CHDL 4150
Cooker hood
Operating and Installation Instructions

2
Printed on recycled paper
AEG - putting words into action

3
Contents
Safety warnings 4
For the User 4
For the Installer 4
Description of the Appliance 6
Extractor version 6
Filter Version 7
Control Panel 8
Maintenance and care 9
Cleaning the hood 9
Metal grease filter 9
Removing the metal grease filter 9
Charcoal filter 10
Changing the light bulb 11
What to do if 12
Service and Spare Parts 13
Guarantee Conditions 14
Technical Specifications 16
Mounting accessories included 16
Electrical connection 16
Safety warnings for the electrician 17
Installation 72
Removing the hood from cabinet 74

4
Safety warnings
For the User
• The cooker hood is designed to extract unpleasant odours from the
kitchen, it will not extract steam.
• Always cover lighted elements, to prevent excess heat from
damaging the appliance. In the case of oil, gas and coal fired
cookers it is essential to avoid open flames.
• Also, when frying, keep the deep frying pan on the cooker top/
cooker under careful control.
• The hot oil in the frying pan might ignite due to overheating.
• The risk of self-ignition increases when the oil being used is dirty.
• It is extremely important to note that overheating can cause a fire.
•Never carry out any flambé cooking under the hood.
•Always disconnect the unit from the power supply before
carrying out any work on the hood, including replacing the
light bulb (take the cartridge fuse out of the fuse holder or switch
off the automatic circuit breaker).
•It is very important to clean the hood and replace the filter at
the recommended intervals. Failure to do so could cause
grease deposits to build up, resulting in a fire hazard.
For the Installer
• When used as an extractor unit, the hood must be fitted with a
120mm diameter hose.
Should there already be an hose of diameter 100 mm that ducts to
the outside through the walls or roof, it is possible to use the 120/
100 mm adapter. In this case the hood will be slightly more noisy.
•When installing the hood, make sure you respect the following
minimum distance from the top edge of the cooking hob/ring
surfaces:
electric cookers 600 mm
gas cookers 650 mm
coal and oil cookers 700 mm min.
• The national standard on fuel-burning systems specifies a maxi-
mum depression of 0.04 bar in such rooms.
• The air outlet must not be connected to chimney flues or combus-
tion gas ducts. The air outlet must under no circumstances be
connected to ventilation ducts for rooms in which fuel-burning
appliances are installed.

5
• It is advisable to apply for authorization from the relevant controlling
authority when connecting the outlet to an unused chimney flue or
combustion gas duct.
The air outlet installation must comply with the regulations laid down
by the relevant authorities.
• When the unit is used in its extractor version, a sufficiently large
ventilation hole must be provided, with dimensions that are
approximately the same as the outlet hole.
• National and regional building regulations impose a number of
restrictions on using hoods and fuel-burning appliances connected
to a chimney, such as coal or oil room-heaters and gas fires, in the
same room.
• Hoods can only be used safely with appliances connected to a
chimney if the room and/or flat (air/environment combination) is
ventilated from outside using a suitable ventilation hole approxi-
mately 500-600 cm2 large to avoid the possibility of a depression
being created during operation of the hood.
• If you have any doubts, contact the relevant controlling authority or
building inspector’s office.
• Since the rule for rooms with fuel burning appliances is “outlet hole
of the same size as the ventilation hole”, a hole of 500-600 cm2,
which is to say a larger hole, could reduce the performance of the
extractor hood.
• If the hood is used in its filtering function, it will operate simply and
safely in the above conditions without the need for any of the
aforementioned measures.
• When the hood is used in its extractor function, the following rules
must be followed to obtain optimal operation:
— short and straight outlet hose
— keep bends in outlet hose to a minimum
— never install the hoses with an acute angle, they must
always follow a gentle curve only
— keep the hose as large as possible (preferably the same
diameter as the outlet hole).
• Failure to observe these basic instructions will drastically reduce the
performance and increase the noise levels of the extractor hood.

6
Description of the Appliance
• The hood is supplied as an extractor unit and can also be used with
a filtering function by fitting one charcoal filter.
• You will need an original AEG charcoal filter for this function
(Available from your local AEG Service Force Centre).
Extractor version
• In this version fumes are extracted to the outside via a hose
connected to the coupling ring A. Fig. 1.
• In order to obtain the best performance the hose should have a
diameter equal to the outlet hole.
Should there already be an hose of diameter 100 mm that ducts to
the outside through the walls or roof, it is possible to use the 120/
100 mm adapter. In this case the hood will be slightly noisier.
Fig. 1
Filter Version
• The air is filtered through a charcoal filter and returned to the
kitchen.
• You will need an original AEG KLF60/80 charcoal filter for the
filtering function. (See Special Accessories).
Fig. 2
A
A

7
Control Panel
• Best results are obtained by using a low speed for normal
conditions and a high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking, you will
then get an under pressure in the kitchen. The hood should be left
on after cooking for about 15 minutes or until all the odours have
disappeared.
The switches are located on the right-hand side of the hood.
• the light switch switches the hood lamp on and off
• the motor switch switches the motor on and off, enabling you to
select one of the three different speeds.
Fig. 3
Light switch
0 = Light OFF
1 = Light ON
Motor switch
0 = Motor OFF
1 = Speed 1 - Slow
2 = Speed 2 - Medium
3 = Speed 3 - Fast

