Electrolux EWT 1362HDS User manual

EWT 1362HDS
EN Washing Machine User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 5
4. CONTROL PANEL............................................................................................. 6
5. PROGRAMME CHART...................................................................................... 7
6. CONSUMPTION VALUES..................................................................................9
7. OPTIONS..........................................................................................................10
8. SETTINGS........................................................................................................11
9. BEFORE FIRST USE....................................................................................... 12
10. DAILY USE..................................................................................................... 12
11. HINTS AND TIPS........................................................................................... 15
12. CARE AND CLEANING..................................................................................16
13. TROUBLESHOOTING....................................................................................18
14. TECHNICAL DATA.........................................................................................21
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Do not exceed the maximum load of 6 kg (refer to the
"Programme chart" chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
•The ventilation opening in the base (if applicable) must
not be covered by a carpet, mat, or any floor covering.
ENGLISH 3

•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in
future they must be reattached to lock
the drum to prevent internal damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area where the appliance is
to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• Do not install the appliance where the
appliance lid cannot be fully opened.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
www.electrolux.com4

access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the
E.E.C. Directives.
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• This appliance is for household use
only.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
3.1 Appliance overview
3
1
4
5
2
1Control panel
2Lid
3Lid handle
4Feet for levelling the appliance
5Rating plate
ENGLISH 5

4. CONTROL PANEL
4.1 Control panel description
Essorage
Température
Départ/Pause
Rinçage
Plus
Départ
Différé
Prélavage
Repassage
Facile
90° 60° 40°
30° 20°
1300 1000 800
400
Soie
D licats
Synth tiques
Blanc/Couleurs
Couette
Rinçage
Vidange
Essorage
Jeans
Rideaux
Sport
Chemises
Laine/Lavage à la main
Coton Eco
1 2 3 4
910
7
6
8
5
1Programme knob
2Spin reduction touchpad
(Essorage)
3Temperature touchpad
(Température)
4Display
5Prewash touchpad (Prélavage)
6Delay start touchpad (Départ
Différé)
7Extra rinse touchpad (Rinçage
Plus)
8Easy iron touchpad
(Repassage Facile)
9Start/Pause touchpad (Départ/
Pause)
10 Time Manager touchpads
4.2 Display
A B
E D
C
A. The time area:
• Programme time.
• The alarm codes. Refer to the
chapter “Troubleshooting” for their
description.
• The level of the Time Manager
.
B. The Delay Start indicator.
C. The Child Lock indicator.
D. The Lid Lock indicator:
• It is on, you cannot open the lid.
• It is off, you can open the lid.
• It flashes, you cannot open the lid.
Wait for some minutes until the
indicator is off.
E. Washing phase indicators.
• : the washing phase
www.electrolux.com6

• : the rinses phase • : the spin phase
5. PROGRAMME CHART
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Blanc/
Couleurs
90°C - Cold
6 kg
1300 rpm
White cotton and coloured cotton. Normal soil
and light soil.
Coton
Eco1)
60°C- 40°C
6 kg
1300 rpm
White cotton and fast-coloured cotton. Normal
soil. The energy consumption decreases and the
time of the washing programme is extended.
Synthétiques
60°C - Cold
2,5 kg
1200 rpm
Synthetic items or mixed fabric items. Normal
soil.
Délicats
40°C - Cold
2,5 kg
1200 rpm
Delicate fabrics such as acrylics, viscose,
polyester items. Normal soil.
Laine/
Lavage à la
main
40°C - Cold
1 kg
1200 rpm
Machine washable wool, hand washable wool
and delicate fabrics with «hand washing» care
symbol.2)
Soie
30°C
1 kg
800 rpm
Special programme for silk and mixed synthet‐
ic items.
Couette
60°C- 30°C
2 kg
800 rpm
Special programme for one synthetic blanket,
duvet, bedspread and so on.
Rinçage
Cold
6 kg
1300 rpm
To rinse and spin the laundry. All fabrics, except
woollens and very delicate fabrics. Reduce the
spin speed accordingly to the type of laundry.
Vidange 6 kg To drain the water in the drum. All fabrics.
Essorage 6 kg
1300 rpm
To spin the laundry and to drain the water in the
drum. All fabrics, except woollens and deli‐
cate fabrics.
Jeans
60°C- Cold
3 kg
1200 rpm
Items in denim and jersey. Also for dark col‐
oured items.
Rideaux
40°C - Cold
2,5 kg
800 rpm
Special programme for curtains. The prewash
phase is activated automatically.3)
Sport
30°C
2,5 kg
800 rpm
Synthetic and delicate items. Light soil items or
items to refresh.
ENGLISH 7

Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Chemises
30°C
1,5 kg
800 rpm
Synthetic and mixed fabric items. Light soil
items and items to freshen up. For 5 - 6 shirts.
1) Standard programmes for the Energy Label consumption values. According to regu‐
lation 1061/2010, these programmes are respectively the «Standard 60°C cotton pro‐
gramme» and the «Standard 40°C cotton programme». They are the most efficient pro‐
grammes in terms of combined energy and water consumption for washing normally soiled
cotton laundry.
The water temperature of the washing phase may differ from the temperature
declared for the selected programme.
2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the
drum doesn't rotate or doesn't rotate properly, but this is normal for this programme.
3) Do not use any detergent for prewash phase to rinse only with water.
Programme options compatibility
Programme
■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■
■ ■ ■ ■
■ ■
■ ■
■ ■ ■ ■
■
■ ■
■ ■ ■ ■ ■
■ ■ ■ ■
■ ■
■ ■
www.electrolux.com8

5.1 Woolmark Apparel Care -
Blue
The wool wash cycle of this machine has
been approved by The Woolmark
Company for the washing of wool
garments labelled as «hand wash»
provided that the garments are washed
according to the instructions issued by
the manufacturer of this washing
machine. Follow the garment care label
for drying and other laundry instructions.
M1145
In UK, Eire, Hong Kong and India the
Woolmark symbol is a certification
trademark.
6. CONSUMPTION VALUES
The data in this table are approximate. Different variables can affect the
data: the quantity and type of laundry, the water and ambient tempera‐
ture.
At the start of the programme, the display shows the programme dura‐
tion for the maximum load capacity.
During the washing phase the programme duration is automatically cal‐
culated and can be greatly reduced if the laundry load is lower than the
maximum load capacity (e.g. Cotton 60°C, maximum load capacity 6 kg,
the programme duration exceeds 2 hours; actual load 1 kg, the pro‐
gramme duration will be less than 1 hour).
When the appliance is calculating the real programme duration a dot
flashes in the display.
Programmes Load
(kg)
Energy
consump‐
tion (kWh)
Water con‐
sumption
(litre)
Approxi‐
mate pro‐
gramme
duration
(minutes)
Remaining
moisture
(%)1)
Blanc/Couleurs
60°C 6 1,10 56 180 52
Blanc/Couleurs
40°C 6 0,65 54 150 52
Synthétiques 40°C 2,5 0,45 46 105 35
Délicats 40°C 2,5 0,55 46 90 35
Laine/Lavage à la
main 30°C 2) 1 0,35 50 65 30
ENGLISH 9

Programmes Load
(kg)
Energy
consump‐
tion (kWh)
Water con‐
sumption
(litre)
Approxi‐
mate pro‐
gramme
duration
(minutes)
Remaining
moisture
(%)1)
Standard cotton programmes
Standard 60°C
cotton 6 0,80 47 246 52
Standard 60°C
cotton 3 0,54 38 174 52
Standard 40°C
cotton 3 0,49 39 175 52
1) At the end of spin phase.
2) Not available for some models.
Off Mode (W) Left On Mode (W)
0.48 0.48
The information given in the chart above is compliant with the EU Commission regu‐
lation 1015/2010 implementing directive 2009/125/EC
7. OPTIONS
7.1 Température
Set this option to change the default
temperature.
Indicator = cold water.
The indicator of the set temperature
comes on.
7.2 Essorage
With this option you can change the
default spin speed.
The indicator of the set speed comes on.
Additional spin options:
Rinse Hold
• Set this option to prevent the laundry
creases.
• The related indicator comes on.
• There is a water in the drum when the
programme is completed.
• The drum turns regularly to prevent
the laundry creases.
• The lid stays locked. You must drain
the water to unlock the lid.
To drain the water refer to
‘At the end of the
programme’.
Night Cycle
• Set this option to remove all spin
phases and to perform a silent
washing.
• The rinse phase uses more water for
some washing programmes.
• The related indicator comes on.
• The washing programme stops with
the water in the drum. The drum turns
regularly to prevent the laundry
creases.
• The lid stays locked. You must drain
the water to unlock the lid.
To drain the water refer to
‘At the end of the
programme’.
www.electrolux.com10
