CONNECTION KIT
This connection kit is designed for use on the following top mount, bottom mount and single door
refrigerators and freezers whose total body height is 1725 mm.
The model numbers and overall dimensions of individual products are:
max
door
height
cabinet
height
total
height
door
width
cabinet
width
total
depth
cabinet
depth
depth
door
open
model description (H) (H1) (H2) (W) (W1) (D) (D1) (D2)
ETE4607SA-R 460 lt Top-Mount, RH Door 1725 1705 1725 699 693 773 641 1360
ETE4607SA-L 460 lt Top-Mount, LH Door 1725 1705 1725 699 693 773 641 1360
ETE5407SA-R 540 lt Top-Mount, RH Door 1725 1705 1725 796 790 773 641 1457
ETE5407SA-L 540 lt Top-Mount, RH Door 1725 1705 1725 796 790 773 641 1457
EBE4507SA-R 450 lt Bottom-Mount, RH Door 1725 1705 1725 699 693 773 641 1360
EBE4507SA-L 450 lt Bottom-Mount, LH Door 1725 1705 1725 699 693 773 641 1360
EBE5307SA-R 530 lt Bottom-Mount, RH Door 1725 1705 1725 796 790 773 641 1457
EBE5307SA-L 530 lt Bottom-Mount, LH Door 1725 1705 1725 796 790 773 641 1457
EBE5367SA-R
530 lt Bottom-Mount, RH Door 1725 1705 1725 796 790 773 641 1457
ERE5047SA-R 500 lt Single Door, Refrigerator 1725 1705 1725 699 693 773 641 1360
EFE4227SA-L 420 lt Single Door, Freezer LH 1725 1705 1725 699 693 773 641 1360
All measurements are in millimetres.
SINGLE CABINET DIMENSIONS
22mm
H2 H1
W
H
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Minimum Recommended Airspaces
If you do not have a
cupboard with a rear
gap, the recommended
clearance area on top
increases from 50mm to
90mm (x) and from
32mm to 72mm (y).
When positioned
in a corner area,
spacing of at
least 400mm on
the hinge side
will allow the
doors to open
enough to
enable the
removal of bins
and shelves.
Front face
of bench
aligned to
front corner
edge of
cabinet.
400mm
D1
D2
W1
W
D
90°
(x)
(y)
(Rear gap)
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Minimum Recommended Airspaces
If you do not have a
cupboard with a rear
gap, the recommended
clearance area on top
increases from 50mm to
90mm (x) and from
32mm to 72mm (y).
When positioned
in a corner area,
spacing of at
least 400mm on
the hinge side
will allow the
doors to open
enough to
enable the
removal of bins
and shelves.
Front face
of bench
aligned to
front corner
edge of
cabinet.
400mm
D1
D2
W1
W
D
90°
(x)
(y)
(Rear gap)
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Minimum Recommended Airspaces
If you do not have a
cupboard with a rear
gap, the recommended
clearance area on top
increases from 50mm to
90mm (x) and from
32mm to 72mm (y).
When positioned
in a corner area,
spacing of at
least 400mm on
the hinge side
will allow the
doors to open
enough to
enable the
removal of bins
and shelves.
Front face
of bench
aligned to
front corner
edge of
cabinet.
400mm
D1
D2
W1
W
D
90°
(x)
(y)
(Rear gap)
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Wa
63mm
Wb
HH1
D1
D

3
JOINED DIMENSIONS
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Wa
63mm
Wb
H
H1
D1
D
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Wa
63mm
Wb
H
H1
D1
D
individual cabinet widths
(W1)
cabinet
height
max door
height
joined
cabinet
width
joined door
width
max total
depth
max cabinet
depth
model 1 model 2 (H1) (H) (Wa) (Wb) (D) (D1)
693 693 170 5 1725 1407 1419 773 641
693 790 1705 1725 1504 1516 773 641
790 790 1705 1725 1601 1613 773 641
All measurements are in millimetres.
Joined cabinet dimensions:
50mm
30mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Please note:
Doors are designed
to sit proud of
cabinetry (not flush).
50mm
30mm
CABINET
DOOR
Minimum
recommended
airspace
Wa
Wb
HH1
D1
D

4 electrolux.com.au
BEFORE YOU BEGIN
• Thoroughly inspect cabinets for any signs of damage
before commencing installation.
• If any damage is identified please contact Electrolux
Service.
• Check refrigerator recess dimensions and ensure
that they provide at least the minimum clearance at
the back, side and top as recommended on page 2.
• The floor where the refrigerator is to be placed must
be level, otherwise you will not be able to install your
refrigerator properly.
• Ensure that the floor and surrounding cupboards are
adequately protected from damage during unpacking
and throughout the installation process.
• Ensure that two adequate and accessible
powerpoints are installed inside the refrigerator
recess before installing and connecting your
appliances. These powerpoints should also be
readily accessible after fridge installation is
completed.
• Do not use extension leads or power board or
double adapter under any circumstances as it may
lead to electric shock and / or fire. Seek assistance
of a licensed electrician if required.
• Unpack the connection kit and check for
completeness by referring to the “Connection
kit package contents” section.
NOTE:
Due to size and weight of the cabinets as well as
complexity of the task ensure that installation is attempted
with at least two able-bodied persons. You are strongly
urged to consider hiring Electrolux Service to do the
installation.

