Elgento E19023 User manual

www.elgento.co
ICE CREAM
MAKER
MODEL E19023
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: Ice Cream Maker
Model: E19023
Rated Voltage: 230 - 240V
Frequency: 50/60Hz
Power consumption: 12W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31).
2009/125/EC Eco-Design of Energy Related Products.
RKW Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RKW has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.elgento.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must be
connected to the terminal marked [N] or coloured
black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable
plug tted to the mains lead and should the fuse
need replacing, you must use an ASTA approved
one (conforming to BS 1362 of the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - and then cut o the mains lead
and immediately dispose of it safely.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
WARNING:
This appliance is double insulated. Do not connect any wire to the earth terminal.

4
CUSTOMER SUPPORT TEAM: [phone]
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
Check that the voltage of the main circuit corresponds with the
rating of the appliance before operating.
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance before
operating.
• Please ensure that the appliance
is used on a stable, level, and
heat resistant surface.
• DO NOT immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• DO NOT leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from the
socket when not in use or before
cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• DO NOT let the cord hang over
the edge of a table or counter or
let it come into contact with any
hot surfaces.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.
• DO NOT pull the plug out by the
cord as this may damage the
plug and/or the cable.
• DO NOT use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• DO NOT carry the appliance by
the power cord.

5
www.elgento.co
• DO NOT use the appliance
outdoors.
• Avoid contact with moving parts
at all times.
• DO NOT overload the appliance.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the service
department.
HIGH VOLTAGE

6
CUSTOMER SUPPORT TEAM: [phone]
WHAT’S IN THE BOX
Instruction Manual
Mixing Paddle
1. Power ON/OFF Switch
2. Lid
3. Mixing Paddle
4. Mixing Bowl
BEFORE YOUR FIRST USE:
• Remove the parts from the packaging.
• Place on a at, dry surface.
• Remove any promotional labels or stickers.
• Wash all surfaces that will come into contact with food in warm soapy water, rinse and dry with a
dish towel.
Dispose of the packaging in a responsible manner.
1
3
2
4

7
www.elgento.co
USING YOUR APPLIANCE
1. Fit the power unit into the lid, It will click
into place.
2. Fit the paddle into the power unit.
3. Remove the freezer bowl from the freezer.
4. Lower the assembled lid/power unit/paddle
onto the freezer bowl and turn clockwise to
lock into position.
5. You can now switch the ice cream maker
on using the On/O button switch.
THE MACHINE MUST BE SWITCHED ON
BEFORE ADDING THE ICE CREAM OR
SORBET RECIPE TO PREVENT THE MIX FROM
IMMEDIATELY FREEZING ON THE INSIDE OF
THE BOWL.
6. Use the chute and pour the ice cream or
sorbet mix into the freezer bowl.
7. Switch o and remove the power unit/lid.
The ice cream is ready to serve.
Note:
• When pouring mixture into the bowl, always
stop at least 4 cm (1.5 inches) from the
top, as the mixture will increase in volume
during freezing.
• Allow the mixture to churn until frozen or
the desired consistency is reached. This
can take up to 15 to 30 minutes, but most
recipes will be ready in less time.
• We recommend freezing the freezer bowl
for 8 hours prior to use.

8
CUSTOMER SUPPORT TEAM: [phone]
IMPORTANT
• DO NOT stop and start the machine during
the freezing process, as the mixture may
freeze in contact with the bowl and prevent
movement of the paddle.
• To avoid overheating the motor, the
direction of rotation will change if the
mixture becomes too thick. If the direction
of rotation continues to change, stop the
machine when the mixture is ready.
• In the unlikely event of the motor
overheating, a safety cut out will operate
causing the motor to stop. If this happens,
switch o, unplug the machine and allow
the power unit to cool.
• The ice cream produced should be a soft
spoonable type. This can be transferred
to a separate container for storage in the
freezer or if you wish to rm the ice cream
before eating.
• DO NOT use metal utensils to remove mix
from the bowl.
• DO NOT remove the freezer bowl from the
freezer until ready to make ice cream.
Note:
• We suggest that you keep the freezer bowl
in the freezer so that it is ready for use.
• Place in a plastic bag before freezing.
Freeze the bowl in the upright position.
• Always make sure the freezer bowl is
thoroughly dry before placing in the freezer.
• Do not puncture or heat the freezer bowl.
• The freezer bowl should be placed in a
freezer that is operating at a temperature
of -18° Centigrade (-0.40° Fahrenheit) or
below for 8 hours before use.
• For best results always refrigerate the
ingredients before making ice cream.
• The addition of alcohol to recipes inhibits
the freezing process.
Milk Ice Cream
Ingredients
350ml Skimmed milk
150ml Whipping cream
50g White sugar
Method
1. Important: Place the cooling bowl in
the freezer for at least 8 hours prior to
preparing your ice cream mixture.
2. Stir the cream until it has thickened and
forms peaks
3. Mix in all the ingredients, then place inside
the refrigerator and cool down to around
5-10℃.
4. Switch on and put the mixed ingredients
inside the ice cream maker.
Banana Ice Cream
Ingredients
1 Large ripe banana
250ml Skimmed milk
160ml Whipping cream
50g White sugar
Method
1. Important: Place the cooling bowl in
the freezer for at least 8 hours prior to
preparing your ice cream mixture.
2. Mash the banana.
3. Stir the cream until it has thickened and
forms peaks
4. Mix in all the ingredients, then place inside
the refrigerator and cool down to around
5-10℃.
5. Switch on and put the mixed ingredients
inside the ice cream maker.

