Elkay LK2000 Operating instructions

WrenchGroove joint pliers Screwdriver Sealant Tape Plumber's Putty
(2) 1/2 in Supply Lines
SAVE FOR CONSUMER
Two Handle Laundry Faucet
Model # LK2000
INSTALLATION / OWNER'S MANUAL
OPTIONAL 2.2GPM AERATOR
ASSEMBLY

3
2
1
Make connections to water lines. Use 1/2" IPS
faucet connections (1) or use coupling nuts (3)
with 3/8"O.D.ball-nose risers (2).
Use wrenches to tighten connections. Do not
overtighten.
Important: After installation is completed, remove
connector. Turn on water supply and allow both hot
and cold water to run for at least one minute each.
While water is running, check for leaks. Replace
connector.
Place gasket (1) on bottom of new faucet. Place
faucet through mounting holes in sink. Secure
faucet to sink using mounting nuts (2) provided.
Shut off water supply at angle stop. Remove old
faucet.Clean sink surface in preparation for new
faucet.
STEPS:
WARNING: Please carefully read and properly follow the instructions for installation found in this manual.
2
1
3-Ø 7/8" (Ø22.2mm)

Loosen sleeve (1) by turning it counter-clockwise
and lift out the cartridge (2). Remove old cartridge
and replace with new cartridge. Make sure the wings
(3) on the two sides of the cartridge sleeve fit well
into the slots (4) on the body. Tighten sleeve (1).
Reinstall the handle.
Shut off water supply. Remove set screw plug (1).
With valves in "closed" position, unscrew set screw
(2) and remove handle (3) from valve stem (6).
Remove screw (4) and pull off adapter (5).
CARTRIDGE REPLACEMENT
3
4
3
12
6
1
2
4
5
CHANGE THE AERATOR
FOR CARE AND MAINTENANCE:
·The water in certain areas of the world can be very caustic -
standing water around the product can cause damage. Be
sure to remove standing water with a dry, soft cloth as soon
as possible.
·For polished brass finishes, as often as once a week, you
can apply a paste wax or special, non-abrasive, brass
coating (DO NOT APPLY POLISH).
·Before applying a protective coating, gently brush the entire
fixture using a soft tooth brush. This will remove any dirt or
deposit build-up.
·These simple steps will add temporary protective coating to
your faucet and extend the life of the finish.
Failure to follow care and cleaning will void your warranty.
For additional information, please visit elkayusa.com .
Congratulations on your purchase of an Elkay product.
Although your product is extremely durable, attention should
be given to the care, cleaning and maintenance of this
product. Cleaning agents and abrasives may cause damage,
which may result in oxidation and discoloration.
By following these simple guidelines for proper care and
cleaning, it will give you years of enjoyment:
TO CLEAN: Simply wipe gently with a damp cloth and blot dry
with a soft towel. A common rule of thumb is: when you dry off,
dry off your product.
·Avoid build-up of soap, toothpaste or mineral deposits, as
these tend to have an adverse effect on the appearance of
the product.
·NEVER use cleaning products of any kind on this product -
especially those containing ammonia, bleach or alcohol - or
those with any form of abrasive.
CARE AND CLEANING INSTRUCTIONS
To replace the aerator
1. Remove connector (1) from spout.
2. Install the aerator assembly (2).
12

Elkay
elkayusa.com
©2011 Elkay
Model # LK2000
P99346 (Rev. date: 04/2011)
REPLACEMENT PARTS
WARRANTY
P46467 Connector
P05136* 2.2GPM Aerator
Assembly
P38111 Set Screw
P38113 Set Screw Plug
(Blue)
P01293* Handle
RP64085 Wearable Ring
RP70106 Snap Ring
RP60046 O-Ring
P38114 Set Screw Plug (Red)
P29249 Cartridge Cold
P35300 Washer
RP70193 Sleeve
RP64044 Adapter
P36164 Screw
P36160 Mounting Nut
ELKAY LIMITED LIFETIME WARRANTY
ELKAY LIMITED LIFETIME WARRANTY
Elkay warrants that all parts and finishes of the Elkay Residential brand
faucets are free from defects in materials and workmanship for the life of
the product, if purchased after 1996. This warranty covers the
original consumer purchaser of the product only.
If the product should leak or drip during normal use, Elkay will provide,
free of charge, a replacement cartridge. For other defects in material or
workmanship, Elkay will, at its option, supply replacement parts (or if no
longer available a comparable product). Elkay reserves the right to
examine product in question and its installation prior to replacement.
What you must do to obtain warranty service:
Either write to Elkay, attention Customer Care, 2222 Camden Court,
Oak Brook, IL 60523 or call 1-800-223-5529. Please provide date of
purchase and installation, description of nature of the defect, and
model number or description of model and/or component part.
THIS LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ANY
OTHER WARRANTIES, EXPRESSED IMPLIED, ARISING BY LAW
OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE. THIS LIMITED WARRANTY MAY NOT
BE ALTERED, VARIED, OR EXTENDED, EXCEPT BY A WRITTEN
INSTRUMENT EXECUTED BY ELKAY. THE REMEDY OF REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS LIMITED
WARRANTY IS EXCLUSIVE. IN NO EVENT SHALL THE
MANUFACTURER BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES TO ANY PERSON, WHETHER OR NOT
OCCASIONED BY NEGLIGENCE OF ELKAY, INCLUDING WITHOUT
LIMITATION DAMAGES FOR LOSS OF USE, COSTS PROPERTY
DAMAGE OR OTHER MONETARY LOSS.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply. This
warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
This warranty covers product installed in the United States and Canada.
What is not covered:
1. Damage caused by accident, negligence, misuse, abuse, improper
installation or operation or failure to follow care or installation instructions
enclosed with your product.
2. Damage occurring during shipment of the product (claims must be
presented to the carrier).
3. Normal wear and tear.
4. Labor charges, costs of removal and reinstallation, and any damages
to other property.
5. All industrial, commercial and business use whose purchasers are
hereby extended a limited lifetime on mechanical parts and 5 years on
finish.
P29250 Cartridge Hot
RP56034* Spout Cap
Spout
Spout Base