5
Item description qty ANC
1Replacement foot base with M4
threaded holes
2x A02102702
2Adjustable Foot Assembly
LH
RH
1x
1x
A02816701
A02816702
3Mounting M5 x 12 bolts 8x A04064701
4M5 nuts 8x A04797101
5Screw 8G x 1/2” type AB pan
head phillips
4x 1449422
6Top front bracket 1x A03972801
7Screw trilobular M5 x 13 6x 811949402
8Bottom rear bracket 1x A03979601
9Bottom front bracket assembly
- grey
(includes tensioner brkt & 3
screws)
1x A03973401
10 Centre trim assembly - grey 1x A03973701
11 Screw thread cutting #8 x 5/8 1x 1460583
CONNECTION KIT PACKAGE CONTENTS

6 electrolux.com.au
INSTALLATION
1.1- Required Tools
• Phillips head screwdriver
• 7mm socket wrench screwdriver
1.2 - Preliminary Operations
1.2.1 - General Preparation
• Pull the appliances together
• Adjust the front feet of the appliances to the same height and alignment
Step 1 .2.2 - Replace Foot Bases
NOTE: 2 people may be required for this operation
• Remove the two front feet that will meet in the middle then remove the factory fitted base, discard and replace
with the foot replacement base part supplied in the kit ensuring that the M4 threaded hole is facing the front and is
nearest the outside edge of the cabinet.
Remove the factory
fitted base
Select the supplied base
(item 5) in the kit
Fit to cabinet
Ensure the hole is nearest the
outside edge of the cabinet
Perform these steps on both cabinets
300mm
100mm
300mm
100mm

7
INSTALLATION (CONTINUED)
1.2.3 - Fitting rear levelling feet
Note: 2 people may be required for this operation
A set of adjustable back feet is provided with the kit. These parts are usually needed only in the case of a particularly
uneven floor and when height adjustments in phase 1.2.1 proved unsuccessfull.
• Temporarily remove the screws (A) holding the
evaporator tray.
• Temporarily remove screw (B)
• Pre-assemble the two nuts to bottom of the foot.
• While one operator is lifting the appliance the
other can assemble the foot with the 2 bolts (D)
and screw (E).
• Repeat the process for the other side.
A
C
E
B
D

8 electrolux.com.au
INSTALLATION (CONTINUED)
Do not tighten
Remove covers
1.3 - Joining the Appliances
Your appliances are delivered with hole covers that cover
the screw holes. These holes are located on the top of the
cabinet, opposite from the door hinge. Carfully remove
these covers, care must be taken to avoid damaging the
appliances.
Carefully pull the appliances together adjacent to the final
installation location, then adjust the front and rear feet to
the same height.
1.3.1 - Top-front and bottom-rear bracket installation
Install the top-front bracket
• Assemble the top-front bracket, fit the 6 screws
in place, but do not tighten them yet leave the
screws loose.
Install the rear-bottom bracket
• Unscrew the 2 central-upper compressor
cover fasteners.
• Remove 2 screws.
• Assemble the rear-bottom bracket reusing
the screws.

9
INSTALLATION (CONTINUED)
1.4 - Bottom-front bracket installation
1.4.1 - Position the bottom-front bracket
• Position the bottom-front bracket between the
two cabinets.
• Fasten with the two M4 screws using a phillips
head screwdriver.
• Extract the tensioner.
1.5 - Fit the centre cover
• Push the centre cover between the two cabinets
• Engage the bottom end of the centre cover into the
tensioner of the bottom-front bracket.
• Lift the top-front bracket (screws should be loose
enough) and slide the centre cover underneath.
• Tighten the screws in the top-front bracket.
• Adjust the tensioner screw as required.
• Fasten the centre cover to the top-front bracket by
means of the the provided self-tapping screw.
Lift top-front
bracket
Slide centre
cover under
Tighten all
screws
Tensioner
screw
Self tapping
screw
Extract the
tensioner
Fit bottom first
Lift top-front
bracket
Slide centre
cover under
Tighten all
screws
Tensioner
screw
Self tapping
screw
Extract the
tensioner
Fit bottom first

10 electrolux.com.au
ADJUSTING DOOR ALIGNMENT
To complete installation of your joined appliances it
may be necessary to slightly adjust door alignment
on the individual appliance. This process is illustrated
in the following section.
1. With the door open, remove the hinge cover by
simultaneously pulling the cover away and up from
the hinge. This action will release the clip that is
retaining the cover to the hinge.
Small plastic clip is located here. With the door
open, pull the cover outward while simultaneously
pulling up in order to release the hinge cover.
2. Slightly loosen the three screws retaining the hinge to
the cabinet. This will allow for slight movement of the
cabinet door.
Have the assistant hold the door in desired position
and fully secure top hinge fasteners, inspect the
alignment and if satisfied clip the hinge cover back
onto the top hinge.
Loosening the top hinge fasteners will allow the top
hinge to be slightly rotated thus adjusting the gap
between doors.

11
NOTES

shop.electrolux.com.au
Electrolux Home Products Australia
telephone: [phone]
fax: [phone]
email: [e-mail]
web: electrolux.com.au
Electrolux Home Products New Zealand
telephone: [phone]
fax: [phone]
email: [e-mail]
web: electrolux.co.nz
To add a touch of
professional inspiration
to your home,
visit electrolux.com.au
or electrolux.co.nz
P/No. A04767001
© 2017 Electrolux Home Products Pty Ltd
Print code: EMAN_FRICONN_Dec17
Issue date: Dec17
