Elgento E22002 User manual

Steam Iron
INSTRUCTION MANUAL E22002
2000W
Afx stamp Here
TO: CUSTOMER SERVICES DEPARTMENT. ELGENTO. SUTTON HOUSE, BERRYHILL ROAD, FENTON, STOKE ON TRENT, STAFFORDSHIRE, ST4 2NL.

Parts Identication
No steam Steam Maximum steam Self-clean
I : Indicator Light
J : Water Tank
K : Soleplate
L : Water Cup
B : Steam Control Dial
This product is guaranteed for 12 months from the date of the original purchase.
If any defect arises due to faulty materials or workmanship the faulty products must
be returned to the place of purchase. Refunds or replacement is at the discretion of
the store.
The following conditions apply:
The product must be returned to the retailer with the original proof of purchase.
The product must be installed and used in accordance with the instructions contained
in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has no responsibility for incidental or consequential loss or damage.
Valid in the UK and Eire only.
Technical Specication.
GUARANTEE.
Steam Iron
E22002
AC: 220V-240V~ 50Hz
Power 2000W
Sutton House,
Berryhill Road,
Fenton
Stoke on Trent
Staffordshire,
ST4 2NL.
BEFORE USING FOR THE FIRST TIME
Dispose of all packaging and plastic bags and in a responsible manner
Some parts of the iron have been slightly greased and as a result, the iron may
smoke slightly when switched on for the rst time. It will not happen again after
the rst use.
Before using for the rst time remove any protective lms or stickers from the
sole plate and the cabinet. Clean the sole place with a soft cloth.
When using the iron for the rst time, test it on an old piece of fabric to ensure
that the sole plate and water tank are completely clean.
A : Temperature Control
C : Top Cover
D : Spray Button
E : Spray nozzle
F : Burst of steam
G : Water Filling Opening
H : Cord Protector

Important safety information
Always follow the safety instructions
Use the iron only for its intended use.
Retain the manual and the safety information in a safe place.
To protect against the risk of electric shock, do not immerse the iron in water
or any other liquids.
The iron should always be turned to the minimum heat setting before plugging
or unplugging from the mains socket.
Never pull the cord to disconnect from the mains: switch off at the wall socket
then grasp plug and pull out to disconnect.
Do not allow the cord to touch hot surfaces.
Allow the iron to cool completely before putting away.
Always switch off at the wall socket and disconnect the iron from the electrical
outlet when lling with water or emptying and when not in use
Do not operate the iron with a damaged cord or if the iron has been dropped
or damaged.
To avoid the risk of electric shock, do not disassemble as there are no user
serviceable components in the iron please take it to a qualied electrician
for examination and/or repair
Close supervision is necessary for any appliance being used by or near children.
Do not leave the iron unattended when connected to the mains or on an ironing
board.
Burns can occur from torching hot metal parts, hot water or steam, use caution
when you turn a steam iron upside down-there may be hot water in the reservoir.
If the iron is not operating normally, disconnect from the power supply and have it
inspected by a qualied electrician.
Your iron is designed to rest on the heel.
Do not leave the iron unattended when switched on.
Do not place the iron on an unprotected surface even if it is on its heel rest.
This appliance is not intended for use by children or the inrm without adequate
supervision or training by a person responsible for their safety.
Children should be supervised at all time to ensure that they do not play
with the appliance.
Keep electrical appliances out of reach from Children
The lling aperture must not be opened during use.
The iron must be used and rested on a stable surface.
Ironing temperature guide
Follow the ironing instructions on the garment label. If these instructions are missing,
but you do know the kind of fabric then see the table.
This table is valid for garment only and is not applicable to any applied nish, gloss etc.
Textile to which some kind of nish gas been applied (gloss, wrinkle, relief etc.) Can
best be ironed at low temperature.
Sort the laundry out according to ironing temperature rst: wool with wool, cotton
with cotton etc.
The iron heats up quicker than it cools down. Therefore, start ironing the lowest
temperature such as those made of synthetic bres.
If the fabric consists of various kinds of bres, always select the lowest ironing tem-
perature of the composition of those.
Fabric, if for example, an article consists of 60% polyester and 40% cotton, is should
be ironed at the temperature indicated for polyester (.) and without steam.
If you do not know what kind(s) of fabric(s) the article has been made of, nd a spot
which will be invisible when wearing or using the article. Try out the ironing tempera-
ture which is most suitable there. Start at a relatively low temperature.
Pure woolen fabrics (100% wool) may be pressed with the iron set to a steam posi-
tion. Preferably set the temperature knob (B) to maximum position
Use a dry pressing cloth.
When steam ironing woolen fabrics, skinning of the fabric may occur. This can be
prevented by hurting the article inside out and ironing the reverse side.
Velvet and other fabrics which rapidly acquire shiny spots should be ironed
in one direction only applying light pressure.
Always keep the appliance moving whilst ironing.
Iron the reverse side of synthetic materials and silk to prevent shining spots.
Do not use the spray to prevent stains.
SAVE THE INSTRUCTION MANUAL FOR FUTURE REFERENCE

