Elgento E22001 User manual

Afx stamp Here
TO: CUSTOMER SERVICES DEPARTMENT. ELGENTO. SUTTON HOUSE, BERRYHILL ROAD, FENTON, STOKE ON TRENT, STAFFORDSHIRE, ST4 2NL.
Steam Iron
INSTRUCTION MANUAL E22001
2600W

PARTS IDENTIFICATION
This product is guaranteed for 12 months from the date of the original purchase.
If any defect arises due to faulty materials or workmanship the faulty products must
be returned to the place of purchase. Refunds or replacement is at the discretion of
the store.
The following conditions apply:
The product must be returned to the retailer with the original proof of purchase.
The product must be installed and used in accordance with the instructions contained
in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has no responsibility for incidental or consequential loss or damage.
Valid in the UK and Eire only.
Technical Specication.
Guarantee.
Steam Iron
Model No E22001
AC: 220V-240V ~50Hz
Power 2600W
Sutton House,
Berryhill Road,
Fenton
Stoke on Trent
Staffordshire,
ST4 2NL.
Before using for the rst time
Dispose of all packaging and plastic bags and in a responsible manner
Some parts of the iron have been slightly greased and as a result, the iron may
smoke slightly when switched on for the rst time.
It will not happen again after the rst use.
Before using for the rst time remove any protective lms or stickers from the
sole plate and the cabinet. Clean the sole place with a soft cloth.
When using the iron for the rst time, test it on an old piece of fabric to ensure
that the sole plate and water tank are completely clean.
Technical Support
If you require technical support or in the unlikely event that your purchase is faulty
please telephone our Helpline for immediate assistance.
0871 221 3619

IMPORTANT SAFETY INFORMATION
ALWAYS FOLLOW THE SAFETY INSTRUCTIONS
Use the iron only for its intended use.
Retain the manual and the safety information in a safe place.
To protect against the risk of electric shock, do not immerse the iron in water
or any other liquids.
The iron should always be turned to the minimum heat setting before plugging
or unplugging from the mains socket.
Never pull the cord to disconnect from the mains: switch off at the wall socket
then grasp plug and pull out to disconnect.
Do not allow the cord to touch hot surfaces.
Allow the iron to cool completely before putting away.
Always switch off at the wall socket and disconnect the iron from the electrical
outlet when lling with water or emptying and when not in use
Do not operate the iron with a damaged cord or if the iron has been dropped
or damaged.
To avoid the risk of electric shock, do not disassemble as there are no user
serviceable components in the iron please take it to a qualied electrician
for examination and/or repair
Close supervision is necessary for any appliance being used by or near children.
Do not leave the iron unattended when connected to the mains or on an ironing
board.
Burns can occur from torching hot metal parts, hot water or steam, use caution
when you turn a steam iron upside down-there may be hot water in the reservoir.
If the iron is not operating normally, disconnect from the power supply and have it
inspected by a qualied electrician.
Your iron is designed to rest on the heel.
Do not leave the iron unattended when switched on.
Do not place the iron on an unprotected surface even if it is on its heel rest.
This appliance is not intended for use by children or the inrm without adequate
supervision or training by a person responsible for their safety.
Children should be supervised at all time to ensure that they do not play
with the appliance.
Keep electrical appliances out of reach from Children
The lling aperture must not be opened during use.
The iron must be used and rested on a stable surface.
SAVETHE INSTRUCTION MANUAL FOR FUTURE REFERENCE
ELECTRICAL SAFETY
The wires in the mains lead are coloured
in accordance with the following code:
GREEN/YELLOW: EARTH (E)
BLUE: NEUTRAL (N)
BROWN: LIVE (L)
As the colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN & YELLOW must be connected to the terminal
in the plug which is marked with the letter “E” by the earth symbol or coloured
GREEN, GREEN/YELLOW.
The wire which is coloured BLUE must be connected to the terminal which is
marked with the letter “N” or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is
marked with the letter “L” or coloured RED
Always ensure that the Mains Cord is xed into the plug through the Cord Guard
or Cable Clamp, (plug wiring diagram above), and that the Cord Guard screws are
tightened to clamp the Cord (outer sheath and inner coloured wires) into position in
the plug. Make sure that plug top is also tted securely.
This appliance must be protected by a 13 Amp fuse in a 13 Amp type (BS1363) plug.
Should you need to replace the fuse, use only a 13Amp ASTA approved BS1362 fuse
(13A).
Elgento. Product Helpline. 0871 221 3619 For all your product needs.

