4K HDMI 2.0 KVM Optical Transceiver
Model: LNK-109KVM
User Manual V1.0

E-link China Technology Co., Ltd.
www.e-linkchina.com.cn 2 [e-mail]
FEATURES
• Supports HDMI Video up to Kx2K@60 Resolution
• HDMI 2.0 with HDCP Support
• DDC CEC HPD Signal Support
• No Settings or Adjustments Necessary, Automatically Recognizes HDCP, EDID & CEC
• Supports up to 300m Transmission Distance with OM multimode fiber
• Standard HDMI Connector
• Supports USB Mouse and Keyboard
• Hot-Pluggable
• EMI/RFI Resistant
• 850nm VCSEL and PIN Photodetector
• Uses Small, Reliable LC Optical Connector
• Operating Case Temperature: 0~50°C
DESCRI TION
The E-link LNK-109KVM HDMI optical transmitter and receiver are designed to send 1
channel of 2.0 compliant HDMI Video with embedded audio over Single optical fibers.
HDCP is automatically supported for the transmission of content-protected video.
The K HDMI optical transceiver supports transmission of an uncompressed lossless
HDMI 2.0 signal over multimode optical fiber at 850nm, for distances up to 300 meters,
at a resolution of Kx2K.
Transmitter converts an HDMI and USB signal to a single 18Gb/s serial data stream for
transmission over optical fibers.
Receiver converts the serial data back to an HDMI signal.
This product is ideal for large-screen displays, conferencing systems and home
entertainment.
This fiber link meets all of the standards of interference immunity, to ensure the stability
of the signal.
The transceivers are RoHS compliant and lead-free. These small modules utilize one
multimode fiber with a standard locking LC optical connector.

E-link China Technology Co., Ltd.
www.e-linkchina.com.cn 3 [e-mail]
Resolution
Chroma Subsampling 4K Resolution 1080 Resolution
: : K@60Hz 1080P@120Hz
:2:2 K@60Hz 1080P@120Hz
:2:0 K@60Hz 1080P@120Hz
LNK-109KVM System Connections

E-link China Technology Co., Ltd.
www.e-linkchina.com.cn sale[email protected]
CONNECTING AND O ERATING LNK-109KVM
1. Connect HDMI port of Transmitter to the video source device, USB port connect to PC’s
USB interface.
2. Connect HDMI port of Receiver to the HDTV (HD monitor), connect USB
keyboard&mouse to the USB port on Receiver.
3. Connect the Transmitter and Receive through LC-LC Fiber Optic Cable (OM ).
. Connect power to the 5V DC port of Transmitter and Receive.
5. Check LED Indicator and image on Display Screen.
LED Indicator
LINK Fiber Link Indicator
FIBER Power Indicator
ackage Includes
■ LNK-109KVM-T- (Transmitter, To Video Source)
■ LNK-109KVM-R - (Receiver, To TV/Display)
■ USB cable x 1pcs
■ User’s Manual
Please verify all items are included in the box. If anything is missing, please contact the vendor.
Note:
1. Please use OM3/ Fiber for the device and the Connector is Simplex LC.
2. The Max distance is 300 meters, it maybe shorter according to optical attenuation.
3. The Transmitter connect to PC/Laptop etc, the receiver connect to TV, Projecor etc
. Power adapter is not included. You can use 5V universal usb power supply or the USB port of PC.
5. The USB port only for USB keyboard&mouse, not support USB disk, Dongle, USB hub etc.
6. If any problems, please contact our Service & Support team.
