Electrolux ICON RH36WC60GS User manual

36" GLASS CANOPY WALL-MOUNT HOOD
FEATURES
Nominal Width
Installation Type
Style
Air Discharge
Air Delivery (CFM)
Blower Type
Electronic Controls with LCD Display
Fan Speeds
Sound Level (dBA)
Dual Halogen Lights
Washable Stainless Steel Filters
Exhaust Duct
Duct Required
ACCESSORIES
Duct-Free Kit – PN# RHDFW60GS
SPECIFICATIONS
Overall Exterior Dimensions –
Width
Height (With One Cover)
(With Flue Extension)
Depth
Voltage Rating
Connected Load (kW Rating) @120 Volts‡
Shipping Weight (Approx.)
Sones Rating
* Ventilation is convertible to be either ducted outside, or recirculated inside requiring no
ducting. (Recirculated option requires use of optional Duct-Free Kit.)
‡ For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and national electric codes. Check local building codes for
installation requirements, as they may very per locale. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxicon.com.
Specifications subject to change.
36"
Wall Mount
Stainless Steel/
Glass Canopy
Vertical
600
Dual Centrifugal
Yes
4
73.8
Yes
Yes
Convertible*
8" Round
Optional
35-7/8"
29-7/16" min.
30-1/8" min.
54-9/16" max.
19-11/16"
120V/60Hz /15A
0.474
67 Lbs.
9.9
electroluxicon.com
Glass Canopy Design
Sophisticated style makes this ventilation unit as
attractive as it is functional. Glass canopy hood
has sleek curved design – making it a focal point
of the kitchen.
600 CFMs / 4-Speed Fan
Features a powerful 4-speed dual centrifugal fan
supplying 600 CFM of air movement. Effectively
and quietly removes smoke, vapors and smells
from the kitchen.
Dual Halogen Lights
Dual halogen lights provide ample illumination
of the cooking surface below with lights located
at two different levels.
Electronic Controls with LCD Display
Easy-to-operate electronic controls
provide convenient access to all fan, clock
and timer settings.
Glass Canopy Wall-Mount Hood
RH36WC60GS

36" Glass Canopy Wall-Mount Hood Specifications
•
Product Weight – 64 Lbs.
•
Wall-Mount Installation
•
Ventilation system is preset to exhaust air outside. If outside ducting is
not possible, optional Duct-Free Kit (PN # RHDFW60GS) is available
to convert ventilation to allow air to recirculate inside. (Refer to Ducted
Option Specifications for outside ventilation.)
•
Sones Rating – 9.9
•
Voltage Rating –120V/60 Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 0.474kW (For use on
adequately wired 120V, dedicated circuit having 2-wire service with a
separate ground wire. Appliance must be grounded for safe operation.)
•
Amps @120 Volts = 3.8 Amps
•
Always consult local and national electric codes. Check local building
codes for installation requirements, as they may vary per locale.
•
Minimum installation height allowed from bottom of hood to cooking
surface is 24"- 30" for electric and 30" for gas. (NOT more than 36"
recommended.)
•
To prepare mounting surface, adequate structure and support must be
provided, capable of supporting 100 lbs.
Ducted Option Specifications
•
For outside ventilation.
•
Exhaust Duct Required – 8" round
•
For most efficient airflow exhaust, use a straight run or as few elbows
as possible.
•
Use metallic flex ducting only to connect rigid duct directly to transitions
(if allowed by code).
•
Thermal breaks such as short section of nonmetallic duct, should be
used in areas of extreme cold.
•
Cold weather installations should have additional backdraft damper
installed.
•
Refer to installation instructions on web for detailed exhaust duct
preparation and converting vent blower system for recirculating inside.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxicon.com for detailed instructions.
Optional Accessories
•
Duct-Free Kit – (PN# RHDFW60GS).
Glass Canopy Wall-Mount Hood
RH36WC60GS
High standards of quality at Electrolux Home Products, Inc. mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxicon.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxicon.ca
RH36WC60GS 10/09 © 2009 Electrolux Home Products, Inc. Printed in the U.S.A.
