Contents
Safety warnings 27
for the installer 27
for the user 27
Description of the appliance 28
Extractor version 28
FilterVersion 28
Control Panel 29
Correctventilation 29
If the hood does not function 29
Before you make contact to service 29
Service and spare parts 29
Maintenance and care 30
Cleaning 30
Metal grease filter 30
Open the metal grease filter 30
Warning 30
Charcoal filter 31
Changingthelightbulb 31
Technical Specifications 31
Special accessories 31
Installation 32
Unpacking 32
Placement 32
Electricalconnection 32
Mounting accessories included 33
Wallunitmounting 33
UK
Before you use the cooker hood we recommend that you read through the whole user manual giving a direct
description of the cooker hood and its functions.
To avoid the risks, that are always present when you use a product driven by electricity, it is important that the
cooker hood is installed correctly and that you read the safety instructions carefully to avoid misuse and hazard.
Save the instruction manual and keep it available at use of the cooker hood

27
Safety warnings
for the installer
•When used as an extractor unit, the hood must
be fitted with a 120mm diameter hose.
•When installing the hood, make sure you
respect the following minimum distance
from the top edge of the cooking hob/ring
surfaces:
electric cookers 600 mm
gas cookers 650 mm
coal and oil cookers 700 mm min.
•The national standard on fuel-burning systems
specifies a maximum depression of 0.04 bar in
such rooms.
•The air outlet must not be connected to chimney
flues or combustion gas ducts. The air outlet
must under no circumstances be connected to
ventilation ducts for rooms in which fuel-burning
appliances are installed.
•It is advisable to apply for authorization from the
relevant controlling authority when connecting
the outlet to an unused chimney flue or
combustion gas duct.
The air outlet installation must comply with the
regulations laid down by the relevant authorities.
•When the unit is used in its extractor version, a
sufficiently large ventilation hole must be
provided, with dimensions that are
approximately the same as the outlet hole.
•Nationalandregionalbuildingregulations
impose a number of restrictions on using hoods
and fuel-burning appliances connected to a
chimney, such as coal or oil room-heaters and
gas fires, in the same room.
•Hoods can only be used safely with appliances
connected to a chimney if the room and/or flat
(air/environmentcombination) is ventilated from
outside using a suitable ventilation hole approxi-
mately 500-600 cm2 large to avoid the
possibility of a depression being created during
operation of the hood.
•If you have any doubts, contact the relevant
controllingauthorityorbuildinginspector’s
office.
•Since the rule for rooms with fuel burning
appliances is “outlet hole of the same size as the
ventilation hole”, a hole of 500-600 cm2, which
is to say a larger hole, could reduce the perfor-
mance of the extractor hood.
•If the hood is used in its filtering function, it will
operate simply and safely in the above
conditions without the need for any of the
aforementioned measures.
•When the hood is used in its extractor function,
the following rules must be followed to obtain
optimaloperation:
—short and straight outlet hose
—keep bends in outlet hose to a minimum
—never install the hoses with an acute angle,
they must always follow a gentle curve only
—keep the hose as large as possible
(preferably the same diameter as the outlet
hole).
•Failure to observe these basic instructions will
drastically reduce the performance and increase
the noise levels of the extractor hood.
for the user
•Always cover lighted elements, to prevent
excess heat from damaging the appliance. In
the case of oil, gas and coal fired cookers it is
essential to avoid open flames.
•Also, when frying, keep the deep frying pan on
the cooker top/cooker under careful control.
•The hot oil in the frying pan might ignite due to
overheating.
•The risk of self-ignition increases when the oil
being used is dirty.
•It is extremely important to note that
overheating can cause a fire.
•Never carry out any flambécooking under
the hood.
•Always disconnect the unit from the power
supply before carrying out any work on the
hood, including replacing the light bulb
(take the cartridge fuse out of the fuse holder or
switch off the automatic circuit breaker).
•It is very important to clean the hood and
replace the filter at the recommended
intervals. Failure to do so could cause
grease deposits to build up, resulting in a
firehazard.

