ElfinX TVBOX-200 User manual
www.elfinx.com 1
TVBOX-200
TV Tuner Box Operating Instructions
OWNER’S MANUAL
CONTENTS:
OPERATING INSTRUCTIONS
DESCRIPTION OF FUNCTIONS AND FEATURES
WIRE CONNECTION GUIDE
INSTALLATION GUIDE
Before operating this set, please read these instructions completely.
www.elfinx.com 2
Safety Instructions
1. The TV Box can be operated on AC SINGLE 100V – 240V.
2. The TV Box is using external AC Adapter (+12V) and it is compatible with car’s +12v battery.
3. Before cleaning the TV Box, you must unplug the power. The TV Box can be kept in good
condition by simple wiping with a clean, soft cloth moistened. Do not use solutions containing
benzol, petroleum or a chemical cloth.
4. Avoid exposing the TV Box to direct sunlight and other source of heat.
5. Adequate ventilation is essential to prevent failure of electrical components.
6. To prevent damage which may result in fire or electrical shock, do not expose the TV Box to rain or
excessive moisture.
7. Remove the plug (power point) when the TV Box is not used for a prolonged period of time.
8. Do not remove the TV Box cover, as live parts are accessible when it is removed. If the TV Box
gets defective, please find a certify technician or contact us for repair by e-mail:
Refer all servicing to qualified service personnel.
Introduction
This TV Box is produced adopting the latest I2C bus-mastering technology for TV sets with big screens and PLL
frequency technology as well as the top-ranking technological design. It can receive all PAL, NTSC cable
(including additional channels) or radio TV signals.
www.elfinx.com 3
Features
=
1. The technology of quick auto search within 10 minutes makes it more convenient. Auto Tuning
System : Frequency synthesizer Auto searching tuning.
2. Frequency Lock Technology: signal received are more stable, better adopting the PLL frequency
technology.
3. It can receive and store over 200 program channels and adapt to the future cable TV station network.
4. The switch power is adopted and adaptive to extensive voltage ranges. It is safe and reliable with
high efficiency and little heat.
5. Possessed with on screen menu display, which is simple and convenient to operate with clear
appearance and complete functions.
6. It has the functions of STANDBY, 24-Hours ON/OFF Time and AUTO OFF without signals for ten
minutes.
7. It has the function of Calendar, which is able to check for year, month, and week from year 1900 to
year 2000 (total 200 years).
8. It has 1 Video and Audio Input and output jacks.
9. Outside power is adopted to make the use more safe and reliable.
10. The shape design is small, easy to store, light weight, and convenient to use.
Operating Instructions
1. Headphone Output
2. TV Antenna In
3. External Cable connection
www.elfinx.com 4
1. Built-in Speaker 2. Power Switch
3. Auto TV Channel Search 4. TV/AV Select
5. Menu 6. Volume Down
7. Volume Up 8. Channel Down
9. Channel Up 10. Remote Sensor & Led Indicator
www.elfinx.com 5
Technological Specification
Frequency: 45 MHz to 870 MHz
Video Output: 1 Vp-p
Audio Output: -6db
TV System: PAL, NTSC, D/K, I, G.M
Power Range: AC 100V – AC 240V
Power Consumption: < 10w
Antenna Impedance: 75 Ohm (unbalanced type)
Remote Control
www.elfinx.com 6
Trouble Shooting
No Picture, No Character
Check whether the product is connected with the power source and whether the power is on; whether
the AV line is connected rightly
No Image or Sound, with Character
Check whether the antenna is connected and search program again.
No Image with Sound
The AV line is connected by mistake
No Sound
Check whether the AV line is connected rightly and whether the volume is decreased or mute.
Cacophony
Check the Sound System item in Preset Menu to see whether the selected system is identical with the
local signal system.
Weak TV Signal or No TV Signal
Search again and check whether the antenna is in good condition and whether the System item is
selected to be in your area in Function Menu.
Out of Control
Power off and turn on again after 10 seconds.
Unable to enter Preset Menu
No manual display under AV and can enter Preset Menu only when turned to the TV state.
Remote Control Not Sensitive or No Work
Check the battery in remote control.
Must be operated within 8 meters.
Should any problem persists, please contact your dealer, installer, and technician.
- Thanks for purchasing elfinx products -