8
Maintenance and care
•The hood must always be disconnected from the electricity
supply before beginning any maintenance work.
Cleaning the hood
• Clean the outside of the hood using a damp cloth and a mild deter-
gent.
• Never use corrosive, abrasive or flammable cleaning products.
• Never insert pointed objects in the motor’s protective grid.
• Only ever clean the switch panel and filter grille using a damp cloth
and mild detergents.
• It is extremely important to clean the unit and change the filters at
the recommended intervals. Failure to do so will cause grease
deposits to build up that could constitute a fire hazard.
Metal grease filter
• The purpose of the grease filters is to absorb grease particles which
form during cooking and it must always be used, either in the
external ducted or internal recycling function.
Attention: the metal grease filters must be removed and washed,
either by hand or in the dishwasher, every four weeks.
Removing the metal grease filter
• Press the handle Q that locks the grease filter N first towards the
opposite side and then extract downwards. Fig. 4.
Hand washing
Soak grease filters for about one hour in hot water with a grease-
Fig. 4
Q
N

9
loosening cleaner, then rinse off thoroughly with hot water. Repeat
the process if necessary. Refit the grease filters when they are dry.
Dishwasher
Place grease filters in dishwasher. Select the most powerful
washing programme and highest temperature, at least 65°C.
Repeat the process. Refit the grease filters when they are dry.
When washing the metal grease filter in the dishwasher a slight
discolouration of the filter can occur, this does not have any impact
on its performance.
• Clean the inner housing using a hot detergent solution only
(never use corrosive, abrasive or flammable cleaning
products).

10
Charcoal filter
• The charcoal filter should only be used if you want to use the hood
in its filtering function.
• To do this you will need an original AEG charcoal filter (see special
accessories).
•Replacing the charcoal filter
The charcoal filters cannot be cleaned, we recommend that they
should be replaced approximately every three months or more often
if the hood is used for more than three hours per day.
•Fitting
Remove the grease filter.
Fit the charcoal filter on the lamp side, press in both red lugs on the
charcoal filter, and unclip the charcoal filter forwards (towards the
front edge of the appliance).
Refit the grease filter.
• To remove press both red lugs and remove the charcoal filter
downwards.
• Always specify the hood model code number and serial number
when ordering replacement filters. This information is shown on the
registration plate located on the inside of the unit.
• The charcoal filter can be ordered from your local AEG Service
Force Centre.
Fig. 5

11
Warning
• Failure to observe the instructions on cleaning the unit and
changing the filters will cause a fire hazard. You are therefore
strongly recommended to follow these instructions.
• The manufacturer declines all responsibility for any damage to the
motor or any fire damage linked to inappropriate maintenance or
failure to observe the above safety recommendations.
Changing the light bulb
• Disconnect the cooker hood from the mains supply.
• Unlock the lighting cover by twisting the bolts to the left and fold
down the bulb cover.
• Replace the old bulb with a new one of the same type.
• Close the bulb cover and relock it by twisting the bolts to the right.
• If the light does not come on, make sure the bulb has been inserted
in correctly before contacting your local AEG Service Force Centre.
Fig. 6

12
What to do if
Ifyourappliancefailstoworkproperlypleasecarryoutthefollowingchecks.
Symptom Solution
The cooker hood will not start... Check that:
The hood is connected to the
electricitysupply.
Check that the fan speed control is
set to 1, 2 or 3.
The cooker hood is not working Chec k that:
effectively.. The fan speed is set high enough
. for the task.
The grease filters are clean.
The kitchen is adequately vented to
allow the entry of fresh air.
If set up for recirculation, check that
the charcoal filter is still effective.
If set up for extraction, check that
the ducting and outlets are not
blocked.
The cooker hood has switched off The safety cut-out device has been
duringoperation... tripped.
Turnoffthehobandthenwaitforthe
device to reset.
Ifthehoodhasbeeninstalledbelow
the heights indicated in the
installation instructions the motor
will cut-out frequently which will
damage the hood.
If after all these checks, the problem persists, contact your local Service
Force Centre, quoting the model and serial number.
Please note that it will be necessary to provide proof of purchase for any
in-guarantee service calls.
In-guarantee customers should ensure that the above checks have been
made as the engineer will make a charge if the fault is not a mechanical or
electrical breakdown.

