Electron TEMPO 12 User manual

ΤΕΜΡΟ 12
USER’S MANUAL

Introduction Tempo 12 is the most powerful 12-channel control desk that combines
economy in price and high performance. It is suitable for permanent
installations or touring requirements for either small stages, studios or
theaters.
Tempo 12 can control 12 channels or 12 programmable memories by using
the 12 sliders. Twelve monitor leds indicate the output level. Each channel
or memory can be flashed to 100% from flash buttons at any time.
The pre-programmed chaser with its own chase master level control, is
activated simply by pressing the chase on-off button. The user can adjust
the rate and select one of three operating modes of the chaser as well as
one of the three functions on each mode:
Mode 1: 1x12 channels Function 1: up
Mode 2: 2x 6 channels Function 2: down
Mode 3: 4x 3 channels Function 3: up-down
The chaser can be assigned to two six-channel groups with a simple press
of a button. Group 1 includes the first six channels of the control desk (1-6)
and group 2 the last six channels (7-12).
The output intensity of Tempo 12 can be adjusted by a grand master control
while blackout is set by the DBO key.
Dimmer packs with DMX-512 input can be connected to the DMX-512
output of Tempo 12. Analogue outputs of Tempo 12 (0/+10V) can drive
dimmer packs with analogue inputs.
For safe and correct operation, please read the instruction manual very
carefully, before using the equipment.
Please, read the instruction manual very carefully.
In case that something is not clear enough in this manual, please contact
your local supplier.
ELECTRON SA is not responsible for any accident or damage caused
by
incorrect installation or improper use of the equipment.
Precautions and
Operation Notes
DBO (blackout) Button
Press this button in order to set all the outputs in blackout condition or to restore. When the
LED indicator which is above this button is turned on, the console is in blackout condition.
DBO
CHASE OFF Button
Press this button when you want to activate or inactivate the chaser. When the LED
indicator, above this button, is turned on, the chaser is inactive.
CHASE
OFF
Any reproduction by means or whole of this user’s manual in any way, is prohibited without the written consent of ELECTRON S.A.

ELECTRON S.A. reserves the right to change or alter any information contained in this manual without prior notice.
MEMORY Button
Select the memories or the channels that you want to adjust from the 12 presets. When
the LED indicator above this button, is turned on, you can adjust the memories. If it is
turned off, you can adjust the channels.
MEMORY
MODE Button
Select one of the three operating chaser modes. The LED indicators, above this button,
indicate the mode that is active.
MODE Twelve-channel chaser.
2 six-channel chasers.
4 three-channel chasers.
FUNCTION Buttοn
Select one of the three chase functions. The LED indicators, above this button, determine
the function that is in operation.
FUNCTION Right chase
Left chase
Right – Left chase
Button 6 / 6
By pressing this button, you can choose the channels, where the chase will run. The LED
indicators, above this button, indicate the channels that the chase runs.
Chase runs channels 1 - 6.
6 / 6 Chase runs channels 7 - 12.
Chase runs all console`s channels.
FLASH Button
Press one or more of these buttons in order to increase (depending on how long you press
the buttons) to 100% the level of the channel (when LED indicator above the memory
button is turned off) or the level of the memory (when LED indicator is turned on).
FLASH
MEMORY PROGRAMMING
1. Press MEMORY button for about 4 sec. The LED indicator, above the button, will start blinking.
2. Adjust the desirable levels on the sliders.
3. Press the STORE button. The two leds above the button will start blinking, which means that the
console is ready to store the levels that you have adjusted in the selected memory.
4. Press one of the FLASH buttons in order to store the adjustments to the corresponding memory. The
two leds above the STORE button are turned off.
5. Repeat steps 2, 3, 4 in order to program more memories.
6. Press MEMORY button for about 4 sec. in order to complete the programming procedure.

DIMMER POWER UNIT CONNECTIONS
Αnalogue output 0-10V with two 9pin D - sub female connectors.
Pin 1 : channel 1 ( or channel 7 for the second connector)
Pin 2 : channel 2 ( or channel 8 for the second connector)
Pin 3 : channel 3 ( or channel 9 for the second connector)
Pin 4 : channel 4 ( or channel 10 for the second connector)
Pin 5 : channel 5 ( or channel 11 for the second connector)
Pin 6 : channel 6 ( or channel 12 for the second connector)
Pin 7,8 : not in use
Pin 9 : common (0V)
Digital output DMX 512 with 5 pin XLR female connector.
Pin 1 : Common
Pin 2 : Data -
Pin 3 : Data +
TECHNICAL SPECIFICATIONS
TEMPO 12
POWER SUPPLY : 230V-50-60Hz
POWER CONSUMPTION : MAX.15KW
DMX-512 (1990) OUTPUT 5PIN XLR CONNECTOR
ANALOGUE OUTPUTS 0/+10V TO TWO 9PIN D - sub CONNECTORS
AMBIENT OPERATING TEMPERATURE : MAX.40°C
DIMENSIONS IN CM (WxDxH): 37,5 X 22,2 X 6,5
WEIGHT : 3 KGS
FEATURES
12 Presets which can be assigned to control 12 channels or 12
programmable memories
12 Flash buttons
12 Monitor leds
Chaser with three operating modes and three functions per mode
Rate indicator with led flashing at rate speed
Capability of assigning the chase to two six-channel groups: (group
1= 1-6 chan., group 2= 7-12 chan.)
Chase master with chase off button
Grand master with blackout button
Analogue output
Digital output
CE approved. Complies with all mandatory European LVD and EMC
regulations
