Electrolux ERR627DSD Operating manual

Rangehood
User and Installation Manual
ERR627SA ERR927SA
ERR627DSD ERR927DSD

2
WELCOME TO ELECTROLUX
Thank you for purchasing an Electrolux appliance.
You’ve chosen a product that brings with it decades
of professional experience and innovation. Ingenious
and stylish, it has been designed with you in mind. So
whenever you use it, you can be safe in the knowledge
that you’ll get great results every time.
Welcome to Electrolux.
LEGEND
The symbols you will see in this booklet have
these meanings:
WARNING!
This symbol indicates information concerning
your personal safety
CAUTION!
This symbol indicates information on how to avoid
damaging the rangehood
IMPORTANT!
This symbol indicates tips and information about
use of the rangehood
ENVIRONMENT!
This symbol indicates tips and information about
economical and ecological use of the rangehood
CONDITIONS OF USE
This appliance is intended to be used in household and
similar applications such as:
•Staff kitchen areas in shops, offices and other
working environments
•Farm houses
•By clients in hotels, motels and other residential
type environments
•Bed and breakfast type environments.
•Catering and similar non-retail applications
CONTENTS
3Important safety instructions
4Installation
6Operation and maintenance
7Warranty
RECORD MODEL AND SERIAL
NUMBER HERE:
Model:
Serial No:
IMPORTANT INFORMATIONTHAT MAY
IMPACT YOUR MANUFACTURER’S
WARRANTY
Adherence to the directions for use in this manual is
extremely important for health and safety. Failure to
strictly adhere to the requirements in this manual may
result in personal injury, property damage and affect
your ability to make a claim under the Electrolux
manufacturer’s warranty provided with your product.
Products must be used, installed and operated in
accordance with this manual. You may not be able
to claim on the Electrolux manufacturer’s warranty in
the event that your product fault is due to failure to
adhere this manual.

3
SAFETY INSTRUCTIONS
Please read the user manual carefully and store in a
handy place for later reference. Pass the user manual on
to possible new owners of the appliance.
Read the following carefully to avoid damage or injury.
Note: You must read these warnings carefully
before installing or using the accessory. If you need
assistance, contact your Customer Care Department.
The manufacturer will not accept liability, should these
instructions or any other safety instructions incorporated
in this book be ignored.
ENVIRONMENT!
Remove and discard any packaging material before
using this accessory. Most of the packaging materials are
recyclable. Please dispose of those materials through your
local recycling depot or by placing them in the appropriate
collection containers.
WARNING!
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning the use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
•Ensure the rangehood is switched off before carrying
out maintenance, to avoid any possibility of electric
shock.
•Grease filters must be removed every four weeks
(maximum) for cleaning to reduce the risk of fire.
•Do not light a flame under the rangehood.
•This rangehood is not recommended for barbecues.
•The exhaust air from the rangehood must not be
discharged into any heating flue, which may carry
combustion products from other sources.
•Exhaust air must not be discharged into a wall cavity,
unless the cavity is designed for the purpose.
•There must be adequate ventilation of the room
when the rangehood is used at the same time as
appliances burning gas or other fuels.
•Always cover lit gas burners with pots or pans when
the rangehood is in use.
•Always switch off gas burners before you remove pots
or pans.
CAUTION
•Accessible parts may become hot when used with
cooking appliance.
•Regulations concerning the discharge of air have to
be fulfilled.
•Failure to install the screws or fixing device in
accordance with these instructions may result in
electrical hazards.
Cleaning
•Wipe the rangehood body and flue with a sponge or
soft cloth soaked in warm soapy water, and dry with a
soft cloth, for stainless steel models apply a stainless
steel protector. Do not use oven cleaners or other
abrasive materials.
•There is a fire risk if cleaning is not carried out in
accordance with the instructions.
Electrical Connection
•Check that the mains voltage matches with the
voltage on the data plate inside the rangehood.
•Check that the installation complies with standards of
local gas and electricity authorities.
•If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Accessories
•Use 150mm round exhaust ducting for best
performance.
•When using flexible duct always install duct with the
wire helix pulled taut to minimise pressure loss.
•Try to keep exhaust duct short and straight.
•Keep bends in the exhaust duct to a minimum.
•Do not restrict exhaust duct.
•Reducing the size of the exhaust duct will reduce the
airflow of the rangehood. Please read instructions
carefully. Service calls resulting from incorrect
installation will be charged for.
Exhaust air from the rangehood must not be discharged
into any heating flue which may carry combustion
products from other sources. In addition, exhaust air
must not be discharged into a wall cavity, unless the
cavity is designed for the purpose. Adequate ventilation
of the room must be ensured when the rangehood is
operating simultaneously with appliances burning gas or
other fuels. Installation must comply in all respects with
your gas and electrical authorities. This rangehood is an
indoor domestic appliance, and has been manufactured
and tested to comply with Australian and New Zealand
Standard AS/NZS 60335.1 and 60335.2.31

