Domes&que)30L)Twin)Slide)Out)
Concealed)Waste)Bin)
;)for)a)300mm)Cupboard)
Contents List
ELITEPOB-300SLIM-0215
• Twin 30L pull-out – 1 x 20L + 1 x 10L
• Suits standard 300mm wide cabinet (external)
• Does not include integrated door mount
• Door mount kit can be purchased separately to affix
ELITEPOB-300SLIM-0215-D
• Twin 30L pull-out – 1 x 20L + 1 x 10L
• Suits standard 300mm wide cabinet (external)
• Includes integrated door mount to attach frame to
cabinet door
Models
Minimum Dimension Requirements
26.8cm

www.ELITEKitchenStorage.com4
©4Copyright420154ELITE®4
Kitchen4Storage4Solu@ons4 www.ELITEKitchenStorage.com4
©4Copyright420164ELITE®4
Kitchen4Storage4Solu@ons4
Domes&que)30L)Twin)Slide)Out)
Concealed)Waste)Bin)
;)for)a)300mm)Cupboard)
Affixing door
Mounting the cabinet door to the frame allows the bin set to slide out when the cabinet door is pulled out.
Alternatively you can install the bin and use a hinged cabinet door and pull the bin set out separately.
Position door brackets Attach door to mount
Model: ELITEPOB-300SLIM-0215
• If you are not attaching a door then it is recommended you affix the part 6 nuts and bolts into the 3
mounting holes on each side of the frame for enhanced stability
• A door mount kit can be purchased and affixed to frame and mounted to door as per below
Models: ELITEPOB-300SLIM-0215-D
• Affix the door brackets to the back of the cabinet door so that it will be in alignment (see diagram)
• Affix the door mount (attached to bin frame) to the door brackets (see diagram)
• Make horizontal, vertical and tilt adjustments to fine-tune the alignment of the door
Front of Cabinet
Mount frame to cabinet base
