Single Handle Kitchen Faucet With Spray
Model # HD2478CRQ
INSTALLATION / OWNER'S MANUAL

STEPS:
WARNING: Please carefully read and properly follow the instructions for installation found in this manual.
For models with spray ( fits 4 - hole
sinks ):Insert spray support through
far right - hand hole on sink. Screw
hold - down nut onto shank and hand
tighten.
For models with spray
Insert spray hose down through support
and sink. Align the tabs (1 & 2) on the
quick connects (3). Push the quick
connector housing firmly upward and
snap it onto the receiving tube tab. Pull
down moderately to ensure the
connection has been made. If it is
necessary to remove the quick
connector, squeeze the tabs on the
hose, and pull down to disconnect.
Place faucet in position on sink. From
under sink, threads mounting nuts
onto faucet. Tighten mounting nuts.
Hand tighten only.
Make connections to water lines.
Thread the nut (1) on the supply line
onto the outlet of the water supply
valve (2) and tighten with a wrench.
Do not overtighten.
Important: After installation is
completed, remove aerator. Turn on
water supply and allow both hot and
cold water to run for at least one
minute each. While water is running,
check for leaks. Replace aerator.
Shut off water supply at angle stop.
Remove old faucet. Clean sink
surface in preparation for new faucet.
1
2
1
2
3

FOR CARE AND MAINTENANCE:
·The water in certain areas of the world can be very caustic -
standing water around the product can cause damage. Be
sure to remove standing water with a dry, soft cloth as soon
as possible.
·For polished brass finishes, as often as once a week, you
can apply a paste wax or special, non-abrasive, brass
coating (DO NOT APPLY POLISH).
·Before applying a protective coating, gently brush the entire
fixture using a soft tooth brush. This will remove any dirt or
deposit build-up.
·These simple steps will add temporary protective coating to
your faucet and extend the life of the finish.
Failure to follow care and cleaning will void your warranty.
For additional information, please visit elkayusa.com .
Congratulations on your purchase of an Elkay product.
Although your product is extremely durable, attention should
be given to the care, cleaning and maintenance of this
product. Cleaning agents and abrasives may cause damage,
which may result in oxidation and discoloration.
By following these simple guidelines for proper care and
cleaning, it will give you years of enjoyment:
TO CLEAN: Simply wipe gently with a damp cloth and blot dry
with a soft towel. A common rule of thumb is: when you dry off,
dry off your product.
· Avoid build-up of soap, toothpaste or mineral deposits, as
these tend to have an adverse effect on the appearance of
the product.
· NEVER use cleaning products of any kind on this product -
especially those containing ammonia, bleach or alcohol - or
those with any form of abrasive.
CARE AND CLEANING INSTRUCTIONS
CARTRIDGE REPLACEMENT
Shut off water supply. Remove handle (refer to step
1). Loosen bonnet (1) and cap (2) by turning it
counter-clockwise and lift out the cartridge (3).
Inspect the rubber valve seat (4) inside body (5).
Tightly bonnet (1) and cap (2). Reinstall the handle.
Turn off water before proceeding! Remove index (1).
With valves in "closed" position, unscrew fastener (2)
and remove handle (3) from valve stem (4).
1
2
3
44
1
2
3
5

Elkay
elkayusa.com
©2022 Elkay
Model # HD2478CRQ
(Rev. date: 04/2022)
REPLACEMENT PARTS
WARRANTY
ELKAY LIMITED LIFETIME WARRANTY
ELKAY LIMITED LIFETIME WARRANTY
Elkay warrants that all parts and finishes of the Elkay Residential brand
faucets are free from defects in materials and workmanship for the life of
the product, if purchased after 1996. This warranty covers the
original consumer purchaser of the product only.
If the product should leak or drip during normal use, Elkay will provide,
free of charge, a replacement cartridge. For other defects in material or
workmanship, Elkay will, at its option, supply replacement parts (or if no
longer available a comparable product). Elkay reserves the right to
examine product in question and its installation prior to replacement.
What you must do to obtain warranty service:
Either write to Elkay Manufacturing Company, attention Consumer Care,
1333 Butterfield Road, Suite 200 Downers Grove, Illinois 60515 or call
1-800-223-5529. Please provide date of purchase and installation,
description of nature of the defect, and model number or description of
model and/or component part.
THIS LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ANY
OTHER WARRANTIES, EXPRESSED IMPLIED, ARISING BY LAW
OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE. THIS LIMITED WARRANTY MAY NOT
BE ALTERED, VARIED, OR EXTENDED, EXCEPT BY A WRITTEN
INSTRUMENT EXECUTED BY ELKAY. THE REMEDY OF REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS LIMITED
WARRANTY IS EXCLUSIVE. IN NO EVENT SHALL THE
MANUFACTURER BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES TO ANY PERSON, WHETHER OR NOT
OCCASIONED BY NEGLIGENCE OF ELKAY, INCLUDING WITHOUT
LIMITATION DAMAGES FOR LOSS OF USE, COSTS PROPERTY
DAMAGE OR OTHER MONETARY LOSS.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply. This
warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
This warranty covers product installed in the United States and Canada.
What is not covered:
1. Damage caused by accident, negligence, misuse, abuse, improper
installation or operation or failure to follow care or installation instructions
enclosed with your product.
2. Damage occurring during shipment of the product (claims must be
presented to the carrier).
3. Normal wear and tear.
4. Labor charges, costs of removal and reinstallation, and any damages
to other property.
5. All industrial, commercial and business use whose purchasers are
hereby extended a limited lifetime on mechanical parts and 5 years on
finish.
RP56109 Mounting Nut
RP30129* Areator
RP50040 Thread Rod
RP36120* Spray
RP70834 Diverter
RP60108 O-ring
RP70832 Washer
RP22008 Seat&Spring
RP22007 Cartridge
RP80108* Cap
RP70108 Cam washer
RP70107 Cam
RP10042 Index
RP50054 Set Screw
RP70371 Bonnet
RP13163* Handle
RP70421 Block
P37142 O-ring