4
INSTALLATION
Standard ducting installation
It is recommended that the unit be positioned at a
minimum of 600mm for an electric cooktop and 650mm
for a gas cooktop, and no further from the cooktop than
800mm. Then unit becomes less effective as the distance
from the cooking surface to the rangehood increase.
650
GAS
ELECTRIC
600
Fixing point dimensions – ERR627SA ERR627DSD
rear cover can be reversed
to suit gap at rear
Fixing point dimensions – ERR927SA ERR927DSD
rear cover can be reversed
to suit gap at rear
WARNING!
accordance with these instructions may result in
electrical hazards.
Parts supplied with hood
1 x Ø 150mm air outlet
1 x Ø 150mm to Ø 120mm converter
2 x rear covers
2 x lateral covers
6 x self tapping screws 3 x 12mm
2 x self tapping screws 3.5 x 10mm
4 x Ø 6 washers
4 x M6 x 40 screws
2 x air intake grilles
Parts to be purchased
•
• Ducting accessories
Drilling holes
Drill the holes on top wooden support
• drill Ø 7mm hole
• drill Ø 16mm hole
• cut Ø 196mm hole
Ø 7 for hood
fastening screws 86 Ø16 for cable
clearance
Øclearance
453/753
door/hood fascia
front of
cabinet
33
210
272 252
192
Fixing the air outlet
ST 3.5 x 10
Fixing the lateral cover
Use screws to fix the lateral cover to the rangehood.
ST 3 x 12
underside of
rangehood
top of cooking
surface
if the cooktop
manufacturer
a greater
clearance
then that
must be used
196 for flue
Aluminium tape or cable ties to secure flue pipe
Failure to install the screws or fixing device in
37
210
453
600
555
280
160
24
04
272
280
20
88
54
150
33
04
37
210
753
900
855
280
160
24
272
280
20
88
54
150
33
Ø
Ø

5
INSTALLATION
Fixing the rangehood
Use screw and washer to fasten the rangehood to the
wood support from upper side.
Ø6mm washer
M6 x 40
screws
Fixing the rear cover
Use screw to x the rear cover.
ST 3×12 self tapping screws
Installing the air intake grill
Carbon lters aren’t required for standard ducted
installation. Remove and replace with air intake grills
provided.
air intake grill
Fixing the ue pipe
Fix a Ø 150mm, non-combustible, rigid ue pipe to the
exhaust transition duct using cable ties or duct tape.
Fixing a Ø 125mm ue pipe
Fix the Ø 150mm to Ø 120mm converter to the rangehood
rst, then x a Ø 125mm noncombustible ue pipe to the
exhaust transition duct using cable ties or duct tape.
IMPORTANT!
If using a exible duct, always install duct with the
wire helix pulled taut to minimise pressure and noise.
Ducting accessories - ERR627SA, ERR927SA
ERR627DSD ERR927DSD
For best performance Ø 150mm ducting is recommended
(Ø 125mm ducting can be used, but will reduce the
airow of the cooker hood).
roof cowl
AR150RC
(AR125RC)
AR150F
(AR125F)
AR150FD
(AR125FD)
AR125FJD
with damper
wall vent kit
AR150WV
(AR125WV)
flexible duct
ACC205
Accessories can be bought from your local appliance
retailer, or in Australia / New Zealand at our online spare
parts and accessories store: shop.electrolux.com.au
Ducted recirculating installation
If ducted recirculating installation is used, carbon lters
are recommended. The carbon lters are already
installed in the rangehood on delivery.
AR150WV
(AR125WV)
Carbon lters diminish cooking odours in the recirculated
air. Depending on the frequency of use and the type
of cooking, the expected life of carbon lters is 1-6
months. Using carbon lters with reduce the airow of
the rangehood.
carbon lter
rigid flue pipe
flexible duct
flue joiner
carbon filter (2)
bend AR150FD
(AR125B) for
Ø 150 bend use