9
www.elgento.co
Mango Ice Cream
Ingredients
2pcs (about 200g) Mango
180 ml Skimmed milk
120ml Whipping cream
50g White sugar
Method
1. Important: Place the cooling bowl in
the freezer for at least 8 hours prior to
preparing your ice cream mixture.
2. Mash the mango.
3. Stir the cream until it has thickened and
forms peaks
4. Mix in all the ingredients, then place inside
the refrigerator and cool down to around
5-10℃.
5. Switch on the unit and put the mixed
ingredients inside the ice cream maker.
Strawberry Ice Cream
Ingredients
200g Fresh strawberries
190ml Skimmed milk
120ml Whipping cream
40g White sugar
Method
1. Important: Place the cooling bowl in
the freezer for at least 8 hours prior to
preparing your ice cream mixture.
2. Mash the strawberries.
3. Stir the cream until it has thickened and
forms peaks
4. Mix in all the ingredients, then place inside
the refrigerator and cool down to around
5-10℃.
5. Switch on and put the mixed ingredients
inside the ice cream maker.
Chocolate Ice Cream
Ingredients
70g Chocolate
270ml Skimmed milk
170ml Whipping cream
40g White sugar
Method
1. Important: Place the cooling bowl in
the freezer for at least 8 hours prior to
preparing your ice cream mixture.
2. Warm up the Skimmed milk and white
sugar. Then put the chocolate inside until
it melted.
3. Stir the cream until it has thickened.
4. Mix in all the ingredients, then place inside
the refrigerator and cool down to around
5-10℃.
5. Switch on and put the mixed ingredients
inside the ice cream maker.
Yoghurt Ice Cream
Ingredients
245ml Yoghurt
15ml Whipping cream
50g White sugar
90ml Strawberry juice
10ml Lemon juice
Method
1. Important: Place the cooling bowl in
the freezer for at least 8 hours prior to
preparing your ice cream mixture.
2. Stir the cream until it has thickened and
forms peaks
3. Mix in all the ingredients, then place inside
the refrigerator and cool down to around
5-10℃.
4. Switch on and put the mixed ingredients
inside the ice cream maker.

10
CUSTOMER SUPPORT TEAM: [phone]
Cheesecake Ice Cream
Ingredients
1 vanilla pod
150 ml milk
1/2 packet of vanilla sugar
2 egg yolks
50g sugar
150g cream
Method
5. Cut the vanilla bean lengthwise and scratch
out the vanilla seeds using a sharp knife.
Put the milk, vanilla sugar, vanilla pod and
seeds into a saucepan and allow to come
briey to the boil.
6. Remove the saucepan from the stove and
allow to infuse for approx 10 mins. Beat
the egg yolk and sugar using a hand mixer
for about 5 mins until the mixture thick and
creamy.
7. Remove the vanilla pod from the milk and
pour the hot milk into the egg mixture while
stirring constantly. Pour the hot milk into
the mixture in a thin stream, otherwise there
is a risk that the eggs will separate.
8. Put the egg milk into the saucepan and
heat slowly (do not boil), stirring with a
whisk, until the mixture thickens. Now put
the ice cream mixture into the refrigerator
for at least 12/max. 24 hours.
9. Beat the cream until it is sti then fold it into
the cooled mixture. Now you can place the
prepared the ice cream mixture into the ice
cream maker.
Check this chart for
basic imperial to metric
conversions of weights.
Imperial Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
15 oz 425g
1 lb 450g
Food Allergies
Important Note:
Some of these
recipes may contain
nuts and/or other
allergens.
Please be careful
when making any of
our sample recipes
that you are NOT
allergic to any of
the ingredients. For
more information on
allergies, please visit
the Food Standards
Agency’s website at:
www.food.gov.uk
Metric Imperial US cups
250ml 8 oz 1 cup
180ml 6  oz 3/4 cup
150ml 5 oz 2/3 cup
120ml 4 oz 1/2 cup
75ml 2 1/2 oz 1/3 cup
60ml 2 oz 1/4 cup
30ml 1 oz 1/8 cup
15ml 1/2 oz 1 tablespoon

11
www.elgento.co
Cleaning and Care
It is important that you follow the cleaning
instructions soon after use to prevent build-up of
food on the appliance.
• Before cleaning ensure that the motor unit
is switched o and that the wall socket is in
the o position.
• We would recommend hand washing of the
attachments.
• The motor unit can be wiped down with a
soft damp cloth and a little detergent for
greasy or stubborn stains.
• Ensure that the attachments are dried
before storing.
Freezer Bowl
• Allow the freezer bowl to reach room
temperature before attempting to clean.
• Wash the inside of the bowl, and then dry
thoroughly. Do not immerse in water.
Paddle
• Remove the paddle from the power unit.
• Wash then dry thoroughly.
Lid
• Wash the lid then dry thoroughly.
Power unit
• Wipe with a damp cloth, and then dry.
IMPORTANT!
Allow to dry fully after cleaning before using
again.
Do not use the appliance if damp. Ensure the
appliance is completely clean and dry before
storing.
Storage
When the appliance is not in use, disconnect
from the mains supply and store in a safe, dry
place, out of reach of children.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are giving you an extra years peace of mind.
To receive your extra years guarantee, register your appliance online by visiting
www.elgento.co
Should you have a problem
with your appliance or need any spare parts please call our
Service Department on:
[phone]
Distributed throughout the UK by RKW LTD
0917.V2
