper
Water Line
Copper Water Line
Water Valve
Water Valve
Bracket
Valve Inlet
From Household Water Supply
Include enough tubing in loop to allow
moving refrigerator out for cleaning.
Copper water line
from household water supply
(Include enough tubing in loop to allow
moving refrigerator out for cleaning.)
Ferrule
(Sleeve)
Copper
water line
Water Valve
Valve Inlet
Water Valve
Bracket
Steel
Clamp
Plastic Water Tubing
to Ice Maker
Fill Tube Brass
Compression
Nut
Figure 2-1. Water Connection
Dispenser Model
Figure 2-2. Water Connection
Non-Dispenser Model Copper Tubing Connection
Wate
6 ft. Stainless Steel water line
from household water supply
r Valve
Valve Inlet
Stainless
Steel water
Water Valve
Bracket
Plastic Water Tubing
to Ice Maker
Fill Tube
line
Figure 2-3 . Water Connection
Non-Dispenser Model Stainless Steel Tubing
Connection

Installation Information
2-5
Leveling
Guidelines for final positioning of the
refrigerator
• All four corners of the cabinet must rest firmly on the
floor.
• The cabinet should be level at the front and rear.
• The sides should tilt ¼ inch (6 mm) from front to
back (to ensure that doors close and seal properly).
• Doors should align with each other and be level.
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
To level the cabinet using the front rollers:
(select models)
1. Slightly open freezer drawer. Lift the left side of the
toe grille and gently pull forward (See Figure 2-4).
2. Lift the right side of the toe grille and gently pull
forward to remove toe grille (See Figure 2-4).
3. Close the drawer and use a flat-blade screwdriver
or 3/8-inch socket wrench to raise or lower the front
rollers. (See Figure 2-5)
4. Ensure both doors are bind-free with their seals
touching the cabinet on all four sides.
5. After unit is leveled, lower anti-tip leg until it contacts
the floor. (See Figure 2-6)
6. Replace the toe grille by fitting it into place.
Raise
Lower
Anti-tip
Leg
Door
Door
Figure 2-5
Figure 2-6
The anti-tip leg must be in contact with the floor to
keep the refrigerator stable. DO NOT use the
anti-tip leg to level the refrigerator.
Figure 2-4.
Spacer Screws
Toe Grille
Must Fit In Slot
On Anti-tip
Bracket

Installation Information
2-6
To Adjust The Door Stop
Door stop is adjustable between 85 to 145 degrees.
NOTE: Views shown in Figures 2-7 - 2-12 are looking
up at the bottom of the refrigerator door.
1. Open door to provide access to set screw.
2. Loosen set screw. (See Figure 2-7)
3. Adjust door to desired location. (See Figure 2-8)
4. Rotate door stop until it makes contact with the lower
hinge. (See Figure 2-9)
5. Re-tighten set screw.
6. Ensure door stops in desired location before
resuming normal use.
Lower
Hinge
Door
Stop
Set
Screw
Min.
Open
Max
Open
Rotate
Door To Desired
Location
Figure 2-7.
Lower
Door
Door
Hinge
Washer
Raise
Figure 2-11.
Figure 2-12.
Figure 2-8.
Rotate
Door
Stop
Re-tighten
Set Screw
Figure 2-9.
Remove Set Screw
Open
Door
90
Degrees
Bottom of Door
Figure 2-10.
To Level The Doors Using The
Adjustable Lower Hinge
1. Open doors to 90 degrees.
2. Extract set screw from lower hinge. (See Figure
2-10)
3. Lift the door while adjusting washer. To raise door,
rotate washer clockwise (when viewed from bottom).
To lower door, rotate washer counter-clockwise
(when viewed from bottom). (See Figure 2-11)
4. Re-install set screw, ensuring it is between spokes
of the set washer. Set screw will not be tight, just
insert until it is flush with hinge. (See Figure 2-12)
NOTE: If after adjusting doors higher the door makes a
popping/clicking sound, remove set screw and replace
with a longer one.

Installation Information
2-7
To Adjust The Flipper Mullion
1. Loosen the set screw located on the flipper mullion
hinge. (See Figure 2-13)
2. Adjust flipper mullion height. For proper connection
with the flipper mullion guide, there should be a
separation about the thickness of a coin
(0.060 inches, or 1.5 mm) between the guide and
flipper mullion. (See Figure 2-14)
3. Re-tighten set screw.
Flipper
Mullion
Hinge
Flipper
Mullion
Set
Screw
Figure 2-13.
Flipper
Mullion
Mullion
Guide
Thickness
Of A Dime
Figure 2-14.
Removing The Doors
If the refrigerator will not fit through an entrance area,
you can remove the doors. Check first by measuring the
entrance.
To prepare for removing the doors:
1. Make sure the electrical power cord is unplugged
from the wall outlet.
2. Open the freezer drawer and remove the toe grille.
3. Remove any food from the door shelves and close
the doors.
To remove the top hinge covers:
1. Remove the two (2) screws from each cover over the
top door hinges. (See Figure 2-15 and 2-16)
2. Lift inside edge of hinge cover and tilt back.
NOTE: DO NOT remove the ground screw from hinge.
NOTE: Non-dispeser models will not have a water
connection routed through the hinge assembly.
Leave
Hinge
With
Door
Multi-wire
Cables
Hinge
Screws
Top Hinge
Cover
Front Cover
Screw Rear
Cover
Screw
Ground
Screw
Top Hinge
Water Line
Figure 2-15.
Leave
Hinge
With
Door
Hinge
Screws
Top Hinge
Cover
Front Cover
Screw
Rear
Cover
Screw
Ground
Screw
To p
Two Wire
Cables
Hinge
Figure 2-16.

Installation Information
2-8
To remove the refrigerator doors:
1. Trace lightly around the door’s top hinges with a
pencil. This will make reinstallation easier.
(See Figure 2-17)
2. Disconnect the harness by grasping both sides of
the connector firmly, depress the latch, and pull
apart. Remove the two (2) screws from the top
hinge. Lift the door off of the bottom hinge and set
it aside. (See Figure 2-18)
3. Detach the water tube from the connector located
behind the refrigerator and pull the tube back out to
the front of the unit. The connector releases when
you press inward on the outer sleeve while pushing
the tube toward the connector then while continuing
to hold in the sleeve, pull the tube away.
(See Figure 2-19)
4. Unscrew the three (3) lower hinge screws and hinge
if necessary.
To reinstall the right door, reverse the above steps.
Once both doors are in place, ensure they are aligned
with each other and level. Replace the top hinge
cover.
Figure 2-17.
Figure 2-18.
Water Line
Approximately 3 ft.
Press
Press
Figure 2-19.
Be sure doors are set aside in a secure position
where they cannot fall and cause personal injury,
or damage to the doors or handles.