6
OPERATION & MAINTENANCE
To operate the rangehood, pull out the retractable hood
and select the extraction level using the switch on the right
hand side.
high
low
To switch on the rangehood light, use the switch located
on the left hand side of the rangehood.
lamp
Replacing the lamp
WARNING!
Ensure the rangehood is switched off before
carrying out maintenance, to avoid any possibility
of electric shock.
Ensure that the rangehood is unplugged, then slide out the
retractable hood and remove the lter. Turn the lamp
anti-clockwise to remove then replace the lamp by turning it
clockwise. Replace the lamps with 4W or 3.5W LED GU10.
Maintaining the rangehood
To maintain efficiency and reduce the risk of fire, the filters
should be removed at least once a month for cleaning.
1. Slide the retractable hood forward 1cm.
2. Push in clip on either side to release filter.
3. Pull filter downwards to remove. Repeat 2 &3 for
models with a second filter.
4. Turn off mains switch before cleaning drawer and
cooker hood body.
5. Soak and agitate the filters in hot, soapy water or
washing soda. Rinse, drain and shake well. The filters
may also be placed in a dishwasher. Please note that
some discolouration may occur. This will not affect
the performance of the rangehood. Do not place the
carbon filters in the dishwasher.
6. After cleaning, re-fit filters making sure the clip pins
are securely fitted into the locating holes in the
rangehood body and for twin filter versions, also
located in the pull out drawer section.
7. Holding clip in, push opposite side of filter up until pins
are over locating holes.
8. Release clip ensuring filter is securely fitted.
CAUTION!
Use both hands for removing and re-fitting the
filters to avoid accidentally dropping the filters
and causing damage to your cooktop or kitchen
surfaces.
lamp
on
off
off

7
This document sets out the terms and conditions of the product
warranties for Electrolux, Westinghouse and Chef Appliances. It is
an important document. Please keep it with your proof of purchase
documents in a safe place for future reference should there be a
manufacturing defect in your Appliance. This warranty is in addition
to other rights you may have under the Australian Consumer Law.
1. I n this warranty:
)a(
)b(
2. Application:
This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand
for a period of 24 months, following the date of original purchase of the
Appliance.
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
offered for a valid warranty claim is repair or replacement. Electrolux or its
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation
will be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This
warranty does not cover:
(a) light globes, batteries, filters or similar perishable parts;
(b) parts and Appliances not supplied by Electrolux;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
(b)
the Appliance is modified without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
carefully check the operating instructions, user manual and the terms
of this warranty;
)a(
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11. Confidentiality: You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: ELECTROLUX, WESTINGHOUSE AND CHEF RANGEHOODS
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
FOR SERVICE
or to find the address of your nearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
AUSTRALIA
ELECTROLUX HOME PRODUCTS
163 O’Riordan Street, Mascot NSW 2020
electrolux.com.au
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
(New Zealand only)
NEW ZEALAND
ELECTROLUX (NZ) Limited
3-5 Niall Burgess Road, Mount Wellington
electrolux.co.nz
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
(New Zealand only)
‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
)c( ‘ASC’ means Electrolux’s authorised serviced centres;
)d( ‘Electrolux, Westinghouse and Chef’ are the brands controlled by
Electrolux Home Products Pty Ltd of 163 O’Riordan Street, Mascot
NSW 2020, ABN 51 004 762 341 in respect of Appliances purchased
in Australia and Electrolux (NZ) Limited (collectively “Electrolux”) of
3-5 Niall Burgess Road, Mount Wellington, in respect of Appliances
purchased in New Zealand;
)e( ‘Warranty Period’ means the period specified in clause 3 of this
warranty;
)f( ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
(c) cosmetic damage which does not affect the operation of the
appliance;
(iii) improper, negligent or faulty servicing or repair works done by
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;

electrolux.com.au/shop
Electrolux Home Products Australia
telephone: 13 13 49
email: [e-mail]
web: electrolux.com.au
Electrolux Home Products New Zealand
telephone: [phone]
email: [e-mail]
web: electrolux.co.nz
P/No. 60901795
© 2019 Electrolux Home Products Pty Ltd.
ABN 51 004 762 341
EMAN_RetRange_June-2020