28
Description of the appliance
Extractor version
•The hood is supplied as an extractor unit and
can also be used with a filtering function by
fitting one charcoal filter (special accessory).
•You will need original ELECTROLUX charcoal
filter for this function (see Special Accessories).
•The air is discharged to the outside through a
pipe, which must be fitted to connection flange
D. Fig. 1.
•In order to obtain the best performance the hose
should have a diameter equal to the outlet hole.
Fig. 1
Filter Version
•The air is filtered through a charcoal filter and
returned to the kitchen through the top grill of
the outlet pipe.
•You will need an original ELECTROLUX
KF825 charcoal filter for the filtering function.
(See Special Accessories).
•Fix the deflector using 2 screws Ø3,5x6.5 mm.
Fig. 2.
Fig. 2

29
Control Panel
•The hood is fitted with one motor having several
speed. Turn the hood on a few minutes before
you start cooking, you will then get an under
pressure in the kitchen. The hood should be left
on after cooking for about 15 minutes or until all
the odours have disappeared.
The control switches are located on the unit’s
frontpanel:
•the light switch switches the hood lamp on and
off;
•the motor switch switches the cooking smoke
and vapour extractor motor on and off, enabling
you to select one of the three different speeds.
Correct ventilation
If the cooker hood is to work correctly there must
be an under pressure in the kitchen. It is important
to keep the kitchen windows closed and have a
window in an adjacent room open
Fig. 3
OI O123
Motor power
adjustable to 3
positions
Light switch
ON/OFF
If the hood does not function
Before you make contact to
service
Check that the power plug is connected to the wall
power outlet and that no fuse is blown. Do not do
any operations that can cause hazard or damage to
the product. If the problem remains contact your
dealer or an approved service company
Remember to save the purchase recite and the
Warranty card (only used in some countries)
Service and spare parts
Service and spare parts you will get via your dealer
or service company.
When you order service or spare parts you should
be ready to give the product number and model
denomination.This information you will find on the
ratinglabel.
Take away the grease filter and you will find the
ratinglabel behind.
Model:
Product number:
Date of purchase:

30
The hood must always be disconnected from the electricity supply before beginning any
maintenance work.
Cleaning
•Warning: always disconnect the hood from the
mains power supply before cleaning it.
Never insert pointed objects in the motor’s
protective grid.
•Wash the outside surfaces using a delicate
detergent solution. Never use caustic detergents
or abrasive brushes or powders.
•Only ever clean the switch panel and filter grille
using a damp cloth and delicate detergents.
•It is extremely important to clean the unit and
change the filters at the recommended intervals.
Failure to do so will cause grease deposits to
build up that could constitute a fire hazard.
Metal grease filter
•The purpose of the grease filters is to aspirate
grease particles which form during cooking and
it must always be used, either in the external
evacuation or internal recycling function.
Attention: the metal grease filters must be
removed and washed, either by hand or in the
dishwasher, every four weeks.
Open the metal grease filter
•Push it towards the back of the unit and then
pull it down and out.Fig. 4.
Hand washing
Soak grease filters for about one hour in hot
water with a grease-loosening cleaner, then
rinse off thoroughly with hot water. Repeat the
process if necessary. Refit the grease filters
when they are dry.
Dishwasher machine
Place grease filters in dish washer. Select most
powerful washing programme and highest
temperature, at least 65°C. Repeat the process.
Refit the grease filters when they are dry.
When washing the metal grease filter in the
dishwasher a slight discoloration of the filter can
occur, this does not have any impact on its
performance.
•Clean the inner housing using a hot detergent
solution only (never use caustic detergents,
abrasive powders or brushes).
Maintenance and care
Warning
•Failure to observe the instructions on cleaning
the unit and changing the filters will cause a fire
hazard. You are therefore strongly
recommended to follow these instructions.
•The manufacturer declines all responsibility for
any damage to the motor or any fire damage
linked to inappropriate maintenance or failure to
observe the above safety recommendations.
Fig. 4

