Elkay Hi-Arc LKE4122 User manual

GENERAL
LKE4122 Single-lever kitchen faucet with circular brass base
finished in polished heavy chrome plate. Tubular brass high-arc
traditional style, 6" swing spout with restricted flow aerator.
Removable cartridge. Temperature and flow controlled by one
movement of the single-lever handle. All operating parts are
replaceable from above deck. 3/8" O.D. copper tube connec-
tions. Requires two faucet holes. Ship. Wt. 3-3/4 lbs.
MAXIMUM FLOW RATE
2.5 GPM/9.5 L/min AT 80 P.S.I.G.
2.2 GPM/8.3 L/min AT 60 P.S.I.G.
CARTRIDGE
Maintenance-free, drip-free washerless
cartridge that is completely
self-contained and easily removable.
A simple cam-activated movement
of the diaphragm controls the flow
of water with a feather-lite touch.
No springs. No wearing action. And
no moving parts exposed to water.
U.S. Patent #4,357,957
This faucet is ADA compliant.
This faucet is certified to ANSI/NSF61 for residential use.
9"
(229mm)
4"
(101.6
mm)
10" (254mm) LONG TUBES
3/8" DIA.
6"
(152.4mm)
Model LKE4122
Elkay 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A. ©2004 Elkay
(Rev. 3/04) 5-37F
www.elkayusa.com
Hi-Arc®Single-Lever Kitchen Faucet
Model LKE4122
®
SPECIFICATIONS
Limited Lifetime Functional and Finish Warranty
Elkay warrants to the original consumer purchaser that the Elkay faucet pur-
chased will be free from defects in material and workmanship for as long as the
original consumer purchaser owns the faucet. Elkay will, at its option, supply
replacement parts (or if no longer available a comparable product) if the faucet
fails due to a defect in material or workmanship. This warranty does not apply
in the event of product surface damage caused by abuse, misuse or improper
care and maintenance. This warranty excludes damage caused by harsh or
abrasive cleaners and/or materials. This warranty excludes all industrial, com-
mercial and business use, whose purchasers are hereby extended a limited
lifetime on mechanical parts and 5 years on finish. Product replacement does
not include transportation cost or labor installation cost. Elkay reserves the
right to examine product in question and its installation prior to replacement.
OTHER WARRANTY CONDITIONS ON FAUCETS
Our warranty does not cover product failure or damage caused by abusive
treatment, misuse, environmental factors, improper care and cleaning, or
damage due to handling or faulty installations. This warranty is extended only
to the original consumer purchaser of the product. This warranty does not
cover shipping costs, labor costs, or any other charges for such items as in-
stallation or replacement of the sink, diagnosis or replacement of any faucet or
component part, or any other expense or loss.
All incidental or consequential damages are specifically excluded. No
additional warranties, express or implied are given. Any implied warranty,
including one of merchantability or fitness for a particular purpose, is
limited to the duration of this written warranty.
Some states do not allow the exclusion or limitation of incidental or con-
sequential damages or limitations on how long an implied warranty lasts, so the
above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
TO OBTAIN SERVICE UNDER WARRANTY
1. Write to: Elkay
Attention: Consumer Services
2222 Camden Court
Oak Brook, IL 60523
2. Include a letter containing the following information:
a. Date of purchase and installation
b. Description of nature of defect
c. Model number or description of model and/or component part if
possible.
ELKAY LIMITED LIFETIME FAUCET WARRANTY ON RESIDENTIAL FAUCETS

A53080E
HANDLE
ASSEMBLY
A52364
DOME
A52848
SLEEVE
A52399R
CARTRIDGE
INCLUDES (2) A53226R
DIAPHRAGMS
A53226R
DIAPHRAGMS (2)
A52387
O RING
REQUIRED
A54442
BASE
SINK
DECK
A52801
MOUNTING
HARDWARE
A52811
HOSE
A54422
SPOUT HOLDER
A52740
LOCKNUT
A51336
WASHER
A53245
O RING
A51861
O RING
A52547
WASHER
A52546
FLANGE
A52650
SLEEVE
A52657 (2)
BEARING
A52656
SPOUT NUT
SPOUTASSEMBLY
A52722 INCLUDES:
A52656, A52657 (2),
A51861, A51357
A52373
CARTRIDGE
SCREW
A51357
AERATOR
Elkay 2222 Camden Court
Oak Brook, IL 60523
www.elkayusa.com
Printed in U.S.A.
©2004 Elkay
5-37F (Rev. 3/04)
Hi-Arc®Single-Lever Kitchen Faucet
Model LKE4122
®
PARTS LIST