HOW TO USE YOUR IRON
FILLING WITH WATER
make sure that your iron is unplugged from the mains supply and the temperature
is set to to the minimum position
place the iron on the heel rest, tilt forward to approximatly a 45o angle and pour
until the water reaches the MAX level marker on the tank.
VERTICAL STEAM
This is a functionn wherby a surge of steam is produced from the sole plate
and is ideal for removing heavy creases from fabric this function can also be used in
the vertical position on heavely creased hanging fabrics
DRY IRONING
Set the dry/steam selector to 0 (= No steam).
Set the correct iron temperature for the fabric that you are ironing (as per the
washing label of the fabric).
When the iron reaches the temperature that you have set the power indicator
lit will go out and you can start to iron (This will cycle on and off as it regulates
the working temperature of the iron)
STEAM IRONING
Fill the water tank as discribed in lling the water
plug the appliance into the wall socket and switch ON
Set the fabric dial to Max position as indicated on the temerature dial the steam iron
will be available when the Max temerature has been reached and the power light is
out do not use until this point as water may leak from the iron.
To increace or decrease the steam out put adjust the fabric dail until you have the
required steam output.
SURGE OF STEAM
This function works well for tough wrinkles and heavy fabrics. By pressing “Surge of
Steam Button”, an intense burst of steam is emitted from the soleplate; this can be
very useful when removing stubborn creases.
The shot of steam facility can be used only while ironing with high ironing
temperature. For optimal result, there should be 5 seconds burst with a minute rest
period as this will allow the iron to reach the optimum temperature and also stop
any water leaking from the sole plate due to the element being at the incorrect tem-
perature to produce steam.
SELF-CLEANING
Use the self-cleaning function once every two weeks.If the water in your area is very
hard (i.e., when lime scale akes come out of the soleplate during ironing), the self-
cleaning function should be used more frequently.
Make sure the appliance is unplugged,set the Dry/Steam Selector to steam level “O”.
Fill the water tank to the MAX position, do not put vinegar or other de-scaling
agents in the water tank.,
Select the maximum ironing temperature, put the plug in the wall socket,unplug the
iron when the power indicator lighter has gone off,
Hold the iron over the sink, press the self-cleaning button until the steam cover jump
out
Then use hand to pull the steam cover upward a little,no need to pull the steam
cover completely out of the iron,at this time,
the self-cleaning begin to work shake the iron to and fro.
Steam and boiling water will come out of the soleplate, impurities and akes (if any)
will be ushed out.
After nishing the self-cleaning process, press the steam cover downward to make
the self-cleaning button return to its original position with no gap.
Repeat the self-cleaning process if the iron still contains a lot of impurities.
After the self-cleaning process, put the plug in the wall socket and let the iron heat
up to allow the soleplate to dry, unplug the iron when it has reached the set ironing
temperature, move the hot iron gently over a piece of used soft dry cloth to remove
any water stains that may have formed on the soleplate,
let the iron cool down fully before you store it.

Imported & Distributed throughout the U.K. By PFD. Ltd. ST4 2NL
www.elgento-products.co.uk
CLEANING AND MAINTENANCE:
Before cleaning, switch off and remove the plug from the socket and allow the iron to
cool down sufciently.
1. Wipe off the soleplate with a damp cloth and a non-abrasive (liquid) cleaner.
2. If the ber is adhered to the soleplate, use a damp cloth with vinegar to wipe off
the soleplate.
3. Never use strong acid or alkali as these may damage the soleplate.
4. If the scale blocks the steam hole, please remove the scale with toothpick; do not
damage the surface of soleplate.
5. Stand the iron on its end and let it cool down sufciently, and meantime pour any
remaining water out of the box, set the dry/steam selector to position “O”.
TYPE OF FABRIC ANDTHERMOSTAT KNOB DIAL FORM: TROUBLESHOOTER

Declaration of Conformity
We PFD Ltd Declare that this product conforms to all the following
product legislation
In accordance with the following directive(s):
2004/108/EEC. The Electromagnetic compatibility Directive
2006/95EC. The LVD directive (Low Voltage Directive)
2002/95/EC. The RoHS. Directive. (Restriction of Hazardous substances Directive)
Peter Bowden
Quality Assurance Manager
Sutton House, Berryhill Road, Fenton, Stoke-On-Trent,
Staffordshire, ST4 2NL.
IMPORTANT This warranty is invalid if alterations have been made to this certicate
Model no: Serial no: Batch no: Name: Address: Post Code Date Purchased: E-mail Address:
promotions from PFD and it’s associated companies please tick this box