13
Service and spare parts
In the event of your appliance requiring service, or if you wish to
purchase spare parts, contact your local AEG Service Force Centre by
telephoning 08705 929 929
Your call will be automatically routed to the Service Centre covering
your post code area.
For the address of your local Service Force Centre and further infor-
mation about Service Force, please visit the website at
www.serviceforce.co.uk
Please ensure that you have read the section „What to do if....“ as the
engineer will make a charge if the fault is not a mechanical or electri-
cal breakdown even the appliance is under warranty.
Please note that proof of purchase is required for in-guarantee
service calls.
Help us to help you
Please determine your type of enquiry before writing or telephoning.
When you contact us we need to know:
• Your name
• Address and post code
• Telephone number
• Clear and concise details of the fault
• Name and model of the appliance*
• E number*
* This information can be found on the rating plate, which can be seen
when the grease filters are removed.
Customer Care
For general enquiries concerning your AEG appliances, or for further
information on AEG products, please contact our Customer Care
Department at the address below or visit our website at
www.aeg.co.uk Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough
Berkshire
SL1 1DZ
Tel.: [phone]*
* calls to this number may be recorded for training purposes.

14
Guarantee conditions
Guarantee Conditions
AEG offer the following guarantee to the first purchaser of this appliance.
1. The guarantee is valid for 12 months commencing when the appliance
is handed over to the first retail purchaser, which must be verified by
purchase invoice or similar documentation.The guarantee does not
cover commercial use.
2. The guarantee covers all parts or components which fail due to faulty
workmanship or faulty materials. The guarantee does not cover
appliances where defects or poor performance are due to misuse,
accidental damage, neglect, faulty installation, unauthorised
modification or attempted repair, commercial use or failure to observe
requirements and recommendations set out in the instruction
book.This guarantee does not cover such parts as light bulbs,
removable glass-ware or plastic.
3. Should guarantee repairs be necessary the purchaser must inform the
nearest customer service office (manufacturer`s service or authorised
agent). AEG reserves the right to stipulate the place of the repair
(i.e.the customer`s home, place of installation or AEG workshop).
4. The guarantee or free replacement includes both labour and materials.
5. Repairs carried out under guarantee do not extend the guarantee
period for the appliance. Parts removed during guarantee repairs
become the property of AEG.
6. The purchaser`s statutory rights are not affected by this guarantee.
European Guarantee
If you should move to another country within Europe then your guarantee
moves with you to your new home subject to the following qualifications:
- The guarantee starts from the date you first purchased your product.
- The guarantee is for the same period and to the same extent for labour
and parts as exist in the new country of use for this brand or range of
products.
- This guarantee relates to you an cannot be transferred to another user.
- Your new home is within the European Community (EC) or European
Free Trade Area.
- The product is installed and used in accordance with our instructions
and is only used domestically, i.e. a normal household.
- The product is installed taking into account regulations in your new
country.

15
BeforeyoumovepleasecontactyournearestCustomerCareCentre,listed
below,to givethem detailsof yournew home.Theywill thenensure thatthe
local Service Organisation is aware of your move and able to look after you
and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]

16
Technical Specifications
Dimensions (in cm):
Height 137
Width 510
Depth 285
Maximum absorbed power: 220 W
Motor absorption: 140 W
Lighting: 2 x 40 W (E14)
Length of the cable: 150 cm
Mounting accessories included
1 Flange Ø 120 mm
1 Adapter Ø 120/100 mm
4 wood-screws 2,9 x 16
Electrical connection
Safety warnings for the electrician
The electric outlet should be placed on the wall inside the chimney.
The hood has a power cable, 150 cm, with earth connection and the
rated voltage is 220 - 240 V. Connect the hood to the mains supply via
a double pole switch which has 3 mm minimum separation between
the contacts. This switch must be accessible at all times.
The following is valid in the United Kingdom only:
- the wire which is coloured green and yellow must be connected to
the terminal which is marked with the letter E or by the earth symbol
( ), or coloured green or green and yellow;
- the wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black, -
- the wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.

17
Installation - Fig. 7
•Drill the base of the wall unit to allow for passage of the hood body.
Fig. 7.1.
•Drill the top of the wall unit to allow for passage of the exhaust pipe
and the electrical cable. Fig. 7.1.
•Remove the grease filter (1).
•Remove the grease filter support frame, by pressing the two spring
clamps located at the sides of the frame (2).
•Through the top of the wall unit, insert a pipe with a diameter of
120mm at the connection ring (3).
•Fit the connection ring on the hood exhaust outlet (4) and fasten it
to the exhaust pipe.
•Insert the body of the hood into the hole in the base of the wall unit
(5) –check the position of the exhaust pipe and the electrical cable,
press firmly so that the anchor springs (6) engage above the bottom
of wall unit. Tighten the screws in the anchor springs firmly.
•If necessary the hood can be fastened with four more screws (7).
•Replace the grease filter support frame.
•Replace the grease filter.

18
OK! OK!
1
22
3-F
4
5-C
7
66
7
7
7
5-C
Fig. 7.1
Fig. 7

19
Removing the hood from cabinet
Follow these steps:
•Remove the grease filter.
•Remove the 4 additional screws from the frame.
•Loosen the screws on the two fixing springs. Fig. 8.
•Push a flat screwdriver into the hole for the fixing springs (right and
left) and push each of the fixing springs inwards. Fig. 9.
•At the same time, pull the extractor hood (right and left) out of the
cabinet.
Re-install it as described above.
Fig. 8
Fig. 9

AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG LI1WYB Ed. 04/02
