Elite Alto Series User manual

...Helpline 01405 746 000
www.elite-furniture.co.uk
Please Read This Leaflet
Before Assembly
Range Alto Bench
Desk Style High Bench
Assembly Instructions
2 Person Assembly
Rev. v2 06/2019
Tools Required
4mm Allen Key or Hex’
Screwdriver (Provided)
Pozi Screwdriver 5mm Allen Key or Hex’
Screwdriver (Provided)
Components
A
A
FE
Desktop Panel x 1
B
B
Leg Frames x 2
C
C
Top Rails x 2
D
D
Bottom Rail x 1
ESupport Rails x 2
FSupport Arms x 4
GLeg Frame Bolts x 12
HTop Rail Bolts (M6x20) x 10
JSupport Rail Bolts (75mm) x 2
KArm Screws (1/2x8 Self Tapper) x 10
HG J K

1
3
1. On each Leg Frame ‘B’, insert Leg Frame Bolts ‘G’ into the
6x positions per leg ‘Z’ (12x in total) so that they are touch tight
only. Be aware that you want the outer positions on the bottom
extended section ‘Y’.
3. When in place, unscrew the touch tightened bolts ‘G’ on the
Top Rails ‘C’ and Bottom Rail ‘D’ until they are tight and secure.
Repeat with Leg Frame ‘B’ on the opposite side.
4
5
4. Position 4x Support Arms ‘F’ over the screw positions on the
2x Top Rails ‘C’. Using 2x Top Rail Bolts ‘H’ per Arm, x each
Support Arms ‘F’ onto the frame.
5. Screw Support Rail ‘E’ to the centre of Support Arms ‘F’
using 2x Top Rail Screws ‘H’ before screwing the Bottom Rail
‘D’ to the Support Rail ‘E’ using 2x Support Rail Bolts ‘J’.
6
6. With assistance, lay Desktop Panel ‘A’ onto the assembled
frames Support Arms ‘F’ and secure in place using 10x Arm
Screws ‘K’.
The Alto Bench is now fully assembled.
ED
Z
B
D
Z
Z
Y
AK
F
C
F
H
B
2
2. With Leg Frame ‘B’ positioned upright, align and join 2x Top
Rails ‘C’ to the top extended sections ‘Z’ and Bottom Rail ‘D’ to
the bottom extended section ‘Y’ covering the inserted Leg
Frame Bolts ‘G’.
Z
Y
B
D
C
C
J
G
H
HJ
K