Filling with water
Remove the mains plug from the wall socket before lling (or emptying) the iron
with water. Set the steam control to O position in order to avoid the water leakage.
Fill the lling cup (M) with water. Hold the iron in a titled position and pore the water
into with the lling aperture to the maximum level.
Fill the iron with normal tap water when using it for the rst time.
For relling, you can also use tap water. However, if the water is very hard, it is advis-
able to use distilled water.
Do not put vinegar, starch, chemically, descaled water or descaling agents
in the water reservoir.
Ironing temperature guide Setting the temperature
Stand the iron on its end.
Set the temperature control to the correct ironing temperature.
Insert the mains plug into the wall socket.
After the temperature pilot light rst has gone out and has come on again, you may
start ironing.
The temperature light will come on from time to time during ironing.
If you set the temperature control to a lower setting after ironing at a high
temperature, please allow time for the iron to cool. This is to prevent scorching on
your garment.
Ironing without steam
Set the steam control (B)l to position O(=no steam).
To switch on the iron, refer to paragraph “Setting the temperature”.
Steam-ironing
Ensure that there is enough water in the water tank.
Set the steam control:.
No steam setting (O) for temperature setting MIN to . . Steam
setting
For temperature settings
Maximum steam setting for temperature setting to MAX.
Water may leak from the soleplate If a too low temperature ( and low) has
been selected.
To switch on the iron, refer to paragraph “setting the temperature”for the
To use the self clean function of the iron turn the steam function knob to the solid
dot.
This function provides an extra amount of steam to remove stubborn creases.
Fill the iron reservoir with water.
Turn the temperature control to the position "MAX"
The indicator light turns off when the required temperature is reached
The iron is ready for use
Press the Steam jet button once
Steam will penetrate into the garment removing the creases
Wait a few seconds before pressing the steam control knob again when there are
stubborn creases usually all creases can be removed within three operations of the
steam jet.
Using the Steam Jet
Reheating the Steam Iron
Pick up the iron or move it slightly
The red indicator light will go out if the temperature of the soleplate has dropped
below the set ironing temperature, the temperature indicator light goes on to show
that the iron is heating to the desired temperature
If the pilot light goes on after you have move the iron, wait for the indicator light to
go out before you comence ironing.
If the pilot light does not go on after you move the iron, the soleplate still has the
right temperature and the iron is ready for use.

Electrical Safety
The wires in the mains lead are coloured
in accordance with the following code:
GREEN/YELLOW: EARTH (E)
BLUE: NEUTRAL (N)
BROWN: LIVE (L)
As the colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN & YELLOW must be connected to the terminal
in the plug which is marked with the letter “E” by the earth symbol or coloured
GREEN, GREEN/YELLOW.
The wire which is coloured BLUE must be connected to the terminal which is
marked with the letter “N” or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is
marked with the letter “L” or coloured RED
Always ensure that the Mains Cord is xed into the plug through the Cord Guard
or Cable Clamp, (plug wiring diagram above), and that the Cord Guard screws are
tightened to clamp the Cord (outer sheath and inner coloured wires) into position in
the plug. Make sure that plug top is also tted securely.
This appliance must be protected by a 13 Amp fuse in a 13 Amp type (BS1363) plug.
Should you need to replace the fuse, use only a 13Amp ASTA approved BS1362 fuse
(13A).
CLEANING AND MAINTENANCE:
Before cleaning, switch off and remove the plug from the socket and allow the iron to
cool down sufciently.
1. Wipe off the soleplate with a damp cloth and a non-abrasive (liquid) cleaner.
2. If the ber is adhered to the soleplate, use a damp cloth with vinegar to wipe off
the soleplate.
3. Never use strong acid or alkali as these may damage the soleplate.
4. If the scale blocks the steam hole, please remove the scale with toothpick; do not
damage the surface of soleplate.
5. Stand the iron on its end and let it cool down sufciently, and meantime pour any
remaining water out of the box, set the dry/steam selector to position “O”.

Declaration of Conformity
We PFD Ltd Declare that this product conforms to all the following
product legislation
In accordance with the following directive(s):
2004/108/EEC. The Electromagnetic compatibility Directive
2006/95EC. The LVD directive (Low Voltage Directive)
2002/95/EC. The RoHS. Directive. (Restriction of Hazardous substances Directive)
Peter Bowden
Quality Assurance Manager
Sutton House, Berryhill Road, Fenton, Stoke-On-Trent,
Staffordshire, ST4 2NL.