31
Charcoal filter
•The charcoal filter should only be used if you
want to use the hood in its filtering function.
•To do this you will need an original
ELECTROLUX charcoal filter (see special
accessories).
•This filter cannot be cleaned or reused.
•As a general rule, the activated carbon
filter should be changed once every four
months.
•Mounting —Fig. 5
Fit one carbon filter on the left and one on the
right so to cover the plastic grids that protect the
fan wheel, then turn clockwise the central
handle of the carbon filter.
•To dismount proceed in reverse order.
•Always specify the hood model code number
and serial number when ordering replacement
filters. This information is shown on the
registration plate located on the inside of the
unit.
•The charcoal filter can be ordered from the
ELECTROLUX technical assistance service.
Changing the light bulb
•Disconnect the cooker hood from the main
supply.
•Remove the lamp cover. Fig. 6.
•Replace the old bulb with a new one of the
same type.
•Remount the lamp cover.
•If the light does not come on, make sure the
bulb has been inserted in correctly before
contacting the technical assistance service.
Fig. 5
Fig. 6
Technical Specifications
Model EFC 6410 EFC 9410
Dimensions Height 87,5-111,6 87,5-111,6
Width 59,9 89,9
Depth 51,5 51,5
Lighting 2 x 40 W 2 x 40 W
Grease filter 2 3
power absorption 250 W 250 W
We reserve the right to generate constructive and chromatic modifications as required by technological growth.
Special accessories
Carbon filter KF825 E-Nr. 942 118 627

32
Installation
Unpacking
Check that the cooker hood has no damages.
Transportation damages should immediately be
reported to the one responsible for the transport
Damages, faults and eventually missing details
should immediately be reported to the seller.
Take care of the packing material so that small
children cannot play with it.
Placement
The hood is to be mounted on the wall.
When installed, the hood must be not less than 60
cm. above electric burners or 75 cm. above gas or
mixed-fuel burners (fig. 7).
Electrical connection
Safety warnings for the electrician
Before connecting the appliance to the power
supply, check that the voltage indicated on the
rating plate corresponds to the mains power supply
available. Appliances fitted with a plug can be
connected to any standard power socket within
easy access.
Should it be necessary to provide a fixed
connection, the hood must only be installed by an
electrician authorised by the local electricity board.
When installing, an omnipolar disconnector with a
distance of at least 3 mm between contacts must
be provided.
This disconnector may be for example a switch,
fuses (plug fuses must be removed from the fuse
box, fault current switches and remote switches
with a distance of over 3 mm between contacts.
The manufacture declines all responsibility for
malfunctions resulting from failure to comply with
the above instructions.
If the power socket is applied directly above the
hood this gives two advantages:
1. the socket is not visible.
2. the appliance can be disconnected at need
merely be removing the plug.
Electrical connection
220-240 V –by means of fixed power cable with
plug.
(Fixed connection of the appliance must only be
carried out by an authorised electrician.)
Min
75 cm
Min
60 cm
Fig. 7

33
Installation
Mounting accessories included
1 deflector
1 chimney support
2 grids
2 hooks
4 wood-screws 5 x 45 mm
4 wall plugs Ø8 mm
2 metal screws 3,5 x 6,5
2 metal screws 3 x 9
Wall unit mounting -
Fig. 8
•Put the template onto the wall
(1) and drill two Ø12mm holes
(2).
•Fit two hooks (3) on the drilled
holes.
•Hang the hood on the hooks and
adjust the position of the hood
using the two screws on the
bottom of the hooks (5).
•Remove the metal filters (4) and
mark two points (6). Remove
the hood and drill two Ø8mm
holes on the marked points.
Fit two Ø8mm wall dowels (7),
Hang again the hood and fix the
hooddefinitivelywithtwo
screws 5X45 (8).
•Fix the chimney support (10)
with two screws 5 x 45 mm (9)
and two wall dowels (11) on the
wall close to the ceiling.
•For exhausting version: Fit
the connection ring (S) on the
top of the hood with two screws
Ø3,5 x 6,5 mm (12S) then fit
an axhausting pipe long enough
to reach the outside (13S).
For recycling version: Fix
definitively the deflector (13K) on
the top of the hood with two screws Ø
3,5 x 6,5 mm (12K).
•Prepare the electric connection (14) (see
relative chapter).
•Fit the chimney (15) and fix it on the chimney
support with two screws 3,0 x 9 mm (16).
The lower part of the chimney must be slided
down and inserted on the housing on the upper
part of the hood (17).
•Fit the two grids (18) on both sides of the
chimney.
Ø120 mm
Fig. 8

34

35

LI1AQA Ed.02/02
